Mazda CX-3 (2019 year). Manual

▼ SiriusXM operation

Select the icon on the home screen to display the Entertainment screen. When

selected, the following icons are indicated in the bottom part of the center display.

Icon

Function

Displays the Entertainment menu. Use to switch to a different audio source.

Displays the channel list of the current category.

Displays the favorites list. Long-press to store the channel currently being aired.
Refer to Operating the Radio on page 5-71.

Indicates that the parental lock function is in use.
Switching of Lock/Unlock and PIN code setting changes can be performed.

Plays each channel in the current channel list for 5 seconds.
Select again to continue receiving the channel.

Plays the previous channel.

Plays the next channel.

Displays sound settings to adjust audio quality level.
Refer to Volume/Display/Sound Controls on page 5-69.

Selection from channel list

Receivable channels can be displayed on
the channel list screen. You can easily
select the channel you want to listen from
the list. Each category can be also
displayed.
1. Select the

icon to display the

channel list.

2. Select a desired channel.

(Select from category list)

1. Select the

icon to display the

channel list.

2. Select

to display the category

list.

3. Select a desired category.

▼ Parental lock

If a channel is locked, the channel is
muted.
To use the parental lock function, the PIN
code must be initialized first.
By using the session lock, the parental
lock can be enabled or disabled during the
current drive cycle (from when the
ignition is switched on to switched off).
When the session lock is on, the parental
lock is available. When the session lock is
off, the parental lock is temporarily
cancelled.
When canceling the parental lock or
session lock, or when changing the PIN
code, PIN code input is required.

Interior Features

Audio Set [Type B (touchscreen)]

5-76

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

How to use AUX mode

▼ Playback

1. Select the icon on the home screen to display the Entertainment screen.
2. Select

to switch to the AUX mode. The following icons are displayed in the lower

part of the center display.

Icon

Function

Displays the Entertainment menu. Use to switch to a different audio source.

Displays sound settings to adjust audio quality level.
Refer to Volume/Display/Sound Controls on page 5-69.

NOTE

•

If a device is not connected to the auxiliary jack, the mode does not switch to the AUX
mode.

•

Adjust the audio volume using the portable audio device, commander switch, or audio
control switch.

•

Audio adjustments can also be made using the portable audio device's volume setting.

•

If the connection plug is pulled out from the auxiliary jack while in AUX mode, noise may
occur.

Interior Features

Audio Set [Type B (touchscreen)]

5-78

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

How to use USB mode

Type

Playable data

USB mode

MP3/WMA/AAC/OGG file

This unit does not support a USB 3.0 device. In addition, other devices may not be
supported depending on the model or OS version.
The recommended capacity of the USB memory is 16 GB or less.
USB devices formatted to FAT32 are supported (USB devices formatted to other formats
such as NTFS are not supported).

▼ Playback

1. Select the icon on the home screen to display the Entertainment screen.
2. Select

to switch the USB mode. The following icons are displayed in the

lower part of the center display.

Icon

Function

Displays the Entertainment menu. Use to switch to a different audio source.

Category list is displayed.

Current track list is displayed.
Select a desired track to play it.

Plays the current track repeatedly.
Select it again to play the tracks in the current track list repeatedly.
When selected again, the function is canceled.

Tracks in the current track list are played randomly.
Select it again to cancel.

Starts playing a track similar to the current track using Gracenote

's More Like This™.

Select the desired song from the category list to cancel More Like This™.

If selected within a few seconds from the beginning of a song which has started to play,
the previous song is selected.
If more than a few seconds have elapsed, the song currently being played is replayed from
the beginning.
Long-press to fast reverse. It stops when you remove your hand from the icon or the
commander knob.

Track is played. When selected again, playback is temporarily stopped.

Advances to the beginning of the next song.
Long-press to fast forward.

Interior Features

Audio Set [Type B (touchscreen)]

5-79

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Icon

Function

Displays sound settings to adjust audio quality level.
Refer to Volume/Display/Sound Controls on page 5-69.

NOTE

•

If a file name in the USB memory is too long, it could cause operation problems such as
not being able to playback the song.
(Recommended: Within 80 characters)

•

The album art may not display depending on the album art size.

•

To move to the desired location on the track, move the slider indicating the playback time.

•

The appearance of the repeat and shuffle icons changes depending on the type of
operation in which the function is used.

Category list

Select the

icon to display the following category list.

Select a desired category and item.

Category

Function

Playlist

Displays playlists on the device.

