Alfa Romeo Tonale (2023 year). Manual in english - page 12





 MULTIMEDIA

364

TomTom Services

(where provided)

Information on TomTom services

NOTE TomTom Services or parts are not

available in all countries or geographic

areas and the functions of live TomTom

Services is subject to the presence of

connectivity in the country of use. For

more information on available services in

each region, go to tomtom.com/services

(https://uk.support.tomtom.com/app/content/name/TechSpecs/).
The following TomTom Services may be

available for the navigation system:

Traffic
Speed Cameras
Weather
Online Search

Traffic

TomTom Traffic is a TomTom service

providing real-time traffic information.
In combination with historical road usage

data, TomTom Traffic helps you plan the

optimum route to your destination taking

into account the current local traffic

conditions.
Your TomTom Navigation App regularly

receives information about the changing

traffic conditions. If traffic jams, heavy

rain, snow or other incidents are found

on your current route, your TomTom

Navigation App will offer to replan your

route to try and avoid any delays.

Looking at traffic on the map

: traffic

problems are displayed on the map
fig. 337. If various issues overlap, the

one with the highest priority will be

displayed; for example, a closed street is

more important than work in progress or

a closed lane.

337

9651216

(1) Traffic incident that affects your

route in your direction of travel.
(2) Roadworks.

Looking at traffic on your route:

the

route bar tells you about traffic delays

while you are driving, using symbols to

show you where each traffic incident

is located on your route. To get more

information about an incident, select

an incident in the route bar. The map
opens zoomed in on the incident fig. 338

and a pop-up opens showing detailed

information about the traffic incident.

338

9651217

The following information can be

displayed: the type of problem (general,

accident, work, etc.), the severity of the

problem, the delay and the extent of the

problem.

Accidents:

The following traffic incident

symbols are used in the map view and

in the route bar to show the cause of

a traffic jam. The symbol or number

at the start of the incident shows the

type of incident or the delay in minutes,

for example 4 minutes. The colour

of the incident indicates the speed of

traffic relative to the maximum allowed

speed at that location, with red being

the slowest. Red indicates the lowest

value. The stripes on the traffic jam are

also animated to show the speed of the

traffic, where appropriate.

Moving Lane Guidance:

Moving

Lane Guidance helps you prepare for

motorway exits and junctions by showing

CarManuals2.com

365

the correct driving lane for your planned

route.

Time-dependent speed limits:

some

speed limits vary depending on the time

of day or driving conditions. Where

possible, the speed limit shown in the

speed panel changes to show these

variable speed limits.
WARNING The speed limit shown in

the speed panel is only an indication.

You must always obey the actual speed

limit for the road you are on and the

conditions you are driving in.

Speed Cameras

The speed camera service warns

about the location of fixed and mobile

speed cameras, Safety Tutors, traffic

light cameras, average speed control

zones and the presence of cameras in

restricted traffic zones.
NOTE When you drive into an area or

country that does not permit speed

camera warnings, your TomTom

Navigation App switches the TomTom

speed cameras service off. You will not

receive speed cameras warnings in those

areas or countries.
Warnings are given as you approach a

speed camera. You are warned in several

ways:

A symbol is shown in the route bar and

on your route on the map

your distance to the speed camera and

the speed limit are shown in the route bar

near the speed camera or if you are

driving in a speed-controlled zone, the

route bar turns orange (speed more

than 5 km/h over the limit) or red (speed

within 5 km/h over the limit)

you hear a warning sound as you

approach the speed camera
The signalling mode can be changed in

the “Settings”>”Sounds and Warnings”

menu.

Weather services

(only available through subscription to

TomTom Services)
The TomTom Weather service provides

detailed reports and 5-day forecasts

for towns and cities. The information is

provided by local weather stations and

is updated hourly. You can get a weather

report for your current location or you

can get a report your destination or a

place you have searched for.
Select the “Weather” app to see the

weather forecast is shown for today at

your current location. Select the down

arrow to scroll down the screen and

display an overview of the day.

Online Search

If you navigation system is connected

to TomTom Services while planning a

route, online search information is also

available.

