Mazda CX-5 (2019 year). Manual

Signal

Warning

(Flashing)

Tire Pressure Moni‐

toring System

Warning Light

If the tire pressure monitoring system has a malfunction, the tire pressure warning light
flashes. Have your vehicle checked by an Authorized Mazda Dealer as soon as possible.

WARNING

If the tire pressure monitoring system warning light illuminates or flashes, or the tire pres‐
sure warning beep sound is heard, decrease vehicle speed immediately and avoid sudden
maneuvering and braking:
If the tire pressure monitoring system warning light illuminates or flashes, or the tire pres‐
sure warning beep sound is heard, it is dangerous to drive the vehicle at high speeds, or
perform sudden maneuvering or braking. Vehicle drivability could worsen and result in an
accident.
To determine if you have a slow leak or a flat, pull over to a safe position where you can
check the visual condition of the tire and determine if you have enough air to proceed to a
place where air may be added and the system monitored again by an Authorized Mazda
Dealer or a tire repair station.

Do not ignore the TPMS Warning Light:
Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated. Have
the problem taken care of as soon as possible before it develops into a more serious situa‐
tion that could lead to tire failure and a dangerous accident.

(Amber)

KEY Warning Indi‐

cation

“Keyless System Malfunction” is displayed

This message is displayed if the advanced keyless entry & push button start system has a
problem.
Contact an Authorized Mazda Dealer.

CAUTION

If the message is indicated, or the push button start indicator light (amber) flashes, the en‐
gine may not start. If the engine cannot be started, try starting it using the emergency oper‐
ation for starting the engine, and have the vehicle inspected at an Authorized Mazda Deal‐
er as soon as possible.
Refer to Emergency Operation for Starting the Engine on page 4-10.

“Ignition is On” is displayed

This message is displayed when the driver's door is opened without switching the ignition
off.

“Key Not Detected” is displayed

This message is displayed when any of the following operations is performed with the key
out of the operational range or placed in areas inside the cabin where it is difficult for the
key to be detected.



The push button start is pressed with the ignition switched off



The ignition is switched on



All doors are closed without switching the ignition off

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-30

*Some models.

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Signal

Warning

(Red)

(Turns on)

KEY Warning

Light

If any malfunction occurs in the keyless entry system, it illuminates continuously.

CAUTION

If the key warning indicator light illuminates or the push button start indicator light (amber)
flashes, the engine may not start. If the engine cannot be started, try starting it using the
emergency operation for starting the engine, and have the vehicle inspected at an Author‐
ized Mazda Dealer as soon as possible.
Refer to Emergency Operation for Starting the Engine on page 4-10.

(Amber)

High Beam Control

System (HBC)

Warning Indication/

Warning Light

The light remains turned on if there is a problem with the system. Have your vehicle in‐
spected at an Authorized Mazda Dealer.

NOTE

If the Forward Sensing Camera (FSC) field of view is impaired during bad weather condi‐
tions (such as rain, fog, and snow) and when the windshield is dirty, the warning indica‐
tion/warning light for the High Beam Control System (HBC) may display/turn on. Howev‐
er, this does not indicate a problem.

Blind Spot Monitor‐

ing (BSM) Warning

Indication

The Warning indication turns on if there is any malfunction in the Blind Spot Monitoring
(BSM). Have your vehicle inspected by an Authorized Mazda Dealer.

NOTE

If the vehicle is driven on a road with less traffic and few vehicles that the radar sensors
can detect, the system may pause. However, it does not indicate a malfunction.

Blind Spot Monitor‐

ing (BSM) OFF In‐

dicator Light

A problem in the system may be indicated under the following conditions.
Have your vehicle inspected at an Authorized Mazda Dealer.



The light does not turn on when the ignition is switched ON.



The light remains on even when the Blind Spot Monitoring (BSM) system can be oper‐
ated.



It turns on while driving the vehicle.

