33 REAR BEARING ELEMENTS 33 - 3 PLATE DRIVE REAR AXLE Detach the brake cable from the hand brake levers. three ways connection. Remove the rear axle, place it on a support and drain the oil, by dismounting both the empty plug and the level one, to speed draining. R EMO UNTING Perform the same operation in reverse order; attention should be paid to the fact that the axle may overturn when lifting it to mount the clips. NOTE: The steps performed when dismounting , remounting the rear axle ( as assembly ) are similar for all types of pick-ups. Dismount : - the four screws of the cardanic flange at the side towards the differential gear; |
