FM 3-04.126 Attack Reconnaissance Helicopter Operations (February 2007) - page 8





Briefings, Reports, and Formats
and RF Hellfire missiles. SAL and RF Hellfire can defeat any known armor. The minimum engagement
range is 500 meters, the maximum range is 8,000 meters, and the maximum aircraft load when configured
with four hellfire launchers is 16 missiles.
Semiactive Laser Hellfire
E-28. The SAL Hellfire requires a laser target designation that may be autonomous or remote
E-29. . The remote designator may offset a maximum of 60 degrees from the gun-to-target line and must
not position its self within a 30 degree safety fan from the firing aircraft.
Longbow Radar Frequency Hellfire
E-30. The Longbow RF Hellfire is a millimeter wave guided missile and a true fire-and-forget weapon.
The millimeter wave radar and missile can engage targets through weather and battlefield obscurants. The
RF missile receives targeting information—to include north, east, and down data—from the acquisition
source: TADS, FCR, or another aircraft. Targeting data can be transferred from a Longbow to an AH-64D
without radar as a radar frequency handover.
MISSION CONFIGURATIONS
E-31. Table E-5 is a matrix of AH-64D mission profiles and typical ammunition loads (weight limits may
require reduction in mission loads).
Table E-5. AH-64D weapons loads, weights, and radius
Weapons:
A
B
C
Weights & Radius:
A
B
C
(110 kts airspeed)
Hellfire
8
16
12
Operate
13897
14009
13953
Rockets
38
0
19
Fuel
2870
2870
2870
30mm
340
340
340
Load
2103
1862
1982
T/O
18870
18741
18805
Radius KM
210.6
210.6
210.6
Radius NM
113.7
113.7
113.7
Endurance
2.23
2.23
2.23
COMMUNICATIONS
E-32. The AH-64D has the following communications systems:
z
The AN/ARC-201D SINCGARS with embedded encryption and data capability (operates in the
30 to 87.975 MHz frequency range and has anti-jam, frequency-hopping capability).
z
The AN/ARC-164 Have Quick II provides anti-jam frequency-hopping UHF-AM
communications in the 225 to 399.975 MHz range at 25 KHz intervals.
z
The AN/ARC-186 provides VHF-AM (116 to 151.975 MHz).
z
The AN/ARC-220 HF radio provides NOE long-range communications in the 2 to 29.999 MHz
range and secure mode when employed with the KY-100.
z
The TSEC/KY-100 provides secure communications for the AN/ARC-220 HF radio.
z
The TSEC/KY-58 interfaces with AN/ARC-201D and AN/ARC-201 radios to provide secure
voice for these radios.
z
The IDM transfers digital messages.
z
Some aircraft may have a second SINCGARS radio in place of the HF radio
NAVIGATION SYSTEMS
E-33. The navigation subsystem consists of the following major components:
z
Embedded global positioning system inertial navigation system (EGI, primary and backup).
z
Doppler radar velocity sensor.
16 February 2007
FM 3-04.126
E-7
Appendix E
z
Radar altimeter.
z
Automatic direction finder (ADF).
z
High integrated air data computer.
z
Flight management computer.
LIMITATIONS
E-34. Prominent limitations of the AH-64 are discussed in the following paragraphs.
Threat Identification
E-35. Threat identification through the FLIR system is extremely difficult; although the crew can easily
find the heat signature of a vehicle, it may not be able to determine whether it is friend or foe. FCR target
identification is limited to radar cross section return data and does not determine actual target validity.
Infrared Radiation Crossover
E-36. The thermal imaging sensor and PNVS operate by determining temperature differentials. When
targets and their surroundings reach the same temperature (normally twice a day), target detection is
degraded; these conditions also make flight difficult while using the FLIR sensor. The same effect occurs
when temperatures do not significantly vary throughout the day or night, or heavy cloud cover exists for
long periods of time. For example, sustained rainfall may reduce the FLIR quality to unusable for flight or
targeting during certain times of the year.
Obscurants
E-37. Some obscurants (such as dust, rain, haze, or smoke) can prevent laser energy from reaching the
target. It also hides the target from incoming munitions seekers for SAL Hellfire and prevents effective use
of FLIR systems. AH-64D FCR and RF Hellfire see and shoot through obscurants.
Low Cloud Ceilings
E-38. Determination of the SAL Hellfire’s maximum employment range requires consideration of cloud
ceilings. Depending on range to target, trajectory mode selected, and lasing techniques, the missile may
climb into low cloud ceilings causing the seeker to break track from the laser spot or preventing the seeker
from acquiring the laser spot.
Instrument Flight Rules
E-39. The AH-64D is not currently certified for IFR operations.
SECTION III - ARMED RECONNIASSANCE HELICOPTER
E-40. The armed reconnaissance helicopter (ARH) has been selected to replace the OH-58D during
force modernization. Table E-5 provides operational characteristics of the ARH.
Table E-6. Armed reconnaissance helicopter characteristics
Specifications
Length: 41 feet 4 inches
Height: 10 feet 11 inches
Fuselage width (w/weapons pylons): 9 feet 5 inches
Main Rotor Diameter: 35 feet
Max Speed (Level): 140 knots
Max Gross Wt: 6250 pounds
Cruise Airspeed: 113 knots*
Combat Radius: 300 kilometers
E-8
FM 3-04.126
16 February 2007
Briefings, Reports, and Formats
Armament
Missile Range (Hellfire): 8,000 meters
Rocket Range (Hydra 70): 6,600-9,000 meters
Gun Range (.50 Caliber)
2,000 meters (1600 meters tracer burnout)
Optics (FLIR)
FLIR:
Detection: 10+ kilometers
Recognition: 8+ kilometers
Identification: 5 kilometers
Television Sensor:
Detection: 10+ kilometers
Recognition: 8 kilometers
Identification: 4-6 kilometers
Laser Range Finder/Designator:
Maximum Ranging Distance: Classified
Commander’s pointer
Eye Safe Laser (Range Only)
AIM-1 Laser boresighted to weapons
Constantly Computed Impact Point
Lasing a known point will update the navigation system.
Pilots use AN/AVS-6 to fly the aircraft at night.
Navigation Equipment
INU/INS/GPS
Slave sights to grid input by operator.
Spiral technology will allow user to look out door and slace sight to specific point.
Full suite for navigation including TACAN/VOR/ILS/GATM and EGI approaches
and departures.
Additional Capabilities
Helmet Display Tracking System
Automatic Flight Control System
Common Avionics Architecture System
Common Missile Warning System
Extended Range
Upgraded engine provides 970 SHP
Limitations
*Varies with environmental/mission conditions.
ARMAMENT SYSTEMS
E-41. ARH armament capabilities consist of a .50-caliber machine gun, 2.75-inch rockets, and Hellfire
missiles. These systems are mounted on two universal weapons pylons. The aircraft has a laser
rangefinder/designator used to designate for the weapons system as well as provide range-to-target
information for onboard weapons systems.
.50-CALIBER MACHINE GUN GAU-19
E-42. This electronically controlled weapon can be mounted in a fixed position on the left weapons
pylon. It is an area weapon system with a maximum effective range of 2000 meters (tracer burnout 1600
meters). The GAU-19 is a 3-barrelled Gatling type machine gun. Ammunition capacity is 500 rounds.
16 February 2007
FM 3-04.126
E-9
Appendix E
2.75-INCH ROCKET SYSTEM FOLDING FIN AERIAL ROCKET
E-43. The ARH can carry two seven-shot rocket pods with a maximum load of 14 rockets for use against
enemy personnel, light armored vehicles, and other soft-skinned targets. This area system can launch
multiple rockets with various warhead mixes including high explosive, high-explosive MPSMs, white
phosphorous, illumination, and flechette. Spiral technology will be introduced with more than seven shots
per side. APKWS will also enable a better PK percentage using these rockets.
HELLFIRE MISSILE
E-44. The SAL Hellfire is used primarily for destruction of tanks, armored vehicles, and other hard-
material targets. The ARH can carry two two-missile launchers for a maximum of four missiles. The
minimum engagement range is 500 meters; maximum range is 8,000 meters. Laser designation may be
autonomous or remote.
COMMUNICATIONS
E-45. The ARH has the following communications systems:
z Two AN/ARC-201D SINCGARS with embedded encryption and data capability. Both operate in
the 30 to 87.975 MHz frequency range and have antijam, frequency-hopping capability.
z An IDM/JVMF transferring digital messages.
z Two AN/ARC-231s, one having the capability to transmit and receive SATCOM, while both
have one of four separate tuneable bands, including FM/VHF/UHF. Have Quick II and FM
secure are also additions to the aircraft.
LIMITATIONS
E-46. The following are possible ARH limitations:
z Obscurants. Some obscurants (dust, rain, haze, or smoke) can keep laser energy from reaching
the target and hide the target from the incoming munitions seeker.
z Low cloud ceilings. Consideration must be given to cloud ceilings determining maximum
employment range of the SAL Hellfire. Depending on distance to target, trajectory mode
selected, and lasing techniques, the missile may climb into low cloud ceilings causing the seeker
to break track from the laser spot or preventing the seeker from acquiring the laser spot.
z Hellfire remote designation constraints. The designating crew may offset a maximum of 60
degrees from the gun-to-target line and must not position its aircraft within a +30-degree safety
fan from the firing aircraft.
z Instrument meteorological conditions. The ARH will be certified but not qualified with the
FAA.
E-10
FM 3-04.126
16 February 2007
Appendix F
Reference Library
This appendix provides a quick reference list of documents available to help with all
aspects of possible battalion/company tasks and responsibilities. All publications are
on a recurring review and rewrite schedule and some references may have new
number and title names; however, this appendix provides the latest published
publications available at the time of print. These publications are available for
downloading at www.apd.army.mil.
SECTION I - PUBLICATIONS
ARMY TRAINING AND EVALUATION PROGRAM, MISSION
TRAINING PLAN
F-1. Army training and evaluation program (ARTEP) MTPs are used to help develop an objective
training plan for the unit which the higher headquarters can evaluate task and mission accomplishment
using prepared evaluation checklists.
z ARTEP 1-111-MTP. Provides MTP for aviation brigades.
z ARTEP 1-113-MTP. Provides MTP for assault helicopter battalions.
z ARTEP 1-118-MTP. Provides MTP for GS aviation battalions.
z ARTEP 1-126-MTP. Provides MTP for attack reconnaissance helicopter battalions/squadrons.
z ARTEP 1-245-MTP. Provides MTP for heavy helicopter battalions.
z ARTEP 1-425-MTP. Provides MTP for ATS battalion.
z ARTEP 1-500-MTP. Provides MTP for intermediate maintenance battalion and company, now
the ASB and ASC.
TRAINING CIRCULARS
F-2. TCs provide guidance to the commander on establishing training requirements and procedures for
individual and crew tasks.
z TC
1-210. ATP commander’s guide to individual and crew standardization. Provides the
commander with established requirements to determine and conduct required aircrew training
common to all aviators and crews.
z TC 1-218. ATM for the utility airplane, C-12, aviator and crew. Provides the commander with
established requirements to determine training requirements for all C-12 aviators to progress and
maintain proficiency in all tasks expected to be performed by the C-12 crew.
z TC 1-219. ATM for the Guardrail common sensor airplane, RC-12, aviator. Provides the
commander with established requirements to determine training requirements for all RC-12
aviators to progress and maintain proficiency in all tasks expected to be performed by the RC-12
crew.
z TC 1-228. ATM for the Kiowa and Cayuse observation helicopters, OH-58A/C and OH-6
respectively, aviator. Provides the commander with established requirements to determine
training requirements for all OH-58A/C and OH-6 aviators to progress and maintain proficiency
in all tasks expected to be performed by the OH-58A/C and OH-6 crew.
16 February 2007
FM 3-04.126
F-1
Appendix F
z TC
1-237. ATM for the utility helicopter, H-60 series, aviator and crew. Provides the
commander with established requirements to determine training requirements for all UH-60
aviators to progress and maintain proficiency in all tasks expected to be performed by the UH-
60 crew.
z TC 1-238. ATM for the Apache AH, AH-64A, aviator. Provides the commander with established
requirements to determine training requirements for all AH-64A aviators to progress and
maintain proficiency in all tasks expected to be performed by the AH-64A crew.
z TC 1-240. ATM for the Chinook cargo helicopter, CH-47D, aviator and crew. Provides the
commander with established requirements to determine training requirements for all CH-47D
aviators to progress and maintain proficiency in all tasks expected to be performed by the CH-
47D crew.
z TC 1-248. ATM for the Kiowa Warrior observation helicopter, OH-58D, aviator. Provides the
commander with established requirements to determine training requirements for all OH-58D
aviators to progress and maintain proficiency in all tasks expected to be performed by the OH-
58D crew
z TC 1-251. ATM for the Apache AH, AH-64D, aviator. Provides the commander with established
requirements to determine training requirements for all AH-64D aviators to progress and
maintain proficiency in all tasks expected to be performed by the AH-64D crew.
z TC 1-600. ATM and commander’s guide for UAS. Provides the commander with established
requirements to determine training requirements for all operators in all tasks expected to be
performed by UAS operators.
