FM 3-22.91 MORTAR FIRE DIRECTION PROCEDURES (July 2008) - page 15





Appendix F
ERROR MESSAGE
EXPLANATION and ACTION
FATAL ERR, REINIT
Mission data have been corrupted.
ACTION: End mission with EOM and restart mission from beginning.
FILE EMPTY
No data in initialization data buffer.
ACTION: Verify the initialization function selection under review and enter the
required initialization data.
FILE FULL
No more initialization data storage space available in buffer.
ACTION: Delete unneeded data to make space for new initialization data entries.
FO TOO CLOSE
FO is too close to target to perform MPI mission (within 10 meters).
ACTION: Verify FO and target coordinate entries.
FORMAT ERROR
All valid data not entered into blank menu fields.
ACTION: Enter all required data into blank menu fields or select alternate menu
sequence using appropriate action switch.
FPF LN EMPTY
Selected FPF line is now unused.
ACTION: Select appropriate FPF line having stored data.
GUN IS ADJUSTED
Adjustments have already been completed for this weapon.
ACTION: Select new weapon to adjust only after all adjustments have been completed for the
current weapon. Once new weapon is selected, previous adjustments are fixed and further
adjustment is not permitted for weapon currently in use.
ID ASSIGNED
This KNPT number or TGT number entry has already been used.
ACTION: Choose alternate number for data storage, or delete stored data before storing
new data.
ILL ENTRY
Illegal value entered into blank field of data entry menu.
ACTION: Determine proper value range for data and change data entry accordingly.
ILLEGAL CHARGE
Manually entered charge is invalid for selected ammunition.
ACTION: Leave charge field blank (MBC selects optimum charge) or enter valid
alternate charge.
ILLEGAL SWITCH
Invalid keypress.
ACTION: Check entry. Make only valid entries.
ILLEGAL TGT NUM
Target number is within target number block range assigned in SET UP.
ACTION: Manually enter a target number outside range defined in SET UP, or notify
sender to retransmit valid target number.
INST:FAIL
Processor failure.
ACTION: Return MBC to next higher maintenance level.
LN ALREADY INIT
FPF line is already in use (initialized).
ACTION: Select alternate FPF line or clear line to reinitialize.
F-4
FM 3-22.91
17 July 2008
Error Messages
ERROR MESSAGE
EXPLANATION and ACTION
MAX
NOT
MAX fire line is closer than MIN fire line.
GREATER
ACTION: Verify MIN and MAX fire line entries.
MODEM:FAIL
Modem CCA failure.
ACTION: Return MBC to next higher maintenance level.
MSG
BUFFER
No messages are stored in message buffers.
EMPTY
ACTION: DO NOT press MSG switch unless message lamp is blinking.
MSN
#
Unassigned mission selected for activation.
UNASSIGNED
ACTION: Activate an alternate mission when operating on a previously initiated
mission.
MSN ERROR
Probable MBC software fault.
ACTION: End mission and reenter. Compute mission. If error reoccurs, return MBC to
next higher maintenance level.
N TOO BIG
Computed delta northing exceeds 32767.
ACTION: Verify all entries affecting delta northing. Also, verify that MIN E and MIN
N entries in SET UP data are appropriate for mission coordinates.
NO ACTIVE MSN
No missions are stored in mission buffers or no mission is presently activated.
ACTION: Initiate new mission using GRID, SHIFT, or POLAR switch or FR message;
or select a stored mission using MSN switch and appropriate display switch.
NO ADJUST DATA
All required adjust data have not been entered.
ACTION: Do not press COMPUTE switch for an ADJ before viewing ADJ data entry
field (DEV).
NO AVAIL MSN
Mission buffers are full (three missions stored).
ACTION: Terminate one stored mission by selecting EOM, EOMRAT, or EOMFPF.
Then initiate new mission.
NO CURRENT MET
Current MET has not been initialized.
ACTION: Enter or review appropriate NEW MET data and initialize CURR MET by
pressing UPDATE*, or select STD MET.
NO FO ENTERED
No FO entry in mission input data.
ACTION: When sending digital response to manual input mission, enter FO ID when
beginning mission. FO ID is entered automatically in BMD-supported missions.
NO MAP MOD
Computation (such as computing gun orders) requires MIN E and MIN N coordinates,
and none were assigned in SET UP data entry.
ACTION: Completely initialize SET UP data.
NO OUTPUT DATA
Review of FIRE DATA or SFTY DATA or other operation (such as ADJ, REG, or
REPLOT) requires existing output data.
ACTION: Press COMPUTE switch after properly entering appropriate mission input
data.
17 July 2008
FM 3-22.91
F-5
Appendix F
ERROR MESSAGE
EXPLANATION and ACTION
NO SHEAF DATA
Special sheaf selected but without width or direction entry.
ACTION: Enter all sheaf data before pressing COMPUTE switch.
NO TGT DATA
Insufficient target location data.
ACTION: Press MSN switch, then sequence through mission input data menus. Enter
all input data on all entry menus.
NO TGT NUM
Target numbers not yet assigned for target block definition in SET UP data.
ACTION: Assign new block of target numbers using SET UP initialization menu
sequence.
NO TRIANGLE
Line segments in SURV INT or RES problem do not converge.
ACTION: Verify input angle and coordinate data entries.
NO WPN DATA
Weapon not yet selected using WPN/AMMO switch.
ACTION: Enter weapon on WPN select menu before pressing COMPUTE switch.
POWER FAILURE
MBC powered down by means other than ON/OFF switch, such as by removing battery
or external power.