Planning a route - Finding a public

charging station

(Q4 Plug-in Hybrid versions)
WARNING In the interest of safety and

to avoid being distracted while you are

driving, you should always plan a route

before you start driving.
To find a charging station, do the

following:

Select the “Main Menu” button to open

the corresponding menu

Select "EV Charging Station"

.

The map opens showing the locations of
charging stations, fig. 339.

339

J0A4033

If a route is planned, the map shows

charging stations near your destination.
If a route isn't planned, the map shows

charging stations near your current

location.

CarManuals2.com

 MULTIMEDIA

366

You can change the screen to display a

list of the charging stations by pressing
this button

.

You can select a charging station from

the list to find it on the map.

Tip

: you can display all results using the

scroll bar on the right of the screen.

Select a charging station from the map

or list, fig. 340. A pop-up menu opens

on the map showing the name of the

charging station.

To plan a route towards the selected

charging station, select the "Drive"
button

. A route is planned and then

guidance to your destination begins. As

soon as you start driving, the guidance

view is shown automatically.

340

J0A4034

Tip

: You can add a charging station as a

stop on your route by using the pop-up

menu. The charging stations that are set

as a stop on your route have a blue icon.

Charging connectors

(Q4 Plug-in Hybrid versions)
Select "Settings" in the Main Menu, then
select "Charging Connectors"

.

You can choose the correct charging

connector to be used when searching

for a charging station. The charging

connector supplied with the car is
already selected, fig. 341.

341

J0A4047

Map update

To ensure optimal performance, the

navigation system must be updated

periodically. For this, the Mopar Map

Care service offers a new map update

every three months.
The updates can be downloaded from

the maps.mopar.eu website and installed

directly on the Alfa Connect system. All

updates are free of charge for 3 years

from the start of the warranty on the car.
The navigation system can also be

updated at the Alfa Romeo Dealership.

NOTE The dealer may charge for

updating the navigation system.

Voice Commands

NOTE Voice entry of addresses is only

supported in the country in which you are

located and provided that the system

language matches the local language.

For example, if the car is located in

Italy, it will be possible to enter Italian

addresses only if the system language is

set to "Italian".
The following voice commands can be

given after pressing the button on the
steering wheel

:

Find <PDI> (Point of Interest)

nearby/along the route (Point of

Interest)

Let's go <home>/<to work>
Go to <address>
Go to the centre of <city name>
Drive to <address>/<POI>/<junction>
Navigate home
Go via home
Clear route
Recent Destinations
Stop at a recent destination
2D view
3D view

CarManuals2.com

367

Volume adjustment

The volume of the navigation system can

only be adjusted when the navigation

system provides voice commands.

SETTINGS

The “Settings” menu is available with the

ignition device in START position.
The "Settings" menu can be accessed by

pressing the "Settings" graphic button

on the status bar or from the main page

of the function you are viewing, bottom

right
NOTE The menu items displayed vary

according to the versions.
The menu is indicative and includes the

following items:

Display
My profile
Safety & driving assistance
Clock & Date
Phone/Bluetooth
Voice
Navigation (where provided)
Camera (where provided)
Mirrors and Windscreen Wipers
Lights
Brakes
Doors & Locks
Key-off options
Audio

Notifications
Radio setup
Geolocation (where provided)
Software update
About the system

MY CAR (CAR INFORMATION)

The “My Car” (Car Information) function

can be activated by using the appropriate

widget on the Main Menu or by pressing

the graphic button “Vehicle” or “App”.
NOTE The widget cannot be enlarged in

the main menu.
The following information is shown on

the main screen ("Overview"):

Scheduled servicing: the display shows

the km (or miles) and months (or weeks

or days) missing until the next service

coupon

iTPMS (indirect Tyre Pressure

Monitoring System): the display shows

the pressure information for each tyre,

monitored by the TPMS (Tyre Pressure

Monitoring System)

Explore Drive Mode (Alfa DNA™

system): information relating to the drive

mode selected using the Alfa DNA™

system is displayed

TRIP COMPUTER

The following information related to

"Trip A", "Trip B", "Current trip” is shown

on the main screen of the "Trip” function:

Average consumption, Average speed,

Distance, Travel time.