SOLDIER TRAINING PUBLICATION
F-3. The Soldier training publication
(STP) is a Soldier’s manual
(SM) and trainer’s guide
(TG)
providing information to leadership on required training for specific MOSs and skills required to attain and
maintain the established level of proficiency expected of a Soldier at each grade within the military
occupational specialty (MOS).
z STP 1-93C1-SM-TG. SM and TG for MOS 15Q, (formerly 93C) air traffic controller, skill level
1. Provides the commander with established requirements to determine training requirements for
all 15Q school trained Soldiers to progress and maintain proficiency in all tasks expected to be
performed.
z STP 1-93C24-SM-TG. SM and TG for MOS 15Q, (formerly 93C) air traffic controller, skill
levels
2/3/4. Provides the commander with established requirements to determine training
requirements for all 15Q school trained Soldiers to progress and maintain proficiency in all tasks
expected to be performed.
z STP 1-93P1-SM-TG. SM and TG for MOS 15P, (formerly 93P) aviation operations specialist,
skill level
1. Provides the commander with established requirements to determine training
requirements for all 15P school trained Soldiers to progress and maintain proficiency in all tasks
expected to be performed.
z STP 1-93P24-SM-TG. SM and TG for MOS 15P, (formerly 93P) aviation operations specialist,
skill levels 2/3/4. Provides the commander with established requirements to determine training
requirements for all 15P school trained Soldiers to progress and maintain proficiency in all tasks
expected to be performed.
z STP 1-15D13-SM-TG. SM and TG for MOS 15D, aircraft power train repairer skill levels 1 & 3.
Provides the commander with established requirements to determine training requirements for
all 15D school trained Soldiers to progress and maintain proficiency in all tasks expected to be
performed.
z STP 1-15M13-SM-TG. SM and TG for MOS 15M, UH-1 helicopter repairer skill levels 1/2/3.
Provides the commander with established requirements to determine training requirements for
all 15M school trained Soldiers to progress and maintain proficiency in all tasks expected to be
performed.
F-2
FM 3-04.126
16 February 2007
Reference Library
z STP 1-15T13-SM-TG. SM and TG for MOS 15T, UH-60 helicopter repairer skill levels 1/2/3.
Provides the commander with established requirements to determine training requirements for
all 15T school trained Soldiers to progress and maintain proficiency in all tasks expected to be
performed.
z STP 1-15U13-SM-TG. SM and TG for MOS 15U, CH-47 helicopter repairer skill levels 1, 2 &
4. Provides the commander with established requirements to determine training requirements for
all 15U school trained Soldiers to progress and maintain proficiency in all tasks expected to be
performed.
FIELD MANUALS
F-4. FMs provide multitude of information specific to the subject of the FM. The FMs discussed below
provide information on the organization, mission, fundamentals, communication, mission employment,
combat support and combat service support operations for Army aviation and various levels and types of
aviation units.
ARMY KEYSTONE FIELD MANUAL FOR ARMY AVIATION
F-5. FM 1-100 (will be revised as 3-04.100), one of the Army’s keystone manuals, is the base doctrine
manual for Army aviation. It provides general guidance for all aviation related missions and units and their
contribution to the Army across the full spectrum of operations and environments.
AVIATION BRIGADE LEVEL FIELD MANUAL
F-6. FM 3-04.111 provides doctrinal information for leaders to understand how CABs operate in various
environments and across the full spectrum of operations including maneuver,
combat
support,
and
sustainment missions.
AVIATION BATTALION LEVEL FIELD MANUAL
F-7. Battalion-level manual is FM 1-113 (will be revised as 3-04.113).
Maintenance
F-8. Maintenance publications are—
z FM 3-04.500.
z FM 3-04.508.
z FM 3-04.513.
z TM 1-1500-204-23-1.
z EM 0126. (TM 1-1520-Apache/Longbow.)
Operations
F-9. Operations publications are—
z Aviation Liaison Officer Handbook, United States Army Aviation Center.
z TC 1-400.
z AR 95-1.
z HQDA Letter 525-03-1.
z DA Form 5484 (Mission Schedule/Brief).
z FM 1-02.21.
z FM 2-0 (FM 34-1).
z FM 3-0.
z FM 3-01.4. J-SEAD.
16 February 2007
FM 3-04.126
F-3
Appendix F
z
FM 3-04.104.
z
FM 3-04.140.
z
FMI 3-04.155.
z
FM
3-04.300.
z
FM
3-04.301.
z
FM
3-04.303.
z
FM
1-564 (will be revised as FM 3-04.564).
z
FM
3-05.30.
z
FM
3-05.60 (FM 1-108).
z
FM
3-06 (FM 90-10).
z
FM
3-06.1.
z
FM
3-06.11 (FM 90-10-1).
z
FM
3-07 (FM 100-23).
z
FM
3-07.31.
z
FM
3-09.32 (FM 90-20).
z
FM
3-13 (FM 100-6).
z
FM
3-21.38.
z
FM
3-50.1.
z
FM
3-50.3.
z
FM
5-0.
z
FM
6-0.
z
FM
6-20 (will be revised as FM 3-09).
z
FM
6-20-40.
z
FM
6-20-50.
z
FM
4-20.197 (will be revised as FM 4-20.197).
z
FM
17-95.
z
FM
34-2-1 (will be revised as FM 2-00.21).
z
FM
34-60 (will be revised as FM 2-01.2).
z
FM
34-130 (will be revised as FM 2-01.3).
z
FM
55-450-2.
z
FM
71-100 (will be revised as FM 3-91).
z
FM
71-100-2.
z
FM
71-100-3.
z
FM
90-4 (will be revised as FM 3-18.12).
z
FM
90-21 (will be revised as FM 3-09.33).
z
FM
100-8 (will be revised as FM 3-16).
z
FM
100-15 (will be revised as FM 3-92).
z
FM
100-17-3 (will be revised as FM 4-01.8).
z
FM
100-17-5.
z
JP 3-0.
z
JP 3-01.4.
z
JP 3-09.
z
JP 3-09.1.
z
JP 3-09.3.
z
JP 3-50.2.
z
JP 3-50.21.
z
JP 3-60.
F-4
FM 3-04.126
16 February 2007
Reference Library
Unit Movement
F-10. Unit movement publications are—
z
EM 0253. (TM 55-1520-241-S).
z
FM 3-35.4.
z
FM 4-01.011 (FM 55-65).
z
SDDCTEA Pamphlet 55-19. (Surface Deployment and Distribution Command Transportation
Engineering Agency Fort Eustis, Virginia).
z
SDDCTEA Pamphlet 55-20. (Surface Deployment and Distribution Command Transportation
Engineering Agency Fort Eustis, Virginia).
z
SDDCTEA Pamphlet 55-21. (Surface Deployment and Distribution Command Transportation
Engineering Agency Fort Eustis, Virginia).
z
SDDCTEA Pamphlet 55-22. (Surface Deployment and Distribution Command Transportation
Engineering Agency Fort Eustis, Virginia).
z
SDDCTEA Pamphlet 55-23. (Surface Deployment and Distribution Command Transportation
Engineering Agency Fort Eustis, Virginia).
z
SDDCTEA Pamphlet 55-24. (Surface Deployment and Distribution Command Transportation
Engineering Agency Fort Eustis, Virginia).
z
SDDCTEA Pamphlet 70-1. (Surface Deployment and Distribution Command Transportation
Engineering Agency Fort Eustis, Virginia).
z
SDDCTEA Pamphlet 700-2. (Surface Deployment and Distribution Command Transportation
Engineering Agency Fort Eustis, Virginia).
z
SDDCTEA Pamphlet 700-4. (Surface Deployment and Distribution Command Transportation
Engineering Agency Fort Eustis, Virginia).
z
SDDCTEA Pamphlet
700-5,
2001.
(Surface Deployment and Distribution Command
Transportation Engineering Agency Fort Eustis, Virginia).
z
SDDCTEA Pamphlet
700-6,
2002.
(Surface Deployment and Distribution Command
Transportation Engineering Agency Fort Eustis, Virginia).
z
TM 1-1520-237-S.
z
TM 1-1520-248-S.
z
TM 1-1520-252-S.
z
TM 55-1520-238-S.
z
TM 55-1560-307-13&P.
z
Unit Movement Officer Deployment Handbook Reference
97-1, United States
Army
Transportation School, Fort Eustis, VA.
Safety
F-11. Safety publications are—
z DODD 2000.12. DOD Antiterrorism/Force Protection Program.
z Department of the Army Pamphlet (DA Pam) 385-64.
z FM 3-100.12.
z FM 100-14.
z U.S. Army Safety Center (USASC). Commander and Staff Risk Management Booklet.
z USASC. Small Unit Risk Management Booklet.
Supply
F-12. Supply publications are—
z AR 700-138.
z CTA 50-900.
16 February 2007
FM 3-04.126
F-5
Appendix F
z CTA 50-909.
z DA Pam 710-2-1.
z DA Pam 710-2-2.
z FM 4-0.
z FM 100-9.
z Supply Bulletin 710-1-1.
Air Traffic Services Publications
F-13. Air Traffic Services publications are—
z FM 1-120 (will be revised as FM 3-04.120).
z FM 3-52.
z FM 3-52.2 (FM 100-103-2).
z JP 3-52
F-14. The publications listed below are Federal Aviation Administration publications.
z Aeronautical Information Manual.
z Air Traffic Bulletin.
z North Atlantic International GA Operations.
z NOTAM Publication (class II).
z Pilot/Controller Glossary.
z Federal Aviation Administration Order (FAAO) 3120.4L.
z FAAO 7000.5C.
z FAAO 7010.1S.
z FAAO 7110.10S.
z FAAO 7110.65R.
z FAAO 7210.3U.
z FAAO 7210.56C.
z FAAO 7340.1Y.
z FAAO 7350.7X.
z FAAO 7400.2F.
z FAAO 7450.1.
z FAAO 7610.4K.
z FAAO 7900.5B.
z FAAO 7930.2.
Training
F-15. Training publications are—
z FM 7-0.
z FM 7-1.
Other
F-16. The following are miscellaneous publications and forms:
z DA Form 1594. Daily Staff Journal or Duty Officer’s Log.
z DA Form 2028. Recommended Changes to Publications and Blank Forms.
z DA Pam 25-30.
z DA Pam 25-33.
z FM 1.
F-6
FM 3-04.126
16 February 2007
Reference Library
z FM 3-90.6.
z FM 7-20 (will be revised as FM 3-21.20).
z FM 8-10-26 (will be revised as FM 4-02.26).
z FM 20-3 (will be revised as FM 3-58.1).
z FM 100-13.
z JP 1-02.
SECTION II - WEBSITES
F-17. In the growing world of digital communications the World Wide Web and links found on it are an
expanding source of information. The military and Soldiers in general are using the internet more everyday
to communicate and locate information relating to their mission, equipment, threat and gain knowledge of
operational and leadership ideas and techniques relating to garrison and operational environments. Some
official web sites are—
z Reimer Digital Library-(www.train.army.mil), used to access military publications online.
z DOD Dictionary of Military Terms and Definitions-(www.dtic.mil).
z Active FM-Army Doctrine and Training Publications (www.army.mil/usapa/doctrine).
z Air War College References, on and offline-(www.au.af.mil).
z AKO-Online medium to access e-mail, publications, current events, links to other military
organizations and special project groups. (www.us.army.mil).
z Army Doctrine Online-(www.doctrine.army.mil).
z Army Homepage-(www.army.mil).
z Army Publishing Directorate (APD)-Home Page (www.apd.army.mil).
z CALL-Public Web Page-Gathers and provides information on lessons learned by Soldiers
conducting military operations. Information is available for downloading and provisions are
established for special requests (www.call.army.mil).
z Fort Rucker-Home of Army Aviation-Online interface providing information regarding
installation, Army aviation, units and directorates, current events and points of contact (www-
rucker.army.mil).
z Joint Electronic Library-Welcome (www.dtic.mil/doctrine).
z TRADOC Homepage-(www.monroe.army.mil).
z Warrant Officer Career Center-(www.usawocc.army.mil ).
