Peugeot Boxer (2016 year). Manual - part 14

Touch Screen Audio - Telematic System

207

AUDIO

and

TELEMA

TICS

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Level 1

Level 2

Level 3

comment

PHonE

Mobile phone

Display and call contacts present in the mobile
phone.

Press these buttons to scroll through the list of
contact names.

go directly to the desired letter in the list.

PHonE

recent calls

All calls

Display and call contacts from the recent calls log.

out

Missed

PHonE

the system memory contains predefined text
messages, which can be sent to reply to a message
received or as a new message.
On receipt of a text message (depending on the
telephone), the system also allows the message in
question to be sent.

PHonE

Settings

tel. connected

Disconnect

Associate up to 10 telephones/audio devices to
simplify and speed up access and connection.

Delete device

Save favourites

texts On

Download

Add device

Audio connect.

PHonE

call

Dial the telephone number using the virtual keypad
in the screen.

PHonE

transf.

transfer calls from the system to the mobile phone
and vice versa.

Mute

Switches of the system microphone for private
conversations.

Touch Screen Audio - Telematic System

208

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Pairing a Bluetooth

telephone

For reasons of safety and because they
require prolonged attention on the part
of the driver, the operations for pairing
a Bluetooth mobile telephone to the
hands-free system of the audio system
must be carried out with the vehicle
stationary.

Switch on the Bluetooth function of your
telephone and ensure that it is "visible to all"
(telephone configuration).

Select "Yes" to start the pairing procedure,
and search for the name of the system in the
telephone (otherwise selecting "No", the main
telephone screen page is displayed).

When the pairing procedure has
finished successfully, a screen page
appears:
-

reply "Yes" to the question, the
mobile phone is saved as the
favourite (this telephone will have
priority over other telephones
paired subsequently).

if no other device has been
paired, the system considers
the first device paired to be the
favourite.

When pairing, a screen page is displayed
showing progress in the operation.

the services available depend on the network,
the SIM card and the compatibility of the
Bluetooth device used. Check the instructions
for your telephone and with your service
provider for the services to which you have
access.

Select the name of the system and, depending
on the telephone, using the telephone's
keypad, enter the PIN displayed in the screen
of the system or confirm in the telephone the
PIN displayed.

Press "PHonE".
If no telephone has yet been paired
in the system, a special page is
displayed in the screen.

If the operation fails, we recommend
switching the Bluetooth function of
your telephone off and then on again.

For telephones not set as favourite, the
order of priority is determined in the
order of connection. the last telephone
connected has the highest priority.

the profiles compatible with the system are:
HFP, OPP, PBAP, A2DP, AVRCP, MAP.

When you return to your vehicle, the last
telephone connected reconnects automatically,
within around 30 seconds of switching on the
ignition (with Bluetooth switched on).
to modify the automatic connection profile,
select the telephone in the list then select the
desired setting.

Automatic reconnection

When the ignition is switched on, the telephone
connected when the ignition was last switched
off reconnects automatically, if this connection
mode had been set during the pairing
procedure (see previous pages).

Connection is conformed by the display of a
message and the name of the telephone.

Touch Screen Audio - Telematic System

209

AUDIO

and

TELEMA

TICS

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Managing paired
telephones

Select "telephone/Bluetooth" then select the
telephone in the list of paired devices.

Select "connected" or "disconnected",
"delete device" or "Add device", "Save
Favourites", "text messages on",
"download" on the list of options offered.

Press "Settings".

this function allows the connection or
disconnection of a peripheral device as
well as the deletion of a pairing.

receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Make a short press on this steering
mounted button to accept an
incoming call.

If there are two calls in progress (one in
progress and one on hold), it is possible to
change from one to the other by pressing the
"Switch calls" button or to combine both calls
in a conference call by pressing the "confer."
button.

Press the "reply" button displayed in the
screen.

Ending a call

to reject a call, press this button at
the steering mounted controls.

Press the "Ignore" button displayed in the
screen.

Making a call

Press "PHonE".

Press the touch keypad.

Press the "contacts" button or the
"recent calls" button.

use of the telephone is not
recommended while driving. We
recommended that you park safely
or make use of the steering mounted
controls.

enter the phone number using the keypad then
press the "call" button to start the call.

Select the desired contact from the list offered
to start the call.

calling a new number

calling a contact

Touch Screen Audio - Telematic System

210

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Level 1

Vehicle information

Level 2

Level 3

Touch Screen Audio - Telematic System

AUDIO

and

TELEMA

TICS

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Level 1

Level 2

Level 3

comment

MorE

Ambient temp.

Displays the ambient temperature.

MorE

clock

Displays the clock.

MorE

compass

Displays the direction of travel.

MorE

trip

current info

Range

Displays the trip computer.
Make a long press on the "trip A" or "trip B"
button to reset the trip in question.

Current fuel consumption

trip A

Average fuel consumption

Average speed

Distance travelled

Journey time

trip B

Average fuel consumption

Average speed

Distance travelled

Journey time

Touch Screen Audio - Telematic System

212

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Level 1

Settings

Level 2

Level 3

Touch Screen Audio - Telematic System

213

AUDIO

and

TELEMA

TICS

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Level 1

Level 2

Level 3

comment

Settings

display

Brightness

Set the brightness of the screen.

display mode

Manual

Set the display mode.