ACTION: Turn power off using ON/OFF switch before disconnecting power source.
PTS AVAIL:##
Remaining number of points available in fire zone storage buffer when new fire zone
entry contains too many points.
ACTION: Define new fire zone with fewer points or delete unused fire zones to
provide additional buffer storage space.
RAM:FAIL @##
IMICRO test random access memory failure.
ACTION: Return MBC to next higher maintenance level.
RANGE
TOO
Range to target is zero, or when entering FIRE ZONES data, distance between points is
SMALL
less than 10 meters.
ACTION: Verify mission input entry or FIRE ZONES data entry.
REG TOO BIG
Range corrections exceed 999 meters when computing a registration.
ACTION: Register target only when range corrections are 999 meters or less (usually
much less).
REV NO. FAILURE
Memory CCA and display/processor CCA have incompatible revision numbers.
ACTION: Return MBC to next higher maintenance level.
RANGE TOO BIG
Entered or computed range is too large.
ACTION: Change distance or coordinate entries to reduce range to acceptable value.
ROM:FAIL A##
MICRO test read-only-memory failure.
ACTION: Return MBC to next higher maintenance level.
F-6
FM 3-22.91
17 July 2008
Error Messages
ERROR MESSAGE
EXPLANATION and ACTION
SAFETY
Impact point is outside defined safety fan boundaries.
VIOLATION
ACTION: Verify target location and safety data entries. Reenter, if necessary. No
further action can be taken.
SINGLE WPN ONLY
More than one weapon is designated on TFC sequence GUNS: @# ________ menu but
selected TFC CONtrol allows only one weapon.
ACTION: Select TFC CONtrol function allowing multiple weapons, or DO NOT enter
additional weapons.
SPC SHEAF ERROR
Weapon registration is illegal while in TFC CONtrol (SPECial SHEAF).
ACTION: To perform a registration, change TFC CONtrol selection.
SUPERSONIC
Calculated shell velocity exceeds mach 1.
ACTION: Prevailing nonstandard conditions provide inaccurate MBC calculations.
Verify all nonstandard initialization entries including AMMO powder TEMP, AMMO
weight corrections, all MET data, and target and weapon ALT.
TEMP OUT OF
Powder temperature entry outside range (-70 to 140).
RNGE
ACTION: Verify that powder temperature entry is within allowable range.
TEMP TOO LOW
MBC cannot compute gun orders for 107-mm mortars with extension when powder
temperature is below -30 degrees.
ACTION: Mission cannot be fired under given conditions. Verify ammunition powder
temperature and target location entries.
TEMP TOO LOW
Air temperature in MET data is below 1536 (153.6 degrees Kelvin or -183.2 degrees
Fahrenheit).
ACTION: Verify that air temperature entry is 1536 or above.
TGT HIGH/RN BIG
Target is beyond maximum range or maximum altitude at maximum allowable safe
charge, and charge has not been manually entered.
ACTION: Mission cannot be fired under given conditions. Verify WPN/AMMO and
target location entries.
TGT
LOW/RN
Target is below minimum range or minimum altitude at minimum allowable safe
SMALL
charge, and charge has not been manually entered.
ACTION: Mission cannot be fired under given conditions. Verify WPN/AMMO and
target location entries.
TGT TOO HIGH
Target altitude is greater than 90 percent of MAX ORD of computed flight trajectory.
Reliable results cannot be obtained.
ACTION: Increase charge or elevation entries, if possible.
17 July 2008
FM 3-22.91
F-7
Glossary
SECTION I. ACRONYMS AND ABBREVIATIONS
AAR
after-action report; after-action review
AC
alternating current
ACA
airspace coordination areas
A/F
adjust fire
AFATDS
Army Field Artillery Tactical Data System
ALT
alternate, used when describing the ALT key
AMC
at my command
AOF
azimuth of fire
AR
Army Regulation
ARTEP
Army Training and Evaluation Program
AZ
azimuth, used in conjunction with the LHMBC, MBC, and MFCS
BIT
built-in test
BOLAD
boundary outer limit alert distances
BPS
bits per second
CAS
close air support
CFF
call for fire
CFL
coordinated fire line
CI
commander’s interface
CMD
command, used in conjunction with the MBC
COMSEC
communications security
CS
O-cholorobrnxylmalonstrile (“tear gas”)
CSR
controlled supply rate
DA
Department of the Army
DC
direct current
DCT
deflection conversion table
DD
driver’s display
DEFK
deflection correction
DF
deflection
DLY
delay
DMD
digital message device
DNL
do not load
DOF
direction of fire
DS
direct support
ELEV
elevation
EOM
end of mission
FA
field artillery
FBCB2
Force XXI battle command—brigade and below
FC
fires cell
FCS
frame check sequencing
FDC
fire direction center
FDCCP
Fire Direction Center Certification Program
FEC
forward error correction
FFE
fire for effect
FIST
fire support team
17 July 2008
FM 3-22.91
Glossary-1
Glossary
FLOT
forward lines of own troops
FM
frequency modulation; field manual
FO
forward observer
FOS
forward observer system
FPF
final protective fires
FPL
final protective line
FR
fire request
FSCL
fire support coordination line
FSCMs
fire support coordination measures
FSCOORD
fire support coordinator
FSE
fire support element
FSO
fire support officer
FT
firing table
FTX
field training exercise
FZ
fuze, used in conjunction with fire control equipment
GD
grid declination, gunner's display
GEOREF
geographical reference
GMT
Greenwich mean time
GPS
Global Positioning System
GT
gun-target
GUI
graphic user interface
HE
