Fiat 500X (2023 year). Manual in english - page 9





268

TECHNICAL SPECIFICATIONS

VEHICLE IDENTIFICATION NUMBER (VIN)

The VIN is stamped on the plate illustrated, located on the

left front corner of the instrument panel cover, visible from

outside the vehicle through the windshield.

Windshield VIN Location

BRAKE SYSTEM

Your vehicle is equipped with dual hydraulic brake

systems. If either of the two hydraulic systems lose normal

capability, the remaining system will still function.

However, there will be some loss of overall braking

effectiveness. You may notice increased pedal travel

during application, greater pedal force required to slow or

stop, and potential activation of the Brake Warning Light.
In the event power assist is lost for any reason (i.e.,

repeated brake applications with the engine OFF) the

brakes will still function. However, the effort required to

brake the vehicle will be much greater than that required

with the power system operating.

WHEEL AND TIRE TORQUE SPECIFICATIONS

Proper lug nut/bolt torque is very important to ensure that

the wheel is properly mounted to the vehicle. Any time a

wheel has been removed and reinstalled on the vehicle,

the lug nuts/bolts should be torqued using a properly

calibrated torque wrench using a six-sided (hex) deep wall

socket.

T

ORQUE

 S

PECIFICATIONS

**Use only authorized dealer recommended lug nuts/

bolts and clean or remove any dirt or oil before tightening.
Inspect the wheel mounting surface prior to mounting the

tire and remove any corrosion or loose particles.

Wheel Mounting Surface

Lug Nut/Bolt Torque

**Lug Nut/

Bolt Size

Lug Nut/

Bolt Socket

Size

89 ft-lb (120 N·m)

M12 x 1.25 x

25.5

17 mm

CarManuals2.com

TECHNICAL SPECIFICATIONS

269

Tighten the lug nuts/bolts in a star pattern until each nut/

bolt has been tightened twice.

Torque Patterns

After 25 miles (40 km) check the lug nut/bolt torque to be

sure that all the lug nuts/bolts are properly tightened.

FUEL REQUIREMENTS

While operating on gasoline with the required octane

number, hearing a light knocking sound from the engine is

not a cause for concern. However, if the engine is heard

making a heavy knocking sound, see an authorized dealer

immediately. Use of gasoline with a lower than

recommended octane number can cause engine failure

and may void or not be covered by the New Vehicle Limited

Warranty.
Poor quality gasoline can cause problems such as hard

starting, stalling, and hesitations. If you experience these

symptoms, try another brand of gasoline before

considering service for the vehicle.

1.3L T

URBO

 E

NGINE

This engine is designed to meet all emission

regulations and provide satisfactory fuel

economy and performance when using

high-quality unleaded regular gasoline having

an octane rating of 87 using the (R+M)/2 method.

For optimum performance and fuel economy the use of

91 octane or higher is recommended.

R

EFORMULATED

 G

ASOLINE



Many areas of the country require the use of

cleaner-burning gasoline referred to as “reformulated

gasoline”. Reformulated gasoline contains oxygenates

and are specifically blended to reduce vehicle emissions

and improve air quality.

The use of reformulated gasoline is recommended.

Properly blended reformulated gasoline will provide

improved performance and durability of engine and fuel

system components.

M

ATERIALS

 A

DDED

 T

O

 F

UEL



Besides using unleaded gasoline with the proper octane

rating, gasolines that contain detergents, corrosion and

stability additives are recommended. Using gasolines that

have these additives will help improve fuel economy,

reduce emissions, and maintain vehicle performance.

Designated TOP TIER Detergent Gasoline

contains a higher level of detergents to further

aide in minimizing engine and fuel system

deposits. When available, the usage of

TOP TIER Detergent Gasoline is recommended. Visit

www.toptiergas.com for a list of TOP TIER Detergent

Gasoline retailers.
Indiscriminate use of fuel system cleaning agents should

be avoided. Many of these materials intended for gum and

varnish removal may contain active solvents or similar

ingredients. These can harm fuel system gasket and

diaphragm materials.

WARNING!

To avoid the risk of forcing the vehicle off the jack, do

not tighten the lug nuts/bolts fully until the vehicle has

been lowered. Failure to follow this warning may result

in personal injury.

9

CarManuals2.com

270

TECHNICAL SPECIFICATIONS



G

ASOLINE

/O

XYGENATE

 B

LENDS



Some fuel suppliers blend unleaded gasoline with

oxygenates such as ethanol.

Problems that result from using gasoline containing more

than 15% ethanol (E-15) or gasoline containing methanol

are not the responsibility of the manufacturer and may

void or not be covered under New Vehicle Limited

Warranty.

D

O

 N

OT

 U

SE

 E-85 I

N

 N

ON

-F

LEX

 F

UEL



V

EHICLES

Non-Flex Fuel Vehicles (FFV) are compatible with gasoline

containing up to 15% ethanol (E-15). Use of gasoline with

higher ethanol content may void the New Vehicle Limited

Warranty.

If a Non-FFV vehicle is inadvertently fueled with E-85 fuel,

the engine will have some or all of these symptoms:

Operate in a lean mode.

OBD II Malfunction Indicator Light on.

Poor engine performance.

Poor cold start and cold drivability.

Increased risk for fuel system component corrosion.

CNG A

ND

 LP F

UEL

 S

YSTEM



M

ODIFICATIONS

Modifications that allow the engine to run on Compressed

Natural Gas (CNG) or Liquid Propane (LP) may result in

damage to the engine, emissions, and fuel system

components. Problems that result from running CNG or LP

are not the responsibility of the manufacturer and may

void or not be covered under the New Vehicle Limited

Warranty.

M

ETHYLCYCLOPENTADIENYL



M

ANGANESE

 T

RICARBONYL

 (MMT) I

N



G

ASOLINE

MMT is a manganese-containing metallic additive that is

blended into some gasolines to increase octane. Gasoline

blended with MMT provides no performance advantage

beyond gasoline of the same octane number without

MMT. Gasoline blended with MMT reduces spark plug life

and reduces emissions system performance in some

vehicles. The manufacturer recommends that gasoline

without MMT be used in your vehicle.

The MMT content of gasoline may not be indicated on the

gasoline pump; therefore, you should ask your gasoline

retailer whether the gasoline contains MMT. MMT is

prohibited in Federal and California reformulated

gasoline.

F

UEL

 S

YSTEM

 C

AUTIONS

NOTE:

Intentional tampering with the emissions control system

can result in civil penalties being assessed against you.

CAUTION!

DO NOT use E-85, gasoline containing methanol, or

gasoline containing more than 15% ethanol (E-15).

Use of these blends may result in starting and

drivability problems, damage critical fuel system

components, cause emissions to exceed the applicable

standard, and/or cause the Malfunction Indicator Light

to illuminate. Please observe pump labels as they

should clearly communicate if a fuel contains greater

than 15% ethanol (E-15).

CAUTION!

Follow these guidelines to maintain your vehicle’s

performance:

The use of leaded gasoline is prohibited by Federal

law. Using leaded gasoline can impair engine perfor

-

mance and damage the emissions control system.

