1. Using a suitable tool, at the line side unlock the lugs (1) on lock tab. 2. Open the tab. Shown on a 4-pin SPT coupling Fig. 535: Opening Tab - Shown On A 4-Pin SPT Coupling Secondary release on version with spring (SPT) 1. Insert a suitable tool between spring (1) and housing and then press spring (1) out. Shown on a 7-pin JPT and SPT coupling Fig. 536: Pressing Spring Out - Shown On A 7-Pin JPT And SPT Coupling Secondary release on version with slider (SPT) 1. Using a suitable tool, push the slider out of the last detent in direction shown by arrow. Press carefully using the tool so that the gasket at the slider is not damaged. Shown on a 6-pin SPT coupling
2004 Mercedes-Benz ML350 1998-2005 GENINFO Overall vehicle - 163 Chassis