high explosive
HEQ
high-explosive quick
HOB
height of burst
IAW
in accordance with
ID
identification
ILLUM
illumination
IMLC
Infantry Mortar Leader’s Course
IMP
impact
IMU
inertial measurement unit
IR
infrared
IS
immediate suppression
ITEP
Individual Training and Evaluation Program
JMEM
joint munitions effectiveness manual
KNPT
known point, used in conjunction with the MBC
L
left, used in conjunction with fire control equipment
LARS
left add, right subtract
LAT
latitude, used in conjunction with fire control equipment
LB
lateral boundaries
LCD
liquid crystal display
LD
line of departure
LED
light-emitting diode
LFX
live-fire exercise
LHMBC
lightweight handheld mortar ballistic computer
LZ
landing zone
m
meter(s)
MANCOC
Maneuver Advanced Noncommissioned Officer Course
MAZ
mounting azimuth
Glossary-2
FM 3-22.91
17 July 2008
Glossary
MBC
mortar ballistic computer
MDP
meteorological datum plane
MET
meteorological
METL
mission-essential task list
MFCS
Mortar Fire Control System
MGRS
Military Grid Reference System
MIN
minimum, used in conjunction with fire control equipment
mm
millimeter
MOA
method of attack
MOC
method of control
MOF
method of fire, multi-option fuze
MOS
military occupational specialty
MPI
mean point of impact
MPS
meters per second
MSDA
mortar surface danger area
Msg
message, used in conjunction with fire control equipment
MTO
message to observer
MTP
mission training plan
MTSQ
mechanical time superquick
NCO
noncommissioned officer
NFA
no-fire area
NGF
naval gunfire
NiMH
nickel metal hydride
Obs Num
observer number
OIC
officer in charge
OP
observation point; operation
OpACK
operationally acknowledge, used in conjunction with fire control equipment
OpOUT
operationally out, used in conjunction with fire control equipment
OpRDY
operationally ready, used in conjunction with fire control equipment
OpSTA
operationally stationary, used in conjunction with fire control equipment
OpStatus
operation status, used in conjunction with fire control equipment
OT
observer-target
PD
point-detonating
PDA
personal digital assistant (Chapter 17 only); power distribution assembly (Chapter 15)
PE
probable error
PEd
probable error in deflection
PEr
probable error in range
PLGR
precision lightweight Global Positioning System receiver
PMCS
preventive maintenance checks and services
PRN
printer, used in conjunction with fire control equipment
PROX
proximity
PTM
plain text message
QWERTY
standard typewriter keyboard, top row left, first six letters
R
right, used in conjunction with fire control equipment
RALS
right add, left subtract
RAM
random access memory; volatile; stores data only until device is turned off or loses
power
RCF
range correction factor
RFA
restricted fire area
RFL
restricted fire line
17 July 2008
FM 3-22.91
Glossary-3
Glossary
Rnds Cmplt
rounds complete, used in conjunction with fire control equipment
ROM
read-only memory
RP
registration point, red phosphorus
RPDA
ruggedized personal digital assistant
RPM
rounds per minute
RTO
radiotelephone operator
S-3
operations and training officer
SAASM
selective availability antispoof module (type of GPS card)
SD
secure digital (memory card)
SL
section left
SOI
signal operating instructions
SOP
standing operating procedure
SQ
superquick
SR
section right
STX
situational training exercise
TC
training circular
TCIM
tactical communication interface modem
TDC
time dispersal coding
TFC
technical fire control
TFT
thin-film transistor
TGT
target, used in conjunction with fire control equipment
TL
traverse leg
TM
technical manual
TMPC
terrain mortar position correction
TOC
tactical operations center
TOF
time of flight
TOT
time on target
TRADOC
United States Army Training and Doctrine Command
TRC
total range correction
TS
traverse station
TTT
time to target
UO
urban operations
URN
unit reference number
US
United States
UTM
universal transverse mercator
V
volt
VA
vertical angle
VDC
volt direct current
VI
vertical interval
VMS
vehicle motion sensor
VT
variable time
WP
white phosphorus
WPN
weapon, used in conjunction with fire control equipment
WR
when ready, used in conjunction with fire control equipment
Glossary-4
FM 3-22.91
17 July 2008
Glossary
SECTION II. TERMS
decrement
a gradual decrease in quality or quantity; or the amount of decrease
random-access memory
read-write computer memory on which the location of data does not affect
the speed of its retrieval; especially, the main storage available to the user
for programs and data
read-only memory
a usually small computer memory that contains special-purpose
information, such as operating system software, which must not and cannot
be altered
volatile memory
memory that stores data only until device is turned off or loses power
zeroize
to return to zero
17 July 2008
FM 3-22.91
Glossary-5
This page intentionally left blank.
References
DOCUMENTS NEEDED
These documents must be available to the intended users of this publication.
ARMY PUBLICATIONS
AR 385-10. The Army Safety Program. 23 August 2007.
AR 385-63. Range Safety. 19 May 2003.
ARTEP 7-90-Drill. Battle, Drills for the Infantry Mortar Platoon, Section, and Squad. 26 July 2002.
DA Pam 385-63. Range Safety. 10 April 2003.
FM 3-09.15, Tactics, Techniques, and Procedures for Field Artillery Meteorology. 25 October
2007.
FM 3-22.90, Mortars. 7 December 2007.