16 February 2007
FM 3-04.126
F-7
Glossary
1SG
first sergeant
A&L
administrative and logistics
A2C2
Army airspace command and control
AA
assembly area
AAA
antiaircraft artillery
AAR
after-action review
AATF
air assault task force
ABCCC
airborne battlefield command and control center
ABCS
Army battle command system
ABF
attack by fire
ACA
airspace coordination area
ACE
air combat element
ACM
airspace coordinating measure
ACO
air control order
ACP
air control point
ACS
air cavalry squadron
ACT
air cavalry troop
AD
air defense
ADA
air defense artillery
ADU
air defense unit
ADVON
advanced party
AFTTP
Air Force tactics, techniques, and procedures
AGL
above ground level
AH
attack helicopter
AHT
assault helicopter troop
AKO
Army Knowledge Online
ALO
air liaison officer
ALSE
aviation life support equipment
ALSO
aviation life support officer
ALSS
aviation life support system
AMC
air mission commander
AMCOM
Aviation and Missile Command
AMO
aviation materiel officer
AMPS
aviation mission planning system
AMSS
Army materiel status system
ANCD
automated net control device
ANGLICO
air and naval gunfire liasion company
AO
area of operations
16 February 2007
FM 3-04.126
Glossary-1
Glossary
AOR
area of responsibility
APC
armored personnel carrier
AR
Army regulation
ARB
attack reconnassaince battalion
ARC
attack reconnaissance company
ARMS
aviation resource management survey
ARH
armed reconnaissance helicopter
ARP
airframe repair platoon
ARS
attack reconnaissance squadron
ART
attack reconnaissance troop
ARTEP
Army training and evaluation program
ASB
aviation support battalion
ASC
aviation support company
ASE
aircraft survivability equipment
ASL
authorized stockage list
ASOC
air support operations center
ATACMS
Army Tactical Missile System
ATF
aviation task force
ATGM
antitank guided missile
ATHP
ammuntion transfer holding point
ATM
aircrew training manual
ATO
air tasking order
ATP
aircrew training program
ATS
air traffic services
AWACS
Airborne Warning and Control System
BAE
brigade aviation element
BAS
battalion aid station
BCD
battlefield coordination detachment
BCM
basic combat manuever
BCT
brigade combat team
BDA
battle damage assessment
BDAR
battle damage assessment and repair
BHO
battle handover
BMNT
begin morning nautical twilight
BP
battle position
BSA
brigade support area
BUB
battle update briefing
C2
command and control
CA
civil affairs
CAB
combat aviation brigade
Glossary-2
FM 3-04.126
16 February 2007
Glossary
CALL
Center for Army Lessons Learned
CAP
combat air patrols
CAS
close air support
CASEVAC
casualty evacuation
CBAT
computer-based ASE training
CBRN
chemical, biological, radiological, and nuclear
CCA
close combat attack
CCIR
commander’s critical information requirement
CCM
close combat maneuver
CCP
casualty collection point
CFL
coordinated fire line
CLC
combat logistics convoy
COA
course of action
COMMEX
communications exercise
COMSEC
communications security
CONUS
continental United States
COP
commom operational picture
CP
command post
CRP
component repair platoon
CSAR
combat search and rescue
CSM
command sergeant major
CSR
controlled supply rate
CTA
common table of allowance
CTASC
corps/theater automated data processing service center
CTC
combat training center
CTL
commander’s task list
CVW
carrier air wing
D3A
decide, detect, deliver, and assess
DA
Department of the Army
DA Pam
Department of the Army pamphlet
DAAS
defense automatic addressing system
DAPP
downed aviator pickup point
DART
downed aircraft recovery team
DEW
directed-energy weapon
DIDEA
detect, identify, decide, engage, and assess
DNBI
disease and nonbattle injury
DOD
Department of Defense
DODAAC
Department of Defense Activity Address Code
DOS
days of supply
DP
decision point
16 February 2007
FM 3-04.126
Glossary-3
Glossary
DS
direct support
DSN
defense switch network
DST
decision support template
DTC
data transfer cartridge
EA
engagement area
ECOORD
effects coordinator
ELINT
electronic intelligence
EMT
emergency medical treatment
EO
electro-optical
EOD
explosive ordnance disposal
EPA
evasive plan of action
ERFS
extended range fuel system
ESR
external supported recovery
ETA
estimated time of arrival
ETE
estimated time en route
ETL
effective translational lift
EW
electronic warfare
FA
field artillery
FAA
forward assembly area
FAC (A)
forward air controller (airborne)
FAAO
Federal Aviation Administration Order
FARE
forward area refueling equipment
FARP
forward arming and refueling point
FBCB2
Force XXI Battle Command—Brigade and Below
FCR
fire control radar
FID
foreign internal defense
FLIR
forward-looking infrared
FLOT
forward line of own troops
FM
field manual, frequency modulated
FMI
field manual interim
FMT
forward maintenance team
FOB
forward operating base
FOV
field of view
FRAGO
fragmentary order
FS
fire support
FSC
forward support company
FSCL
fire support coordination line
FSCM
fire support coordinating measure
FSE
fire support element
FSO
fire support officer
Glossary-4
FM 3-04.126
16 February 2007
Glossary
FST
forward support troop
FW
fixed-wing
GPS
global positioning system
GS
general support
GSR
ground surveillance radar
HA
holding area
HAA
heavy assembly area
HBCT
heavy brigade combat team
HF
high frequency
HHC
headquarters and headquarters company
HHT
headquarters and headquarters troop
HMMWV
high mobility multi-purpose wheeled vehicle
HPT
high-payoff target
HPTL
high-payoff target list
HSC
headquarters and support company
HSS
health support service
HVT
high-value target
IA
interdiction attack
IATF
individual aircrew training folder
IBCT
infantry brigade combat team
IDM
improved data modem
IED
improvised explosive device
IFF
identification friend or for
IIMC
inadvertent instrument meteorological conditions
ILAP
integrated logistics analysis program
IMDC
isolated, missing, detained, or captured
INTREP
intelligence report
IP
instructor pilot
IPB
intelligence preparation of the battlefield
IR
infrared
ISOPREP
isolated personnel report
ISR
intelligence, surveillance, and reconnaissance
IZLID
infrared zoom laser illuminator designator
JAAT
joint air attack team
JAOC
Joint Force Operations Center
JFACC
joint force air component commander
JFC
Joint Force Commander
JP
joint publication
JPRC
joint personnel recovery center
J-SEAD
joint suppression of enemy air defenses
16 February 2007
FM 3-04.126
Glossary-5
Glossary
LAN
local area network
LAR
logistics assistant representative
LD
line of departure
LDO
laser designator operator
LNO
liaison officer
LOA
limit of advance
LOC
line of communications
LOGPAC
logistics package
LOGTAADS
Logistics Army Authorization Document System
LOS
line of sight
LP
listening post
LRP
logistics release point
LRU
line replaceable unit
LSA
logistics support area
LST
laser spot trackers
LTL
laser target line
LZ
landing zone
MAC
maintenance allocation chart
MCS
maneuver control system
MDMP
military decisionmaking process
MEDEVAC
medical evacuation
METL
mission essential task list
METT-TC
mission, enemy, terrain and weather, troops and support available, time
available, civil considerations
MGRS
military grid reference system
MMC
materiel management center
MOPP
mission-oriented protective posture
MOS
military occupational specialty
MP
maintenance test pilot
MRE
meal, ready to eat
MRLS
multiple launch rocket system
MSR
main supply route
MTOE
modified table of organization and equipment
MTP
mission training plan
NAI
named area of interest
NAVAID
navigational aid
NCO
noncommissioned officer
NCOIC
noncommissioned officer in charge
NEO
noncombatant evacuation operation
NFA
no fire area
NMC
not mission capable
Glossary-6
FM 3-04.126
16 February 2007
Glossary
NMP
National Maintenance Program
NOE
nap-of-the-earth
NOTAM
notice to airmen
NSFS
naval surface fire support
NVD
night vision device
NVG
night vision goggles
O&I
operations and intelligence
OAKOC
observation and fields of fire, avenues of approach, key terrain, obstacles and
movement, and cover and concealment
OCONUS
outside the continental United States
OH
observation helicopter
OP
observation post
OPCON
operational control
OPLAN
operational plan
OPORD
operating order
OPSEC
operations security
OPTEMPO
operating tempo
OSC
on-scene commander
P4T2
problem, plan, people, parts, time, and tools
PBO
property book officer
PBUSE
property book and unit supply system-enhanced
PC
pilot in command
PCC
precombat check
PCI
precombat inspection
PEO
peace enforcement operation
PFZ
priority fire zone
PIR
priority intelligence report
Pk
probability of kill
PKO
peacekeeping operation
PL
phase line
PLL
prescribed load list
PLS
palletized load system
PMCS
preventive maintenance checks and services
POL
petroleum, oils, and lubricants
PP
passage point
PPC
performance planning card
PPM
progressive phase maintenance
PR
personnel recovery
PRCC
personnel recovery coordination cell
PRO
personnel recovery officer
PSYOPS
psychological operations
16 February 2007
FM 3-04.126
Glossary-7
Glossary
PZ
pickup zone
QA
quality assurance
QRF
quick reaction force
R&S
reconnaissance and surveillance
REDCON
readiness condition
RESCORT
rescue escort
RETRANS
retransmission
RF
radar frequency
RFA
restricted fire area
RMB
rescue mission brief
RMC
rescue mission commander
ROE
rules of engagement
ROI
rules of instruction
ROZ
restricted operating zone
RP
release point
RSR
required supply rate
RTD
return to duty
RTF
return to force
RTO
radio telephone operator
RX
reparable exchange
S-1
personnel staff officer
S-2
intelligence staff officer
S-3
operations staff officer
S-4
logistics staff officer
S-6
command, control, communications, and computer operations (C4 Ops) officer
SA
situational awareness
SAMS
standard Army maintenance system
SAMS-1
standard Army maintenance system-level 1
SAMS-2
standard Army maintenance system-level 2
SAMS-E
standard Army maintenance system-enhanced
SAR
search and rescue
SARIR
search and rescue incident report
SARSS
standard Army retail supply system
SARSS-1
standard Army retail supply system-level 1
SARSS-2
standard Army retail supply system-level 2
SARSS-Gateway
standard Army retail supply system-gateway
SATCOM
satellite communication
SBCT
Stryker brigade combat team
SBF
support by fire
SCAR
security clearance access roster
Glossary-8
FM 3-04.126
16 February 2007
Glossary
SEAD
suppression of enemy air defense
SECM
shop equipment contact maintenance
SINCGARS
single-channel ground and airborne radio system
SITREP
situation report
SKO
sets. kits, and outfits
SKOT
sets, kits, outfits, and special tools
SM
Soldier’s manual
SO
safety officer
SOI
signal operation instructions
SOP
standing operating procedure
SP
standardization instructor pilot
SPINS
special instructions
SPOTREP
spot report
SSA
supply support activity
SSM
surface-to-surface missile
STAMIS
standard army management information system
STP
Soldier training publication
STX
situational training exercise
SU
situational understanding
SWT
scout weapons team
TA
target acquisition
TAC CP
tactical command post
TACFIRE
tactical fire direction system
TACON
tactical control
TACOPS
tactical operations
TACSOP
tactical standing operating procedure
TB
technical bulletin
TC
training circular
TCF
tactical combat force
TCP
traffic control point
TDH
time, distance, and heading
TF
task force
TG
trainer’s guide
TLP
troop leading procedures
TM
technical manual
TOC
tactical operations center
TOC NCOIC
tactical operations center noncommissioned officer in charge
TOE
table of organization and equipment
TOT
time on target
TRP
target reference point
16 February 2007
FM 3-04.126
Glossary-9
Glossary
TTP
tactics, techniques, and procedures
TTT
time to target
UAS
unmanned aerial system
UBL
unit basic load
UH
utility helicopter
UHF
ultra high frequency
UIC
unit identification code
ULLS
unit-level logistics system
ULLS-A
unit-level logistics system-aviation
ULLS-S4
unit-level logistics system-logistics staff officer
UMT
unit ministry team
USAAWC
United States Army Aviation Warfighting Center
USASC
United States Army Safety Center
VBIED
vehicle-borne improvised explosive device
VHF
very high frequency
WARNO
warning order
WFF
warfighting function
XO
executive officer
Glossary-10
FM 3-04.126
16 February 2007
References
The bibliography lists FMs by new number followed by old number. These publications are sources for
additional information on the topics in this FM. Most JPs can be found at http://www.dtic.mil/doctrine/jel/.
Most Army doctrinal publications are available online at http://155.217.58.58/atdls.html. FAA Orders can
be found at http://www.faa.gov/ATpubs/.
SOURCES USED
These are the sources quoted or paraphrased in this publication.
ARMY PUBLICATION
AR 95-1. Flight Regulations. 3 February 2006.
AR 700-138. Army Logistics Readiness and Sustainability. 26 February 2004.
COMMON TABLE OF ALLOWANCES
CTA 8-100. Army Medical Department Expendable/Durable Items. 17 December 2004.
CTA 50-900. Clothing and Individual Equipment. 2 October 2006.
CTA 50-909. Field and Garrison Furnishings and Equipment. 26 September 2006.
FIELD MANUALS
FM 1 (FM 100-1). The Army. 14 June 2005.
FM 1-100. Army Aviation Operations. 21 February 1997.
FM 1-120. Army Air Traffic Services Contingency and Combat Zone Operations. 22 May 1995.
FM 3-0 (FM 100-5). Operations. 14 June 2001.
FM 3-04.111. Aviation Brigades. 21August 2003.
FM 3-04.140. Helicopter Gunnery. 14 July 2003.
FM 3-04.500. Army Aviation Maintenance. 23 August 2006.
FM 3-04.513 (FM 1-513). Battlefield Recovery and Evacuation of Aircraft. 27 September 2000.
FM 3-06. Urban Operation. 1 June 2003.
FM 3-06.1 (FM 1-130). Aviation Urban Operations Multiservice Procedures for Aviation Urban
Operations. 9 July 2005.
FM 3-06.11 (FM 90-10-1). Combined Arms Operations in Urban Terrain. 28 February 2002.
FM 3-09.32 (FM 90-20). Multiservice Procedures for the Joint Application of Firepower. 29 October
2004.
FM 3-20.96. Cavalry Squadron (RSTA). 20 September 2006.
FM 3-50.1. Army Personnel Recovery. 10 August 2005.
FM 3-90. Tactics. 4 July 2001.
FM 4-0 (FM 100-10). Combat Service Support. 29 August 2003.
FM 4-30.31. Recovery and Battlefield Damage Assessment and Repair. 19 September 2006.
FM 5-0 (FM 101-5). Army Planning and Orders Production. 20 January 2005.
FM 6-0. Mission Command: Command and Control of Army Forces. 11 August 2003.
FM 7-1. Battle Focused Training. 15 September 2003.
FM 10-1. Quartermaster Principles. 11 August 1994.