PERFORMANCE

(where provided)
The “Performance” function can be

activated by clicking on the appropriate

widget on the Main Menu or by pressing

the graphic button “Vehicle” or “App”.
The following information is shown on

the main screen of the "Performance":

"Technical gauges”: instantaneous

turbo pressure and engine torque values

“Accessory indicators" (where

provided): engine oil temperature,

transmission temperature, charge status

of conventional battery

"Consumption history": graph of

average and instantaneous fuel

consumption in the last period

"Engine torque": engine torque

transmitted to each wheel and vehicle

pitch

"Drag Race" (where provided): current

acceleration and braking distance

performance of the car since the last

measurement and best result

APP

Pressing the graphic button "App" will

display the "Favourites", "Recent", "Other

categories" and "All" submenus.

CarManuals2.com

 MULTIMEDIA

368

Favourites

The "Favourites" submenu contains

the "Performance" pages (according

to the version/market): “Electrical

Functions” (Q4 Plug-in Hybrid versions),

"Performance", "Device Manager",

"Android Auto" (or Apple CarPlay),

"Alexa" (where provided), "MyCar",

"Software Update".
The "Favourites" page can contain up to 4

favourite pages. A message will indicate

that you have reached the maximum

number of pages allowed if you try to add

an additional page.
To add or remove an app from the

Favourites list, select or deselect the

star that appears on the app icon in the

list shown in the "Recent", "Categories"

or "All" pages. A pop-up will tell you

whether you want to save the app in your

favourites or not. The operation can be

cancelled by selecting "Cancel" or "X".

Recent

The "Recent" submenu contains recently

used or downloaded apps. The user

will see a list of apps arranged in

chronological order.

Categories

The "Categories" submenu contains a list

of filtered categories from the various

apps. The following are displayed in

order: "Media", "Comfort", "Nav" (where

provided), "Phone", "Vehicle", "System",

"More". The applications in each category

are displayed in alphabetical order.

All

The "All" submenu all available apps and

allows the user to search for them in

alphabetical order from A to Z or Z to A.

WIDGETS

On the main page it is possible to display

screens summarizing the Alfa Connect

system functions (called "widgets")

chosen by the user from a list of available

widgets. To add a Widget, press the
button

on the display and select the

desired Widget from the list.
Some Widgets can also be customised by
pressing the button

next to the title.

This will open the customisation screen.

Then select “Add widget”.
The number of Widgets which can be

installed per page depends on their size.

You can add multiple pages (up to a

maximum of five in total) by pressing

the "+" button on the display. To switch

between pages, simply touch the page

briefly and swipe your finger rightwards

or leftwards.
Pages can be deleted using the "Delete

page" function or reordered using the

"Reorder pages" function.
NOTE The customisation is only active

when the car is stationary. If an attempt

is made to customise with the car in

motion or to resume driving without

having completed the procedure, a

warning message will appear on the

display and the operation will be ended.

MOVING THE WIDGETS

Select the desired widget and then:

Moving the widget

: hold the desired

widget pressed for a few seconds and

then move it to the right or left of the

display.

Resizing the widget

(where provided):

press the widget resize icon to be

resized.

View widget content

: select the desired

widget and then scroll vertically. When

reordering the widgets (viewing their

thumbnails), it will not be possible to

view their contents.

CarManuals2.com

369

PROFILES

By entering the Profiles environment you

can create an avatar and enter your own

customisations.
Selecting "All profiles" displays all

existing profiles. Profiles can be cleared

in one step using the "Delete personal

data" function in the "Settings" menu

and the restore to default conditions

function.
To create your profile select "Add

profile" and type in the name of your

choice, choose one of the available

avatars and store the car seat you

normally occupy.
Selecting "Edit profile” allows you

to enter or edit customisations in the

profile.
It is possible to exclude all profiles and

keep the default settings by pressing the

"Mod. Parking attendant" button on the

"All profiles" page.
NOTE After changing the profile, it

is necessary to wait up to 5 minutes

approx. to load the relative settings to

the Connect system.

UPDATING THE SYSTEM

The Alfa Connect system can be updated

remotely via Over The Air updates.
NOTE The images are given by way of

example only. They may differ from

those shown below according to the

version/market.