FT 60-P-1. Firing Tables For Mortar, 60mm, M224 Firing Cartridge, HE, M720 Cartridge, HE,
M720A1 Cartridge, HE, M49A4 Cartridge, HE, M888 Cartridge, HE, M768 Cartridge, HE,
XM1046 Cartridge, HE, M1061 Cartridge, WP, M50A3 Cartridge, WP, M302A2 and
M302A1 Cartridge, WP, M722 Cartridge, WP, M722A1 Cartridge, Illum, M83A3 Cartridge,
Illum, M721 Cartridge, IR, M767 Cartridge, FRPC, M769 Cartridge, TP (SR), M766. 22
March 1980.
STP 7-11B1-SM-TG. Soldier’s Manual and Trainer’s Guide, MOS 11B, Infantry, Skill Level 1. 6
August 2004.
STP 7-11B24-SM-TG. Soldier’s Manual and Trainer’s Guide, MOS 11B, Infantry, Skill Levels 2, 3,
and 4. 28 May 2004.
STP 7-11C14-SM-TG. Soldier’s Manual and Trainer’s Guide, MOS 11C, Indirect Fire Infantryman,
Skill Levels 1/2/3/4.
28 May 2004.
TM 9-1010-223-10. Operator’s Manual, Lightweight Company Mortar, 60-mm: M224 (NSN 1010-01-
020-5626). 15 September 1998.
TM 9-1015-249-10. Operator’s Manual, Mortar, 81-mm, M252. 30 October 1987.
TM 9-1015-250-10. Operator’s Manual for Mortar, 120mm: Towed M120 (NSN 1015-01-226-
1672)(EIC:4SL) and Mortar, 120mm: Carrier-Mounted M121 (NSN 1015-01-292-3801) (EIC
4SE). 19 August 1996.
TM 9-1015-254-13&P. Operator’s, Unit, and Direct Support Maintenance Manual with Repair Parts
and Special Tools List (RPSTL) for Mortar, Subcaliber Insert: M303 (1015-01-377-4824)
(EIC:4SR). 2 March 1994.
TM 9-1220-248-10. Operator’s Manual for Mortar Fire Control System, M95, NSN 1230-01-503-
7784) (EIC:3QT) (with Version 3 Software) . 31 October 2005.
TM 9-1290-262-10. Operator’s Manual, Aiming Circle, M2 W/E (1290-00-614-0008) and M2A2 W/E
(1290-01-067-0687). 15 April 1981.
TM 9-1290-333-15. Operator, Organizational, Field and Depot Maintenance Manual (Including
Repair Parts and Special Tools List), Compass, Magnetic, Unmounted: M2 (1290-930-4260).
7 November 1963.
TM 9-1315-249-12&P. Operator’s and Unit Maintenance Manual (Including Repair Parts and
Special Tools List) for
81-mm Mortar Training Device:
81-mm Sabot (Inert) M1 and
22-mm Sub-Caliber Practice Cartridges M744, M745, M746, and M747. 1 September 1990.
TM 9-2350-277-10. Operator's Manual For Carrier, Personnel, Full-Tracked, Armored, M113A3
(NSN 2350-01-219-7577) Carrier, Command Post, Light Tracked, M577A3 (2350-01-369-
6058) Carrier, Anti-Tank
(Tow), Full Tracked, Armored, M901A3
(2350-01-369-7253)
Carrier, Fire Support Personnel, Full Tracked, Armored, M981A3
(2350-01-369-6079)
Carrier, Smoke Generator, Full Tracked, M1059A3 (2350-01-369-6083) Carrier, Mortar,
120-mm M121, Self Propelled, M1064A3
(2350-01-369-6282) Carrier, Standardized
Integrated Command Post System (SICPS) M1068A3; Carrier, Mechanized Smoke Obscurant
M58. 2 January 2001.
17 July 2008
FM 3-22.91
References-1
References
ARMY FORMS
DA Form 2188-R. Data Sheet (LRA).
DA Form 2399-R. Computer’s Record (LRA).
DA Form 2601-1-R. MET Data Correction Sheet for Mortars (LRA).
DA Form 2601-2-R. MET Data Correction Sheet 6400-Mils (Mortars) (LRA).
DA Form 3675-R. Ballistic Message (LRA).
DA Form 3677-R. Computer MET Message (LRA).
DA Form 5472-R. Computer's Record (MPI) (LRA).
READINGS RECOMMENDED
These sources contain relevant supplemental information.
FM 4-25.11. First Aid. Reprinted with Change 1. 23 December 2002.
FM 6-30. Tactics, Techniques, and Procedures for Observed Fire. 16 July 1991.
FM 7-0. Training the Force. 22 October 2002.
FM 7-1. Battle Focused Training. 15 September 2003.
FM 7-90. Tactical Employment of Mortars. 09 October 1992.
FM 25-4. How to Conduct Training Exercises. 10 September 1984.
FT 81-AR-2. Firing Tables for Mortar, 81-mm, M252, Firing Cartridge, HE, M821, Cartridge, HE
M889, Cartridge, RP, M819, Cartridge Illum, M853A1, Cartridge TP, M879, Cartridge HE,
M821A1 and 821A2, Cartridge HE, M889A1 and Mortar, 81mm, M29A1, Mortar,81mm,
M252, Mortar,
120mm, M120 and M121 with 81mm, Insert Training Device Firing
Cartridge, TP (SR), M880. 1 June 1997.
TB 43-0250. Ammunition Handling, Storage and Safety. 3 December 2007.