FM 17-95. Cavalry Operations. 24 December 1996.
16 February 2007
FM 3-04.126
References-1
References
FM 34-130. Intelligence Preparation of the Battlefield. 8 July 1994.
FM 90-21. (JAAT) Multiservice Procedures for Joint Air Attack Team Operations. 3 June 1998.
FM 101-5-2. U.S. Army Report and Message Formats. 29 June 1999.
FIELD MANUAL INTERIMS
FMI 4-90.1. Heavy Brigade Combat Team Logistics. 15 March 2005.
FMI 5-0.1. The Operations Process. 31 March 2006.
JOINT PUBLICATIONS
JP 1-02. Department of Defense Dictionary of Military and Associated Terms. 14 April 2006.
JP 3-09.3. Joint Tactics, Techniques, and Procedures for Close Air Support (CAS). 3 September 2003.
JP 3-09.1. Joint Tactics, Techniques, and Procedures for Laser Designation Procedures (JLASER).
28 May 1999.
JP 3-30. Command and Control for Joint Air Operations. 5 June 2003.
JP 3-52. Joint Doctrine Airspace Control in a Combat Zone. 30 August 2004.
JP 3-60. Joint Doctrine for Targeting. 17 January 2002.
JP 4-0. Doctrine for Logistic Support of Joint Operations. 6 April 2000.
JP 4-03. Joint Bulk Petroleum and Water Doctrine. 23 May 2003.
TRAINING CIRCULARS
TC 1-400. Brigade Aviation Element Handbook. 27 April 2006.
TC 1-201. Tactical Flight Procedures. 20 January 1984.
TC 1-210. Aircrew Training Program Commander’s Guide to Individual, Crew, and Collective
Training. 20 June 2006.
TECHNICAL MANUALS
TM 1-1520-248-10. Operator's Manual for Army OH-58D Helicopter. 15 March 2005.
TM 750-244-1-5. Procedures for the Destruction of Aircraft and Associated Equipment to Prevent
Enemy Use. 12 November 1971.
DOCUMENTS NEEDED
These documents must be available to the intended users of this publication.
DEPARTMENT OF THE ARMY FORMS
DA Form 1594. Daily Staff Journal or Duty Officer’s Log.
DA Form 2028. Recommended Changes to Publications and Blank Forms.
DA Form 5484. Mission Schedule/Brief.
DA Form 7573. Aircraft Survivability Equipment (ASE) Risk Assessment Worksheet Survivability Risk
Analysis.
DEPARTMENT OF DEFENSE FORMS
DD Form 1972. Joint Tactical Air Strike Request.
DD Form 1833. Isolated Personnel Report.
References-2
FM 3-04.126
16 February 2007
References
READINGS RECOMMENDED
These sources contain relevant supplemental information.
Aviation Liaison Officer Handbook, United States Army Aviation Center. July 2001.
AR 200-1. Environmental Protection and Enhancement. 21 February 1997.
AR 385-40. Accident Reporting and Records. 1 November 1994.
AR 385-64. U.S. Army Explosives Safety Program. 1 February 2000.
AR 385-95. Army Aviation Accident Prevention. 10 December 1999.
AR 600-55. The Army Driver and Operator Standardization Program (Selection, Training, Testing,
and Licensing). 31 December 1993.
AR 710-2. Supply Policy Below the National Level. 8 July 2005.
ARTEP 1-111-MTP. Mission Training Plan for the Aviation Brigades. 27 October 2005.
ARTEP 1-113-MTP. Mission Training Plan for the Assault Helicopter Battalion. 29 December 2005.
ARTEP 1-118-MTP. General Support Aviation Battalion. 17 January 2006.
ARTEP 1-126-MTP. Mission Training Plan for the Attack Reconnaissance Helicopter
Battalion/Squadron. 8 March 2006.
ARTEP 1-245-MTP. Mission Training Plan for the Heavy Lift Helicopter Battalion. 31 August 2001.
ARTEP 1-425-MTP. Mission Training Plan for the Air Traffic Services Battalion. 19 December 2002.
ARTEP 1-500-MTP. Aviation Intermediate Maintenance (AVIM) Battalion and Company. 1 April
2002.
DA Pam 25-30. Consolidated Index of Army Publications and Blank Forms.
DA Pam 25-33. User’s Guide for Army Publications and Forms.
DA Pam 385-40. Army Accident Investigation and Reporting.
DA Pam 385-64. Ammunition and Explosives Safety Standards.
DA Pam 710-2-1. Using Unit Supply System (Manual Procedures).
DA Pam 710-2-2. Supply Support Activity Supply System: Manual Procedures.
DODD 2000.12. DOD Antiterrorism (AT) Program. 18 August 2003.
EM 0007. FEDLOG. 1 October 2006. (S&I, Commander, USAMC Logistics Support Activity, ATTN:
AMXLS-MLA, (A. LEWIS) Bldg 5307, Redstone Arsenal, Al 35898-7466.)
EM 0126. TM 1-1520-Longbow/Apache. Interactive Electronic Technical Manual for
Longbow/Apache. 27 December 2005.
EM 0253. TM 1-1520-248-S. Interactive Electronic Technical Manual for Preparation for Shipment
of Army Model OH-58D Helicopter. 30 June 2004.
FAAO 3120.4L. Air Traffic Technical Training .22 June 2005.
FAAO 7000.5C. Submissions for Air Traffic Publications. 18 October 2001.
FAAO 7010.1S. Air Traffic Control Safety and Audits. 1 October 2005.
FAAO 7110.10S. Flight Services. 3 August 2006.
FAAO 7110.65R. Air Traffic Control. 3 August 2006.
FAAO 7210.3U. Facility Operation and Administration. 3 August 2006.
FAAO 7210.56C. Air Traffic Quality Assurance. 15 August 2002.
FAAO 7340.1Y. Contractions. 3 August 2006.
FAAO 7350.7X. Location Identifiers. 3 August 2006.
FAAO 7400.2F. Procedures for Handling Airspace Matters. 3 August 2006.
FAAO 7450.1. Special Use Airspace Management System. 21 June 1999.
16 February 2007
FM 3-04.126
References-3
References
FAAO 7610.4K. Special Military Operations. 5 August 2004.
FAAO 7900.5B. Surface Weather Observing. 11 May 2001.
FAAO 7930.2. Notices to Airmen (NOTAMs). 16 February 2006.
FM 1-02. Operational Terms and Graphics. 21 September 2004.
FM 1-113. Utility and Cargo Helicopter Operations. 12 September 1997.
FM 1-564. Shipboard Operations. 29 June 1997.
FM 2-0 (FM 34-1). Intelligence and Electronic Warfare Operations. 27 February 1994.
FM 3-01.4. J-SEAD, Multiservice Tactics, Techniques, and Procedures (MTTP) for Joint Suppression
of Enemy Air Defenses (U). 28 May 2004.
FM 3-04.104. Tactics, Techniques, and Procedures for Forward Arming and Refueling Point. 3
August 2006.
FM 3-04.300. Flight Operations Procedures. 26 April 2004.
FM 3-04.301. Aeromedical Training for Flight Personnel. 29 September 2000.
FM 3-04.303. Air Traffic Services Facility Operations, Training, Maintenance, and Standardization. 3
December 2003.
FM 3-04.508 (FM 1-508). Maintaining Aviation Life Support System Maintenance Management and
Training Programs. 23 April 2004.
FM 3-05.30 (FM 33-1). Psychological Operations. 15 April 2005.
FM 3-05.60 (FM 1-108). Army Special Operations Forces Aviation Operations. 16 October 2000.
FM 3-07 (FM 100-23). Stability Operations and Support Operations. 20 February 2003.
FM 3-07.31. Peace Operations Multiservice Tactics, Techniques, and Procedures for Conducting
Peace Operations. 26 October 2003.
FM 3-13. Information Operations:Doctrine, Tactice, Techniques, and Procedures.. 28 November
2003.
FM 3-19.1 (FM 19-1). Military Police Operations. 22 March 2001.
FM 3-21.38. Pathfinder Operations. 25 April 2006.
FM 3-35.4. Deployment Fort-to-Port. 19 June 2002.
FM 3-50.3. Multi-Service Procedures for Survival, Evasion and Recovery. 19 March 2003.
FM 3-52 (FM 100-103). Army Airspace Command and Control in a Combat Zone. 1 August 2002.
FM 3-52.2 (FM 100-103-2). Multi-Service Procedures for the Theater Air-Ground System. 8
December 2003.
FM 3-90.1 (FM 71-1). Tank and Mechanized Infantry Company Team. 9 December 2002.
FM 3-90.6. The Brigade Combat Team. 4 August 2006.
FM 3-90-96. Cavalry Squadron (RSTA). 20 September 2006.
FM 3-100.4. Environmental Considerations in Military Operations. 15 June 2000.
FM 3-100.12. Risk Management Multiservice Tactics, Techniques, and Procedures for Risk
Management. 15 February 2001.
FM 4-01.011 (FM 55-65). Unit Movement Operations. 31 October 2002.
FM 4-01.45. Multi-Service Tactics, Techniques, and Procedures for Convoy Operations. 24 March
2005.
FM 4-20.197 (FM 10-450-3). Multiservice Helicopter Sling Load: Basic Operations and Equipment.
20 July 2006.
FM 5-34. Engineer Field Data. 19 July 2005.
FM 5-103. Survivability. 10 June 1985.
FM 6-20. Fire Support in the AirLand Battle. 17 May 1988.
References-4
FM 3-04.126
16 February 2007
References
FM 6-20-40. Tactics, Techniques, and Procedures for Fire Support For Brigade Operations (Heavy).
5 January 1990.
FM 6-20-50. Tactics, Techniques, and Procedures for Fire Support for Brigade Operations (Light). 5
January 1990.
FM 7-0. Training the Force. 22 October 2002.
FM 7-15. The Army Universal Task List. 31 August 2003.
FM 7-20. The Infantry Battalion. 6 April 1992.
FM 8-10-26. Employment of the Medical Company (Air Ambulance). 16 February 1999.
FM 10-67-1. Concepts and Equipment of Petroleum Operations. 2 April 1998.
FM 20-3. Camouflage, Concealment, and Decoys. 30 August 1999.
FM 34-2-1. Tactics, Techniques, and Procedures for Reconnaissance and Surveillance and
Intelligence Support to Counterreconnaissance. 19 Jun 91.
FM 34-60. Counterintelligence. 3 October 1995.
FM 55-30. Army Motor Transport Units and Operations. 15 September 1999.
FM 55-450-2. Army Helicopter Internal Load Operations. 5 June 1992.
FM 71-100. Division Operations. 28 August 1996.
FM 71-100-2. Infantry Division Operations, Tactics, Techniques, and Procedures. 31 August 1993.
FM 71-100-3. Air Assault Division Operations Tactics, Techniques, And Procedures. 29 October
1996.
FM 90-4. Air Assault Operations. 16 March 1987.
FM 100-8. The Army in Multinational Operations. 24 November 1997.
FM 100-9. Reconstitution. 13 January 1992.
FM 100-13. Battlefield Coordination Detachment. (BCD). 5 September 1996.
FM 100-14. Risk Management. Change 1. 8 August 2005.
FM 100-15. Corps Operations. 29 October 1996.
FM 100-17-3. Reception, Staging, Onward Movement, and Integration. 17 March 1999.
FM 100-17-5. Redeployment. 29 September 1999.
FMI 3-04.155. Army Unmanned Aircraft System Operations. 4 April 2006.
GTA 05-08-001. Survivability Positions. 1 August 1993.
JP 3-0. Joint Operations. 17 September 2006.
JP 3-01.4. JTTP for Joint Suppression of Enemy Air Defenses (J-SEAD). 25 July 1995.
JP 3-09. Doctrine for Joint Fire Support. 12 May 1998.
JP 3-50.2. Doctrine for Joint Combat Search and Rescue. 26 January 1996.
JP 3-50.21. Joint Tactics, Techniques and Procedures for Combat Search and Rescue. 23 March 1998.
SDDCTEA Pamphlet 55-19. Tie-down Handbook for Rail Movements. September 2003. (Surface
Deployment and Distribution Command Transportation Engineering Agency Fort Eustis,
Virginia).
SDDCTEA Pamphlet 55-20. Tie-down Handbook for Truck Movements. July 2001. (Surface
Deployment and Distribution Command Transportation Engineering Agency Fort Eustis,
Virginia ).
SDDCTEA Pamphlet 55-21. Lifting and Tiedown Handbook for U.S. Military Helicopters. June 2006.
(Surface Deployment and Distribution Command Transportation Engineering Agency Fort
Eustis, Virginia).
SDDCTEA Pamphlet 55-22. Lashing Handboo for Marine Movements. August 2005. (Surface
Deployment and Distribution Command Transportation Engineering Agency Fort Eustis,
Virginia).
16 February 2007
FM 3-04.126
References-5
References
SDDCTEA Pamphlet 55-23. Tiedown Handbook for Containerized Movements. September 2003.
(Surface Deployment and Distribution Command Transportation Engineering Agency Fort
Eustis, Virginia).
SDDCTEA Pamphlet 55-24. Vehicle Preparation Handbook for Fixed Wing Air Movements. 2002.
(Surface Deployment and Distribution Command Transportation Engineering Agency Fort
Eustis, Virginia).