Auto

Language

Deutsch

Choose the desired language.

english

español

Français

Italiano

Nederlands

Polski

Português

Türkçe

units of measurement

Fuel consumption

Set the units used for the display of fuel
consumption, distance and temperature.

Distances

temperature

touch screen sound

Activate or deactivate the audible signal when
touching a screen button.

Off

display trip B

Display trip B in the driver's screen.

Off

Touch Screen Audio - Telematic System

214

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Level 1

Level 2

Level 3

Touch Screen Audio - Telematic System

215

AUDIO

and

TELEMA

TICS

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Level 1

Level 2

Level 3

comment

Settings

Voice

commands

Voice response time

Brief

Set the response time for the voice system.

Long

display command list

Never

Display suggestions with the different options
during a voice session.

With help

Always

Settings

clock and date

Set time and format

Set the time.

display time mode

Activate or deactivate display of the digital clock
in the status bar.

Off

Sync time

Activate or deactivate the automatic display of
time.

Off

Set date

Set the date.

Touch Screen Audio - Telematic System

216

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Level 1

Level 2

Level 3

Touch Screen Audio - Telematic System

217

AUDIO

and

TELEMA

TICS

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Level 1

Level 2

Level 3

comment

Settings

Safety /Help

reversing camera

Display the reversing camera in reverse.

Off

camera delay

Maintain the display in the screen of the image
from the reversing camera for a maximum of
10 seconds or up to 8 mph (18 km/h).

Off

Settings

Lamps

daytime lighting

Activate or deactivate the automatic illumination
of headlamps when starting.

Off

Settings

doors

and locking

Autoclose

Activate or deactivate the automatic locking of
doors when the vehicle is moving.

Off

Touch Screen Audio - Telematic System

218

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Level 1

Level 2

Level 3

Touch Screen Audio - Telematic System

219

AUDIO

and

TELEMA

TICS

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Level 1

Level 2

Level 3

comment

Settings

Audio

Equaliser

Adjust the bass, mid-range and treble.

Balance / Fade

Bass

Adjust the balance of the speakers, front and rear,
left and right.
Press the button in the middle of the arrows to
balance the adjustments.

Mid-range

treble

Volume / Speed

Select the desired setting, the option is
highlighted.

Loudness

Optimise audio quality at low volume.

Automatic radio

Adjust the radio on startup or restore the active
state the last time the ignition was switched to
StOP.

radio off delay

Adjust the setting.

Set Aux vol.

Adjust the settings.

Settings

telephone /

Bluetooth

tel. connected

Connect

Start the connection to the selected Bluetooth
peripheral device.

Delete device

Delete the selected peripheral device.

Save favourites

Save the selected peripheral device in favourites.

texts On

Adjust the settings.

Download

Add device

Add a new peripheral device.

connect audio

Connect a device in audio only.

Touch Screen Audio - Telematic System

220

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Level 1

Level 2

Level 3

Touch Screen Audio - Telematic System

221

AUDIO

and

TELEMA

TICS

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Level 1

Level 2

Level 3

comment

Settings

radio settings

dAB announcements

Activate or deactivate announcements.

Off

Categories

Activate or deactivate option: Alarm, event
announcement, Finance flash, Info flash,
Programme info, Special event, Sport info, Public
transport info, Alarm info, Weather flash.

Settings

restore settings

Yes

Restore the default settings for the screen, clock,
sounds and the radio.

Settings

Erase

personal data

Yes

erase personal data, Bluetooth devices
and pre-settings included.

Touch Screen Audio - Telematic System

222

boxer_en_Chap10a_Autoradio_Fiat-tactile-1_ed01-2015

Voice commands

Steering mounted controls

Information - using the system

Instead of touching the screen, you can
use your voice to issue commands to
the system.

Voice interaction can be quickly used
if these buttons are pressed during
a voice message from the system; It
allows a voice command to be issued
directly.
For example, if the system is speaking
a voice help message and if you want
to know the command to give the
system, by pressing these buttons, the
voice message is interrupted and the
desired voice command can be spoken
directly (so avoiding the need to listed
to the complete voice help message).
When the system is waiting for a voice
command from the user, pressing these
buttons closes the voice session.

to ensure that your voice commands
are always recognised by the system,
we recommend that you follow the
advice below:
-

speak with a normal tone of voice,

before speaking, always wait for
the "beep" (audible signal),

the system is able to recognise
the voice commands delivered,
independent off gender, tone and
inflexion of the voice of the person
speaking,

keep the noise level inside the
vehicle as low as possible,

before speaking a voice command,
ask other passengers not to speak.
As the system recognizes voice
commands whatever is said, when
more than one person speaks
at the same time, it is possible
that the system will recognise
commands different or additional to
the one intended,

every time a button is pressed, a
"beep" (audible signal) is produced
and the screen displays a page of
suggestions asking the user to speak a
command.

for best operation, it is
recommended that the windows
and opening roof (for versions/
markets where it is available) be
closed to avoid interference from
extraneous noises.

this button switches on the
"telephone" voice recognition mode,
which makes it possible to start calls,
view the log of recent/received/made,
display contacts, etc.

this button switches on the "Radio/
Media" voice recognition mode,
which makes it possible to tune to a
specific radio station radio or specific
AM/FM radio frequency, play a track
or an album on a uSB memory stick/
iPod/MP3 CD.

Content .. 12 13 14 15 ..