INTERNET WEBSITES
US Army Publishing Directorage
DA Forms
General Dennis J. Reimer Training and
Doctrine Digital Library
References-2
FM 3-22.91
17 July 2008
Index
NUMBERS
B
check fire, 15-40, 15-41
(illus)
50-meter bracket, splitting of,
ballistic(s), 2-1
14-2 (illus)
message, 4-22
commander’s interface, 15-4
(illus)
6400-mil meteorological
basic
message, 4-37
data, 4-34 (illus)
communications
safety diagram, C-5 (illus)
connector, 17-23 (illus)
A
fields, 4-17 (illus)
battalion fire support
adjustment, firing, 13-16,
parameters, screen setup,
personnel, 1-3 (illus)
13-17 (illus), 13-20 (illus)
17-24 (illus)
plan, 2-22
air temperature and density
company fire support
battery life, 17-4 (illus)
corrections, 4-32 (illus)
personnel, 1-3 (illus)
bracket, splitting of, 14-2
plan, 2-20
alerts, 15-44 (illus)
(illus)
computer
alignment
burst line, M301A3, 13-13
meteorological message,
of plots, 13-5 (illus)
(illus)
4-36
with impact point, 14-26
record, 4-3
(illus)
bursts, 2-2
Computer's Record (see DA
alphanumeric and minus sign
C
Form 2399-R)
keys, 6-6 (illus)
call for fire, 5-1, 8-14 (illus)
configuration, system, 15-13
altitude correction, 14-18
and fire direction center
(illus)
order, E-9 (illus)
consolidated target list, 2-21
example, and fire direction
(illus)
ammunition, 2-25
center order, 8-14
data fields, 4-11 (illus)
control buttons, 18-23 (illus)
(illus)
expended screen 18-11
format, 5-7
conversion table, deflection,
(illus)
menu selection, 18-22
14-3 (illus)
fire unit screen, 15-28
(illus)
(illus)
coordinated illumination,
roll up screen, 15-29
certification
8-23
(illus)
Mortar Fire Control
data screen, 18-48 (illus)
screens, 17-15 (illus),
System, E-3
high-explosive solution
17-16 (illus)
plotting board, E-2
screen, 18-48 (illus)
unit screen, 15-27 (illus)
mission
channel A screen, 15-24
data screen, 18-48 (illus)
analysis and attack, target,
(illus)
initialization screen,
2-22
character groups, 4-26
18-47 (illus)
angle T, 4-17, 4-18 (illus),
through 4-27 (illus)
correction(s), 14-20 (illus)
4-19 (illus)
charge
air temperature and
attack
determination of, 12-4
density, 4-32 (illus)
area, size of, 2-23
(illus)
factors, 4-34 (illus), 14-17
methods of, 2-27
versus range chart, 12-4
and basic data, 4-34
target analysis and, 2-22
(illus)
(illus)
zone and range, 12-5
meteorological, 4-37
audible alarm, 6-11
(illus)
crypto key, 17-31
authentication and call for
chart
fire, 5-8
current screen, MET data,
data fields, 4-7 (illus),
15-35 (illus)
4-12 (illus)
firing, 12-13
17 July 2008
FM 3-22.91
Index-1
Index
D
declination diagram, 7-4
select known point
(illus)
number screen, 18-32
DA Forms
(illus)
2188-1-R (LHMBC/
deflection
selecting rnds complete,
MFCS Data Sheet),
determination of, 12-3
18-31 (illus)
4-14 (illus)
(illus)
solution/gun orders
2188-R (Data Sheet), 4-9
scale, superimposition of
screen, 18-25 (illus)
(illus), 14-12 (illus)
referred, 12-3 (illus)
target screen, 18-27 (illus)
2399-R (Computer's
deflection conversion table,
Record), 4-3 (illus),
direct lay
8-19 (illus), 12-21,
14-9 (illus), 14-11
first adjustment, 18-17
12-22, 14-3 (illus)
(illus), 14-16, 14-23
(illus)
intersection, 12-25
(illus)
missions, 18-16 (illus)
resection, 12-24 (illus)
completed adjustment,
direction and distance, 12-26
13-3 (illus)
desktop, 17-5 (illus)
(illus)
completed call for fire
determination
and fire direction
dispersion, 2-9
of a spotting, 9-7 (illus)
center order, 13-2
of charge, 12-4 (illus)
distance table for a 2-meter
(illus)
of deflection, 12-3 (illus)
subtense bar, D-8 (illus)
2601-1-R (Met Data
of deflection and range,
Correction Sheet for
driver’s display, 15-7 (illus)
12-7 (illus)
Mortars), 4-30 (illus),
of range, 12-12 (illus)
E
4-31 (illus)
2601-2-R (Meteorological
diagram
edit Commo Address screen,
Data Correction Sheet
construction of a, D-7
17-27 (illus)
6400 Mils [Mortars]),
(illus)
elliptical pattern, 2-10 (illus)
4-38 (illus), 4-39 (illus)
declination, 7-4 (illus)
3675-R (Ballistic
end of mission, 18-32 (illus)
digital device support, 10-1
Message), 4-24 (illus),
message, 16-14 (illus)
4-28 (illus)
digital fire mission (see also
screen and information,
3677-R (Computer Met
screen), 18-23 (illus)
18-10 (illus), 18-11
Message), 4-25 (illus)
end of mission message,
(illus)
5472-R (Computer's
18-32 (illus)
engagement, method of, 5-3
Record), 4-16 (illus)
