SsangYong Rexton. Service manual - part 269
ELECTRICAL WIRING DIAGRAMS 5-109
SSANGYONG REXTON XDi (LHD)
A. CONNECTOR INFORMATION
B. CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION
Connector Number
(Pin Number, Color)
Engine Room Fuse Box (D) - Engine
Engine Room Fuse Box (E) - Engine
Engine Room Fuse Box (F) - Engine
Engine Room Fuse Box (J) - Engine
Main - Floor (LH)
Main - Floor (LH)
Main - Floor (LH)
Engine - Main (RH)
W/H Main
W/H Main
W/H Main
W/H Engine
W/H Engine
W/H Main
W/H Main
C104 (20Pin, White)
C105 (22Pin, White)
C106 (18Pin, White)
C107 (14Pin, White)
C203 (13Pin, Green)
C205 (11Pin, White)
C209 (22Pin, Yellow)
C210 (13Pin, Green)
S203 (14Pin, Black)
S204 (14Pin, Black)
S208 (14Pin, Black)
G102
G105
G201
G203
Connecting Wiring
Harness
Engine Room Fuse Box
Engine Room Fuse Box
Engine Room Fuse Box
Engine Room Fuse Box
Under the I/P Fuse Box
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Inside Driver Side Cowl PNL
Upper the I/P Relay Box
Behind the Left the FATC
Behind the Right the FATC
Center BATT
Behine the Right Head Lamp
Inside Driver Side Cowl PNL
Under the Seat Heating SW
GND
W/H Air Bag
Remark
Connector Position