SDDCTEA Pamphlet 70-1. Transportability for Better Deployability. 2003. (Surface Deployment and
Distribution Command Transportation Engineering Agency Fort Eustis, Virginia).
SDDCTEA Pamphlet 700-2. Logistics Handbook for Strategic Mobility Planning. 2002. (Surface
Deployment and Distribution Command Transportation Engineering Agency Fort Eustis,
Virginia).
SDDCTEA Pamphlet 700-4. Vessel Characteristics for Shiploading. 2001. (Surface Deployment and
Distribution Command Transportation Engineering Agency Fort Eustis, Virginia).
SDDCTEA Pamphlet 700-5. Deployment Planning Guide. 2001. (Surface Deployment and
Distribution Command Transportation Engineering Agency Fort Eustis, Virginia).
SDDCTEA Pamphlet 700-6. Large, Medium-Speed Roll-on/Roll-off (RORO) (LMSR) Users’ Manual.
2002. (Surface Deployment and Distribution Command Transportation Engineering Agency
Fort Eustis, Virginia).
STP 1-15D13-SM-TG. Soldier's Manual and Trainer's Guide for MOS 15D, Aircraft Powertrain
Repairer, Skill Levels 1 and 3. 27 October 2004.
STP 1-15M13-SM-TG. Soldier's Manual and Trainer's Guide for MOS 15M, UH-1 Helicopter
Repairer, Skill Levels 1, 2, and 3. 26 October 2004.
STP 1-15T13-SM-TG. Soldier's Manual and Trainer's Guide, MOS 15T, UH-60 Helicopter Repairer,
Skill Levels 1, 2, and 3. 6 January 2005.
STP 1-15U13-SM-TG. Soldier's Manual and Trainer's Guide for MOS 15U, CH-47D Helicopter
Repairer, Skill Levels 1, 2, and 3. 29 October 2004.
STP 1-93C1-SM-TG. Soldier's Manual and Trainer's Guide, MOS 93C, Air Traffic Control, Skill
Level 1. 1 March 2002.
STP 1-93C24-SM-TG. Soldier's Manual and Trainer's Guide, MOS 93C, Air Traffic Control, Skill
Levels 2/3/4. 4 June 2002.
STP 1-93P1-SM-TG. Soldier's Manual and Trainer's Guide, MOS 93P, Aviation Operations
Specialist, Skill Level 1. 1 October 2002.
STP 1-93P24-SM-TG. Soldier's Manual and Trainer's Guide, MOS 93P, Aviation Operations
Specialist, Skill Levels 2/3/4. 1 October 2002.
TC 1-218. Aircrew Training Manual Utility Airplane C-12. 13 September 2005.
TC 1-219. Aircrew Training Manual, Guardrail Common Sensor Airplane RC-12. 3 June 2002.
TC 1-228. Aircrew Training Manual, OH 58-A, Kiowa Helicopter. 13 June 2006.
TC 1-237. Aircrew Training Manual, Utility Helicopter, H-60 Series. 27 September 2005.
TC 1-238. Aircrew Training Manual, Attack Helicopter, AH-64A. 23 September 2005.
TC 1-240. Aircrew Training Manual Cargo Helicopter, CH-47D. 12 September 2005.
TC 1-248. Aircrew Training Manual, OH-58D, Kiowa Warrior. 12 September 2005.
TC 1-251. Aircrew Training Manual Attack Helicopter AH-64D. 14 September 2005.
TC 1-600. Unmanned Aircraft Systems Commander's Guide and Aircrew Training Manual. 23 June
2006.
TM 1-1500-204-23-1. Aviation Unit Maintenance (AVUM) and Aviation Intermediate Maintenance
(AVIM) Manual for General Aircraft Maintenance (General Maintenance and Practices)
Volume 1. 31 July 1992.
References-6
FM 3-04.126
16 February 2007
References
TM 1-1520-237-S. Preparation for Shipment of Army Models, UH-60A, UH-60L, EH-60A, UH-60Q
and HH-60L Helicopters. 17 April 2006.
TM 1-1520-252-S. Preparation for Shipment of MH-47E Helicopter. 28 June 1995.
TM 55-1520-238-S. Preparation for Shipment Army AH-64A Helicopter. 30 September 1990.
TM 55-1520-241-S. Preparation for Shipment of CH-47 Helicopter. 1 March 1979.
TM 55-1560-307-13&P. Operator, Aviation Unit and Aviation Intermediate Maintenance Manual
With Repair Parts and Special Tools List for Extended Range Fuel System Army Model CH-
47 Helicopter. 11 December 1990.
Unit Movement Officer (UMO) Deployment Handbook Reference 97-1, U.S. Army Transportation
School, Fort Eustis, VA.
USASC. Commander and Staff Risk Management Booklet. 6 January 1999.
USASC. Small Unit Risk Management Booklet. 6 January 1999.
16 February 2007
FM 3-04.126
References-7
Index
airborne warning and control
Army tactical missile system
A
system (AWACS), C-4
(ATACMS), C-16
action on contact, 1-4, 1-5, 2-
aircraft maintenance platoon,
Army warfighting function, 1-2,
19, 2-22, 2-35, 2-36, 3-2, 3-
1-9, 1-11
2-16
12, 3-17, 3-20, 3-31, 3-39, 3-
49, 3-51, 3-58, 3-59, 3-82, 3-
aircraft survivability equipment
assault helicopter troop (AHT),
86, A-6
(ASE), 2-10, 2-22, 2-28, 2-
1-5, 1-9, 1-11
29, 2-32, 2-33, 2-37, 3-33, 3-
action on the objective, 2-36
assembly area (AA), 1-4, 2-6,
99, 3-120, A-1, A-2, A-4, A-
2-8, 2-19, 2-20, 2-22, 2-29,
administrative and logistics
6, A-7, A-8, A-9
2-32, 2-36, 3-21, 3-27, 3-55,
(A&L), 2-3, 2-4, 2-13
aircraft survivability equipment
3-82, 3-114, 3-116, 3-117, 3-
advanced party (ADVON), 3-96
trainer (ASET), A-8, A-9
119
aerial observation, 3-10
aircrew training manual (ATM),
assigned, C-1, C-5, C-8
aerial reconnaissance, C-8
2-35, 3-69, A-8
Assistant Chief of Staff,
aerial vehicle (AV), C-17
aircrew training program (ATP),
Operations and Plans (G3),
2-28, 2-29, A-8
C-5, C-7
after-action review (AAR), 2-40
airframe repair platoon (ARP),
attached, C-2
AH-64A, C-1
1-11, 4-12, 4-13
attack by fire (ABF), 2-33, 2-34,
air assault, 1-3, 1-4, 3-28, 3-30,
air-ground integration, 3-3
3-7, 3-19, 3-21, 3-59, 3-64,
3-50, 3-52, 3-53, 3-54, 3-86,
3-82, 3-84, 3-85, 3-86, 3-94,
3-91, 3-110, 3-111, 3-116, 3-
airspace, 1-6, 2-10, 2-17, 3-8,
3-110, 3-117, 3-119, 4-23, A-
121, B-4
3-91, 3-97, 3-99, 3-111, 4-
4, B-3, C-6
10, B-10, D-5
air assault task force, 2-26
attack guidance, 2-24, 3-12
airspace coordinating measure
air control order (ACO), 2-22,
(ACM), 2-11, C-8, C-10, C-
attack guidance matrix, 2-24
2-32, 2-33
11, C-16
attack operation, 1-3, 3-85, 3-
air defense (AD), C-3, C-4, C-
airspace coordination area
86
5, C-6
(ACA), C-8, C-10
authorized stock level (ASL), 4-
air defense artillery (ADA), C-6,
airspace management, 2-10
5, 4-19
C-13
airspace workstation, 2-2
avenue of approach, 3-14, 3-
air interdiction, 2-24
25, 3-26, 3-27, 3-33, 3-35, 3-
ambush, 3-22, 3-42, 3-48, 3-
air liaison officer (ALO), 2-5, 2-
36, 3-41, 3-42, 3-45, 3-52, 3-
49, 3-111
15, B-10, C-7
54, 3-74, 3-75, 3-76, 3-94, 3-
air mission commander (AMC),
ammunition transfer holding
110
point (ATHP), 4-19
2-27, 2-28, 2-31, 2-33, 2-39,
avenues of approach, C-3
3-2, 3-3, 3-10, 3-50, 3-58, 3-
area of operations (AO), C-1,
aviation battalion task force
62, 3-64, 3-80, 3-89, 3-90, 3-
C-2, C-4, C-17
(ABTF), 2-23, 2-26, 3-1, B-2
91, 3-94, 4-6, B-2, B-3, C-
armament maintenance officer,
11, C-13, D-6, D-16
aviation life support equipment
2-30
(ALSE), 2-30, 3-113, 4-25
air movement, 1-3, 1-3, 2-19,
armorer, 2-13, 2-14, 4-16
3-28, 3-50, 3-52, 3-53, 3-95
aviation life support officer
Army airspace command and
(ALSO), 2-30
air route, 3-21, 3-23
control (A2C2), 1-6, 1-9, 2-4,
aviation life support system
air support, C-3, C-7
2-9, 2-10, 2-11, 2-35, 3-119,
(ALSS), 2-30, 4-25
operations center, C-3
B-2, B-3, C-5
aviation maintenance
air tasking order (ATO), 2-9, 2-
Army battle command system
company, 1-5, 1-9, 2-12, 4-1,
22, 3-89, 3-97, C-4, C-7
(ABCS), 2-2
4-2, 4-6, 4-7, 4-9, 4-12, 4-13,
air traffic services (ATS), 2-10,
Army Tactical Command and
4-17, 4-19, 4-20, 4-24
4-14
Control System (ATCCS), 2-
aviation maintenance troop, 1-
2, 2-9
airborne warning and control
9, 1-11
system, 3-120
16 February 2007
FM 3-04.126
Index-1
Index
aviation materiel officer (AMO),
3-86, 3-110, 3-119, B-2, B-3,
close air support (CAS), 2-10,
2-12
C-5, C-6, C-12
2-17, 2-24, 2-29, 3-3, 3-19,
3-54, 3-58, 3-59, 3-63, 3-64,
aviation mission planning
battle rhythm, 2-9, 3-13, 3-19
3-75, 3-78, 3-88, 3-109, B-3,
system (AMPS), 2-2, 2-10,
battle update briefing (BUB), 2-
B-4, B-10, C-2, C-4, C-11,
2-29, 2-32, 2-33, 2-34, 2-35,
18
C-12, C-19
3-7, 3-38, 3-112, A-4, A-6,
battlefield geometry, 3-16
B-9
close combat, 1-4, 3-11, 3-19
boundaries, 2-1, 3-23, 3-24, 3-
aviation support battalion
close combat attack (CCA), 1-
25, 3-26, 3-27, 3-28, 3-99
(ASB), 1-5, 1-9, 2-12, 2-13,
3, 1-4, 3-3, 3-40, 3-42, 3-48,
4-1, 4-2, 4-3, 4-4, 4-5, 4-7,
bounding overwatch, 3-6, 3-9,
3-52, 3-53, 3-54, 3-59, 3-60,
4-9, 4-13, 4-14, 4-15, 4-16,
3-10, 3-36
3-61, 3-62, 3-63, 3-110, 3-
4-17, 4-18, 4-19, 4-20, 4-21,
brigade aviation element
111, 3-116
4-23
(BAE), 2-2, 2-10, B-2, B-10
close combat maneuver
aviation support company
brigade combat team (BCT), 2-
(CCM), 3-119
(ASC), 4-1, 4-5, 4-6, 4-7, 4-
10, C-5
cloverleaf, 3-62
12, 4-17, 4-19, 4-20, 4-22, 4-
brigade support battalion, 1-10
collective task, 2-28, 2-40
24
bump plan, 2-22, 2-38
combat air patrol (CAP), C-4
aviation support troop, 1-9, 1-
bypass, 1-4, 3-2, 3-11, 3-12, 3-
combat aviation brigade (CAB),
11
13, 3-16, 3-19, 3-22, 3-23, 3-
1-5, 1-6, 2-2, 2-34, 3-114, 4-
axis of advance, 3-39, 3-41, 3-
26, 3-27, 3-42, 3-48, 3-53, 3-
1, 4-3, 4-6, 4-7, 4-9, 4-17, 4-
42, 3-43, 3-44
63, 3-82, 4-2
19, B-10
B
combat cruise, 3-4, 3-5
C
backbrief, 2-35
combat cruise left and right, 3-4
call for fire, 2-37, 3-2
basic combat maneuver
combat load, 4-4
casualty collection point (CCP),
(BCM), 3-2
2-21
combat logistics patrol (CLP),
basic combat maneuvers, 3-51
4-2
casualty evacuation
basic load, 2-21, 4-4