final adjustment, 18-30
(illus)
estimation of range, 12-27
danger mortar, 14-22 (illus),
fire for effect solution
(illus)
14-25 (illus)
screen, 18-30 (illus)
example illumination
data
first adjustment, 18-29
adjustment, 13-13 (illus)
entry, 7-2
(illus)
fields, 4-15 (illus)
message send status
example situation charts
initialization, 5-13, 7-9
screens, 18-25 (illus)
number 1, 8-17 (illus)
Lightweight Handheld
mission
numbers 2 and 3, 8-17
Mortar Ballistic
data screen, 18-24
(illus)
Computer (LHMBC),
(illus)
numbers 4 and 5, 8-17
4-14
messages screens,
(illus)
mission, 18-50 (illus),
18-29 (illus)
F
18-71 (illus)
status screen, 18-27
plane, meteorological,
(illus)
fall of rounds, 13-12 (illus)
4-27 (illus)
new call for fire screen,
screen, 15-16 (illus)
18-23 (illus)
sheet, 4-9, 4-14
system configuration,
15-13
Data Sheet (see DA Form
2188-R)
Index-2
FM 3-22.91
17 July 2008
Index
field(s)
field-expedient survey
firing
ammunition data, 4-11
techniques, D-1
120-E-1, example
(illus)
completed, 2-6 (illus)
final protective fire, 2-16
chart data, 4-7 (illus), 4-12
adjustment, 13-16, 13-17
(illus), 14-23, 14-24
(illus)
(illus), 13-20 (illus)
(illus)
communications, 4-17
chart, 12-13
adjustment
(illus)
correction fields, 4-12
A1, 18-53 (illus),
data, 4-15 (illus)
(illus)
18-54 (illus)
fire direction center order,
data, 2-1
A2, 18-56 (illus)
4-5 (illus)
data fields, 4-12 (illus)
A3, 18-57 (illus)
firing correction, 4-12
tables, 2-6, 4-19, 4-32
A4, 18-58 (illus)
(illus)
through 4-35 (illus)
first, 18-53 (illus)
firing data, 4-12 (illus)
60-mm mortar, 4-20
sheaf, preparation for,
forward observer data,
(illus)
18-55 (illus)
4-11 (illus)
81-mm mortar, 4-21
changing of
location of, 12-27
(illus)
adjusting gun,
(illus)
120-mm mortar, 4-22
18-52 (illus)
geographical reference,
(illus)
fire for effect volleys,
4-15 (illus)
FT 81-A1-3
18-59 (illus)
grid mission screen, 18-3
charge 5, 13-18
dimensions, 9-9 (illus)
(illus)
(illus)
initial solution screen,
initial
charge 8, 13-14
18-51 (illus)
chart data, 4-6 (illus)
(illus)
mission data screen, 16-34
fire command, 4-6
(illus), 18-50 (illus)
first plot, 12-17 (illus)
(illus)
section solution, 18-59
intelligence, 4-13 (illus)
forward observer
(illus)
lightweight handheld
data fields, 4-11 (illus)
solution screen, 16-35
mortar ballistic
location of, 12-27 (illus)
(illus)
computer data, 4-10
storing, 18-60 (illus)
forward plotting target, 12-20
(illus)
(illus)
meteorological data
fire
correction sheet, 4-29
and control, 5-4
function(s)
(illus)
control
ammunition/status
mission data screen, 18-4
equipment, 7-1, 12-1
function, 15-27
(illus)
systems, 1-2
meteorological data
observer correction, 4-7
technical, 8-11
screen, 15-32
(illus)
direction, 2-1, 3-1
target/known point screen,
parameter setup, 17-25
direction center, 3-2, E-1
15-36
(illus)
order, 9-18 (illus)
function keys, 15-3 (illus)
quick smoke mission data
final protective, 9-8, 14-21
screen, 18-63 (illus)
mission keys, 6-7 (illus)
G
Solution/Gun Orders
missions, 18-1
geographical reference
screen, 18-5 (illus)
Mortar Fire Control
fields, 4-15 (illus)
subscriber, 4-16 (illus)
System and, 16-1
screen, 15-17 (illus)
Subsequent Adjust screen,
planning, 2-14
18-10 (illus)
searching, 8-20, 13-8
global positioning system
subsequent command, 4-8
support coordination
(GPS), 17-29, 17-30
(illus)
measures, 2-19
(illus), 17-31 (illus)
target identification, 4-11
support plan
graphic resection, D-1
(illus)
battalion, 2-18
target screen box, 18-23
company, 2-20
graphical user interface,
(illus)
personnel, 1-3 (illus)
15-10 (illus)
weapon data, 4-10 (illus),
traversing, 8-13, 13-1
4-16 (illus)
window, 18-26 (illus)
17 July 2008
FM 3-22.91
Index-3
Index
grid, 12-15 (illus)
solution and display of
lightweight handheld mortar
intersection, 12-14 (illus)
fuze setting, 18-43
ballistic computer
manual, 18-2 (illus), 18-3
(illus)
(LHMBC), 17-1, 17-2
(illus), 18-50 (illus)
targets screen, 18-41
(illus), 17-3 (illus),
mission, 8-1, 12-23, 18-2
(illus)
17-4 (illus), 18-1, E-4
screen fields, 18-3
communication, 17-23
immediate
(illus)
through 17-28 (illus)
smoke, 18-70 through
data fields, 4-10 (illus)
groups, six-character, 4-23
18-71 (illus)
graphical user interface,
(illus)
smoke or suppression,
15-9, 17-4
9-12
gunner’s display, 15-6 (illus)
screens,
suppression, 18-72
startup, 17-8
