8 Attach guard plate for radiator/condenser y Guard plate for radiator/condenser Engine 606 in model 124, Engine 606.961 in model 140, Engine 112, 113, 604, 605, 611.960 in model Engine 628.962, 612.965, 606.964, 112.945, Engine 112 in model 220, Engine 113 in model 211, 215, 220, Engine 112 in model 208, Engine 112, 113, 612.963, 628.963 in model Engine 137, 275 in model 215, 220, Engine 613.960, 628.960 in model 220, Engine 113.992 in model 230.474, Engine 271 in model 209, 203, Engine 285.950 in model 240.078 /178, Engine 612.967 in model 209.316, Engine 648 in model 220 Engine 112.951 in model 639.601/603/ 605/ 603 /605 /701 /703 /705 /801 /803 /805 Engine 646.982 in model 639.601/ 603/ 605/ WF58.50-P-0110-01A 9 Remove air cleaner housing (5) 10 Remove air intake pipe (6) with resonance Separate connector of hot film mass air flow sensor (HFM) for this step and unbolt air The air intake pipe is attached at the rear at the intake manifold with a plastic plate. Do not damage the plastic strap. Engine 112.942/ 970 AR07.07-P-1454A Engine 113.942/ 965/ 981 AR07.07-P-1454MV
Danger! Risk of explosion caused by fuel igniting, No fire, sparks, open flames or smoking. Wear protective clothing when handling fuel. AS47.00-Z-0001-01A 11 Disconnect fuel line at fuel rail Release fuel pressure at service valve! Collect fuel! Engine 112: #
*BA07.52-P-1001-01A Engine 113: #
*BA07.52-P-1001-01A Pressure hose *119589046300 12 Remove right and left ignition coils (12) AR15.12-P-2003A 13 Remove right and left cylinder head covers (13) AR01.20-P-5014B 14 Remove the intake manifold (14)
Installation: On vehicles with engine damage, the intake manifold must be AR09.20-P-1310A The intake manifold system must not be disassembled. Remove intake manifold with fuel distributor 15.1 Remove camshaft position sensor (15) Only necessary if the right cylinder head is removed. AR15.10-P-2000A Copyright DaimlerChrysler AG 20.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorded by Modification services. Page 3 |