Artist

Displays the artist name list.
All the tracks or tracks for each album of the selected artist can be played.

Album

Displays the album name list.

Song

All the tracks in the device are displayed.

Genre

Displays the genre list.
All the tracks or tracks per album or artist in the selected genre can be played.

Audiobook

Displays the audiobook list.
Chapters can be selected and played.

Podcast

Displays the podcast list.
Episode can be selected and played.

Folder

Displays the folder/file list.

1 Playlist folders of Apple devices are not supported.

2 Apple device only

3 USB-Sticks and USB-Android™ device only

Interior Features

Audio Set [Type B (touchscreen)]

5-80

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Example of use (to play all tracks in
USB device)

(Method 1)

1. Select

to display the category list.

2. Select

All the tracks in the USB device are
displayed.

3. Select a desired track.

The selected track is played. All the
tracks in the USB device can be played
by continuing playback.

NOTE
Only the tracks in the desired category
selected in Step 2 are played.

(Method 2)

1. Select

to display the category list.

2. Select

All the folders in the USB device are
displayed.

3. Select

All the tracks in the USB device are
displayed.

4. Select a desired track.

The selected track is played. All the
tracks in the USB device can be played
by continuing playback.

1 Can be operated using an Android™

device or USB flash memory.

NOTE
Only the tracks in the desired folder
selected in Step 3 are played.

Interior Features

Audio Set [Type B (touchscreen)]

5-81

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

▼ Gracenote

Database

When a USB device is connected to this unit and the audio is played, the album name, artist
name, genre and title information are automatically displayed if there is a match in the
vehicle's database compilation to the music being played. The information stored in this
device uses database information in the Gracenote

music recognition service.

CAUTION

For information related to the most recent Gracenote

database which can be used and how

to install it, go to the Mazda Hands Free Website:
http://www.mazdahandsfree.com

Introduction

Gracenote, the Gracenote logo and logotype are either a registered trademark or a trademark
of Gracenote, Inc. in the United States and/or other countries.

Gracenote

End User License Agreement

This application or device contains software from Gracenote, Inc. of Emeryville, California
(“Gracenote”). The software from Gracenote (the “Gracenote Software”) enables this
application to perform disc and/or file identification and obtain music-related information,
including name, artist, track, and title information (“Gracenote Data”) from online servers or
embedded databases (collectively, “Gracenote Servers”) and to perform other functions. You
may use Gracenote Data only by means of the intended End-User functions of this
application or device.
You agree that you will use Gracenote Data, the Gracenote Software, and Gracenote Servers
for your own personal non-commercial use only. You agree not to assign, copy, transfer or
transmit the Gracenote Software or any Gracenote Data to any third party. YOU AGREE
NOT TO USE OR EXPLOIT GRACENOTE DATA, THE GRACENOTE SOFTWARE,
OR GRACENOTE SERVERS, EXCEPT AS EXPRESSLY PERMITTED HEREIN.
You agree that your non-exclusive license to use the Gracenote Data, the Gracenote
Software, and Gracenote Servers will terminate if you violate these restrictions. If your
license terminates, you agree to cease any and all use of the Gracenote Data, the Gracenote
Software, and Gracenote Servers. Gracenote reserves all rights in Gracenote Data, the
Gracenote Software, and the Gracenote Servers, including all ownership rights. Under no
circumstances will Gracenote become liable for any payment to you for any information that
you provide. You agree that Gracenote, Inc. may enforce its rights under this Agreement
against you directly in its own name.

Interior Features

Audio Set [Type B (touchscreen)]

5-82

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

The Gracenote service uses a unique identifier to track queries for statistical purposes. The
purpose of a randomly assigned numeric identifier is to allow the Gracenote service to count
queries without knowing anything about who you are. For more information, see the web
page for the Gracenote Privacy Policy for the Gracenote service.
The Gracenote Software and each item of Gracenote Data are licensed to you “AS IS.”
Gracenote makes no representations or warranties, express or implied, regarding the
accuracy of any Gracenote Data from in the Gracenote Servers. Gracenote reserves the right
to delete data from the Gracenote Servers or to change data categories for any cause that
Gracenote deems sufficient. No warranty is made that the Gracenote Software or Gracenote
Servers are error-free or that functioning of Gracenote Software or Gracenote Servers will
be uninterrupted. Gracenote is not obligated to provide you with new enhanced or additional
data types or categories that Gracenote may provide in the future and is free to discontinue
its services at any time.
GRACENOTE DISCLAIMS ALL WARRANTIES EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND
NON-INFRINGEMENT. GRACENOTE DOES NOT WARRANT THE RESULTS THAT
WILL BE OBTAINED BY YOUR USE OF THE GRACENOTE SOFTWARE OR ANY
GRACENOTE SERVER. IN NO CASE WILL GRACENOTE BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTAL DAMAGES OR FOR ANY LOST PROFITS OR
LOST REVENUES.
© Gracenote, Inc. 2009

Updating the database

The Gracenote

media database can be updated using USB device.