gun-target azimuth chart,
through 18-73 (illus)
8-16 (illus)
line drawn in any
impact, mean point of, 14-3
direction, D-2 (illus)
H
indicators, light-emitting
location of round relative to
hasty survey, D-4 (illus)
diode, 6-10 (illus)
height of burst, 13-18
height of burst, 13-14, 13-18
indirect fire team, 1-2 (illus)
(illus)
(illus)
initial
log-in screen, 15-12 (illus)
high-explosive adjustment
chart data fields, 4-6
M
phase, 18-63 (illus), 18-64
(illus)
(illus)
fire command fields, 4-6
M16 plotting board, 11-2,
(illus)
11-3 (illus)
hipshoot, 18-17 (illus), 18-20
certification, E-2
(illus)
initialization, 7-5
data for traversing fire,
mission(s), 18-17
of mission, 18-40 (illus),
13-1 (illus)
mission screen, 18-17
18-50 (illus), 18-70
(illus)
(illus)
M19 plotting board, 11-4
end of, 18-20 (illus)
(illus)
intelligence fields, 4-13
solution screen, 18-18
certification, E-2
(illus)
(illus)
manual
Subsequent Adjust screen,
K
adjust fire screen, 16-18
18-19 (illus)
keys, special, 9-19
(illus)
hollow cross with target
call for fire screen, 16-16
known point, 16-22
number, 12-8 (illus)
(illus)
screen, 15-38 (illus),
end of mission screen,
I
16-23 (illus)
16-19 (illus)
icons (see Mortar Fire
L
fire missions, 18-1
Control System), B-1
grid, 18-2 (illus), 18-50
laser polar
(illus)
identification, observer, 5-1
mission screen, 18-14
final protective fire,
(illus), 18-47 (illus)
illumination, 8-21, 13-12,
mission initialization
plot missions, 18-14
18-40 (illus), 18-42
screen, 18-50 (illus)
(illus)
latitude/longitude alternate
mission entry, 18-2 (illus)
first subsequent
methods screen, 15-22
mission menu, 18-2 (illus)
adjustment, 18-45 (illus)
(illus)
maximum rate of fire, 2-23
safety data screen, 18-44
LHMBC (see lightweight
(illus)
mean point of impact, 2-10
handheld mortar ballistic
second subsequent
(illus)
computer)
adjustment, 18-45 (illus)
registration, 9-4
light-emitting diode
memory, 6-13
indicators, 6-10 (illus)
Index-4
FM 3-22.91
17 July 2008
Index
message
data, 18-50 (illus), 18-71
smoke, 16-43, 18-61
6400-mil meteorological,
(illus)
special, 16-19, 18-33
4-37
screen, 16-2 (illus),
status screen, 16-29
ballistic, 4-22
16-6 (illus), 16-13
(illus), 16-39 (illus),
computer meteorological,
(illus), 16-25 (illus),
16-42 (illus)
4-36
18-3 (illus), 18-3
modified observed chart,
icons, 17-7 (illus)
(illus), 18-4 (illus)
12-20 (illus)
meteorological, 4-37
screen fields, 18-4
plain text, 15-41
(illus)
modified-observed firing
priorities, 17-7 (illus)
digital, 16-5, 18-21
chart, 12-13
receipt of, 18-22
fire, 16-4
mortar ballistic computer
screens, 16-12 (illus),
direct lay, 18-16 (illus)
(MBC), 6-1 (illus),
16-30 (illus), 16-43
end of
7-1, E-5
(illus)
message, 16-14 (illus)
example test situations,
switch entries, 9-20 (illus)
screen, 18-11 (illus)
E-5
to observer, 5-6
final protective fires,
16-32, 18-49
Mortar Fire Control System,
meteorological (MET)
fire, 16-4
4-14, 15-1, 15-2 (illus)
current screen, 17-20
grid, 8-1, 12-23, 18-2,
capabilities, 15-8
(illus)
18-3 (illus)
certification, E-3
data
hipshoot, 18-17
fire missions, 16-1
correction sheet fields,
illumination, 16-24, 18-39
4-29 (illus)
mortar
coordinated, 16-30,
current screen, 15-35
and corresponding
18-46
(illus)
ammunition, 6-12
initialization, 18-40
plane, 4-27 (illus)
(illus)
(illus), 18-50 (illus),
edit
location replot, 12-18
18-70 (illus)
lines screen, new,
(illus)
manual, 16-16
17-19 (illus)
surface danger zone, C-2
manual fire, 18-1
station screen, 17-19
(illus)
menu, manual, 18-2 (illus)
(illus)
message
mounting azimuth and
messages, 4-41 (illus),
end of mission, 16-4
references screen, 15-23
4-42 (illus)
(illus)
(illus)
new screen, 17-18 (illus)
end of screen, 18-10
multiple transfer limits, 14-6
method(s)
through 18-11 (illus)
(illus)
of attack, 2-27
polar, 18-14 (illus)
of engagement, 5-3
polar plot, 8-8, 12-24,
muzzle velocity, 2-3
18-13
military grid reference system
N
priority icon, 18-22 (illus)
(MGRS) alternate
quick fire, 18-15
new
methods, 15-21 (illus)
registration, 18-34
call-for-fire screen, 16-5
minimum
screen
(illus), 16-24 (illus),
easting and northing,
direct lay, 18-16 (illus)
16-33 (illus)
17-11 (illus)
polar, 18-13 (illus)
meteorological data
zone, location of, 17-11
quickfire, 18-15 (illus)
screen, 15-34 (illus)
(illus)
selection, 18-11 (illus)
O
status, 16-11 (illus),
