Fig. 289: Identifying Dimension (A) On Left And Right From Upper Edge Of Transmission Tunnel 4. From the transmission tunnel cutout of the floor covering measure dimension (c) and from the inner edge of the cutout of the 40 % rear seat (3) measure the dimension (d) and mark floor covering. Fig. 290: Identifying Transmission Tunnel Cutout Of Floor Covering Dimension (C) 5. Cut into floor covering toward left-hand side (e). Incision should be located in the center of the transmission tunnel. 6. Starting from the center of the previous incision, cut into floor covering toward the rear (f). 7. Guide wiring harness for video player (4) and wiring harness for DVD player (5) from the incision behind
2001 Mercedes-Benz ML320 1998-2005 ACCESSORIES & BODY, CAB Electrical System - Body - 163 Chassis