An out-of-tune engine or certain fuel or ignition

malfunctions can cause the catalytic converter to

overheat. If you notice a pungent burning odor or

some light smoke, your engine may be out of tune or

malfunctioning and may require immediate service.

Contact an authorized dealer for service assistance.

The use of fuel additives, which are now being sold

as octane enhancers, is not recommended. Most of

these products contain high concentrations of meth

-

anol. Fuel system damage or vehicle performance

problems resulting from the use of such fuels or addi

-

tives is not the responsibility of the manufacturer

and may void or not be covered under the New

Vehicle Limited Warranty.

CarManuals2.com

TECHNICAL SPECIFICATIONS

271

FLUID CAPACITIES

ENGINE FLUIDS AND LUBRICANTS

US

Metric

Fuel (Approximate)
1.3L Turbo

12.7 gal

48 L

Engine Oil With Filter
1.3L Turbo

4.8 qt

4.5 L

Cooling System *
1.3L Turbo

8.8 qt

8.3 L

* Includes heater and coolant recovery bottle filled to MAX level.

Component

Fluid, Lubricant, or Genuine Part

Engine Coolant

We recommend using Mopar® Antifreeze/Coolant 10 Year/150,000 Mile (240,000 km)

Formula OAT (Organic Additive Technology) or equivalent meeting the requirements of the

manufacturer Material Standard MS.90032.

Engine Oil

We recommend using Mopar® SAE 0W-30 Full Synthetic Engine Oil which meets the

requirements of the manufacturer Material Standard MS-13340. Equivalent full synthetic

SAE 0W-30 engine oil can be used but must have the API Starburst trademark

Ú

page 224.

Fuel Selection

91 Octane (R+M)/2 Recommended, 87 Octane (R+M)/2 Acceptable, 0-15% Ethanol.

9

CarManuals2.com

272

TECHNICAL SPECIFICATIONS



CHASSIS FLUIDS AND LUBRICANTS

Component

Fluid, Lubricant, or Genuine Part

Automatic Transmission

Use only Mopar® ZF 8 & 9 Speed ATF Automatic Transmission Fluid, or equivalent.

Failure to use the correct fluid may affect the function or performance of your

transmission.

Power Transfer Unit (PTU)

We recommend using Mopar® Front Axle/PTU Synthetic Axle Lubricant SAE 75W-90

(API GL-5).

Rear Differential Module (RDM)

We recommend using Mopar® Rear Axle/RDM Synthetic Axle Lubricant SAE 75W-90

(API GL-5).

Brake Master Cylinder

We recommend using Mopar® DOT 4.
DOT 4 brake fluid must be changed every two years regardless of mileage.

CarManuals2.com

273

CUSTOMER ASSISTANCE

SUGGESTIONS FOR OBTAINING SERVICE

FOR YOUR VEHICLE

P

REPARE

 F

OR

 T

HE

 A

PPOINTMENT

All work to be performed may not be covered by the

warranty. Discuss additional charges with the service

manager. Keep a maintenance log of your vehicle's

service history. This can often provide a clue to the current

problem.

P

REPARE

 A L

IST

Make a written list of your vehicle's problems or the

specific work you want done. If you've had an accident or

work done that is not on your maintenance log, let the

service advisor know.

B

E

 R

EASONABLE

 W

ITH

 R

EQUESTS

If you list a number of items and you must have your

vehicle by the end of the day, discuss the situation with the

service advisor and list the items in order of priority.

At many authorized dealers, you may obtain a rental at

vehicle (additional charges may apply). If you need a

rental, it is advisable to make these arrangements when

you call for an appointment.

IF YOU NEED ASSISTANCE

FCA US LLC and its authorized dealers are vitally

interested in your satisfaction. We want you to be happy

with our products and services.
Warranty service must be done by an authorized dealer.

We strongly recommend that you take the vehicle to an

authorized dealer. They know your vehicle the best, and

are most concerned that you get prompt and high quality

service. FCA US LLC's authorized dealers have the

facilities, factory-trained technicians, special tools, and

the latest information to ensure the vehicle is fixed

correctly and in a timely manner.
This is why you should always talk to an authorized

dealer’s service manager first. If for some reason you are

still not satisfied, talk to the general manager or owner of

the authorized dealer. They want to know if you need

assistance. If an authorized dealer is unable to resolve the

concern, you may contact FCA US LLC's Customer

Assistance center.

Any communication to FCA US LLC's customer center

should include the following information:

Owner's name and address

Owner's telephone number (home, mobile and office)

Authorized dealer name

Vehicle Identification Number (VIN)

Vehicle delivery date and mileage

R

OADSIDE

 A

SSISTANCE

Available 24 hours, 7 days a week.
Call 1-888-242-6342 or visit fiat.rsahelp.com (USA)
Call 1-800-363-4869 or visit fca.roadsideaid.com

(Canada)
Who is Covered
You are covered by Roadside Assistance services if you

are a purchaser for use of the vehicle. Roadside

Assistance services last for five years or 60,000 miles on

the odometer, whichever occurs first, calculated from the

start date of the Basic Limited Warranty, as set forth in the
Warranty Information book.

1

1. Towing services provided through Cross Country Motor Club, Inc.
Medford, MA 02155, except in AK,CA, HI, OR, WI, and WY, where services
are provided by Cross Country Motor Club of California, Inc., Thousand
Oaks, CA 91360.

10

CarManuals2.com

274

CUSTOMER ASSISTANCE



What to Do
If your vehicle requires jump start assistance, out of

gas/fuel delivery, tire service, lockout service or towing as

a result of a mechanical breakdown, dial toll-free: USA:

1-888-242-6342/Canada: 1-800-363-4869. Provide your

name, Vehicle Identification Number (VIN) required for

covered services, license plate number, and your location,

including the telephone number from which you are

calling. Briefly describe the nature of the problem and

answer a few simple questions. You will be given the name

of the service provider and an estimated time of arrival. If

you feel you are in an unsafe situation, please let us know.

With your consent, we will contact local police or safety

authorities.
If Unable to Contact Roadside Assistance
If you are unable to contact Roadside Assistance or

unable to provide a valid Vehicle Identification Number

(VIN), and you obtain towing services on your own, you may

submit your original receipts from the licensed towing or

service facility, for services rendered within 30 days of the

occurrence. Be sure to include your VIN, odometer

mileage at the time of service, and current mailing

address. We will process the claim based on vehicle and

service eligibility. If eligible, we will reimburse you for the

reasonable amount actually paid, based on the usual and

customary charges for that service in the area where they

were provided. FCA US LLC’s determination relating to

reimbursement is final. Correspondence should be

mailed to:
FCA US LLC Customer Assistance
P.O. Box 9145
Medford, MA 02155

Attention Claims Department
FCA US LLC reserves the right to modify the terms or

discontinue the Roadside Assistance Program at any time.

The Roadside Assistance program is subject to restrictions

and conditions of use, which are determined solely by

FCA US LLC.
Flat Tire Service
If you are inconvenienced by a flat tire, we will dispatch a

service provider to use your vehicle’s temporary spare tire

(if equipped) as recommended in your Owner’s Manual.

