DI01-58 CHANGED BY EFFECTIVE DATE AFFECTED VIN ENGINE ASSEMBLY DI ENG SM - 2004.4 36. Remove the piston assembly from the cylinder block. A. Unscrew the bearing cap bolts. Installation Notice * Tighten the bolts from #1 cap. C. Remove the piston assembly through the cylinder. Installation Notice * Align the oil grooves in bearing cap and connecting rod. B. Remove the bearing caps and lower bearing shells. Y220_01128 Y220_01129 Y220_01130 Y220_01131 Tightening torque 25 ± 2.5 Nm 35. Unscrew the bolts and remove the oil strainer assembly. Installation Notice Step 1 Step 2 55 ± 5.0 Nm 90° + 10° Notice Do not mix up upper and lower crankshaft bearing |
