Mercedes-Benz ML320. Service manual - part 562

natural gas powered
vehicles. Risk of frostbite to
body parts caused by
escaping natural gas or
contact with components
near the valves when
draining compressed-gas
tanks. Risk of poisoning or
suffocation caused by
inhaling natural gas. 6/07
G/02/07. This WIS printout
will not be recorded by the
updateservice.

Risk of explosion caused by
liquefied petroleum gas
escaping or pressurized gas
reservoirs overheating when
working on vehicles
operated with liquefied
petroleum gas. Risk of
frostbite to body parts
caused by liquefied
petroleum gas exiting under
pressure. Risk of poisoning
or risk of suffocation caused
by inhaling liquefied
petroleum gas.

ENGINE 111.984 For
Fluid Gas Concern

AS00.00-Z-0023-01A

Risk of injury caused by
burns to skin and eyes. Risk
of poisoning caused by
inhaling fumes when
working with heat-
shrinkable tubing.

MODEL 124, 126, 129,
140, 163, 164, 168, 169,
170, 171, 199, 202, 203,
204, 208, 209, 210, 211,
215, 216, 219, 220, 221,
230, 240, 245, 251, 374,
375, 414, 450, 454, 461,
463, 638, 690, 901, 902,
903, 904, 905, 930, 932,
933, 934, 940, 942, 943,
944, 950, 952, 953, 954,
957, 958, 970, 972, 974,
975, 976 ...

AS00.19-Z-0001-01A

Risk of injury caused by
burns to skin and eyes, risk
of poisoning caused by
inhaling fumes during
soldering.

MODEL 124, 126, 129,
140, 163, 164, 168, 169,
170, 171, 199, 202, 203,
208, 209, 210, 211, 215,
216, 219, 220, 221, 230,
240, 245, 251, 414, 461,
463...

AS00.19-Z-0002-01A

2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis

RISK OF INJURY & RISK OF POISONING - AS00.19-Z-0001-01A

Work in well ventilated rooms only. Wear safety glasses with side protection and protective gloves.

Potential risks

Risk of death caused by
vehicle slipping or toppling
off of the lifting platform.

MODEL all

AS00.00-Z-0010-01A

Risk of death caused by
body parts being pulled in
by rotating vehicle wheels
and roller dynamometer
rollers

MODEL all

AS00.00-Z-0019-01A

Risk of death caused by
contact with parts
conducting high voltages.

MODEL 129, 163, 164,
169, 170, 171, 202, 203,
208, 209, 210, 211, 215,
219, 220, 221, 230,
251 ...

AS00.00-Z-0020-01A

Risk of injury caused by
body parts becoming
jammed, pinched or severed
by doors, covers, flaps or by
loose components

MODEL 903 ...

AS00.00-Z-0025-01A

Risk of injury to skin and
eyes from handling hot or
glowing objects. Risk of fire
caused by contact of
glowing objects with
flammable materials.

MODEL 903 ...

AS00.00-Z-0026-01A

Risk of death caused by
coming into contact with
electrical parts of the 110V
system. Risk of injury
caused by burns, which can
be produced by electrical
shocks or by body parts
coming in direct contact
with electrical currents.

MODEL 903 ...

AS00.00-Z-0027-01A

Risk of injury to hands or
eyes when working on
hydraulic pressure reservoir
systems caused by hydraulic
fluid to specification 345.0
spraying out under pressure

MODEL all

AS00.00-Z-0028-01A

2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis

Risk of injury

When working with heat-shrinkable tubing, excessive temperatures may cause burns to skin and eye.

Risk of poisoning

When working with heat-shrinkable tubing, vapors may be produced which lead to symptoms of poisoning such
as coughing, headaches, dizziness and nausea. Moreover, irritation may occur to the respiratory paths and eyes.

Safety precautions/instructions



Work only in well ventilated rooms.



Avoid overheating the heat-shrinkable tubing.



Stop heat-shrinking immediately if the shrink hose becomes blistered or charred or shows other signs of
damage.



Do not inhale the vapors.



Avoid contact with melted shrink tubing.



Wear safety glasses with side protection and protective gloves.

First aid measures

When eyes or skin come in contact with melted shrink tubing



Flush the affected area immediately with plenty of water for approx. 15 minutes.



Treat affected areas like burn wounds. Do not remove any burned parts.



Contact physician or medical service.

When vapor is inhaled:



Take victim to fresh air.



Keep victim calm and cover with a blanket.



Contact physician or medical service.

Fire protection measures

Suitable extinguishing agents



Water mist, general-purpose foam, powder, carbon dioxide



Protective equipment for firefighters (compressed air equipment, oxygen apparatus, chemical resistant
protective clothing)

RISK OF INJURY & RISK OF POISONING - AS00.19-Z-0002-01A

Wear protective gloves, protective clothing and safety glasses. Ensure that the work area is adequately

2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis

ventilated. Secure power supply cables. Avoid sources of fire in working area.

Potential risks

Risk of injury



Contact with hot objects without suitable protective clothing causes severe burns to the skin and eyes.



Melted, spraying and dripping soldering tin can cause injuries to skin and eyes.



Electric shock may occur if network or high-voltage lines become scorched or cut by sharp objects.

Risk of poisoning



Caused by inhaling the vapors of the soldering additives, in particular fluxes.

Fire hazard



Caused by igniting combustible materials and objects located close to the soldering equipment.

Safety instructions/precautions



Wear suitable protective work clothing and protective gloves.



Wear safety glasses.



Protect power supply cable against heat and sharp edges.



Create safe work surface for putting down hot tools and objects.



Do not use soldering tool in wet or damp environments.



Avoid unintentional operation.



Switch off equipment after use.



Do not work on parts that are under voltage.



Use available soldering fume extractors.



Only perform soldering operations in well-ventilated rooms.



Keep combustible objects away from the workplace.



When working with soldering materials, do not eat, drink, smoke, and sniff. Keep well away from food.

First aid measures



Do not rub affected areas of the skin; pour plenty of lukewarm water over affected areas and cover over
with sterile bandages.



Move unconscious victim immediately to fresh air and provide artificial respiration, if necessary.



With severe injuries, call a doctor immediately.

SELF-DIAGNOSTIC SYSTEM

CONNECTING AND USING TEST EQUIPMENT - AD00.00-P-1000AZ

2004 Mercedes-Benz ML350

1998-2005 GENINFO Overall vehicle - 163 Chassis