This is not a permanent flat tire repair.
Out of Gas/Fuel Delivery
Drivers cannot always count on a gas station being

nearby, especially when traveling away from home. We will

dispatch a service provider to deliver a small amount of

fuel (maximum two gallons) to get you to a nearby station.

This service is limited to two occurrences in a 12-month

period.
Battery Jump Assistance
No time is a good time for a depleted battery. With

Roadside Assistance, you do not have to worry about

being stranded. We will dispatch a service provider to

provide you with a battery jump anytime, day or night.
Lockout Service
Whether the keys are locked in your vehicle or frozen locks

are keeping you from getting on your way, help is just a

phone call away. This service is limited to providing access

to the vehicle’s seating area. It does not cover the cost of

replacement keys.

Towing Service
Our towing service gives you peace of mind and

confidence. If your vehicle becomes disabled as a result of

a mechanical breakdown, Roadside Assistance will

dispatch a towing service to transport your vehicle to the

closest authorized FIAT® dealer. If you choose to go to

another dealer, you will be responsible for the cost if the

extra distance exceeds 10 miles.

FCA US LLC C

USTOMER

 C

ENTER

P.O. Box 21–8004
Auburn Hills, MI 48321–8004
Phone: (888) 242-6342

FCA C

ANADA

 I

NC

. C

USTOMER

 C

ENTER

P.O. Box 1621
Windsor, Ontario N9A 4H6
Phone: (800) 465-2001 English / (800) 387-9983 French

M

EXICO

Av. Prolongacion Paseo de la Reforma, 1240
Sante Fe C.P. 05109
Mexico, D.F.
In Mexico City: 800-505-1300
Outside Mexico City: +(52)55 50817568

CarManuals2.com

CUSTOMER ASSISTANCE

275

P

UERTO

 R

ICO

 A

ND

 U.S. V

IRGIN



I

SLANDS

FCA Caribbean LLC
P.O. Box 191857
San Juan 00919-1857
Phone: (888) 242-6342
Fax: (787) 782-3345

C

USTOMER

 A

SSISTANCE

 F

OR

 T

HE



H

EARING

 O

R

 S

PEECH

 I

MPAIRED

(TDD/TTY)

To assist customers who have hearing difficulties,

FCA US LLC has installed special TDD (Telecommunication

Devices for the Deaf) equipment at its customer center.

Any hearing or speech impaired customer, who has access

to a TDD or a conventional teletypewriter (TTY) in the

United States, can communicate with FCA US LLC by

dialing 1-800-380-2479.
Canadian residents with hearing difficulties that require

assistance can use the special needs relay service offered

by Bell Canada. For TTY teletypewriter users, dial 711 and

for Voice callers, dial 1-800-855-0511 to connect with a

Bell Relay Service operator.

S

ERVICE

 C

ONTRACT



You may have purchased a service contract for a vehicle

to help protect you from the high cost of unexpected

repairs after FCA US LLC's New Vehicle Limited Warranty

expires. The Mopar® Vehicle Protection plans are the

ONLY vehicle extended protection plans authorized,

endorsed and backed by FCA US LLC to provide additional

protection beyond your vehicle’s warranty. If you

purchased a Mopar® Vehicle Protection Plan, you will

receive Plan Provisions and an Owner Identification Card

in the mail within three weeks of the vehicle delivery date.

If you have any questions about the service contract, call

the FCA US LLC’s Service Contract National Customer

Hotline at 1-800-521-9922 (Canadian residents, call

(800) 465-2001 English / (800) 387-9983 French).
FCA US LLC is not responsible for any service contract you

may have purchased from another manufacturer. If you

require service after the FCA US LLC New Vehicle Limited

Warranty expires, please refer to the contract documents,

and contact the person listed in those documents.
We appreciate that you have made a major investment

when you purchased the vehicle. An authorized dealer has

also made a major investment in facilities, tools, and

training to assure that you are absolutely delighted with

the ownership experience.

WARRANTY INFORMATION

See the Warranty Information for the terms and provisions

of FCA US LLC warranties applicable to this vehicle and

market. Refer to www.mopar.com/om for further

information.
See the Warranty Information for the terms and provisions

of FCA Canada Inc. warranties applicable to this vehicle

and market. Refer to www.owners.mopar.ca/en for further

information.
Use this QR code to access your digital

experience.

WARNING!

Engine exhaust (internal combustion engines only),

some of its constituents, and certain vehicle

components contain, or emit, chemicals known to the

State of California to cause cancer and birth defects, or

other reproductive harm. In addition, certain fluids

contained in vehicles and certain products of

component wear contain, or emit, chemicals known to

the State of California to cause cancer and birth

defects, or other reproductive harm.

10

CarManuals2.com

276

CUSTOMER ASSISTANCE



MOPAR® PARTS

Mopar® original equipment parts & accessories and

factory filled fluids are available from an authorized

dealer. They are recommended for your vehicle to keep it

operating at its best and maintain its original condition.

REPORTING SAFETY DEFECTS

I

N

 T

HE

 50 U

NITED

 S

TATES

 A

ND



W

ASHINGTON

, D.C.

If you believe that your vehicle has a

defect that could cause a crash or cause

injury or death, you should immediately

inform the National Highway Traffic

Safety Administration (NHTSA) in

addition to notifying FCA US LLC.

If NHTSA receives similar complaints, it

may open an investigation, and if it finds

that a safety defect exists in a group of

vehicles, it may order a recall and

remedy campaign. However, NHTSA

cannot become involved in individual

problems between you, an authorized

dealer or FCA US LLC.
To contact NHTSA, you may call the

Vehicle Safety Hotline toll free at

1-888-327-4236

(TTY: 1-800-424-9153); or go to

http://www.safercar.gov; or write to:

Administrator, NHTSA, 1200 New Jersey

Avenue, SE., West Building, Washington,

D.C. 20590. You can also obtain other

information about motor vehicle safety

from http://www.safercar.gov.

I

N

 C

ANADA

If you believe that your vehicle has a

safety defect, you should contact the

Customer Service Department

immediately.

Canadian customers who wish to report

a safety defect to the Canadian

government should contact Transport

Canada, Motor Vehicle Defect

Investigations and Recalls at

1-800-333-0510 or go to

wwwapps.tc.gc.ca/Saf-Sec-Sur/7/

PCDB-BDPP.

PUBLICATION ORDER FORMS

To order the following manuals, you may use either the

website or the phone numbers listed below.
Service Manuals
These comprehensive Service Manuals provide a

complete working knowledge of the vehicle, system,

and/or components and is written in straightforward

language with illustrations, diagrams, and charts.
Diagnostic Procedure Manuals
Diagnostic Procedure Manuals are filled with diagrams,

charts and detailed illustrations. These manuals make it

easy to find and fix problems on computer-controlled

vehicle systems and features. They show exactly how to

find and correct problems, using step-by-step

troubleshooting and drivability procedures, proven

diagnostic tests and a complete list of all tools and

equipment.