(CASEVAC), 1-5, 2-36, 2-37,
combat search and rescue
battalion aid station (BAS), 4-
3-50, 3-111
(CSAR), 3-87, 3-89
17
center of gravity, 3-15
combat spread, 3-4, 3-6, 3-51
battalion support area (BSA),
chaplain, 2-8, 4-16
combat training center (CTC),
4-3, 4-14
A-8
checklist, 2-11, 2-31, 2-35, B-7,
battle captain, 2-15
D-1
command and control (C2), xi,
battle command, 1-9, 2-13, 4-5
1-2, 1-5, 1-6, 2-1, 2-2, 2-3,
checkpoint, 2-19, 3-22, 3-23, 3-
2-5, 2-14, 2-15, 2-16, 2-17,
battle damage assessment
26, 3-91, 3-99, 3-100, 3-118
2-18, 2-19, 2-20, 2-22, 3-2,
(BDA), 2-8, 2-24, 2-25, 2-37,
chemical officer, 2-11
3-14, 3-31, 3-36, 3-47, 3-49,
2-39, 3-61, 3-62, 3-63, 3-83,
chemical, biolgical, radiological,
3-50, 3-61, 3-63, 3-82, 3-83,
3-119, C-7
and nuclear (CBRN), 1-6, 1-
3-89, 3-90, 3-94, 3-95, 3-97,
battle damage assessment and
9, 2-11, 2-12, 2-14, 2-18, 2-
3-100, 3-118, 4-2, 4-10, 4-
repair (BDAR), 4-9
20, 2-21, 3-24, 3-25, 3-119,
14, 4-16, B-4, C-3, C-4, C-7,
battle damage assessment
4-16, D-3, D-4, D-14, D-15
C-13
repair (BDAR), 4-9, 4-12, 4-
chemical, biological,
system, C-3
13, 4-16, 4-17
radiological, and nuclear
command group, 1-6, 2-5, 3-
battle drill, 2-2, 2-35, 2-40, 3-
(CBRN), 1-6
13, 4-16
12, 3-58, 3-63, 3-89, B-8
civil affairs (CA), 2-24, 3-13
command net, 2-3
battle handover (BHO), 2-39, 3-
civil support, 1-2, 3-1, 3-14, 3-
command post (CP), 1-6, 1-9,
3, 3-19, 3-25, 3-38, 3-56, 3-
95, 3-96, 3-97, 3-98, 4-23
2-3, 2-4, 2-5, 2-12, 2-13, 2-
58, 3-86, 3-118, 3-119
civil-military operations officer
14, 2-15, 2-16, 2-17, 2-18, 2-
battle handover line, 3-117
(S9), 2-15
19, 2-20, 2-21, 2-26, 2-27, 4-
16, B-9, D-11
battle position (BP), 2-36, 3-7,
class of supply, 2-12
3-21, 3-37, 3-41, 3-42, 3-43,
command relationships
clearance of fire, 2-37
3-44, 3-64, 3-74, 3-75, 3-77,
assigned, C-1, C-5, C-8
3-78, 3-82, 3-83, 3-84, 3-85,
attached, C-2
Index-2
FM 3-04.126
16 February 2007
Index
operational control
27, 3-33, 3-38, 3-49, 3-61, 3-
Defense Finance and
(OPCON), C-8
73, 3-76, 3-78, 3-80, 3-116,
Accounting Service, 4-24
tactical control (TACON), C-
3-117, 3-118, 3-119, B-2, B-
defensive operation, 2-17
1, C-8
8, B-9, D-3
defensive operations, C-1
command sergeant major
control point, 3-91
deferred maintenance, 2-27, 4-
(CSM), 2-6, 2-18, D-2, D-16
controlled supply rate (CSR), 4-
9
commander, C-1, C-2, C-3, C-
4
delay, 1-2, 2-25, 3-32, 3-33, 3-
4, C-5, C-7, C-8, C-13
convoy, 1-2, 1-3, 2-19, 2-20, 3-
42, 3-44, 3-63, 4-8, A-6
air mission (AMC), C-11, C-
48, 3-49, 3-50, 3-97, 4-15,
13
demonstration, 1-3, 3-120, 3-
D-2, D-3, D-11
joint force (JFC), C-1, C-8
121
convoy security, 1-3, 3-31, 3-
joint force air component
Department of Defense (DOD),
46, 3-48, 3-49, 4-15
(JFACC), C-8
3-87
mission (MC), C-1, C-2, C-
coordinated fire line (CFL), 3-
direct fire, 2-8, 3-2, 3-12, 3-13,
3, C-4, C-5, C-8, C-10, C-
16
3-18, 3-20, 3-23, 3-32, 3-37,
14, C-17, C-19
coordinating staff, 1-7, 2-7
3-40, 3-41, 3-42, 3-59, 3-63,
commander’s critical
coordination point, 3-26
3-71, 3-73, 3-74, 3-75, 3-76,
intelligence requirement
3-77, 3-80, 3-82, 3-83, 3-87,
cordon and search, 3-45
(CCIR), 2-7
3-99, B-5
corridor, 2-29, 2-32, 3-21, 3-72,
commander’s task list (CTL), 2-
direct support (DS), 2-14, 2-17,
3-103, B-2
28
3-41, 4-3, 4-21, 4-22, B-9, C-
counter-drug operation, 3-96
commander's critical
5
countermeasure, 2-3, 2-29, A-
intelligence requirement
directed-energy weapon
2, A-6, A-9, C-20
(CCIR), 2-7, 2-15, 3-13, 3-
(DEW), A-1, A-2
14, 3-19
countersurveillance, 2-3
disease and non-battle injury
commander's task list (CTL), 2-
course of action (COA), C-3, C-
(DNBI), 4-18, D-13
28, 2-29, 3-115
6
dismounted patrol, 1-5
common operating picture
cover operation, 1-5, 3-34, 3-44
displacement, 2-14, 2-18, 3-38
(COP), 2-14, 3-31
crew chief, 2-28
distribution company, 4-1
common operational picture
crew mission brief, 2-35
(COP), 1-4
distribution platoon, 1-9, 1-10,
crew rest, 3-13, 3-50
4-13, 4-14
communication card, 2-34, 2-
crew-served weapon (CSW), 2-
divert, C-7
35
20, D-2
communications, C-2, C-3, C-4,
diving fire, 3-10, 3-69, 3-70, 3-
109
C-7, C-12, C-19
D
downed aircraft recovery team
communications exercise
data transfer cartridge, 2-34, 2-
(DART), 2-22, 3-89, 4-9, 4-
(COMMEX), 2-37
38
12
communications security
day of supply (DOS), 4-4, 4-13,
(COMSEC), 2-3, 2-12, 2-32,
4-18, 4-20
downed aviator pickup point
(DAPP), 2-22
2-37, 2-38, 4-16, D-19
debrief, 2-38, 2-39, 2-40, 3-116
Drug Enforcement Agency, B-7
communications/automation, 4-
deception, 2-24, 3-93, 3-120
16
decide, detect, deliver, and
E
component repair platoon
assess (D3A), 2-23
economy of force, 1-3, 3-17, 3-
(CRP), 1-9, 1-11, 4-12, 4-13,
decision point (DP), 2-19, 3-72,
31, 3-35
4-19, 4-20
4-14
effective translational lift (ETL),
computer-based ASE training
decisive point (DP), C-3
3-69
(CBAT), 2-28, A-8, A-9
decontamination, 2-11, 2-14, 4-
effects coordinator, B-10
contact point, 3-23, 3-26, 3-
16, 4-18
effects coordinator (ECOORD),
116, 3-117
defend, 3-42, 3-44, 4-6, 4-19
C-5
continuous attack, 3-64
defense automatic addressing
electromagnetic, 2-3, 2-17
contour, 3-6, 3-8, 3-9, 3-10
system (DAAS), 4-23, 4-24
electromagnetic pulse, 2-3
control measure, 2-9, 2-19, 2-
electronic attack, C-5, C-16
32, 3-18, 3-19, 3-23, 3-26, 3-
16 February 2007
FM 3-04.126
Index-3
Index
electronic warfare (EW), 2-10,
field of view (FOV), 3-6, 3-8, 3-
formation, 2-38, 3-2, 3-3, 3-5,
2-24, 2-29, 2-32, 2-33, 3-10,
112, 3-113
3-6, 3-9, 3-12, 3-50, 3-51, 3-
3-33, 3-63, A-2, A-4, A-6, A-
53, 3-75, 3-80, 3-92, 3-93, A-
fighter management, 2-9, 2-22,
8, A-9, C-1, C-4, C-7, C-16
6, A-7, B-15
3-8, 3-9, 3-13, 3-47, B-10
electro-optical (EO), A-1, A-2,
forward air controller-airborne
fire control radar (FCR), 1-8, 1-
A-4
(FAC[A]), B-7
9, 3-91, 3-119, 3-120
emergency medical team
forward area refueling
fire distribution, 3-76, 3-86
(EMT), 4-17
equipment (FARE), 4-14, 4-
fire support (FS), 1-6, 2-4, 2-
15
emergency medical treatment
10, 2-11, 2-14, 2-16, 2-17, 2-
(EMT), 4-17
forward arming and refueling
24, 2-29, 2-34, 2-35, 3-54, 3-
point (FARP), 2-3, 2-4, 2-10,
engagement, C-5, C-19
63, 3-77, 3-78, 3-118, 3-120,
2-12, 2-15, 2-22, 2-29, 2-32,
B-5, B-6, B-8, B-9, C-2, C-5,
engagement area (EA), 1-5, 2-
2-33, 2-36, 2-37, 2-39, 3-1,
C-6, C-7, C-13, C-19
33, 3-3, 3-16, 3-19, 3-63, 3-
3-22, 3-24, 3-35, 3-54, 3-55,
71, 3-73, 3-74, 3-75, 3-76, 3-
fire support coordinating
3-56, 3-59, 3-64, 3-93, 3-98,
78, 3-80, 3-81, 3-83, A-4, B-
measure (FSCM), C-6, C-16
3-102, 3-119, 4-2, 4-3, 4-13,
2, B-9, C-2, C-3, C-4, C-5,
fire support coordination line
4-14, 4-15
C-6
(FSCL), 3-33, C-4
forward line of own troops
engagement criteria, 2-5, 3-16,
fire support coordination
(FLOT), 2-36, 3-43, 3-84, 3-
3-19
measure (FSCM), 2-11
93, 3-117, 4-15, D-5
escort, 1-5, 3-48, 3-49, 3-50, 3-
fire support element (FSE), 2-
forward maintenance team
51, 3-53, 3-88, 3-91, 3-92, 3-
16, C-1, C-2, C-3, C-5
(FMT), 4-12, 4-16
94, 3-109, D-14
fire support officer (FSO), 2-5,
forward operating base (FOB),
estimated time en route (ETE),
2-11, 2-15, 2-16, 2-24, 2-25,
3-84
3-7
3-75, C-5
forward support company
estimated time of arrival (ETA),
fires
(FSC), 1-5
3-2
indirect, C-5, C-6, C-8, C-17
forward support troop (FST), 1-
evasive plan of action (EPA), 3-
first sergeant (1SG), 2-12, 2-
9
89, 3-93, 3-115, D-4
13, 2-17, 2-20, 2-26, 2-27, 2-
forward-looking infrared (FLIR),
execution matrix, 2-34, 2-35
31, 4-2, 4-3, 4-17, D-2, D-16
3-3, 3-75, 3-99, B-5, C-17
executive officer (XO), 1-7, 1-8,
fix, 1-3, 3-20, 3-31, 3-32, 3-44,
fragmentary order (FRAGO), 2-
2-3, 2-6, 2-7, 2-15, 2-18, 2-
3-83, 3-87, 4-9
17, 3-47, 3-61, 3-116
20, 4-17, D-3, D-16
fixed-base operation, 2-6
fratricide, C-4
exploitation, 3-17
fixed-wing (FW), 2-25
freedom of maneuver, 3-11, 3-
explosive ordnance device
fixing, 1-3, 3-19, 3-73, 3-87
12, 3-20
(EOD), D-15
flight lead, 3-10, C-11
full spectrum operation, xi, 3-
explosive ordnance disposal
flight operations officer, 2-9, 2-
14, 3-19, B-15
(EOD), 4-9
11, 2-12
external supported recovery
G
flight surgeon, 2-7, 2-8, 2-15, 4-
(ESR), 3-88
general support (GS), C-5
17
extraction, 2-25, 3-15, 3-54, 3-
Global Command and Control
flight technique, 2-36, 3-8, 3-9,
91, 3-92, B-8
System-Army, 2-2
3-27, 3-30
global positioning system
F
flow chart, 2-27, 4-7, 4-8
(GPS), 2-22, 2-33, 3-100, 3-
feint, 1-3, 3-120, 3-121
flying hour program, 2-10, 4-7
117, B-8, B-9, D-8, D-9
field artillery (FA), 2-4, 2-11, 3-
food service, 2-6, 2-12, 2-27, 4-
ground control station, 2-18
41, 3-64, 3-83, C-5
14, 4-18
ground maintenance platoon,
field feeding section, 1-9, 4-13,
force protection, 2-6, 3-14, 3-
1-9, 1-10, 4-13, 4-15
4-14
16, 3-20, 3-87, 4-5, C-3, D-1
guard, 1-5, 2-21, 3-30, 3-31, 3-
field maintenance, 4-6, 4-11, 4-
Force XXI battle command
33, 3-34, 3-40, 3-41, 3-42, 3-
15, 4-16, 4-17, 4-20, 4-24
brigade and below (FBCB2),
43, 3-44
field of fire, 3-10, 3-38, 3-80, 3-
2-2, 2-13, 2-20, 4-14
gunnery, 2-11, 2-28, 2-29
98, 3-103
Index-4
FM 3-04.126
