Mercedes-Benz ML320. Service manual - part 381





1998-2005 ENGINE

Electrical System - Engine - 163 Chassis

GENERAL INFORMATION

GENERAL NOTES: PASSENGER CARS: ELECTRICAL SYSTEM - ENGINE - AH15.00-Z-9999AZ

MODEL all



General notes on
contactless high voltage
distribution

ENGINE 112, 113...

AH15.10-P-1002-
01WA



General notes on
contactless high voltage
distribution

ENGINE 104, 111...

AH15.10-P-1002-
01WD



General notes on
contactless high voltage
distribution

ENGINE 119, 120...

AH15.10-P-1002-
01WE



General notes on testing
contactless high voltage
distribution

ENGINE 104, 111, 112, 113,
119, 120...

AH15.10-P-1003-01W



Notes on ignition coil
characteristics of ignition
systems

ENGINE 104, 111, 112, 113,
119, 120...

AH15.10-P-1001-01A



Notes on avoiding
damage to ignition system

ENGINE
266.920 /940 /960 /980 in
MODEL 169.0/3,245.2

AH15.10-P-0002-
01AK



Notes on avoiding
damage to the ignition
system

ENGINE 111 mit Benzin-
Einspritz-und Zundsystem
PMS

AH15.10-P-0002-01B



Notes on avoiding
damage to the ignition
system

ENGINE 104, 111 mit Benzin-
Einspritz-und Zundsystem
HFM

AH15.10-P-0002-01C



Notes on avoiding
damage to the ignition
system

ENGINE 103, 104, 119 mit
Benzin-Einspritzanlage KE

AH15.10-P-0002-01E



Notes on avoiding
damage to the ignition
system

ENGINE 104, 119, 120 mit
Benzin-Einspritzanlage LH

AH15.10-P-0002-01F



Notes on avoiding
damage to the ignition
system

ENGINE 166 mit Benzin-
Einspritz- und Zundsystem
MSM

AH15.10-P-0002-01G



Information on avoiding
damage to ignition system

ENGINE 137, 275, 285

AH15.10-P-0002-01L



Notes on avoiding

ENGINE 272, 273

AH15.10-P-0002-01V



2001 Mercedes-Benz ML320

1998-2005 ENGINE Electrical System - Engine - 163 Chassis





2001 Mercedes-Benz ML320

1998-2005 ENGINE Electrical System - Engine - 163 Chassis



me



me



NOTES ON AVOIDING DAMAGE TO IGNITION SYSTEM - AH15.10-P-0002-01D

Engine 104, 111, 112, 113, 119, 120, 156, 271

To avoid damage to control unit connect and disconnect the two connectors on control unit only when
ignition is switched off.

Terminal 1 of ignition coils must not be short-circuited to GND, e.g. as anti-theft protection.

Install only original ignition system components.

Do not operate ignition system at starting speed unless all of the ignition cables are connected.

No tests such as holding ignition cable 4 at a distance to GND, unplugging a spark plug connector or
pulling cable 4 out of the ignition coils, may be performed at starting speed or when the engine is
running.

Every high voltage circuit must be loaded with at least 2 kohms (spark plug connector).

If it is necessary to test the ignition spark when providing roadside assistance, this must only be done with
a spark plug at a cylinder ignition cable. Ensure that the spark plug has good contact to ground.

Before working at cranking speed, e.g. checking compression pressure, switch off ignition and disconnect
connector "2" from control unit.

 Engine 120 has two fuel injection and ignition systems.

Use of testers

Only connect and disconnect secondary measuring sensor to corresponding ignition cables when vertical
engine and ignition are switched off.

If the shot-circuit protection is operated (cylinder comparison) and the engine stays upright, it is not
possible to conduct the test with this test instrument.

Do not connect test lamp to ignition coil terminals 1 and 15.

NOTES ON IGNITION COIL CHARACTERISTICS OF IGNITION SYSTEMS - AH15.10-P-1001-01A

Engine 104, 111, 112, 113, 119, 120



In the case of the twin-spark ignition coil with kV pickup in ignition systems ME-SFI 2.1 and HFM-SFI, no
measurement facility exists at the ignition coil using the kV pickup although a kV pickup is fitted. It is only

damage to ignition system



Notes on avoiding
damage to ignition system

ENGINE 104, 111, 112, 113,
119, 120, 156, 271, 112 mit
Benzin-Einspritz- und
Zundsystem ME

AH15.10-P-0002-01D



Notes for ceramic glow
plugs

ENGINE 646.8, 642

AH15.20-P-0001-01A



2001 Mercedes-Benz ML320

1998-2005 ENGINE Electrical System - Engine - 163 Chassis



me



possible to test the primary ignition circuit with adapter cable A.