CarManuals2.com

CUSTOMER ASSISTANCE

277

To order a hard copy of your Service or Diagnostic

Procedure manuals, visit:
www.techauthority.com (US and Canada).
Owner's Manuals
These Owner's Manuals have been prepared with the

assistance of service and engineering specialists to

acquaint you with specific FCA vehicles.
To access your Owner's Information online, visit

www.mopar.com/om (US) or www.owners.mopar.ca

(Canada).
Or
Call Tech Authority toll free at:

1-800-890-4038 (US)

Owner's Manuals, Radio Manuals and Warranty

Information Books can be ordered through Archway at:

1-800-387-1143 (Canada)

GENERAL INFORMATION

RADIO
The following regulatory statement applies to RADIO

devices equipped in this vehicle:
FCC ID: Y70VP2RFP
IC: 7812H-VP2RFP
This device complies with Part 15 of the FCC Rules and

with Innovation, Science and Economic Development

Canada license-exempt RSS standard(s). Operation is

subject to the following two conditions:

1. This device may not cause harmful interference, and
2. This device must accept any interference received,

including interference that may cause undesired

operation.

Le présent appareil est conforme aux CNR d`Innovation,

Science and Economic Development applicables aux

appareils radio exempts de licence. L'exploitation est

autorisée aux deux conditions suivantes:
1. l'appareil ne doit pas produire de brouillage, et
2. l'utilisateur de l'appareil doit accepter tout brouillage

radioélectrique subi, même si le brouillage est

susceptible d'en compromettre le fonctionnement.

La operación de este equipo está sujeta a las siguientes

dos condiciones:
1. es posible que este equipo o dispositivo no cause

interferencia perjudicial y

2. este equipo o dispositivo debe aceptar cualquier

interferencia, incluyendo la que pueda causar su

operación no deseada.

RF Exposure Requirements
To comply with FCC RF exposure compliance

requirements, the device must be installed and operated

to provide a separation distance of at least 20 cm from all

persons.
This equipment complies with Canada radiation exposure

limits set forth for an uncontrolled environment.

This equipment should be installed and operated with

minimum distance 20 cm between the radiator and

your body.

Déclaration d’exposition aux radiations
Cet équipement est conforme aux limites d’exposition aux

rayonnements ISED établies pour un environnement non

contrôlé. Cet équipement doit être installé et utilisé avec

un minimum de 20 cm de distance entre la source de

rayonnement et votre corps

NOTE:

Changes or modifications not expressly approved by the

party responsible for compliance could void the user’s

authority to operate the equipment.

NOTE:

Remarque: Les changements ou modifications non

expressément approuvés par la partie responsable de la

conformité peuvent annuler l'autorisation de l'utilisateur à

utiliser l'équipement.
Front Radar for USA
FCC ID: NF3-MRREVO14F
This device complies with Part 15 of the FCC Rules

Operation is subject to the following two conditions: this

device may not cause harmful interference, and this

device must accept any interference received, including

interference that may cause undesired operation.

Changes or modifications made to this equipment not

expressly approved by Robert BOSCH GmbH may void the

FCC authorization to operate this equipment. This

equipment has been tested and found to comply with the

limits for a Class A digital device, pursuant to Part 15 of

the FCC Rules.

10

CarManuals2.com

278

CUSTOMER ASSISTANCE



These limits are designed to provide reasonable

protection against harmful interference when the

equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in

accordance with the instruction manual, may cause

harmful interference to radio communications. Operation

of this equipment in a residential area is likely to cause

harmful interference in which case the user will be

required to correct the interference at his own expense.
Front Radar for Canada
IC: 3887A-MRREVO14F
This device complies with Industry Canada license-exempt

RSS standard(s). Operation is subject to the following two

conditions: (1) this device must not cause interference,

and (2) this device must accept any interference, including

interference that may cause undesired operation of the

device. Le présent appareil est conforme aux CNR

d'Industrie Canada applicables aux appareils radio

exempts de licence. L'exploitation est autorisée aux deux

conditions suivantes: (1) l'appareil ne doit pas produire de

brouillage, et (2) l'utilisateur de l'appareil doit accepter

tout brouillage radioélectrique subi, même si le brouillage

est susceptible d'en compromettre le fonctionnement.

Radiofrequency Radiation Exposure Information
This equipment complies with FCC and IC radiation

exposure limits set forth for an uncontrolled environment.

This equipment should be installed and operated with a

minimum distance of 20 cm between the radiator and

your body. This transmitter must not be co-located or

operating in conjunction with any other antenna or

transmitter.
Cet équipement est conforme aux limites d'exposition aux

rayonnements IC établies pour un environnement non

contrôlé. Cet équipement doit être installé et utilisé avec

un minimum de 20 cm de distance entre la source de

rayonnement et votre corps. Ce transmetteur ne doit pas

être place au même endroit ou utilise simultanément avec

un autre transmetteur ou antenne.
BSM System for Canada:
This device contains license-exempt transmitter(s)/

receiver(s) that comply with Innovation, Science, and

Economic Development Canada’s license-exempt RSS(s).

Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including

interference that may cause undesired operation of

the device.

L’é

?

metteur/ré

?

cepteur exempt de licence contenu dans le

pré

?

sent appareil est conforme aux CNR d’Innovation,

Sciences et Dé

?

veloppement é

?

conomique Canada

applicables aux appareils radio exempts de licence.

L’exploitation est autorisé

?

e aux deux conditions

suivantes:
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioé

?

lec

-

trique subi, mê

?

me si le brouillage est susceptible

d’en compromettre le fonctionnement.

BSM System for USA:
This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:
1. this device may not cause harmful interference, and
2. this device must accept any interference received,

including interference that may cause undesired

operation.

CAUTION TO USERS: Changes or modifications not

expressly approved by the party responsible for

compliance could void theuser’s authority to operate the

equipment.

CarManuals2.com

CUSTOMER ASSISTANCE

279

S180227006 (Keyfob)
FCC ID: M3N40821302
IC: 7812A-40821302
IFETEL: RLVCOS116-1005
S180222004 (RFHM)
FCC ID: M3N32296000
IC: 7812A-32296000
IFETEL: RLVCOS116-1003
A2C91227100 (KIN)
FCC ID:KR5A2C91227100
IC: 7812D-91227100
IFETEL: RLVCOA216-0991
This device complies with Part 15 of the FCC Rules and

with Innovation, Science and Economic Development

Canada license-exempt RSS standard(s). Operation is

subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,

including interference that may cause undesired

operation.

Le présent appareil est conforme aux CNR d`Innovation,

Science and Economic Development applicables aux

appareils radio exempts de licence. L'exploitation est

autorisée aux deux conditions suivantes:
1. l'appareil ne doit pas produire de brouillage, et
2. l'utilisateur de l'appareil doit accepter tout brouillage

radioélectrique subi, même si le brouillage est

susceptible d'en compromettre le fonctionnement.

La operación de este equipo está sujeta a las siguientes

dos condiciones:
1. es posible que este equipo o dispositivo no cause

interferencia perjudicial y

2. este equipo o dispositivo debe aceptar cualquier

interferencia, incluyendo la que pueda causar su

operación no deseada.