1. Connect a USB device containing the software for updating Gracenote

2. Select the

icon on the home screen to display the Settings screen.

3. Select the

tab and select

4. Select

. The list of the update package stored in the USB device and the version

are displayed.

5. Select the package to use the update.
6. Select

NOTE
Gracenote

can be downloaded from the Mazda Hands-free Website.

Interior Features

Audio Set [Type B (touchscreen)]

5-83

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Bluetooth

▼ Introduction

Bluetooth

Hands-Free outline

When a Bluetooth

device (mobile phone) is connected to the vehicle's Bluetooth

unit via

radio wave transmission, a call can be made or received by pressing the talk button, pick-up
button, or hang-up button on the audio remote control switch, or by operating the center
display. For example, even if a device (mobile phone) is in your coat pocket, a call can be
made without taking the device (mobile phone) out and operating it directly.

Bluetooth

audio outline

When a portable audio unit equipped with the Bluetooth

communication function is paired

to the vehicle, you can listen to music stored on the paired portable audio device from the
vehicle's speakers. It is not necessary to connect the portable audio device to the vehicle's
external input terminal. After programming, operate the vehicle audio control panel to play/
stop the audio.

NOTE

•

For your safety, a device can be paired only when the vehicle is parked. If the vehicle
starts to move, the pairing procedure will end. Park the vehicle in a safe place before
pairing.

•

The communication range of a Bluetooth

equipped device is about 10 meters (32 ft) or

less.

•

Basic audio operation is available using voice commands even if Bluetooth

is not

connected.

•

For safety reasons, operation of the center display is disabled while the vehicle is being
driven. However, items not displayed in gray can be operated using the commander
switch while the vehicle is being driven.

CAUTION

Some Bluetooth

mobile devices are not compatible with the vehicle. Consult an Authorized

Mazda Dealer, Mazda's call center or Web support center for information regarding
Bluetooth

mobile device compatibility:

U.S.A.

Phone: 800-430-0153
Web: www.mazdausa.com/mazdaconnect

Interior Features

Audio Set [Type B (touchscreen)]

5-84

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Canada

Phone: 800-430-0153
Web: www.mazdahandsfree.ca

Mexico

Center of Attention to Client (CAC)
Phone: 01-800-01-MAZDA
Web: www.mazdamexico.com.mx

Applicable Bluetooth

specification (Recommended)

Ver. 1.1/1.2/2.0 EDR/2.1 EDR/3.0 (conformity)

▼ Component Parts

Microphone

Talk button, Pick-up button and Hang-up button

Microphone

Audio unit

Talk button

Hang-up button

Pick-up button

Microphone (hands-free)

The microphone is used for speaking voice commands or when making a Hands-free call.

Talk button

Activates the voice recognition. In addition, it skips the voice guidance.

Interior Features

Audio Set [Type B (touchscreen)]

5-85

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Pick-up button

Responds to incoming calls. In addition, after selecting a contact or dialing a number, it
places the call when the button is pressed.

Hang-up button

Ends the call or refuses an incoming call. In addition, it ends the voice recognition
operation.

Commander switch

The commander switch is used for volume adjustment and display operation. Tilt or turn the
commander knob to move the cursor. Press the commander knob to select the icon.

Volume adjustment

The volume dial of the commander switch is used to adjust the volume. Turn the dial to the
right to increase volume, to the left to decrease it.
The volume can also be adjusted using the volume button on the steering wheel.

NOTE

•

Press the volume dial to switch the audio MUTE on and off.

•

If the volume is lower compared to other audio modes, increase the volume from the
device side.

Conversation volume and the volume of the voice guidance and ringtone can each be set in
advance.
1. Select the icon on the home screen to display the Communication screen.
2. Select

3. Adjust the

and the

using the slider.

