FRONT BEARING ELEMENTS 31 - 32 31 FRONT SUSPENSION SPRING D ISMO UNTING Dismount the shock absorber and the spring by means of the SUS 478 device. Clamp the SUS 480 device into the vice. assembly on the SUS 480 device. Place the upper plate and press the spring until the SUS 478 device is released. Dismount the SUS 478 device. R EMOUNTING NOTE: The lower end of the spring must be in contact with the plate and aligned with the SUS 478 device support slot. Dismount the SUS 480 device. Place the new spring on the SUS 480 device. Press the spring , observing its mounting po- sition. Mount the SUS 478 device (the grippers shall be hooked on the last but one upper coil). |