NOTE Instead of using external Wi-Fi

connections, Over The Air software

updates use the data connectivity

included with the car, at no additional

cost to the customer.
WARNING Some car or phone settings

may be lost after an Over The Air

software update. Check and if necessary

re-enter the missing settings on the Alfa

Connect system.
WARNING Some automatic system

updates could take place during a phase

of non-use, with the engine off. This may

require to switch the ignition device

from STOP to ENGINE and back several

times to re-establish all audio and video

functionality, .
When a software update is available, a

pop-up window will appear on screen

informing that a new software version

or new features for the Alfa Connect

system are available.
NOTE The rear-view camera, Alfa

Connect system and other driver

assistance systems are not available

during the update. It is recommended

to carry out the update when the car is

stationary.

Instant update

Press the "Update Now" button fig. 342

to update the software immediately

when the pop-up window appears on

screen.

Scheduled update

The scheduled update option allows you

to define a different update time. Press
the arrows

/ on the screen to set

the desired time.

342

5520732D

NOTE The scheduled update option can

be used 20 times per update. After the

20th postponement the update will be

made mandatory when the car is first

started. In case of a mandatory update

you can only press the "OK" button on the

pop-up and start the update.
During the update the radio will show

the percentage of the update completed

and the time remaining until completion
fig. 343. When the update is complete the

Alfa Connect system will automatically

restart.

CarManuals2.com

 MULTIMEDIA

370

343

5520733D

Updates over external Wi-Fi

When a software update via Wi-Fi is

available, a pop-up window will appear on

the screen offering the update instantly

or at a later time.
NOTE The rear-view camera, Alfa

Connect system and other driver

assistance systems are not available

during the update. It is recommended

to carry out the update when the car is

stationary.
To allow the Alfa Connect system to

update its software:

Select "Settings" on the screen
Select "Wi-Fi" in the settings list
Select the correct Wi-Fi router from

those shown
NOTE If the Wi-Fi router is too far from

the car, it will not be shown among the

available ones.

If prompted, enter the password to

access the router and select "OK".
To enable software updates:

Select “Enable software download

over Wi-Fi" on the Wi-Fi settings screen.

When a software update is available,

a pop-up window will appear on the Alfa

Connect system screen to alert you that

a new update is available. When asked to

connect to a Wi-Fi network, select "Yes".

During the update, a second pop-up

screen shows the estimated time

remaining and the progress percentage

of the update. When the update is

finished, press "OK".

Instant update

When the pop-up window appears on

screen, press the "Update Now" button

to update the software immediately.

Scheduled update

Use the scheduled update option to set a

deferred update time. Press the arrows

/ on the screen to set the desired

time.
NOTE The scheduled update option can

be used 20 times per update. After the

20th postponement the update will be

made mandatory when the car is first

started. In case of a mandatory update

you can only press the "OK" button on the

pop-up and start the update.

During the update the radio will show

the percentage of the update completed

and the time remaining until completion
fig. 343. When the update is complete the

Alfa Connect system will automatically

restart.

Update errors

In the event of errors during the updating

phase, the operation is interrupted and

a message is displayed notifying that

the previous version of the software has

been restored.
Contact an Alfa Romeo Dealership in this

case.

CONNECTED SERVICES - ALFA

CONNECT SERVICES

302)

(for versions/markets where provided)

Alfa Connected Services enrich

the experience of use of the car by

connecting it to the network.
The services (where provided) allow

you to receive timely assistance in

case of need and emergency, to obtain

information about the status of your car,

its location, control it remotely and

to improve the navigation experience

CarManuals2.com

371

(where provided) thanks to real-time

updates.
You can access the Alfa Connect

Services using a dedicated mobile app

for smartphone, smartwatch, web portal

or the Alfa Connect system of your car.
The availability of services is subject to a

Alfa Connect Services subscription.
More information on Alfa Connect

Services (applicability, availability,

compatibility, packages and

specifications) can be found on the

official Alfa Romeo website.

GENERAL DISCLAIMER

Personal data & customization

FCA collects, processes and

uses the personal data of the car in

accordance with legal requirements.