Interior Features

Audio Set [Type B (touchscreen)]

5-86

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Bluetooth

Preparation

▼ Device pairing

To use Bluetooth

audio and Hands-Free,

the device equipped with Bluetooth

has

to be paired to the unit using the following
procedure. A maximum of 7 devices
including Bluetooth

audio devices and

hands-free mobile phones can be paired.

NOTE

•

The Bluetooth

system may not operate

for 1 or 2 minutes after the ignition is
switched to ACC or ON. However, this
does not indicate a problem. If the
Bluetooth

system does not connect

automatically after 1 or 2 minutes have
elapsed, make sure that the Bluetooth

setting on the device is normal and
attempt to reconnect the Bluetooth

device from the vehicle side.

•

If Bluetooth

-enabled devices are used

in the following locations or conditions,
connection via Bluetooth

may not be

possible.

•

The device is in a location hidden
from the center display such as behind
or under a seat, or inside the glove
compartment.

•

The device contacts or is covered by a
metal object or body.

•

The device is set to power-saving
mode.

Pairing Procedure

1. Select the

icon on the home screen

to display the Settings screen.

2. Select the

tab.

3. Select

4. Turn the Bluetooth

setting on.

5. Select

to display the

message and switch to the device
operation.

6. Using your device, perform a search

for the Bluetooth

device (Peripheral

device).

7. Select “Mazda” from the device list

searched by the device.

8. (Device with Bluetooth

version 2.0)

Input the displayed 4-digit pairing
code into the device.
(Device with Bluetooth

version 2.1

or higher)
Make sure the displayed 6-digit code
on the audio is also displayed on the
device, and touch the

Connection permission and phonebook
access permission for your mobile
device may be required depending on
the mobile device.

9. If pairing is successful, the functions

of the device connected to Bluetooth

are displayed.

10. (Devices compatible with Mazda

E-mail / SMS function)
SMS (Short Message Service)
messages, and E-mail for the device
are downloaded automatically. A
download permission operation for
your device may be required
depending on the device.

NOTE
When Call history and messages are
downloaded automatically, each automatic
download setting must be on.
Refer to Communication Settings on page
5-109.

Interior Features

Audio Set [Type B (touchscreen)]

5-87

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

After a device is registered, the system
automatically identifies the device. By
activating Bluetooth

Hands-Free again,

or by activating Bluetooth

Hands-Free

first after switching the ignition from OFF
to ACC, the device connection condition
is indicated in the center display.

IMPORTANT note about pairing and
automatic reconnection:

•

If pairing is redone on the same
mobile phone device, first clear
“Mazda” displayed on the Bluetooth

setting screen of the mobile device.

•

When the OS of the device is updated,
the pairing information may be deleted.
If this happens, reprogram the pairing
information to the Bluetooth

unit.

•

Before you pair your device, make sure
that Bluetooth

is “ON”, both on your

phone and on the vehicle.

▼ Device selection

If several devices have been paired, the
Bluetooth

unit links the device last

paired. If you would like to link a different
paired device, it is necessary to change the
link. The order of device priority after the
link has been changed is maintained even
when the ignition is switched off.

Connecting other devices

1. Select the

icon on the home screen

to display the Settings screen.

2. Select the

tab.

3. Select

4. Turn the Bluetooth

setting on.

5. Select the name of the device you

would like to connect.

selection

Connects both devices as hands-free
and Bluetooth

audio.

selection

Connects as a hands-free device.

selection

Connects as Bluetooth

audio.

NOTE
The following functions can be used for
the Hands-free or audio.

•

Hands-free: Phone calls and
E-mail/SMS

•

Audio: Bluetooth

audio, Pandora

Aha™, Stitcher™ radio

Disconnecting a device

1. Select the

icon on the home screen

to display the Settings screen.

2. Select the

tab.

3. Select

4. Turn the Bluetooth

setting on.

5. Select the device name which is

currently connected.

6. Select

Interior Features

Audio Set [Type B (touchscreen)]

5-88

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

▼ Deleting a device

Selecting and deleting devices

1. Select the

icon on the home screen

to display the Settings screen.

2. Select the

tab.

3. Select

4. Turn the Bluetooth

setting on.

5. Select the device name which you

would like to delete.

6. Select

7. Select

Deleting all devices

1. Select the

icon on the home screen

to display the Settings screen.

2. Select the

tab.

3. Select

4. Select

5. Select

6. Select

▼ Changing PIN code

PIN code (4 digits) can be changed.
1. Select the

icon on the home screen

to display the Settings screen.