NOTE

If the vehicle is driven on a road with less traffic and few vehicles that the radar sensors
can detect, the system may pause (The Blind Spot Monitoring (BSM) OFF indicator light
in the instrument cluster illuminates). However, it does not indicate a malfunction.

(Amber)

Mazda Radar Cruise
Control with Stop &

Go function

(MRCC with Stop

& Go function)

Warning Indication

The message is displayed when the system has a malfunction. Have your vehicle inspect‐
ed at an Authorized Mazda Dealer.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

7-31

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Signal

Warning

Lane-keep Assist

System (LAS) &

Lane Departure

Warning System

(LDWS) Warning

Indication

The message is displayed when the system has a malfunction. Have your vehicle inspect‐
ed at an Authorized Mazda Dealer.
The system does not operate when the warning message is displayed.

CAUTION

 Always use tires for all wheels that are of the specified size, and the same manufacture,

brand, and tread pattern. In addition, do not use tires with significantly different wear
patterns on the same vehicle. If such improper tires are used, the system may not operate
normally.

 When an emergency spare tire is used, the system may not operate normally.

LED Headlight

Warning Light

This light illuminates if there is a malfunction in the LED headlight. Have your vehicle
inspected by an Authorized Mazda Dealer.

▼ Taking Action

Take the appropriate action and verify that the warning light turns off.

Signal

Warning

Action to be taken

(Amber)

Smart Brake Support/

Smart City Brake Sup‐

port (SBS/SCBS)

Warning Indication/

Warning Light

The light turns on if the windshield or the
radar sensor are dirty, or there is a malfunc‐
tion in the system.

Verify the reason why the warning light is
illuminated on the center display.
If the reason why the warning light is illu‐
minated is due to a dirty windshield, clean
the windshield.
If the warning light is illuminated because
of a dirty radar sensor, clean the front em‐
blem.
For any other reasons, have the vehicle in‐
spected at an Authorized Mazda Dealer.

Low Fuel Warning In‐

dication/Warning

Light

The light turns on when the remaining fuel
is about 9.0 L (2.3 US gal, 1.9 Imp gal).

NOTE

The light illumination timing may vary be‐
cause fuel inside the fuel tank moves
around according to the driving conditions
and the vehicle posture.

Add fuel.

Check Fuel Cap Warn‐

ing Indication/Warning

Light

If the check fuel cap warning light illumi‐
nates while driving, the fuel-filler cap may
not be installed properly.

Stop the engine and reinstall the fuel-filler
cap.
Refer to Refueling on page 3-30.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-32

*Some models.

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Signal

Warning

Action to be taken

Engine Oil Level

Warning Light

This warning light indicates that the engine
oil level is around the MIN mark (page
6-26).

Add 1 L (0.3 US gal, 0.2 Imp gal) of en‐
gine oil (page 6-24).

Seat Belt Warning

Light (Front seat)

Except Mexico
The seat belt warning light turns on if the
driver or front passenger's seat is occupied
and the seat belt is not fastened with the ig‐
nition switched ON.
If the driver or front passenger's seat belt is
unfastened (only when the front passenger's
seat is occupied) and the vehicle is driven at
a speed faster than about 20 km/h (12 mph),
the warning light flashes. After a short time,
the warning light stops flashing, but re‐
mains illuminated.

NOTE



The warning light flashes for about 6
seconds if the driver's seat belt is not fas‐
tened when the ignition is switched ON.



To allow the front passenger occupant
classification sensor to function properly,
do not place and sit on an additional seat
cushion on the front passenger's seat.
The sensor may not function properly be‐
cause the additional seat cushion could
cause sensor interference.



If a small child is seated on the front pas‐
senger's seat, the warning light may not
operate.