More information can be found in the

general conditions of service and on data

protection policies on the Alfa Romeo

official website

The Customer is solely responsible

for using the services in the vehicle, even

if by other people, and shall inform all

users and occupants of the car about the

services and the operations and limits of

the system

Operating prerequisites

Registration and activation are

required to use some of the Alfa Connect

Services. Go to the portal, accessible

through the official Alfa Romeo website,

or use the My Alfa Connect mobile

application to do so and login on with

your devices

Alfa Connect Services is not available

in all countries and is subject to

limitations depending on Alfa Connect

system type, location and duration of the

services

The full operation of the Alfa Connect

Services, including eCall EU emergency

call and roadside assistance calls

(ASSIST), is subject to mobile network

and GPS geolocation coverage, without

which the proper provision of services

is not guaranteed. Coverage may

not be guaranteed in places such as

tunnels, garages, multi-storey car parks,

mountains, etc.

the services may be unavailable in

the event of mobile network overload

or problems related to the car power

source (e.g. low conventional battery)

When using the services, customers

shall keep their passwords secret for

strictly personal use and not disclose

them to third parties

SERVICES

NOTE The date and time shown on Alfa

Connect system display must match

the actual date and time, even after

disconnecting the battery. Adjust it from

the "Settings" menu of the Alfa Connect

system. Any discrepancy between the

date and time on the display and the

actual date and time may be due to a

malfunction in the Connected Services.
According on the equipment of the car

and of the country, different services

may be available for different durations.

For further information about your car,

go to the personal page on the official

Alfa Romeo website.
Some of the packages made available to

the customer are:

My Assistant

: Customer assistance

and safety warning service, which

includes:

"EMERGENCY CALL “EU eCall”

and ASSIST roadside assistance"

(see "In emergency” chapter)

"Vehicle Health Report":

information on the status and

condition of the car, notifying

potential maintenance needs to the

customer via periodic e-mails. This

service is provided on condition

that the Customer has previously

provided the FCA network with a

valid e-mail address

“In-Vehicle Notifications":

possibility to receive messages

and/or notifications related to the

provision of services and reminder

messages about the execution of

service and/or recall campaigns on

the Alfa Connect system display

CarManuals2.com

 MULTIMEDIA

372

You can contact FCA Customer

Service for further information

regarding the messages received

My eCharge

(Q4 Plug-in Hybrid

versions only): this is a service that

allows you to find, use and pay for

charging at public charging stations and

keep track of your charging history.

The service also allows you to manage

recharges with your private wallbox

charging station directly from your

smartphone.

My Car

: vehicle status monitoring

service.

My Remote

: this can be used to

manage remote operations (switching

on lights, door lock/unlock, find vehicle,

etc.) from the My Alfa Connect mobile

app and through compatible voice

assistants.

For Q4 Plug-In Hybrid

versions only

, it is also possible to use

the "E-Control" services that allow to

manage, remotely, all the functions

related to the of the high voltage battery

charging, such as charging activation,

charging programming and charge level

monitoring and respective climate

control system programming.
If you are planning a high-voltage battery

charging session using the Alfa Connect

system display on the car and you are

charging using tools/connections

supplied with planning solutions, make

sure that the programming is compatible

with the programming of the vehicle,

otherwise charging may not take place.

My Navigation

: connected navigation

service (subject to availability according

to version/market)

My Wi-Fi

: Optional Wi-Fi Hotspot

service. This service provides Internet

access from the car to all devices with

Wi-Fi connection (smartphones, tablets,

laptops) (supported technologies: 3G –

4G). This creates a private Wi-Fi internet

access point in the car. The function,

available only with the ignition device in

ON position or with the engine started

allows the connection of up to eight

devices simultaneously, but not the

direct communication between devices.

The quality of the service offered by the

integrated Wi-Fi Hotspot depends on

the coverage of the mobile operator's

network.

Alexa Voice Service

(where

provided): Users with active data plan

with the Wi-Fi Hotspot service can also

use the Alexa voice service activated by

the Connect system on-board the vehicle

to perform operations, such as checking

the weather or news, playing music,

interacting with the navigation system

and remotely controlling intelligent

devices in their home. The service can

also be accessed remotely, directly

from home, to send destinations to

the car, monitor the remaining charge,

find the nearest charging stations and

much more! Follow the steps on the

Ubigi website for Alfa Romeo to carry

out immediate activation of the Wi-Fi

Hotspot service.