2. Select the

tab.

3. Select

4. Select

5. Select

6. Input the new PIN code to be set.
7. Select .

Available Language

The Bluetooth

Hands-Free System

applies to the following languages:

•

English

•

Spanish

•

French

Refer to Settings on page 5-112.

Interior Features

Audio Set [Type B (touchscreen)]

5-89

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Bluetooth

Audio

Applicable Bluetooth

specification

(Recommended)
Ver. 1.1/1.2/2.0 EDR/2.1 EDR/3.0
(conformity)
Response profile

•

A2DP (Advanced Audio Distribution
Profile) Ver. 1.0/1.2

•

AVRCP (Audio/Video Remote Control
Profile) Ver. 1.0/1.3/1.4

A2DP is a profile which transmits only
audio to the Bluetooth

unit. If your

Bluetooth

audio device corresponds only

to A2DP, but not AVRCP, you cannot
operate it using the control panel of the
vehicle's audio system. In this case, only
the operations on the mobile device are
available the same as when a portable
audio device for a non-compliant
Bluetooth

device is connected to the

AUX terminal.

Function

A2DP

AVRCP

Ver.

1.0

Ver.

1.3

Ver.

1.4

Playback

Pause

File (Track)
up/down

—

Reverse

—

Fast-forward

—

Text display

—

Repeat

—

De-

pends

on de-

vice

De-

pends

on de-

vice

Function

A2DP

AVRCP

Ver.

1.0

Ver.

1.3

Ver.

1.4

Shuffle

—

De-

pends

on de-

vice

De-

pends

on de-

vice

Scan

—

De-

pends

on de-

vice

De-

pends

on de-

vice

Folder up/
down

—

De-

pends

on de-

vice

X: Available
—: Not available

NOTE

•

The battery consumption of Bluetooth

audio devices increases while
Bluetooth

is connected.

•

If a general mobile phone device is USB
connected during music playback over
the Bluetooth

connection, the

Bluetooth

connection is disconnected.

For this reason, you cannot have music
playback over a Bluetooth

connection

and music playback using a USB
connection at the same time.

•

If a device which supports AVRCP Ver.
1.6 or higher is connected, song
information may not display correctly.

•

The system may not operate normally
depending on the Bluetooth

audio

device.

Interior Features

Audio Set [Type B (touchscreen)]

5-90

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

▼ Switching to Bluetooth

audio mode

To listen to music or voice audio recorded to a Bluetooth

audio device, switch to the

Bluetooth

audio mode to operate the audio device using the audio system control panel.

Any Bluetooth

audio device must be paired to the vehicle's Bluetooth

unit before it can

be used.
Refer to Bluetooth

Preparation (Type B) on page 5-87.

1. Turn on the Bluetooth

audio device's power.

2. Switch the ignition to ACC or ON.
3. Select the icon on the home screen to display the Entertainment screen.
4. When

is selected, switches to the Bluetooth

audio mode to begin playback.

NOTE

•

If the application screen is not displayed on the device, Bluetooth

audio may not play on

the center display.

•

If Bluetooth

audio is used after using Pandora

, Aha™ or Stitcher™ radio, the

application on the mobile device has to be closed first.

•

If the Bluetooth

audio device does not begin playback, select the

icon.

•

If the mode is switched from Bluetooth

audio mode to another mode (radio mode), audio

playback from the Bluetooth

audio device stops.

▼ Playback

To listen to a Bluetooth

audio device over the vehicle's speaker system, switch the mode to

Bluetooth

audio mode. (Refer to “Switching to Bluetooth

audio mode”)

After switching to the Bluetooth

audio mode, the following icons are displayed in the

lower part of the display. Icons which can be used differ depending on the version of the
Bluetooth

audio device which you are currently using.

Icon

Function

Displays the Entertainment menu. Use to switch to a different audio source.

(AVRCP Ver. 1.4 only)
Displays the top level folder/file list.
Select the folder which you want to select.
The files in the selected folder are displayed.
Select the file you want to play.
(AVRCP Ver. 1.3 or higher)
Replays the song currently being played repeatedly.
When selected again, the songs in the folder are played repeatedly.
Select it again to cancel.
Icons change when the song is repeated or the folder is repeated.

Interior Features

Audio Set [Type B (touchscreen)]

5-91

CX-3_8GR7-EA-18B_Edition1

2017-12-20 16:18:14

Mazda CX-3 (2019 year). Manual - part 23