16 February 2007
Index
H
improvised explosive device
isolated personnel report
(IED), 2-8, 3-8, 3-22, 3-48
(ISOPREP), 2-9, 3-89, 3-93,
hasty attack, 3-19, 3-44, 3-50,
D-4, D-6
3-58
improvised explosive devise
(IED), 2-8
isolated, missing, detained, or
Have Quick, 2-32, 2-37, C-4,
captured (IMDC), 3-87, 3-88,
C-7
inadvertent instrument
3-91, 3-93
meteorological condition
hazardous material, 3-16
(IIMC), 2-22, 2-33, 2-34, 2-
J
headquarters, C-7
35, 2-36, 3-9
joint air attack team (JAAT), 1-
headquarters and headquarters
incursion, 3-38, 3-40
3, 2-4, 2-37, 3-19, 3-58, 3-
company (HHC), 1-5
indirect fire, 1-2, 1-3, 2-8, 3-10,
63, 3-64, 3-82, 3-110, B-3,
headquarters and headquarters
3-12, 3-13, 3-16, 3-19, 3-20,
C-1, C-2, C-3, C-4, C-5, C-6,
troop (HHT), 1-9
3-21, 3-32, 3-33, 3-35, 3-37,
C-7, C-8, C-10, C-11, C-13,
headquarters and support
3-38, 3-53, 3-58, 3-59, 3-63,
C-16, C-17, C-18, C-19
company (HSC), 4-1
3-75, 3-82, 3-83, 3-94, A-1,
joint fire, 3-10, 3-58, 3-59, 3-63,
B-3, B-4, B-5
health services, 2-7
3-82, 3-86
indirect fires, C-5, C-6, C-8, C-
health support service (HSS),
joint force air component
17
4-17, 4-20
commander (JFACC), C-8
individual aircrew training folder
heavy brigade combat team
joint force commander (JFC),
(IATF), 2-28, A-9
(HBCT), B-15
C-1, C-8
infantry brigade combat team
heavy expanded mobility
joint personnel recovery center
(IBCT), B-16
tactical truck (HEMTT), 4-15
(JPRC), 3-89
infantry fighting vehicle, 3-111
helicopter gunnery skills test, 2-
joint publication (JP), C-1, C-4,
28
information operation, 2-11
C-5, C-6, C-10
Hellfire, 1-4, 2-25, 3-21, 3-62,
infrared (IR), 2-17, 3-3, 3-6, 3-
joint suppression enemy air
3-109, C-3, C-5
52, 3-60, 3-62, 3-70, 3-113,
defense (J-SEAD), 2-11, 3-6,
high explosive, 3-109
A-1, A-4, A-8, B-4, B-5, B-6,
3-10, 3-21, 3-54, A-6, B-4
B-7, C-3, C-5, C-12, C-16,
high frequency (HF), 2-2, 2-4
joint suppression of enemy air
C-17, D-5
defense (J-SEAD), C-6
high risk to capture, 3-89
instructor pilot (IP), 2-11, C-12,
high value target (HVT), 2-23,
C-19
K
3-63
instrument examiner, 2-28
kill zone, 3-21, 3-55
high-payoff target (HPT), 2-23,
instrument flight, 2-29
L
2-24, 3-13, 3-20, 3-37, B-1,
intelligence, C-3
C-5
landing zone (KZ), 3-53
intelligence estimate, 2-7, 2-8
high-payoff target list (HPTL),
landing zone (LZ), 1-3, 2-17, 3-
2-24
intelligence officer (S2), C-3, C-
27, 3-28, 3-30, 3-50, 3-53, 3-
5
54, 3-93, 3-94, 3-102, 3-109,
holding area (HA), 3-7, 3-21, 3-
3-110, 3-111, 3-113, B-2, B-
64, 3-84, 3-117, B-2, B-9
intelligence preparation of the
9, D-9
battlefield (IPB), 1-2, 2-7, 2-
Homeland Defense, 3-95
9, 3-7, 3-12, 3-22, 3-27, 3-
landing zone L(Z), 3-29
hover fire, 3-69
58, 3-71, 3-72, 3-81, C-3, C-
laser, 1-2, 3-2, 3-70, 3-75, 3-
hovering, 3-62, 3-99, 3-103
4, C-6
109, 3-110, 3-113, 3-114, 3-
human resources specialist, 2-
intelligence report (INTREP), 2-
119, A-1, A-2, B-5, B-6
14
3, 2-17
lead, 1-4, 2-1, 2-31, 3-2, 3-3, 3-
intelligence summary, 2-17
4, 3-5, 3-6, 3-7, 3-9, 3-12, 3-
I
18, 3-31, 3-33, 3-38, 3-39, 3-
intelligence, surveillance, and
identification (ID), C-5, C-16, C-
41, 3-43, 3-48, 3-51, 3-62, 3-
reconnaissance (ISR), 1-2,
17
85, 3-86, 3-100, 3-103, 3-
2-8, 2-9, 3-21, 3-63, 3-88, B-
identification friend or foe (IFF),
112, 3-116, 3-119, 4-13, B-1
1, B-2
2-22, 2-32, 2-38, 3-99, 3-
liaison, 1-2, 2-6, 2-8, 2-9, 2-10,
interdiction attack, 1-3, 2-36, 3-
117, 3-118, A-6, A-8, C-16
3-118, 4-5, 4-16, B-7, B-10,
59, 3-63
improved data modem (IDM),
C-2
isolated personnel, 3-89, 3-90,
2-2, 3-119
liaison officer (LNO), C-5
3-91, 3-94, D-5, D-6
16 February 2007
FM 3-04.126
Index-5
Index
lift, 3-28, 3-52, 3-91, 3-114
marshalling area, 2-19
nap-of-the-earth (NOE), 3-6, 3-
8, 3-9, 3-10, 3-69, 3-84, C-2
limit of advance (LOA), 3-13, 3-
massed attack, 1-5
16, 3-17, 3-23, 3-25, 3-27, B-
naval surface fire support
master gunner, 2-11, 2-28
9
(NSFS), 2-24, 3-6, 3-63, B-
materiel management center
10, C-1, C-2, C-5
line of communication (LOC),
(MMC), 4-3, 4-4, 4-5
1-4, 1-5, 3-19, 3-21, 3-30, 3-
navigational aid (NAVAID), 3-
materiel readiness officer, 2-6
31, 3-33, 4-14
20, 4-10
maximum destruction, 3-64
line of departure (LD), 3-23, 3-
network control station, 2-4
25, 3-26, 3-27
medical estimate, 2-8
network support company, 4-1
line of sight (LOS), 2-25, 3-7, 3-
medical evacuation
night vision device (NVD), 2-
69, 3-112, 3-114, A-1, A-2,
(MEDEVAC), 2-19, 3-50, 3-
25, 3-6, 3-8, 3-54, 3-99, 3-
B-6
114, 4-17
102, 3-113, 3-114, 3-115, 4-
line replacement unit (LRU), 4-
medical treatment squad, 1-6,
5, B-5, B-6, C-5, D-9
7, 4-13, 4-20
4-16
night vision goggle (NVG), 2-
linkup, 2-25, 3-91
military decision making
29, 3-3, 3-5, B-4, B-5, B-6,
process (MDMP), 2-10, 2-22,
C-11, C-17
local area network (LAN), 2-12,
2-23, 2-30, 3-120, 4-20, B-2
4-16, 4-24
night vision system, 3-5, 3-6
military operation, 2-2, 2-25, 3-
logistic support area (LSA), 2-
no fire area (NFA), 3-47, B-2
14, 3-15, 4-1, 4-19, A-2
21
noncombatant evacuation
mission essential task list
logistics assistant
operation (NEO), D-1
(METL), 2-13, 2-27, 2-28, 3-
representative (LAR), 4-19,
nonlethal, C-6, C-16
95, 3-97, 3-114, B-10
4-20
no-notice evaluation, 2-28
mission oriented protective
logistics estimate, 2-7, 2-12
posture (MOPP), 2-14
no-notice program, 2-28
logistics package (LOGPAC),
mission planning, C-3
not mission capable (NMC), 4-
2-13, 4-3, 4-14
21
mission training plan (MTP), 4-
logistics release point (LRP), 4-
17, D-3
notice to airmen (NOTAM), 2-
2, 4-15
33, 2-34, 2-35
mission, enemy, terrain and
logistics section, 2-15
weather, troops and support
O
logistics support area (LSA), 2-
available, time available, and
21
objective area, 2-36, 3-6, 3-27,
civil consideration (METT-
3-28, 3-30, 3-46, 3-47, 3-50,
low-level, 3-6
TC), 2-5, 2-15, 2-18, 2-19, 2-
3-53, 3-82, 3-89, 3-90, 3-91,
20, 2-30, 3-2, 3-3, 3-4, 3-6,
M
3-93, 3-94, 3-104, 3-105, 3-
3-7, 3-8, 3-10, 3-12, 3-16, 3-
112, 3-113, D-6, D-7
main CP, 2-5, 2-6, 2-7, 2-14, 2-
17, 3-20, 3-27, 3-33, 3-38, 3-
15, 2-16, 2-17, 2-18, 2-19, 2-
44, 3-48, 3-49, 3-50, 3-51, 3-
observation, 1-5, 2-5, 2-17, 3-3,
20, 2-21, 2-26, 4-5
52, 3-53, 3-54, 3-84, 3-93, 3-
3-4, 3-5, 3-6, 3-10, 3-12, 3-
96, 4-2, 4-9, 4-15
17, 3-19, 3-20, 3-21, 3-23, 3-
main support battalion, 4-18
30, 3-31, 3-33, 3-35, 3-37, 3-
mobility, C-17
maintenance, 2-12, 2-39, 4-6,
38, 3-40, 3-46, 3-47, 3-54, 3-
4-8, 4-11, 4-13, D-1, D-16
movement control, 1-4, 4-18
56, 3-83, 3-106, 3-112, 3-
maintenance allocation chart
movement order, 2-19, 2-20
113, D-10
(MAC), 4-6, 4-12, 4-19, 4-20
movement technique, 3-2, 3-3,
observation and fields of fire,
maintenance management, 1-
3-6, 3-7, 3-9, 3-10, 3-23, 3-
avenues of approach, key
11, 4-19, 4-21, 4-24, 4-25
26, 3-27, 3-118
terrain, obstacles and
maintenance operational
movement to contact, 1-3, 1-4,
movement, and cover and
check, 2-29, 4-11
1-5, 3-1, 3-43, 3-58, 3-80, 3-
concealment (OAKOC), 3-14
86, 3-87, C-5
observation post (OP), 1-5, 2-
maintenance test flight, 2-29
33, 3-33, 3-35, 3-36, 3-37, 3-
maintenance test pilot (MP), 1-
N
38, 3-39, 3-42, 3-43, 3-44, 3-
11, 2-29, D-2
named area of interest (NAI),
47, 3-54, 3-55, 3-56, 3-57, 3-
maneuver space, 1-4, 3-6, 3-
3-17, 3-26, 3-35, 3-54, 3-72,
112
30, 3-31, 3-34, 3-38, 3-48, 3-
3-112, C-3
observer controller, 2-40
81
march column, 2-19
Index-6
FM 3-04.126
16 February 2007
Index
obstacle, 3-2, 3-12, 3-23, 3-26,
permissive, 3-24, 3-28, 3-92
priority of fire, 3-41
3-32, 3-52, 3-96, 3-113
personal staff, 1-7
priority of fire zone (PFZ), 3-78,
offensive operation, 2-17, 2-26,
3-86
personnel estimate, 2-7, 2-8
3-1, 3-37, 3-44, 3-58, 3-116
problem, plan, people, parts,
personnel readiness, 2-7
OH-58D, C-1
time and tools (P4T2), 4-7,
personnel recovery (PR), 2-5,
4-9, 4-10
on-scene commander (OSC),
2-10, 2-29, 2-35, 3-47, 3-87,
3-89, 3-90, D-4, D-6, D-7
production control, 1-9, 1-11, 4-
3-88, 3-89, 3-90, 3-91, 3-92,
8, 4-12, 4-13, 4-19, 4-20, 4-
operating order (OPORD), 2-
3-93, 4-9, C-7, D-4, D-5, D-6
24
17, 2-32, 2-34, 3-11, 3-12, 3-
personnel recovery
13, 3-19, 3-72, 3-96, 3-114,
progressive phase
coordination cell (PRCC), 3-
3-120, 4-10, 4-19, A-2, B-9,
maintenance (PPM), 4-8
89, 3-93
B-11, D-16
Property Book and Unit Supply
personnel recovery officer
operating tempo (OPTEMPO),
System-Enhanced (PBUSE),
(PRO), 3-89
3-60, 3-114, 4-13
4-22, 4-23
phase line (PL), 3-23, 3-26, 3-
operation characteristics
property book officer (PBO), 4-
27, 3-33, 3-36, 3-38, 3-42, 3-
tempo, C-17
5, 4-22
117
operational control (OPCON),
psychological operations
phase maintenance, 4-8
2-2, 2-27, 3-116, 4-3, C-8
(PSYOPS), 2-24, 3-34
phased attack, 3-64
operational environment, 1-1,
pursuit, 3-17, 3-117
phases/progressive preventive
1-2, 1-9, 1-11, 2-5, 2-7, 2-8,
maintenance, 2-27
Q
2-13, 3-1, 3-9, 3-12, 3-14, 3-
32, 3-34, 3-35, 3-58, 3-63, 3-
pickup zone (PZ), 1-3, 3-28, 3-
quality assurance (QA), 1-9, 1-
75, 3-87, 3-95, 3-98, 3-118,
29, 3-30, 3-50, 3-52, 3-54, 3-
11, 4-12, 4-19
4-1, 4-5, B-1, B-3, B-9