CAUTION TO USERS
Changes or modifications not expressly approved by the

party responsible for compliance could void the user’s

authority to operate the equipment.

CHANGE OF OWNERSHIP OR ADDRESS

*If you have purchased this vehicle used or have changed

your address, please provide the following information

and mail to:
FCA US LLC
P.O. Box 21–8008
Auburn Hills, MI 48321–8004
Make sure to include the following:

Date of Sale (mm/dd/yy)

Vehicle Indentification Number (17 Character ID

located on top left of the instrument panel)

Exact Odometer Reading

First and Last Name

Phone Number

Street Address, City, State and Zip Code

Email Address

*Applies to US residents only.

10

CarManuals2.com

280

INDEX

A

About Your Brakes ....................................................... 268

Adaptive Cruise Control (ACC) (Cruise Control).............80

Adding Engine Coolant (Antifreeze) ............................ 229

Adding Fuel......................................................................96

Adding Washing Fluid .................................................. 223

Additives, Fuel .............................................................. 269

Advance Phone Connectivity....................................... 143

Air Bag........................................................................... 178

Air Bag Operation.................................................... 179

Driver Knee Air Bag ................................................ 179

Enhanced Accident Response ......................182

215

Event Data Recorder (EDR).................................... 215

Front Air Bag ........................................................... 178

If Deployment Occurs ............................................. 182

Knee Impact Bolsters............................................. 179

Maintaining Your Air Bag System .......................... 185

Maintenance........................................................... 185

Redundant Air Bag Warning Light ......................... 177

Side Air Bags........................................................... 179

Transporting Pets.................................................... 196

Air Bag Light ................................................................. 197

Air Cleaner, Engine (Engine Air Cleaner Filter)........... 225

Air Conditioner Maintenance ...................................... 226

Air Conditioner Refrigerant.......................................... 226

Air Conditioner System ................................................ 226

Air Conditioning ...............................................................36

Air Conditioning Filter ........................................... 40

226

Air Conditioning, Operating Tips ....................................40

Air Filter .........................................................................225

Air Pressure

Tires..........................................................................257

Alarm

Arm The System.........................................................18

Disarm The System ...................................................18

Security Alarm..................................................... 18

60

All Wheel Drive (AWD).....................................................76

Alterations/Modifications

Vehicle.......................................................................... 7

Android Auto........................................................ 145

,

146

Android Auto™



b

 ......................................................145

Antifreeze (Engine Coolant) ............................... 229

,

271

Disposal ...................................................................230

Anti-Lock Brake System (ABS) .....................................158

Anti-Lock Warning Light..................................................61

Apple CarPlay ...................................................... 145

,

148

Apple CarPlay®

b

......................................................147

Assist, Hill Start.............................................................161

Audio Settings...............................................................132

Audio Systems (Radio) .................................................106

Auto Down Power Windows............................................45

Auto Up Power Windows ................................................45

Automatic Climate Controls ...........................................35

Automatic Door Locks ....................................................21

Automatic Headlights .....................................................30

Automatic High Beams...................................................30

Automatic Temperature Control (ATC) ..........................40

Automatic Transmission ....................................... 72

,

232

Adding Fluid....................................................232

,

272

Fluid And Filter Change...........................................232

Fluid Change ...........................................................232

Fluid Level Check.................................................... 232

Fluid Type .......................................................232

,

272

Special Additives..................................................... 232

Axle Fluid....................................................................... 272

Axle Lubrication............................................................ 272

B

Battery.................................................................... 59

,

223

Charging System Light.............................................. 59

Keyless Key Fob Replacement................................. 13

Belts, Seat..................................................................... 197

Blind Spot Monitoring ..................................................162

Bluetooth

Connecting To A Particular Mobile Phone

Or Audio Device After Pairing ............................ 139

Body Mechanism Lubrication...................................... 226

B-Pillar Location ...........................................................254

Brake Assist System..................................................... 159

Brake Control System, Electronic................................159

Brake Fluid....................................................................272

Brake System ......................................................231

,

268

Anti-Lock (ABS)........................................................268

Fluid Check.............................................................. 272

Master Cylinder.......................................................231

Warning Light ............................................................ 58

Brightness, Interior Lights.............................................. 32

Bulbs, Light...................................................................198

CarManuals2.com

281

C

Camera, Rear ..................................................................95

Capacities, Fluid........................................................... 271

Caps, Filler

Oil (Engine).............................................................. 222

Radiator (Coolant Pressure)................................... 230

Car Washes .................................................................. 266

Carbon Monoxide Warning.......................................... 199

Cargo Compartment .......................................................50

CD.................................................................................. 134

Cellular Phone.............................................................. 157

Certification Label...........................................................96

Chains, Tire................................................................... 263

Chart, Tire Sizing .......................................................... 251

Check Engine Light (Malfunction Indicator Light).........67

Checking Your Vehicle For Safety ............................... 196

Checks, Safety.............................................................. 196

Child Restraint.............................................................. 185

Child Restraints

Booster Seats.......................................................... 188

Child Seat Installation ............................................ 195

How To Stow An unused ALR Seat Belt................. 192

Infant And Child Restraints .................................... 187

LATCH Positions...................................................... 189

Locating The LATCH Anchorages........................... 191

Lower Anchors And Tethers For Children.............. 189

Older Children And Child Restraints...................... 187

Seating Positions .................................................... 188

Cigar Lighter ....................................................................44

Clean Air Gasoline........................................................ 269

Cleaning

Wheels..................................................................... 262

Climate Control ...............................................................35

Clutch ............................................................................231

Fluid..........................................................................231

Cold Weather Operation.................................................68

Compact Spare Tire......................................................261

Console............................................................................42

Floor ...........................................................................42

Contract, Service ..........................................................275

Controls .........................................................................126

Cooling Pressure Cap (Radiator Cap)..........................230

Cooling System .............................................................228

Adding Coolant (Antifreeze) ....................................229

Coolant Level...........................................................230

Cooling Capacity ......................................................271

Disposal Of Used Coolant .......................................230

Drain, Flush, And Refill............................................229

Inspection ...................................................... 229

,

230

Points To Remember...............................................230

Pressure Cap ...........................................................230

Radiator Cap............................................................230

Selection Of Coolant (Antifreeze) ................. 229

,

271

Corrosion Protection.....................................................265

Cruise Control (Speed Control) ......................................79

Cruise Light ..............................................................64

65

Customer Assistance....................................................273

Customer Programmable Features .............................106

Cybersecurity ................................................................106

D

Daytime Running Lights .................................................30

Defroster, Rear Window .................................................35

Defroster, Windshield...................................................197

De-Icer, Remote Start.....................................................17

Deleting A Phone ..........................................................140

Description

b

.............................................................204

Diagnostic System, Onboard ......................................... 66

Dimmer Switch

Headlight ................................................................... 30

Dipsticks

Oil (Engine) .............................................................. 223

Disabled Vehicle Towing.............................................. 213

Disc Drive...................................................................... 134

