147

Controls in detail

Power windows

Closing the windows

왘

Press and hold the lower part of
switches 1 or 2.

The corresponding window will move
upwards until you release the switch.

148

Controls in detail

Sliding/pop-up roof*

왔

Sliding/pop-up roof*

Opening and closing the
sliding/pop-up roof

The sliding/pop-up roof can be opened
and closed electrically. The switch for the
sliding/pop-roof is on the overhead
control panel.

1 Push up to raise roof at rear
2 Push back to slide roof open
3 Push down to lower roof at rear
4 Push forward to slide roof closed

With the roof closed or tilted open, a
screen can be slid into the roof opening to
guard against sun rays. When sliding the
roof open, the screen will also retract.

Warning!

G

When closing the sliding/pop-up roof, make
sure that there is no danger of anyone being
harmed by the closing procedure.

The closing procedure can be immediately
reversed by moving the switch in
direction 1 or 2.

When leaving the vehicle, always remove the
key from steering lock and lock your vehicle.
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Unsupervised use of vehicle equipment may
cause an accident and/or serious personal
injury.

!

To avoid damaging the seals, do not
transport any objects with sharp edges
which can stick out of the
sliding/pop-up roof.

Do not open the sliding/pop-up roof if
there is snow or ice on the roof, as this
could result in malfunctions.

The sliding/pop-up roof can be opened
or closed manually should an electrical
malfunction occur (

컄

page 265).

149

Controls in detail

Sliding/pop-up roof*

왘

Turn the key in the steering lock to
position 1 or 2 (

컄

page 33).

Opening and closing the
sliding/pop-up roof

왘

To open, close, raise or lower the
sliding/pop-up roof, move the switch
in the required direction 1 to 4.

Release the switch when the roof has
reached the desired position.

Raising the roof

왘

Press and hold the switch in
direction 1.

The roof is raised at rear.

Lowering the roof

왘

Pull and hold the switch in direction 3.

The sliding/ pop-up roof is lowered and
closed.

Opening the sliding / pop-up roof auto-
matically

왘

Briefly press switch in direction 2.

The sliding/pop up roof will not open
completely.

왘

Press switch again to open the
sliding/pop-up roof completely.

Stopping the roof

왘

Briefly press the switch in any direc-
tion.

The movement of the roof will stop.

Synchronizing the sliding/pop-up roof

The power sliding /pop-up roof must be re-
synchronized each time after:

앫

the battery has been disconnected

앫

the sliding /pop-up roof has been
closed manually

앫

the sliding /pop-up roof does not open
smoothly

앫

a malfunction

Synchronizing

왘

Remove the fuse from the fuse box
(

컄

page 287).

왘

Replace the fuse in the fuse box.

왘

Switch on ignition.

왘

Press and hold the switch in
direction 1 until the sliding/pop-up
roof is fully raised at the rear.

Hold the switch for approximately one
second.

The sliding/pop-up roof is synchro-
nized.

150

Controls in detail

Driving systems

왔

Driving systems

The driving systems of your vehicle are de-
scribed on the following pages:

앫

Cruise control, with which the vehicle
can maintain a preset speed.

앫

Parktronic*, with which you can assist
your parking maneuvers.

The driving systems BAS, ABS, ESP, EBB
and 4-ETS, are described in the “Safety
and Security” section (

컄

page 76).

Cruise control

Cruise control automatically maintains the
speed you set for your vehicle.

Use of cruise control is recommended for
driving at a constant speed for extended
periods of time. You can set or resume
cruise control at any speed over 20 mph
(30 km/h).

The cruise control function is operated by
means of the cruise control lever.

The cruise control lever is the uppermost
lever found on the left-hand side of the
steering column (

컄

page 23).

Warning!

G

Cruise control is a convenience system de-
signed to assist the driver during vehicle op-
eration. The driver is and must remain
responsible for the vehicle speed and for
safe brake operation.

Only use cruise control if the road, traffic
and weather conditions make it advisable to
travel at a steady speed.

앫

The use of cruise control can be danger-
ous on winding roads or in heavy traffic
because conditions do not allow safe
driving at a steady speed.

앫

The use of cruise control can be danger-
ous on slippery roads. Rapid changes in
tire traction can result in wheel spin and
loss of control.

앫

Deactivate cruise control when driving
in fog.

The “Resume” function should only be oper-
ated if the driver is fully aware of the previ-
ously set speed and wishes to resume this
particular preset speed.
