Peugeot Boxer (2016 year). Manual

Touch Screen Audio - Telematic System

223

AUDIO

and

TELEMA

TICS

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Global voice commands

these commands can be made from any screen page after pressing the voice recognition or telephone button located on the steering wheel,
as long as there is no telephone call in progress.

Level 1

Level 2

Level 3

comment

Help

Provides generic help to the user by suggesting
certain available commands.

cancel

Closes the current voice session.

repeat

Repeats to the user the last voice message spoken.

Voice tutorial

Provides the user with detailed description of how
to use the voice system.

Touch Screen Audio - Telematic System

224

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Level 1

Level 2

Level 3

comment

call*

Henri dupont

Dials the telephone number associated with contact
Henri Dupont.

call*

Henri dupont

Mobile phone

Dials the telephone number labelled mobile phone
associated with contact Henri Dupont.

call number

0123456789

Calls the telephone number 0123456789.

call again

Calls the number or contact of the last call made.

call back

Calls the number or contact of the last call received.

recent calls*

Displays the list of recent calls: outgoing, missed
and incoming.

calls made*

Displays the list of outgoing calls.

Missed calls*

Displays the list of missed calls.

* this function is available only if the telephone connected to the system supports downloading of contacts and recent calls and if the

download has been done.

"telephone" voice commands

If a telephone is connected to the system, these voice commands can be issued from any main screen page after pressing the telephone
button on the steering wheel, as long as there is no telephone call in progress.
If there is no telephone connected, a voice message announces: "No telephone connected. Connect a telephone and try again" and the voice
session will be closed.

Touch Screen Audio - Telematic System

225

AUDIO

and

TELEMA

TICS

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

"telephone" voice commands

It is possible to replace the "Mobile phone" label by one of the three other labels available: "Home"; "Work"; "Other".

Level 1

Level 2

Level 3

comment

Incoming calls*

Displays the list of calls received.

contacts*

Displays the list of contacts on the telephone
connected.

Search*

Henri dupont

Displays the contact Henri Dupont in the list of
contacts will all of the numbers saved.

Search*

Henri dupont

Mobile phone

Calls the telephone number labelled mobile phone
associated with contact Henri Dupont.

display messages**

Displays the list of text messages received by the
telephone connected.

If the telephone allows the "first name" (Henri) and "surname" (Dupont) to be entered in two separate fields, issue the following voice
commands:
-

"Call"; "Henri"; "Dupont" or "Call"; "Dupont"; "Henri".

"Search"; "Henri"; "Dupont" or "Search"; "Dupont"; "Henri".

* this function is only available if the telephone connected to the system supports downloading of contacts and recent calls and if the

download has been done.

** this function is only available if the telephone connected to the system supports the speaking text messages.

Touch Screen Audio - Telematic System

226

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

"AM / FM / dAB radio" voice commands

these voice commands can be issued from any main screen page after pressing the voice recognition button on the steering wheel, as long as
there is no telephone call in progress.

Level 1

Level 2

Level 3

comment

tune to

105.5

tunes the radio to the frequency 105.5 on the
FM waveband.

tune to

940

tunes the radio to the frequency 940 on the
AM waveband.

tune to*

FIP

tune the radio to the FIP station.

tune to dAB channel**

radio noVA

tunes the DAB radio to the Radio NOVA channel.

* the name "FIP" can be replaced by any other FM station name received by the radio. Not all radio stations provide this service.
** the name "Radio NOVA" can be replaced by any other DAB channel name received by the radio. Not all DAB channels provide this

service.

Touch Screen Audio - Telematic System

227

AUDIO

and

TELEMA

TICS

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

"Media" voice commands

these voice commands can be issued from any main screen page after pressing the voice recognition button on the steering wheel, as long as
there is no telephone call in progress.

Level 1

Level 2

Level 3

comment

Play track

"title 1"

Plays the track "title 1".

Play album

"Album 1"

Plays the songs in album "Album 1".

Play artist

"Artist 1"

Plays the songs by "Artist 1".

Play musical genre

"jazz"

Plays the songs of the "Jazz" musical genre.

Play playlist

"Playlist 1"

Plays the songs in the playlist "Playlist 1".

Play podcast

"radio 1"

Plays the podcast "Podcast 1".

Play audio book

"Book 1"

Plays the audio book "Book 1".

Play track number

"5"

Plays track number "5".

Select

"uSB"

Selects the uSB media as the active audio source.

Scan

"Album"

Displays the list of albums available.

Touch Screen Audio - Telematic System

228

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

"navigation" voice commands

these voice commands can be issued from any main screen page after pressing the voice recognition button on the steering wheel, as long as
there is no telephone call in progress.

Level 1

Level 2

Level 3

comment

Go home

Displays the route home.

2d mode

Changes to 2D mode.

3d mode

Changes to 3D mode.

delete route

Deletes the route displayed.