Disconnecting...............................................................140

Disposal

Antifreeze (Engine Coolant).................................... 230

Disturb...........................................................................142

Door Ajar ......................................................................... 59

Door Ajar Light................................................................ 59

Door Locks

Automatic .................................................................. 21

Dead Lock Device ..................................................... 21

Remote Keyless Entry............................................... 19

Drag & Drop..................................................................124

Driver Memory Presets ................................................131

Driver’s Seat Back Tilt.................................................... 23

Driving

Through Flowing, Rising, Or Shallow

Standing Water ..................................................104

Dynamic Selector ........................................................... 76

E

Electric Brake Control System..................................... 159

Anti-Lock Brake System..........................................158

Traction Control System .........................................162

Electric Park Brake......................................................... 70

Electric Parking Brake.................................................... 70

Electrical Outlet, Auxiliary (Power Outlet) ..................... 44

Electrical Power Outlets................................................. 44

Electronic Stability Control (ESC) ................................160

11

CarManuals2.com

282



Electronic Throttle Control Warning Light......................60

Emergency Refueling................................................... 210

Emergency, In Case Of

Hazard Warning Flasher......................................... 200

Jacking..................................................................... 200

Jump Starting.......................................................... 208

Overheating............................................................. 211

Towing ..................................................................... 213

Emission Control System Maintenance.........................67

Engine........................................................................... 222

Air Cleaner............................................................... 225

Break-In Recommendations .....................................69

Checking Oil Level .................................................. 223

Compartment.......................................................... 222

Coolant (Antifreeze)................................................ 271

Cooling..................................................................... 228

Exhaust Gas Caution .............................................. 199

Fails To Start ..............................................................69

Flooded, Starting .......................................................69

Jump Starting.......................................................... 208

Oil....................................................................224

271

Oil Filler Cap ............................................................ 222

Oil Filter ................................................................... 225

Oil Selection ...................................................224

271

Overheating............................................................. 211

Starting.......................................................................68

Engine Oil Change Reset — If Equipped

b

..................54

Enhanced Accident Response Feature .............182

215

Ethanol.......................................................................... 270

Exhaust Gas Cautions.................................................. 199

Exhaust System...................................................199

228

Exterior Lighting ..............................................................29

Exterior Lights........................................................ 29

198

F

Filters

Air Cleaner ...............................................................225

Air Conditioning ................................................40

,

226

Engine Oil.................................................................225

Engine Oil Disposal..................................................224

Flashers

Hazard Warning.......................................................200

Turn Signals...............................................31

65

,

198

Flash-To-Pass..................................................................30

Flooded Engine Starting.................................................69

Floor Console ..................................................................42

Fluid Capacities ............................................................271

Fluid Leaks....................................................................198

Fluid Level Checks

Engine Oil.................................................................223

Fluid, Brake...................................................................272

Fog Lights........................................................................31

Folding Rear Seats .........................................................23

Freeing A Stuck Vehicle................................................212

Front And Rear Park Assist System...............................87

Fuel................................................................................269

Adding ........................................................................96

Additives...................................................................269

Clean Air...................................................................269

Ethanol.....................................................................270

Gasoline ...................................................................269

Gauge.........................................................................62

Materials Added ......................................................269

Methanol..................................................................270

Octane Rating................................................ 269

,

271

Specifications ..........................................................271

Tank Capacity ..........................................................271

Full Brake Control System ...........................................165

Fuses............................................................................. 233

G

Gasoline, (Fuel) ............................................................ 269

Gasoline, Clean Air .......................................................269

Gasoline, Reformulated...............................................269

Gauges

Fuel ............................................................................ 62

Gear Selector Override.................................................211

Glass Cleaning.............................................................. 267

Glove Compartment Storage......................................... 42

Gross Axle Weight Rating........................................ 97

98

GVWR .............................................................................. 96

H

Hazard

Driving Through Flowing, Rising, Or

Shallow Standing Water .................................... 104

Hazard Warning Flashers............................................. 200

Head Restraints.............................................................. 25

Headlights

Automatic .................................................................. 30

Cleaning...................................................................266

Delay .......................................................................... 30

High Beam/Low Beam Select Switch ...................... 30

Lights On Reminder .................................................. 30

Passing ...................................................................... 30

Switch ........................................................................ 29

Time Delay................................................................. 30

Heated Mirrors ............................................................... 29

Heated Seats.................................................................. 25

High Beam/Low Beam Select (Dimmer) Switch........... 30

Hill Start Assist ............................................................. 161

CarManuals2.com

283

Hitches

Trailer Towing.............................................................99

Hood Prop........................................................................48

Hood Release..................................................................48

I

Ignition.............................................................................15

Switch.........................................................................15

Instrument Cluster ..........................................................52

Display........................................................................53

Instrument Cluster

b

...................................................52

Instrument Panel Lens Cleaning................................. 267

Interior Appearance Care ............................................ 266

Interior Lights ..................................................................32

Intermittent Wipers (Delay Wipers)................................33

iPod/USB/MP3 Control ..................................................43

J

Jack Location................................................................ 201

Jack Operation ............................................................. 202

Jacking And Tire Changing ¹........................................ 200

Jacking Instructions ..................................................... 202

Jump Starting ............................................................... 208

K

Key Fob

Arm The Alarm............................................................18

Disarm The Alarm ......................................................18

Keyless Entry..............................................................20

Remote Keyless Entry ...............................................12

Key Fob Battery Service (Remote Keyless Entry) .........13

Keyless Enter 'n Go™

Enter The Trunk .........................................................20

Lock The Vehicle’s Doors ................................ 20

116

Passive Entry .............................................................20

Passive Entry Programming......................................20

Remote Control..........................................................20

Unlock From The Driver’s Side .................................20

Unlock From The Passenger’s Side..........................20

Keyless Entry...................................................................12

Keys .................................................................................12

Replacement .............................................................14

L

Lane Change And Turn Signals......................................31

Lane Change Assist ........................................................31

LaneSense ......................................................................92

Lap/Shoulder Belts ......................................................172

Latches..........................................................................198

Hood...........................................................................48

Leaks, Fluid...................................................................198

Life Of Tires ...................................................................259

Liftgate ............................................................................49

Closing........................................................................50

Opening......................................................................49

Liftgate Window Wiper/Washer.....................................35

Light Bulbs ....................................................................198

Lighter

Cigar ...........................................................................44

Lights .............................................................................198

Adaptive Cruise Control ............................................60

Air Bag......................................................................197

Audio System.............................................................61

Automatic Headlights................................................30

Brake Warning...........................................................58

Coolant Temperature ................................................59

Cruise ..................................................................64

65

Daytime Running.......................................................30

Dimmer Switch, Headlight........................................ 30

Drive Mode ................................................................ 61

Electric Power Steering............................................. 60

Electronic Park Brake ............................................... 61

Electronic Stability Control ....................................... 61

Exterior.............................................................. 29

,

198

Exterior Bulb.............................................................. 64

External Light............................................................. 61

Fog ...................................................................... 31

64

Fuel Cutoff.......................................................... 62

64

Fuel Level .................................................................. 62

Full Brake Control ..................................................... 64

Hazard Warning Flasher .........................................200

Headlight Switch ....................................................... 29

Headlights.................................................................. 29

Headlights On Reminder .......................................... 30

High Beam.......................................................... 30

65

Hood Open................................................................. 60

Icy Road Condition .................................................... 64

Immobilizer Fail......................................................... 64

Instrument Cluster .................................................... 29

Intensity Control........................................................ 32

Interior ....................................................................... 32