Fasten the seat belts.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-33

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Signal

Warning

Action to be taken

Seat Belt Warning

Light (Front seat)

Mexico
The seat belt warning light turns on if the
driver or front passenger's seat is occupied
and the seat belt is not fastened with the ig‐
nition switched ON.
If the driver or front passenger's seat belt is
unfastened (only when the front passenger's
seat is occupied) and the vehicle is driven at
a speed faster than about 20 km/h (12 mph),
the warning light flashes. After a short time,
the warning light stops flashing, but re‐
mains illuminated. If a seat belt remains un‐
fastened, the warning light flashes again for
a given period of time.

NOTE



Placing heavy items on the front pas‐
senger's seat may cause the front pas‐
senger's seat belt warning function to op‐
erate depending on the weight of the
item.



To allow the front passenger seat weight
sensor to function properly, do not place
and sit on an additional seat cushion on
the front passenger's seat. The sensor
may not function properly because the
additional seat cushion could cause sen‐
sor interference.



If a small child is seated on the front pas‐
senger's seat, the warning light may not
operate.

Fasten the seat belts.

(Red)

Seat Belt Warning

Light (Rear seat)

If the rear seat belts are not fastened while
the ignition is switched ON , the driver and
the passenger are alerted by the warning
light.
The warning light operates even if there is
no passenger on the rear seat.

NOTE

If a rear seat belt is not fastened by a cer‐
tain period of time after the engine has
been started, the warning light turns off.

Fasten the seat belts.

Low Washer Fluid

Level Warning Indica‐

tion/Warning Light

This warning light indicates that little wash‐
er fluid remains.

Add washer fluid (page 6-29).

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-34

*Some models.

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Signal

Warning

Action to be taken

Door-Ajar/Lift‐

gate-Ajar Warning In‐

dication/Warning

Light

The light turns on if any door/liftgate is not
closed securely.

Close the door/liftgate securely.

Tire Pressure Monitoring System Warning Light (Turns on)

Take the appropriate action and verify that the warning light turns off.

Warning

When the warning light illuminates, and the warning beep sound is heard when tire pressure is too low in one or
more tires.

WARNING

If the tire pressure monitoring system warning light illuminates or flashes, or the tire pressure warning beep sound
is heard, decrease vehicle speed immediately and avoid sudden maneuvering and braking:
If the tire pressure monitoring system warning light illuminates or flashes, or the tire pressure warning beep sound
is heard, it is dangerous to drive the vehicle at high speeds, or perform sudden maneuvering or braking. Vehicle
drivability could worsen and result in an accident.
To determine if you have a slow leak or a flat, pull over to a safe position where you can check the visual condition
of the tire and determine if you have enough air to proceed to a place where air may be added and the system
monitored again by an Authorized Mazda Dealer or a tire repair station.

Do not ignore the TPMS Warning Light:
Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated. Have the problem taken
care of as soon as possible before it develops into a more serious situation that could lead to tire failure and a
dangerous accident.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

7-35

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Action to be taken

Inspect the tires and adjust to the specified inflation pressure (page 6-41).

CAUTION

When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the
tire pressure sensors may be damaged.

NOTE



Perform tire pressure adjustment when the tires are cold. Tire pressure will vary according to the tire temper‐
ature, therefore let the vehicle stand for 1 hour or only drive it 1.6 km (1 mile) or less before adjusting the
tire pressures. When pressure is adjusted on hot tires to the cold inflation pressure, the TPMS warning light/
beep may turn on after the tires cool and pressure drops below specification.
Also, an illuminated TPMS warning light, resulting from the tire air pressure dropping due to cold ambient
temperature, may turn off if the ambient temperature rises. In this case, it will also be necessary to adjust the
tire air pressures. If the TPMS warning light illuminates due to a drop in tire air pressure, make sure to check
and adjust the tire air pressures.



After adjusting the tire air pressures, it may require some time for the TPMS warning light to turn off. If the
TPMS warning light remains illuminated, drive the vehicle at a speed of at least 25 km/h (16 mph) for 10
minutes, and then verify that it turns off.