Add a favourite

Displays the favourites screen page.

repeat instruction

Repeats the last voice message spoken.

Touch Screen Audio - Telematic System

229

AUDIO

and

TELEMA

TICS

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

"test message" voice commands

these voice commands can be issued from any main screen page after pressing the telephone button on the steering wheel, as long as there
is no telephone call in progress.

Level 1

Level 2

Level 3

comment

Send a text to

0123456789

Starts the voice procedure for sending a pre-
defined text message using the system.

Send a text to

Henri dupont

Mobile phone

display text

Henri dupont

Mobile phone

Displays the message box downloaded from
the telephone.

Touch Screen Audio - Telematic System

230

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

"Hands-free calls" voice commands

Commands available during a call.
these voice commands can be issued from any main screen page during a call after pressing the telephone button on the steering wheel, as
long as there is no telephone call in progress.

Level 1

Level 2

Level 3

comment

Send 0123456789

the selection tones for 0123456789 are sent.

Send "Voicemail
password"

the selection tones for the numbers saved in
"Voicemail password" are sent.

Activate speakers

transfers the call to the telephone or the system.

Activate / deactivate
mike

System mike ON / OFF.

Audio System

231

AUDIO

and

TELEMA

TICS

boxer_en_Chap10b_Autoradio_Fiat-4_ed01-2015

Audio system

Multimedia audio system - Bluetooth

telephone

Contents

First steps

232

Steering mounted controls

233

Radio 234
Media 236
telephone 238
Settings 239
Voice commands

240

the system is coded in such a way that it will only operate in
your vehicle.

As a safety measure, the driver must only carry out operations
which require prolonged attention while the vehicle is stationary.
When the engine is not running and to prevent discharging of the
battery, the audio system may switch off following activation of
energy economy mode.

Audio System

232

boxer_en_Chap10b_Autoradio_Fiat-4_ed01-2015

First steps

On/off, volume setting.

Select FM and AM wavebands.

Display the list of connected
telephones.

Rotate: scroll through a list or adjust
radio station.
Press: confirm the option displayed in
the screen.

Select uSB or AuX source.

Information on the current radio
station or media.

Repeat play.

Select preset stations.
FM-A, FM-B, FM-C, AM-A, AM-B,
AM-C.

Mute / restore sound.

Radio buttons 1 to 6:
Select a pre-set radio station.
Long press: pre-set a station.

Random (shuffle) play

Automatic frequency search up.
Select the next uSB track.
Press and hold: fast forward.

Display the menu and adjust options.

Automatic frequency search down.
Select the previous uSB track.
Press and hold: fast back.

Abandon the current operation.
go up one level (menu or folder).

Audio System

233

AUDIO

and

TELEMA

TICS

boxer_en_Chap10b_Autoradio_Fiat-4_ed01-2015

Steering mounted controls

Pause / restore the CD, uSB/iPod,
Bluetooth

sources.

Mute / restore sound from the radio.
Switch the microphone off / on during
a telephone call.

Switch voice recognition on.
Interrupt a voice message to start a
new voice command.
Interrupt voice recognition.

Push up or down: increase or
decrease the volume for voice
announcements and music sources,
hands-free and speaking texts.

Accept an incoming call.
Accept a second incoming call and
put the current call on hold.
Switch on voice recognition for the
telephone function.
Interrupt a voice message to issue
another voice command.
Interrupt voice recognition.

Radio, push up or down: select the
next / previous station.
Radio, hold up or down: sweep
frequencies up / down until the button
is released.
Media, push up or down: select the
next / previous track.
Media, hold up or down: fast forward /
back until the button is released.

Reject the incoming call.
end the call in progress.

Audio System

234

boxer_en_Chap10b_Autoradio_Fiat-4_ed01-2015

Briefly press one of the buttons to
carry out an automatic search down/
up for radio stations.

Press the "rAdIo" button to select
the FM or AM waveband.

turn the dial to carry out a manual
search down/up for radio stations.

Press the dial to display the list of
stations received locally.
turn the dial to choose a radio station
then press to select it.

Press the "rAdIo" button to select
the FM or AM waveband.

Press the MEnu button.

Press the "A-B-c" button to select
one of the three sets of preset
stations.

Select "regional" then press to
switch RDS on or off.

Make a long press one of the buttons
to preset the current radio station.
the name of the station is displayed
and an audible signal confirms the
preset.

Press "InFo" to display information
on the current radio station.

Presetting a station

Selecting a station

the surroundings (hills, buildings,
tunnel, parking, under ground...) may
prevent reception, including RDS
alternative frequencies.
this phenomenon is normal in the
propagation of radio waves and does
not in any way imply a fault with the
audio system.

RDS, if displayed, makes it possible
to continue listening to the same radio
station using the alternative frequencies
function. However, in certain conditions
it may not be possible to stay with the
same station as not all radio stations
cover the entire country. When reception
is poor the system switches to a regional
frequency.