LaneSense................................................... 62

64

65

Light Sensor .............................................................. 65

Lights On Reminder .................................................. 30

Loose Fuel Filler Cap ................................................ 62

Malfunction Indicator (Check Engine) ..................... 62

Park............................................................................ 64

Passing ...................................................................... 30

Seat Belt Reminder................................................... 60

Security Alarm ........................................................... 60

Service ....................................................................... 62

Service LaneSense ................................................... 62

Service Stop Start ..................................................... 63

11

CarManuals2.com

284



Speed .........................................................................65

StopStart Active .........................................................65

Tire Pressure Monitoring (TPMS)........................... 169

Transmission Fault ....................................................60

Transmission Temperature.......................................63

Trunk Open.................................................................60

Turn Signals .............................................. 31

,

65

198

Vanity Mirror...............................................................28

Loading Vehicle...............................................................96

Tires......................................................................... 254

Locks

Automatic Door..........................................................19

Child Protection .........................................................21

Low Tire Pressure System ........................................... 169

Lubrication, Body ......................................................... 226

Lug Nuts/Bolts ............................................................. 268

M

Maintenance Free Battery........................................... 223

Maintenance Schedule................................................ 216

Malfunction Indicator Light (Check Engine) ..................62

Manual

Service..................................................................... 276

Manual Climate Controls................................................38

Master Cylinder

Brakes ..................................................................... 231

Media Mode ................................................................. 134

Methanol ...................................................................... 270

Mirrors .............................................................................28

Heated........................................................................29

Outside .......................................................................28

Vanity..........................................................................28

Modifications/Alterations

Vehicle..........................................................................7

Monitor, Tire Pressure System.....................................169

Mopar Parts ..................................................................276

MP3 Control ....................................................................43

N

New Vehicle Break-In Period..........................................69

O

Occupant Restraints.....................................................171

Octane Rating, Gasoline (Fuel) .......................... 269

,

271

Oil Change Indicator .......................................................54

Reset..........................................................................54

Oil Filter, Change ..........................................................225

Oil Filter, Selection........................................................225

Oil Pressure Light............................................................ 60

Oil, Engine ........................................................... 224

,

271

Capacity ...................................................................271

Checking ..................................................................223

Dipstick ....................................................................223

Disposal ...................................................................224

Filter .........................................................................225

Filter Disposal..........................................................224

Identification Logo...................................................224

Materials Added To .................................................224

Pressure Warning Light.............................................60

Recommendation.......................................... 224

,

271

Viscosity ...................................................................271

Onboard Diagnostic System...........................................66

Operating Precautions....................................................66

Operator Manual

Owner's Manual.......................................................276

Outside Rearview Mirrors...............................................28

Overheating, Engine .....................................................211

P

Paint Care ..................................................................... 265

Pair (Link) Uconnect Phone To A

Mobile Phone

b

.........................................................138

Park Assist ...................................................................... 87

Park Assist System, Front And Rear.............................. 87

Parking Brake ................................................................. 70

Personalized Main Menu Bar ...................................... 124

Pets ............................................................................... 196

Phone Mode .................................................................136

Placard, Tire And Loading Information .......................254

Power

Brakes...................................................................... 268

Mirrors ....................................................................... 29

Steering ..................................................................... 77

Power Folding Roof ........................................................ 46

Pregnant Women And Seat Belts................................175

Preparation For Jacking ...............................................201

Presets ..........................................................................131

R

Radial Ply Tires ............................................................. 258

Radiator Cap (Coolant Pressure Cap) .........................230

Radio

Presets..................................................................... 131

Radio Controls .............................................................. 126

Radio Mode ..................................................................126

Radio Operation ..................................................126

,

157

Radio Remote Controls................................................125

Rain Sensitive Wiper System......................................... 34

Rear Camera................................................................... 95

Rear Cross Path............................................................ 164

Rear Seats, Folding ........................................................ 23

Rear Window Defroster.................................................. 35

CarManuals2.com

285

Rear Wiper/Washer ........................................................35

Recreational Towing .................................................... 103

Reformulated Gasoline................................................ 269

Refrigerant.................................................................... 226

Release, Hood.................................................................48

Reminder, Lights On .......................................................30

Reminder, Seat Belt..................................................... 172

Remote Control

Starting System..........................................................16

Remote Keyless Entry.....................................................12

Arm The Alarm............................................................18

Disarm The Alarm ......................................................18

Remote Sound System (Radio) Control...................... 125

Remote Starting

Uconnect Customer Programmable Features .........17

Uconnect Settings......................................................17

Remote Starting System.................................................16

Replacement Keys..........................................................14

Replacement Tires....................................................... 259

Reporting Safety Defects............................................. 276

Restraints, Child........................................................... 185

Restraints, Head .............................................................25

Roll Over Warning ............................................................. 7

Rotation, Tires .............................................................. 264

S

Safety............................................................................ 125

Safety Checks Inside Vehicle ...................................... 197

Safety Checks Outside Vehicle ................................... 198

Safety Defects, Reporting............................................ 276

Safety Features............................................................ 125

Safety Information, Tire ............................................... 250

Safety Tips.................................................................... 196

Safety, Exhaust Gas..................................................... 199

Satellite Radio...............................................................127

Saved Radio Stations ...................................................131

Schedule, Maintenance ...............................................216

Seat Belt Reminder ........................................................60

Seat Belts............................................................ 171

,

197

Adjustable Shoulder Belt ........................................175

Adjustable Upper Shoulder Anchorage..................175

Adjustable Upper Shoulder Belt Anchorage ..........175

Automatic Locking Retractor (ALR) ........................176

Child Restraints .......................................................185

Front Seat ............................................. 171

172

,

174

Inspection ................................................................197

Lap/Shoulder Belt Operation .................................174

Lap/Shoulder Belt Untwisting ................................174

Lap/Shoulder Belts .................................................172

Operating Instructions.............................................174

Pregnant Women.....................................................175

Rear Seat .................................................................172

Reminder .................................................................172

Untwisting Procedure..............................................174

Seat Belts Maintenance...............................................267

Seats................................................................................23

Adjustment.................................................................23

Heated........................................................................25

Rear Folding...............................................................23

Seatback Release .....................................................23

Tilting..........................................................................23

Security Alarm..........................................................18

60

Arm The System.........................................................18

Disarm The System ...................................................18

Selection Of Coolant (Antifreeze).................................271

Semi-Auto Kit ................................................................204

Sentry Key Replacement................................................14

Service Assistance........................................................273

Service Contract ...........................................................275

Service Manuals...........................................................276

Settings .........................................................................106