My Fleet Manager

: innovative fleet

management service. With its simple

and intuitive interface, and total

remote accessibility, it allows absolute

control over the activities, service

status, maintenance and servicing

of each vehicle. With a simple “click”

on your smartphone you will have all

the information you need in real time,

without leaving the office or on the move.
NOTE The hotspot name and password

can only be changed with the ignition

device in the ON position.
You can enrich Alfa Connect Services

experience by purchasing optional

services for which a subscription is

required.
These can be subscribed to

independently by the customer from the

catalogue of services available for the

car, directly on the personal page of the

official Alfa Romeo website.

My Alert:

optional service with

app and web notifications in case of

suspected theft attempts and assistance

in case of theft.

CarManuals2.com

373

DEACTIVATION OF GEOLOCATION

MODE

(for versions/markets where provided)
If you wish to deactivate geolocation

mode, simply do so from the Alfa
Connect system fig. 344 (see the

"Settings" menu of the Alfa Connect

system for more details).
When geolocation mode is deactivated

some of the services on mobile apps and

web that use the location of the car will

not be available.
WARNING The

icon is shown at the

bottom left of the Alfa Connect system

display when the geolocation function

is active (ON). When geolocation is on,

the vehicle position is tracked to enable

the functions that require it. When

geolocation is off, the vehicle position is

only tracked by the navigation, safety,

insurance and driver assistance systems

(where provided). See the Alfa Connect

system "Settings" chapter to deactivate

the function.

344

12126S2094EM

WARNING If the “default settings are

restored”, turn off the engine (ignition

device to STOP) and wait a few minutes

before restarting it (ignition device to

ENGINE). The incorrect performance

of the operation and the short period

of time passed between turning off

the engine and turning it back on may

cause the Privacy settings to not be

maintained. In this case, repeat the

operation, extending the wait time

between turning off the engine and

turning it back on.

UPDATING THE SYSTEM

Alfa Connect Services and the Alfa

Connect system application software are

updated remotely in order to provide

the customer with newer software

versions that include new features or

enhancements/enrichments of features

already offered.
Updates are made at the discretion of

FCA.

Some system updates will be

managed automatically, others will be

communicated to the Customer through

messages on the Alfa Connect system

display, allowing the customer to confirm

or postpone the update.
The customer will be notified by the

Alfa Connect system if the system is

unavailable.
To obtain more information about

services, features, specifications,

availability and any updates please

always refer to the content included in

the official website of Alfa Romeo.

DEACTIVATION OF ALFA CONNECT

SERVICES

If you sell your car on which the Alfa

Connect Services are still active, you

will be responsible for logging off your

profile from the services on the page

on the official Alfa Romeo website, by

contacting the Customer Care or by

going to an Alfa Romeo dealership.
The customer is also responsible for

informing the new owner of any services

not yet expired associated with a new

Alfa Connect Services account.

CarManuals2.com

 MULTIMEDIA

374

WARNING

302)

Always follow the highway code of

the country in which you are driving, and

concentrate on the road. Always drive

safely with your hands on the steering

wheel. Only use the Alfa Connect system

functions when you are sure that it is safe to

do so. The customer is liable for all risks

associated with using the operations and

applications of the car. Failure to follow

these rules may cause serious accidents

and/or death.

OFFICIAL TYPE APPROVALS

All radio equipment provided with the

car complies with Directive 2014/53/EU,

UA.RED.TR, the French SAR Decree

Law of 15/11/2019 and the UKCA (UK

Conformity Assessed) Certification

of 01/01/2021 in force in the United

Kingdom.
For further information visit

the www.mopar.eu/owner or

http://aftersales.fiat.com/elum/

websites

Radio frequency devices

All radio frequency devices comply with

the regulations in force in the countries

in which they are sold.

For further information visit

the www.mopar.eu/owner or

http://aftersales.fiat.com/elum/

websites

CarManuals2.com















Content      ..     10      11      12