Tires lose air naturally over time and the TPMS cannot tell if the tires are getting too soft over time or you
have a flat. However, when you find one low tire in a set of four-that is an indication of trouble; you should
have someone drive the vehicle slowly forward so you can inspect any low tire for cuts and any metal objects
sticking through tread or sidewall. Put a few drops of water in the valve stem to see if it bubbles indicating a
bad valve. Leaks need to be addressed by more than simply refilling the trouble tire as leaks are dangerous
― take it to an Authorized Mazda Dealer which has all the equipment to fix tires, TPMS systems and order
the best replacement tire for your vehicle.

If the warning light illuminates again even after the tire pressures are adjusted, there may be a tire puncture.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-36

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

KEY Warning Indication/Warning Light

Take the appropriate action and verify that the warning light turns off.

Signal

Cause

Action to be taken

(White)

KEY Warning Indica‐

tion

The key battery is dead.

Replace the key battery (page 6-38).

(Red)

(Flashing)

KEY Warning Light

The key battery is dead.

Replace the key battery (page 6-38).

The key is not within the operation range.

Bring the key into the operation range
(page 3-8).

The key is placed in areas inside the cabin
where it is difficult for the key to be detect‐
ed.

A key from another manufacturer similar to
the key is in the operation range.

Take the key from another manufacturer
similar to the key out of the operation
range.

Without the ignition switched off, the key is
taken out of the cabin, and then all the
doors are closed.

Bring the key back into the cabin.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-37

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Message Indicated in Multi-information Display

If there is a notification from the vehicle, a message is displayed in the multi-information
display. Check the information and take the necessary action.

(Display example)

Instrument Cluster

Type A

Type B

If the warning light turns on/flashes simultaneously or a symbol is indicated in the display,
check the information regarding the warning light or symbol.
Refer to If a Warning Light Turns On or Flashes on page 7-23.

Display

Content

Action to be taken

Indicated when the push button start is
pressed while the selector lever is not in
the P position.

Shift the selector lever to the P position.

Indicated when the push button start is
pressed without depressing the brake
pedal.

Depress the brake pedal and press the
push button start.

Indicates when the Electric Parking
Brake (EPB) switch is operated without
depressing the brake pedal.

Operate the Electric Parking Brake
(EPB) switch while depressing the brake
pedal.

Indicates when there is a problem with
the brake related system while the vehi‐
cle is being held in a stop position by the
AUTOHOLD function or during the
Mazda Radar Cruise Control with Stop
& Go function (MRCC with Stop & Go
function) stop hold control.

Depress the brake pedal.
Cancel the AUTOHOLD function or the
Mazda Radar Cruise Control with Stop
& Go function (MRCC with Stop & Go
function), and have your vehicle inspect‐
ed at an Authorized Mazda Dealer.

Indicates the possibility of the vehicle
not being held in the stopped position by
the AUTOHOLD function or the Mazda
Radar Cruise Control with Stop & Go
function (MRCC with Stop & Go func‐
tion) stop hold control, such as on steep
slopes.

Depress and hold your foot on the brake
pedal.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-38

*Some models.

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Display

Content

Action to be taken

Indicates when the cancel operation is
done without depressing the brake pedal
while the vehicle is being held in the
stopped position by the AUTOHOLD
function.

Cancel the AUTOHOLD function stop
hold control while depressing the brake
pedal.

Indicated when the engine coolant tem‐
perature is high or the engine is hot, and
the engine output is limited.

Drive slowly and make sure that the in‐
dication turns off.
If the indication does not turn off, con‐
sult an Authorized Mazda Dealer.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-39

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Message Indicated on Display

If a message is displayed in the center display, take appropriate action (in a calm manner)
according to the displayed message.

(Display example)

▼ Stop Vehicle in Safe Place Immediately

If the following messages are displayed in the center display , a vehicle system may be
malfunctioning. Stop the vehicle in a safe place and contact an Authorized Mazda Dealer.