Personal...................................................................106

Settings, Audio.............................................................. 132

Shift Lever Override...................................................... 211

Shoulder Belts .............................................................. 172

Signals, Turn................................................... 31

65

,

198

Sirius Satellite Radio.................................................... 127

Favorites..................................................................130

Replay ...................................................................... 129

SiriusXM Satellite Radio

Browse in SXM ........................................................130

Favorites..................................................................130

Replay ...................................................................... 129

Snow Chains (Tire Chains)...........................................263

Snow Tires ....................................................................260

Spare Tires................................................. 260

261

,

262

Specifications

Fuel (Gasoline) ........................................................271

Oil ............................................................................. 271

Speed Control

Distance Setting (ACC Only) ..................................... 80

Mode Setting (ACC Only)........................................... 80

Resume...................................................................... 80

Starting............................................................................ 68

Button ........................................................................ 15

Cold Weather............................................................. 68

Engine Fails To Start................................................. 69

Remote ...................................................................... 16

Starting And Operating................................................... 68

Starting Procedures ....................................................... 68

Steering

Tilt Column................................................................. 22

Wheel, Heated........................................................... 22

Wheel, Tilt.................................................................. 22

11

CarManuals2.com

286



Steering Wheel Audio Controls ................................... 125

Steering Wheel Mounted Sound System.................... 125

Stop/Start........................................................................77

Storage ............................................................................42

Storage, Vehicle ..............................................................40

Store Radio Presets ..................................................... 131

Storing Your Vehicle..................................................... 265

Stuck, Freeing .............................................................. 212

Sun Visor Extension ........................................................28

Supplemental Restraint System – Air Bag ................. 178

Sway Control, Trailer.......................................................98

System, Remote Starting................................................16

T

Telescoping Steering Column ........................................22

Temperature Control, Automatic (ATC)..........................40

Tilt Steering Column .......................................................22

Time Delay

Headlight ....................................................................30

Tip Start ...........................................................................68

Tire And Loading Information Placard ........................ 254

Tire Markings................................................................ 250

Tire Pressure Monitoring System (TPMS)

b

............ 169

Tire Safety Information ................................................ 250

Tire Service Kit ............................................................. 204

Tires ......................................... 198

,

257

,

260

261

,

264

Aging (Life Of Tires) .................................................259

Air Pressure..............................................................257

Chains ......................................................................263

Changing..................................................................200

Compact Spare........................................................261

General Information............................. 257

260

,

261

High Speed ..............................................................258

Inflation Pressure ....................................................257

Life Of Tires..............................................................259

Load Capacity ..........................................................254

Pressure Monitoring System (TPMS) ..............63

,

169

Quality Grading........................................................264

Radial .......................................................................258

Replacement ...........................................................259

Rotation....................................................................264

Safety ............................................................. 250

,

257

Sizes.........................................................................251

Snow Tires................................................................260

Spare Tires............................................ 260

261

,

262

Spinning ...................................................................258

Trailer Towing ..........................................................101

Tread Wear Indicators.............................................259

Wheel Nut Torque....................................................268

To Open Hood .................................................................48

Tongue Weight/Trailer Weight..................................... 100

Towing ............................................................................. 97

Disabled Vehicle...................................................... 213

Guide.......................................................................... 99

Recreational ............................................................ 103

Weight........................................................................ 99

Towing Behind A Motorhome ...................................... 103

Towing Eyes ..................................................................213

Traction .........................................................................104

Traction Control............................................................ 162

Trailer Towing ................................................................. 97

Hitches....................................................................... 99

Minimum Requirements.........................................100

Trailer And Tongue Weight ..................................... 100

Wiring....................................................................... 101

Trailer Towing Guide ...................................................... 99

Trailer Weight.................................................................. 99

Transfer Case

Fluid .........................................................................272

Transmission

Automatic .........................................................72

,

232

Fluid .........................................................................272

Transporting Pets .........................................................196

Tread Wear Indicators..................................................259

Turn Signals............................................................. 31

65

CarManuals2.com

287

U

Uconnect

Phone Call Features ............................................... 141

Things You Should Know About Your

Uconnect Phone ................................................ 143

Uconnect Settings................................................... 106

Uconnect Phone.........................................137

,

138

139

Answer Or Ignore An Incoming Call —

Call Currently In Progress.................................. 142

Answer Or Ignore An Incoming Call —

No Call Currently In Progress............................ 142

Bluetooth Communication Link ............................. 145

Call Continuation .................................................... 143

Call Controls............................................................ 141

Call Termination...................................................... 143

Cancel Command ................................................... 138

Connecting To A Particular Mobile Phone

Or Audio Device After Pairing............................ 139

Help Command ....................................................... 138

Join Calls ................................................................. 143

Making A Phone Or Audio Device A Favorite......... 140

Making A Second Call While Current Call

Is In Progress ..................................................... 143

Managing Your Favorites ....................................... 141

Natural Speech....................................................... 137

Operation................................................................. 137

Overview.................................................................. 136

Pair (Link) Uconnect Phone To A Mobile Phone ... 138

Pair A Bluetooth Streaming Audio Device..............139

Phonebook Download.............................................140

Place/Retrieve A Call From Hold............................142

Power-Up..................................................................145

Recent Calls.............................................................142

Redial .......................................................................143

To Remove A Favorite .............................................141

Toggling Between Calls ...........................................143

Touch-Tone Number Entry ......................................142

Transfer Call To And From Mobile Phone ..............143

Voice Command ......................................................143

Uconnect Settings

Customer Programmable Features.............. 106

,

116

Passive Entry Programming....................................116

Uconnect System..........................................................122

Uniform Tire Quality Grades.........................................264

Untwisting Procedure, Seat Belt..................................174

USB ..................................................................................43

V

Vanity Mirrors..................................................................28

Vehicle Identification Number (VIN) ............................268

Vehicle Loading......................................................96

,

254

Vehicle Maintenance....................................................224

Vehicle Modifications/Alterations ................................... 7

Vehicle Storage...............................................................40

Voice Command........................................... 27

146

,

148

Voice Recognition System (VR)......................................27

W

Warning Flashers, Hazard............................................ 200

Warnings, Roll Over...........................................................7

Warranty Information...................................................275

Washer

Adding Fluid............................................................. 223

Washing Vehicle ...........................................................266

Water

Driving Through.......................................................104

Wheel And Wheel Tire Care .........................................262

Wheel And Wheel Tire Trim..........................................262

Wind Buffeting................................................................ 46

Window Fogging ............................................................. 40

Windows.......................................................................... 45

Windshield Defroster ...................................................197

Windshield Washers ...................................................... 33

Windshield Wiper Blades............................................. 226

Windshield Wiper De-Icer .............................................. 35

Windshield Wipers.......................................................... 33

Wipers Blade Replacement .........................................226

Wipers, Intermittent ....................................................... 33

Wipers, Rain Sensitive ................................................... 34

Wrecker Towing ............................................................ 213

11

CarManuals2.com















Content      ..     7      8      9
