DISTRIBUTION - FRONT TABLE OF CONTENTS page page AIR FILTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 . . . . . . . . . . . . . . . . . . . . . . . . . 45 AIR OUTLETS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 . . . . . . . . . . . . . . . . . . . . . . . . . 46 BLOWER MOTOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 . . . . . . . . . . . . . . . . . . . . . . . . . 47 DEFROSTER DUCTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 . . . . . . . . . . . . . . . . . . . . . . . . . 47 FLOOR DISTRIBUTION DUCTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 . . . . . . . . . . . . . . . . . . . . . . . . . 48 HVAC HOUSING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 . . . . . . . . . . . . . . . . . . . . . . . . . 49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 . . . . . . . . . . . . . . . . . . . . . . . . . 50 INSTRUMENT PANEL DUCTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 . . . . . . . . . . . . . . . . . . . . . . . . . 51 AIR FILTER REMOVAL (1) Remove the insulation blanket from the venti- lation housing in the engine compartment (Fig. 1). (2) Open the locking clips at the front and rear of the ventilation housing. (3) Slide the ventilation housing cover in the direc- tion of the arrow shown. (4) Remove the air filter. INSTALLATION (1) Install the air filter into the ventilation hous- ing. (2) Install the ventilation housing cover the ventilation housing. NOTE: The locking tabs should retain the ventila- (4) Install the insulation blanket onto the ventila- tion housing. AIR OUTLETS REMOVAL WARNING: To avoid personal injury or death, on restraint system before attempting any steering wheel, steering column, airbag, seat belt (1) Disconnect and isolate the battery negative cable. (2) If servicing the driver side air outlets, remove the instrument cluster bezel (Refer to 23 - BODY/IN- PANEL/CLUSTER BEZEL - REMOVAL). (3) If servicing the passenger side air outlets, remove the passenger side airbag (Refer to 8 - ELEC- AIRBAG - REMOVAL). Fig. 1 Air Filter Element 1 - VENTILATION HOUSING INSULATION BLANKET VA DISTRIBUTION - FRONT 24 - 45 |
