Mercedes-Benz ML320. Service manual - part 564





Fig. 328: Connecting Hand-Held Tester (HHT) For Read Out Diagnostic Trouble Code Memory

 Note system-specific deviations listed in respective diagnosis description in chapter entitled "Diagnosis

Previous Knowledge".

Stored faults possibly caused by cables being disconnected during testing or by simulation must be erased from
the fault memory once the work is completed.

CONNECT STAR DIAGNOSIS AND READ OUT FAULT MEMORY - AD00.00-P-2000-04A

Fig. 329: Connecting STAR DIAGNOSIS For Read Out Fault Memory (Illustrated On Model 210)



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



Fig. 330: Connecting STAR DIAGNOSIS For Read Out Fault Memory (Illustrated On Model 163)

Fig. 331: Connecting STAR DIAGNOSIS For Read Out Fault Memory (Illustrated On Model 164.1)

Fig. 332: Connecting STAR DIAGNOSIS For Read Out Fault Memory (Illustrated On Model 461.302)



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



Fig. 333: Connecting STAR DIAGNOSIS For Read Out Fault Memory (Illustrated On Model 171.4)

1. Connect STAR DIAGNOSIS (0100) to diagnostic socket, on the data link connector (X11/4) or on the

data link connector (1.3) (X11/22).

2. Switch on ignition.

3. Start the Diagnosis Assistance System.

4. In the "Model" menu, select the sub menu "Other model series".

5. Go through the instructions on the screen:

Enter the control unit version.

Read fault memory, erase.

Read actual values.

Perform actuations.

Adaptation of control units

6. Disconnect STAR DIAGNOSIS (0100).

 Stored faults which may be caused by disconnecting cables or by simulation during testing operations must

be deleted in the diagnostic trouble code memory following completion of the operations.

EXPLANATION OF DIAGNOSTIC SYMBOLS - AD00.00-P-2001A

MODEL 124, 129, 140, 163, 168, 170, 201, 202, 208, 210, 215, 220

DIAGNOSIS ASSIGNMENT - AD00.00-P-2002A

MODEL 124, 129, 140, 163, 168, 170, 201, 202, 208, 210

CONNECT DIAGNOSIS TESTING EQUIPMENT - AD00.00-P-2003A

MODELS 124, 129, 140, 163, 168, 170, 201, 202, 203, 208, 209, 210, 220

MODELS 211.004 /006 /016 /026 /028 /042 /043 /061 /065 /070 /076 /206 /216 /226 /242 /261 /265 /616,
215.374




Explanation of symbols for
testers and components



AD00.00-P-2000-01A



Assignment of data link
connector

Models 124.034/036,
129.063/067/076, 140, 170,
202, 208, 210

AD00.00-P-2000-02A



Assignment of data link
connector

Model 124 except
124.034/036,
129.060/061/066, 201

AD00.00-P-2000-02B



Assignment of data link
connector

Models 163, 168

AD00.00-P-2000-02C



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me



MODEL 230.474

STAR DIAGNOSIS PROCEDURAL SCHEMATIC - AD00.00-P-2004-02A

Fig. 334: Star Diagnosis Procedural Schematic

DIAGNOSTIC PROCEDURE - AD00.00-P-2004A

MODELS 124.034 /036, 129.058 /063 /067 /076, 140, 163 168, 170, 202, 203, 208, 210, 215, 220

TESTING & REPAIR

TESTING AND REPAIR WORK: PASSENGER CARS: OVERALL VEHICLE - AR00.00-Z-9163AA

MODEL 163



Connect hand-held tester
(HHT), read out
diagnostic trouble code
memory

Models 124.034/036,
129.063/067/076, 140, 170,
202, 208, 210

AD00.00-P-2000-03A



Connect hand-held tester
(HHT), read out
diagnostic trouble code
memory

Model 124 except
124.034/036,
129.060/061/066, 201

AD00.00-P-2000-03B



Connect hand-held tester
(HHT), read out
diagnostic trouble code
memory

Model 163 up to 31.8.01, 168 AD00.00-P-2000-03C



Connect STAR
DIAGNOSIS and read out
fault memory

Models 124.034/036,
129.058/063/067/076, 140,
163, 168, 170, 202, 203, 208,
209, 210, 211, 215.374, 220,
230

AD00.00-P-2000-04A



STAR DIAGNOSIS procedural
schematic

AD00.00-P-2004-02A



2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis



me