102, 3-110, 3-113, B-2, D-14
quartering party, 2-6, 2-13, 2-
operational exposure guidance,
pilot in command (PC), 2-5, 2-
19, 2-20, 2-21
2-14
26, 2-27, 2-35, 3-2, 3-115
quick reaction force (QRF), 1-2,
operational plan (OPLAN), 2-
planning
1-4, 2-6, 2-21, 2-35, 3-40, 3-
17, 3-96
responsibilities, C-7
42, 3-89, 3-92, 3-114, 3-115,
Planning
3-116, 4-9
operational readiness rate, 4-7,
4-8
process, C-3, C-4
R
operations
planning cell, 2-28, 2-31, 2-32,
racetrack, 3-62
defensive, C-1
2-33
radar frequency (RF), 2-25, 3-
support, C-1
plans cell, 2-15, 2-16
70, A-4, A-8
operations and intelligence
platoon leader, 2-27, 2-28, 2-
radio telephone operator
(O&I), 2-3, 2-4
29, 3-2
(RTO), 2-16
operations cell, 2-15, 2-32, 2-
platoon sergeant, 2-27, 2-29, 4-
raid, 1-3
33, 3-114
5
rally point, 2-19, 2-20
operations estimate, 2-7, 2-9
postal service, 2-7
range fan, 3-77
operations security (OPSEC),
precombat check (PCC), 2-19,
2-3
2-38
readiness condition
(REDCON), 3-114
overwatch, 3-12, 3-22, 3-26, 3-
precombat inspection (PCI), 2-
118, D-8
19, 2-20, 2-38
reconnaissance, 3-10, 3-13, 3-
15, 3-16, 3-17, 3-54, C-1, C-
prescribed load list (PLL), 4-12,
P
2, C-3, C-4, C-5, C-16
4-16, 4-19, 4-24
palletized load system (PLS),
aerial, C-8
preventive maintenance checks
4-15, D-6, D-7
reconnaissance and
and services (PMCS), 2-38,
passage of line, 2-22
surveillance (R&S), 1-3, 1-4,
4-11, 4-22, D-3
3-20, 3-121
passage of lines, 2-36
preventive medicine, 4-17
reconnaissance-by-fire, 3-18,
passage point (PP), 2-32, D-5
priority fire zone (PFZ), 3-78
3-20, 3-21
performance planning card
priority intelligence requirement
recoverable, 2-28
(PPC), 2-32, 2-34, 2-35
(PIR), 1-2, 2-39, 3-30, 3-31,
perimeter, 2-20, 4-4, 4-6
3-33, 3-47, A-4
16 February 2007
FM 3-04.126
Index-7
Index
rehearsal, 2-19, 2-21, 2-35, 2-
scout weapons team (SWT), 3-
spider web, 3-100
36, 2-37, 2-38, 3-73, 3-78, 3-
2, 3-3, 3-4, 3-48, 3-49, 3-50,
split-based operation, 2-26, 3-
80, 3-82, 3-115, A-2, B-9
3-51, 3-53, 3-58, 3-62, 3-63
96, 4-17, 4-19, B-9
relay, C-4, C-7, C-8
screen, 1-5, 3-34, 3-35, 3-38,
spot report (SPOTREP), 2-37,
3-54, 3-110
release point (RP), 2-19, 2-20,
2-39, 3-80, 3-82, 3-83, D-10
2-21, 2-37, 3-22, 3-23, 3-48,
screen line, 3-33, 3-36, 3-38, 3-
stability, 1-2, 3-1, 3-13, 3-14, 3-
3-86, D-8, D-11, D-12
39, 3-42, 3-54, 3-56
15, 3-34, 3-69, 3-95, 3-96, 3-
reparable exchange (RX), 4-20
search and attack, 3-86, 3-87
97, 3-98, 4-23
required supply rate (RSR), 4-4
search and rescue (SAR), 3-
standard Army maintenance
88, 3-89, D-7
system (SAMS), 4-23
rescue escort (RESCORT), 3-
89, 3-90, 3-91, 3-94, D-6, D-
search and rescue incident
standard Army maintenance
7, D-9
report (SARIR), 3-93, D-7
system-enhanced (SAMS-
E), 4-22
rescue mission brief (RMB), 3-
sector of fire, 3-77, 3-106
90, 3-93, 3-94
standard Army maintenance
security, 3-30, 3-31
system-level 1 (SAMS-1), 4-
rescue mission commander
security clearance access
20, 4-21, 4-22
(RMC), 3-90, 3-91, 3-93, 3-
roster (SCAR), A-9
94, D-6, D-7
standard Army maintenance
semiactive laser, 2-25
system-level 2 (SAMS-2), 4-
reserve, 2-16, 2-32, 3-37, 3-42,
serial, 2-19, 4-22
20, 4-21, 4-22
3-54, 3-55
sets, kits, and outfits (SKO), 4-
standard Army maintenance-
restricted fire area (RFA), 3-47
13
enhanced (SAMS-E), 4-22
restricted operating zone
sets, kits, outfits, and special
standard Army management
(ROZ), 3-90, B-2
tools (SKOT), 4-6
information system
retransmission (RETRANS), 2-
shop equipment contact
(STAMIS), 4-12, 4-14, 4-19,
2, 2-12
maintenance (SECM), 4-19,
4-20, 4-23, 4-24
return to duty (RTD), 2-13, D-
4-20
standard Army retail supply
13
signal officer (S6), 2-12, 2-15,
system (SARSS), 4-16, 4-22,
return to force (RTF), 4-24
4-23
2-17, 2-20
risk assessment, 2-29, 2-33, 2-
signal operation instruction
standard Army retail supply
34, 2-35, 3-115, A-2, A-3, A-
system-gateway (SARSS-
(SOI), 2-12
4
Gateway), 4-23
simultaneous attack, 1-5
risk management, 2-5, 2-10, 2-
standard Army retail supply
single channel air-ground radio
11, 2-29
system-Gateway (SARSS-
system (SINCGARS), 2-11,
road march, 2-19
Gateway), 4-21, 4-23
2-32, B-9
rules of engagement (ROE), 2-
standard Army retail supply
situational awareness (SA), 1-
5, 2-37, 3-16, 3-37, 3-47, 3-
system-level 1 (SARSS-1),
2, 1-4, 2-2, 2-5, 2-16, 3-6, 3-
93, 3-96, 3-97, 3-98, A-6, B-
4-16, 4-23
36, 3-38, 3-58, 3-59, 3-61, 3-
1, C-7
standard Army retail supply
97, 3-112, 3-119, A-6, B-5,
rules of instruction (ROI), 3-96,
B-9, C-16, C-17
system-level 2 (SARSS-2),
3-97, 3-98
4-23
situational training exercise
running estimate, 2-7
(STX), 2-28, 2-29, A-9, B-8
standardization instructor pilot
(SP), 2-11, 2-28, 2-31, A-9
running fire, 3-10, 3-69, 3-70,
situational understanding (SU),
3-103
1-2, 2-14, 2-16, 2-18, C-16
standing operating procedure
(SOP), C-4
small scale contingency (SSC),
S
1-2, 3-98
status chart, 2-27
safety, C-19
small unmanned aircraft
stay behind equipment, 4-5
safety officer (SO), 2-11, 2-15,
system (SUAS), 2-18
straight trail, 3-4
2-18, 2-29, 2-31, 4-14
special instructions (SPINS), 2-
Stryker brigade combat team
satellite communication
9, 2-22, 2-24, 3-89, 3-93
(SBCT), 1-5, B-15
(SATCOM), 2-2, 2-4
special staff, 1-7
supply point distribution, 4-2
scheduled maintenance, 2-27,
specific information
supply section, 1-6, 4-16, 4-19
4-8
requirement, 3-13
supply sergeant, 2-13, 4-16
scheme of maneuver, C-13
Index-8
FM 3-04.126
16 February 2007
Index
supply support activity (SSA),
tactical satellite, 2-2
unit basic load (UBL), 4-4
4-5, 4-17, 4-19, 4-23
tactics, techniques, and
unit distribution, 4-2
support area, 2-12, 2-13, 2-15,
procedures (TTP), 2-10, 2-
unit maintenance, 1-11, 2-29,
4-3, D-3
27, 2-29, 2-36, 3-3, 3-10
4-6, 4-7, 4-8, 4-11, 4-19
support by fire (SBF), 2-33, 3-
target acquisition (TA), 2-24, 3-
unit ministry team (UMT), 1-6,
19, 3-21, 3-119, B-3
10, C-1, C-19, C-20, D-3
1-9, 2-8, 2-15, 4-16, 4-18, D-
support relationships
target handover, 3-3, 3-61, 3-
2
direct support (DS), C-5
113
unit trainer, 2-29
general support (GS), C-5
target reference point (TRP), 2-
unit-level logistics system
suppression, C-6
33, 3-60, 3-76, 3-105, 3-106,
(ULLS), 4-21
B-4
suppression enemy air defense
unit-level logistics system-
(SEAD), 3-73, 3-93, B-4, F-
targeting, 2-23, 2-24, 3-3, 3-13,
aviation (ULLS-A), 4-8, 4-18,
3, 4, 5
3-14, 3-69, 3-104, 3-105, 3-
4-23, 4-24
106, C-13
suppression of enemy air
unit-level logistics system-
defense (SEAD), C-2, C-5,
task force (TF), 1-2, 2-13, 2-26,
logistics officer (ULLS-S4),
C-6, C-8, C-12, C-15, C-16
3-7, 3-37, 3-38, 3-42, 3-53,
4-3
3-54, 3-92, 3-114, 3-115, 3-
suppressive fire, 3-4, 3-12, 3-
unit-level logistics sytem
116, B-10
51, 3-58, 3-103, 3-109, 3-
(ULLS), 4-23
110, 3-113
task organization, 2-1, 2-17, 2-
unit-level maintenance, 2-12, 4-
20, 3-34, 3-61, 3-96
surveillance, 1-3, 1-5, 2-3, 2-
11, 4-16
18, 3-3, 3-6, 3-10, 3-11, 3-
team brief, 2-35
unmanned aerial system
21, 3-27, 3-30, 3-33, 3-35, 3-
technical supply, 4-12, 4-19
(UAS), 2-12, 2-24, 3-12, 3-
36, 3-41, 3-45, 3-86, 3-110
terminal area phase, 3-94
30, 3-34, 3-54, 3-75, 3-99, 3-
survey, 2-3, 2-14, 2-18, 2-29,
112, 3-120, 4-17, 4-19, B-3,
terrain flight, 3-5, 3-6, 3-7, 3-8,
3-28, D-9
B-10, F-2
3-9, 3-10, 3-26, 3-70, 3-86
survivability, C-3, C-5, C-6
unmanned aircraft systems
terrain management, 1-4, 2-17
survival, escape, rescue, and
(UAS), C-4
terrain model, 2-19, 2-36
evasion, 2-5
unscheduled maintenance, 2-
threat, C-3, C-5, C-6, C-17
sustainment, xi, 1-4, 1-9, 2-1,
27, 4-8, 4-9, 4-11, 4-12, 4-13
2-11, 2-13, 2-14, 2-16, 2-17,
throughput distribution, 4-2
urban operation, 2-17, 3-10, 3-
2-19, 3-12, 3-17, 3-19, 3-30,
time on target (TOT), 2-24, 2-
31, 3-32, 3-98, 3-109, 3-111
3-31, 3-64, 3-73, 3-97, 4-1,
37
4-2, 4-3, 4-5, 4-6, 4-14, 4-15,
V
time/distance/heading (TDH),
4-16, 4-17, 4-19, 4-20, 4-22,
2-32
vehicle-borne improvised
B-9, B-15
explosive device (VBIED), 3-
traffic control post (TCP), 3-45
sustainment maintenance, 4-6
8, 3-22
trail, 3-2, 3-6, 3-9, 3-36, 3-43,
synchronization matrix, 2-9
very high frequency (VHF), 2-3,
3-48, 3-49, 3-91, 3-119
2-4, 3-89
T
training, C-1, C-2, C-4, C-7, C-
video, 2-39, 3-20, 3-28
8
tactical air control party
(TACP), C-3, C-5, C-7, C-11
training meeting, 2-28
W
tactical airspace integration
traveling, 3-6, 3-9, 3-36, 3-47
warning order (WARNO), 2-18,
system, 2-2
2-20, 2-31, 2-32, D-15
traveling overwatch, 3-6, 3-9
tactical combat force (TCF), 4-
waypoint, 3-17, 3-119
trigger, 3-13, 3-19, 3-30, 3-76,
5
3-80, 3-83
weather, C-4, C-6
tactical control (TACON), 3-
troop leading procedures
wedge formation, C-20
116, C-1, C-8
(TLP), 2-19
wingman, 1-4, 3-2, 3-3, 3-4, 3-
tactical fire direction system
5, 3-6, 3-89, 3-103, D-6
U
(TACFIRE), 2-4
tactical operations center
ultra high frequency (UHF), 2-
3, 2-4, 3-89
(TOC), 2-3, 2-4, 2-7, 2-11, 2-
15, 2-16, 2-18, 2-20, 2-21, 3-
unexploded ordnance (UXO),
89, 4-9, 4-17, D-12
D-15
16 February 2007
FM 3-04.126
Index-9















Content      ..     6      7      8