Radio

rdS

Audio System

235

AUDIO

and

TELEMA

TICS

boxer_en_Chap10b_Autoradio_Fiat-4_ed01-2015

Select "Alternative frequencies
(AF)" then press to activate or
deactivate the frequency.

Press the "MEnu" button.

Select "traffic information
(tA)" then press to switch traffic
announcements on or off.

When the "regional" function is on,
the system can then search for a
stronger frequency at any time.

the tA (traffic Announcement)
function gives priority to playing tA
alert messages. to be active, this
function requires good reception of
a radio station that broadcasts this
type of message. As soon as traffic
information is broadcast, the media
playing is interrupted automatically
to transmit the tA message. Normal
play of the media is restored after
transmission of the message.

Alternative frequencies (AF)

receiving tA messages

Audio System

236

boxer_en_Chap10b_Autoradio_Fiat-4_ed01-2015

uSB player

Auxiliary socket (Aux)

uSB port

Media

the system builds playlists (in temporary
memory), an operation which can take from
a few seconds to several minutes at the first
connection.
Reduce the number of non-music files and the
number of folders to reduce the waiting time.
the playlists are updated every time the
ignition is switched off or connection of a uSB
memory stick. However, the audio system
memorises these lists and if they are not
modified, the loading time will be shorter.

Insert a uSB memory stick or connect a
peripheral device to the uSB port in the central
storage space, provided for transferring data
to the system, using a suitable cable (not
supplied).

Located on the centre console, this port is used
only for powering and recharging the portable
device connected.

Connect the portable device (MP3 player…) to
the auxiliary Jack socket using an audio cable
(not supplied).

First adjust the volume on your portable device
(to a high level). then adjust the volume of your
audio system.
Control is via the portable device.

the functions of the device connected to the
"AuX" socket are controlled directly from the
device itself: changing track / folder / playlist or
starting/ending/pausing play using the audio
system control panel or steering mounted
controls is therefore not possible.
Do not leave the cable of your portable device
connected to the AuX socket when not in use,
to avoid possible noises from the speakers.

Audio System

237

AUDIO

and

TELEMA

TICS

boxer_en_Chap10b_Autoradio_Fiat-4_ed01-2015

It is recommended that official Apple

uSB cables are used to ensure correct
operation.

the system does not support
two identical devices connected at
the same time (two memory sticks,
two Apple

players) but it is possible

to connect one memory stick and one
Apple

player at the same time.

the system supports uSB mass storage
devices, BlackBerry

devices or Apple

players via uSB ports. the adaptor cable is not
supplied.
Other peripherals, not recognised on
connection, must be connected to the auxiliary
socket using a Jack cable (not supplied).

use only uSB memory sticks formatted FAt 32
(File Allocation table).

It is advisable to restrict file names to
20 characters, without using of special
characters (e.g.: " " ? ; ù) to avoid any playing
and displaying problems.

Information and advice

the version of software in the audio
system may not be compatible with the
generation of your Apple

player.

connecting Apple

players

Connect the Apple

player to the uSB port

using a suitable cable (not supplied).
Play starts automatically.

Control is via the audio system.

the classifications available are those
of the portable device connected
(artists / albums / genres / tracks /
playlists / audio books / podcasts).
the default classification used is by
artist. to modify the classification used,
return to the first level of the menu
then select the desired classification
(playlists for example) and confirm
to go down through the menu to the
desired track.

Audio System

238

boxer_en_Chap10b_Autoradio_Fiat-4_ed01-2015

telephone

Pairing a Bluetooth

telephone

As a safety measure and because they
require prolonged attention on the part
of the driver, the operations for pairing
the Bluetooth mobile telephone to the
hands-free system of the audio system
must be carried out with the vehicle
stationary.

Switch on the Bluetooth function of your
telephone and ensure that it is "visible to all"
(telephone configuration).

Select "connect tel" to start the
pairing procedure, and search for the
name of the system in the telephone.

When the pairing procedure has
finished successfully, a screen page
with "connection successful"
appears:
Confirm to display the menus.

the telephone menu gives access to
the following functions in particular:
"call log", "contacts"*, "Keypad".

When pairing, a screen page is displayed
showing progress in the operation.

using the telephone's keypad, enter the PIN
displayed in the screen of the system or
confirm in the telephone the PIN displayed.

Press "Phone".
If no telephone has yet been paired
in the system, a special page is
displayed in the screen.

If the operation fails, we recommend
switching the function Bluetooth of
your telephone off and then on again.

* If your telephone is fully compatible.

receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Press this button to accept the
incoming call.

Or press this button to reject the call.

Ending a call

to reject a call, press this button at
the steering mounted controls.

Making a call

Select "call log" for access to the
recent calls made.

Select "contacts" to display your
contacts and use the dial to scroll
through the list.

to dial a number, use the system's
"Keypad".

Peugeot Boxer (2016 year). Manual - part 15