Display

Indicated Condition

Displays if the engine coolant temperature has increased excessively.

Displays if the charging system has a malfunction.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-40

*Some models.

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Warning Sound is

Activated

▼ Lights-On Reminder

The lights-on reminder is operable when
the time setting

of the auto headlight off

function is off.
If lights are on and the ignition is switched
to ACC or off, a continuous beep sound
will be heard when the driver's door is
opened.

1 If the light switch is left on, the auto

headlight off function automatically
turns off the lights about 30 seconds
after switching the ignition off. The
time setting can be changed.
Refer to Personalization Features on
page 9-12.

NOTE



When the ignition is switched to ACC,
the “Ignition Not Switched Off (STOP)
Warning Beep” (page 7-43) overrides
the lights-on reminder.



A personalized function is available to
change the sound volume for the
lights-on reminder.
Refer to Personalization Features on
page 9-12.

▼ Air Bag/Front Seat Belt

Pretensioner System Warning Beep

If there is a problem with the air bag/seat
belt pretensioner systems and the warning
light illumination, a warning beep sound
will be heard for about 5 seconds every
minute.

The air bag and seat belt pretensioner
system warning beep sound will continue
to be heard for approximately 35 minutes.
Have your vehicle inspected at an
Authorized Mazda Dealer as soon as
possible.

WARNING

Do not drive the vehicle with the air bag/
seat belt pretensioner system warning beep
sounding:
Driving the vehicle with the air bag/seat
belt pretensioner system warning beep
sounding is dangerous. In a collision, the
air bags and the seat belt pretensioner
system will not deploy and this could result
in death or serious injury. Contact an
Authorized Mazda Dealer to have the
vehicle inspected as soon as possible.

▼ Seat Belt Warning Beep

Front seat

Except Mexico

If the driver's seat belt is not fastened
when the ignition is switched ON, a beep
sound will be heard for about 6 seconds. If
the driver or the front passenger's seat belt
is not fastened and the vehicle is driven at
a speed faster than about 20 km/h (12
mph), a beep sound will be heard again for
a specified period of time.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-42

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Until a seat belt is fastened or a given
period of time has elapsed, the beep sound
will not stop even if the vehicle speed falls
below 20 km/h (12 mph).

NOTE



To allow the front passenger occupant
classification sensor to function
properly, do not place and sit on an
additional seat cushion on the front
passenger's seat. The sensor may not
function properly because the additional
seat cushion could cause sensor
interference.



If a small child is seated on the front
passenger's seat, the warning beep may
not operate.

Mexico

If the vehicle speed exceeds about 20
km/h (12 mph) with the driver or front
passenger's seat belt unfastened, a warning
beep sounds continuously. If the seat belt
remains unfastened, the beep sound stops
once and then continues for about 90
seconds. The beep stops after the driver or
front passenger's seat belt is fastened.
Until a seat belt is fastened or a given
period of time has elapsed, the beep sound
will not stop even if the vehicle speed falls
below 20 km/h (12 mph).

NOTE



Placing heavy items on the front
passenger's seat may cause the front
passenger's seat belt warning function
to operate depending on the weight of
the item.



If a small child is seated on the front
passenger's seat, the warning beep may
not operate.

Rear seat

The warning beep only sounds if a seat
belt is unfastened after being fastened.

▼ Ignition Not Switched Off (STOP)

Warning Beep

If the driver's door is opened with the
ignition switched to ACC, a beep will be
heard continuously in the cabin to notify
the driver that the ignition has not been
switched OFF (STOP). Under this
condition, the keyless entry system will
not operate, the vehicle cannot be locked,
and the battery voltage will be depleted.

▼ Key Removed from Vehicle Warning

Beep

Vehicles with advanced keyless function

If the key is taken out of the vehicle while
the ignition is not switched OFF and all
the doors are closed, the beep which
sounds outside of the vehicle will be heard
6 times, the beep which sounds inside the
vehicle will be heard 6 times.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-43

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Vehicles without advanced keyless
function

If the key is taken out of the vehicle while
the ignition is not switched OFF and all
the doors are closed, a beep will be heard
in the cabin 6 times.

NOTE
Because the key utilizes low-intensity
radio waves, the Key Removed From
Vehicle Warning may activate if the key is
carried together with a metal object or it
is placed in a poor signal reception area.

▼ Request Switch Inoperable Warning

Beep (With the advanced keyless
function)

If the request switch is pressed with the
door open or ajar, or the ignition is not
switched OFF with a key being carried, a
beep will be heard outside for about 2
seconds to notify the driver that the door
or liftgate cannot be locked.

▼ Key Left-in-luggage Compartment

Warning Beep (With the advanced
keyless function)

If the key is left in the luggage
compartment with all the doors locked and
the liftgate closed, a beep will be heard
outside for about 10 seconds to notify the
driver that the key is in the luggage
compartment. In this case, take out the key
by pressing the electric liftgate opener and
opening the liftgate. The key taken out of
the luggage compartment may not operate
because its functions have been
temporarily stopped. To restore the key's
functions, perform the applicable
procedure (page 3-8).

▼ Key Left-in-vehicle Warning Beep

(With the advanced keyless
function)

If all the doors and luggage compartment
are locked using another key while the key
is left in the cabin, the beep which sounds
outside of the vehicle will be heard for
about 10 seconds to notify the driver that
the key is in the cabin. In this case, take
out the key by opening the door. A key
taken out of the vehicle using this method
may not operate because its functions have
been temporarily stopped. To restore the
key's functions, perform the applicable
procedure (page 3-8).

▼ Power Liftgate Warning Beep

If system operation precautions are
necessary, the driver is notified by the
warning sound.

Cautions

What to check

The beep sounds 3 times

The conditions required
for the power liftgate to
operate have not been
met, such as an object
being stuck in the lift‐
gate.

The beep sound contin‐
ues

The vehicle is being
driven with the liftgate
open. Stop the vehicle
and close the liftgate.

▼ Electric Parking Brake (EPB)

Warning Beep

The warning buzzer is activated under the
following conditions:



The vehicle is driven with the parking
brake applied.



The Electric Parking Brake (EPB)
switch is pulled while the vehicle is
driven.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

7-44

*Some models.

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

▼ AUTOHOLD Warning Beep

Warning light flashes/message is displayed
and beep sound is activated
simultaneously for about 5 seconds when
using AUTOHOLD function or when
AUTOHOLD switch is operated.
Because a problem with AUTOHOLD
function has occurred, AUTOHOLD
function does not operate even if
AUTOHOLD switch is operated.

If the warning light flashes/message is
displayed and the beep sound is activated
simultaneously, have your vehicle
inspected at an Authorized Mazda Dealer.

▼ Power Steering Warning Buzzer

If the power steering system has a
malfunction, the power steering
malfunction indication/malfunction
indicator light turns on or flashes and the
buzzer operates at the same time.
Refer to Stop Vehicle in Safe Place
Immediately on page 7-24.

▼ Tire Inflation Pressure Warning

Beep

The warning beep sound will be heard for
about 3 seconds if the tire pressures
decrease.
Refer to Tire Pressure Monitoring System
on page 4-219.

▼ Blind Spot Monitoring (BSM)

Warning Beep

Driving forward

The warning beep operates when the turn
signal lever is operated to the side where
the Blind Spot Monitoring (BSM) warning
light is illuminated.

NOTE
A personalized function is available to
change the Blind Spot Monitoring (BSM)
warning beep sound volume.
Refer to Personalization Features on page
9-12.

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

7-45

CX-5_8HE3-EA-18I_Edition1

2018-6-29 13:44:47

Mazda CX-5 (2019 year). Manual - part 38