mission(s) (see also special
16-29 (illus), 16-39
observed
missions), 1-4, 16-1,
(illus), 16-42 (illus)
chart, 12-19, 12-20 (illus)
16-2, 16-4, 18-1
search, 13-11 (illus),
fire charts, 12-1
completed, 13-7 (illus)
13-12 (illus)
observer
search and traverse, 18-74
correction fields, 4-7
shift from a known point,
(illus)
8-5, 12-23, 18-12
identification, 5-1
17 July 2008
FM 3-22.91
Index-5
Index
one probable error, 2-12
plotting board
mission
(illus)
certification, E-2
data screen fields, 18-63
(illus)
one-gun illumination Fire for
pointing device, 15-6 (illus)
initialization screen,
Effect Solution screen,
polar
18-62 (illus)
18-46 (illus)
alternate methods screen,
target location information,
operation(s), 2-17
15-21 (illus)
18-62 (illus)
screen, 18-76 (illus),
mission, 8-8, 18-14 (illus)
18-77 (illus)
screen, 18-13 (illus)
R
plot mission, 12-24, 18-13
out of sheaf, 14-4 (illus)
radar registration, 9-6, 14-19
position(s), 1-3
P
001, 17-30
range, 2-2
parameter setup fields and
entry, 17-8
determination, 12-12
settings, 17-25 (illus)
mortar, plotting of, 12-16
(illus)
(illus)
estimate, reference point to
password screen, 17-9 (illus)
screen, 15-18 (illus)
forward observer, 12-27
pattern, elliptical, 2-10 (illus)
(illus)
power distribution assembly,
lateral spread, 8-23 (illus)
pivot point, 12-14 (illus)
15-5 (illus)
probability curve, 2-12
PKG 11, 15-34 (illus)
probability, 2-9, 2-12 (illus)
(illus)
standard, 2-7
plain text
probable error, 2-12
message read screen,
in deflection, 2-13 (illus)
rate of fire
15-42 (illus)
range, 2-12
60-mm mortar, 2-24 (illus)
messages, 15-41
81-mm mortar, 2-24 (illus)
procedures, 1-4
120-mm mortar, 2-25
plot screen, 16-9 (illus),
projectile movements, 2-2
(illus)
16-38 (illus)
propellants, 2-2
rectangles, 2-11 (illus)
plot(ting) (see also plotting
temperature of, 4-35 (illus)
board, replotting)
registration, 2-23
alignment, 13-5 (illus)
protractor aligned with
adjust sheaf screen, 18-37
board, 11-1
correct azimuth, D-2 (illus)
(illus)
M16, 11-3 (illus)
error and warnings screen,
Q
M19, 11-4 (illus)
18-38 (illus)
preparation of, 12-2
quickfire
fire for effect solution
(illus)
missions, 18-15
screen, 18-36 (illus)
updated, 12-8 (illus)
mission screen, 18-15
first subsequent
first, 12-17 (illus)
(illus)
adjustment, 18-36 (illus)
of first round, 12-10
mission initialization
of mortar position, 12-9,
screen, 18-34 (illus)
qualification, E-2
12-16
point, 16-20
parallel line, 12-11
quick fire mission screen,
screen, 16-21 (illus)
of
18-15 (illus)
sheaf adjustment, 9-1
mortars, 14-26 (illus)
save registration point
quick smoke, 9-13
observer’s correction,
screen, 18-39 (illus)
ammunition expended
12-6
second subsequent
screen, 18-69 (illus)
rounds, 14-6 (illus)
adjustment, 18-36 (illus)
end of mission screen,
starting points, 13-4
solution/gun orders screen,
18-69 (illus)
surveyed registration,
18-35 (illus)
guns A1, A2, A3, and A4
14-2 (illus)
solutions, 18-68 (illus)
replotting of previously fired
target, forward, 12-20
targets, 12-21 (illus)
(illus)
test, E-46
reregistration, 14-11 (illus)
Index-6
FM 3-22.91
17 July 2008
Index
final protective fire, 18-50
safety data, 18-8 (illus)
rounds, plotting of, 14-6
(illus)
segment, add new safety
(illus)
fire-for-effect solution,
fan, 17-21 (illus)
18-30 (illus)
Send Status, 17-28 (illus)
S
Setup Commo Addresses,
safety, C-1, C-4 (illus)
17-26 (illus)
global positioning system
danger close, 5-4, 9-11
Setup Data, 17-17 (illus)
status, 17-30 (illus)
danger mortar, 14-22
setup geographical
grid mission, 18-3 (illus)
reference, 17-10 (illus)
hipshoot, 18-17 (illus),
shift mission, 18-12 (illus)
data screen, 16-8 (illus),
18-20 (illus)
subsequent adjust, 18-9
16-27 (illus), 16-36
illumination, 18-40 (illus)
(illus)
(illus)
immediate
targets(s), 18-6 (illus),
fan screen, 15-39
smoke, 18-70 (illus),
18-27 (illus)
surface danger zones, C-1,
18-71 (illus)
unit list, 17-12 (illus),
C-2 (illus)
suppression, 18-72
17-13 (illus)
warning
(illus), 18-73 (illus)
use of default versus
known point, number,
screens, Mortar Fire Control
technical fire control
18-32 (illus)
System
settings, 7-8
laser polar mission, 18-14
alerts, 15-44 (illus)
(illus)
ammunition
safety data
manual
fire unit, 15-28 (illus)
screen, 18-8 (illus)
grid, 18-2 (illus), 18-50
roll up, 15-29 (illus)
switch entries, 9-21 (illus)
(illus)
unit, 15-27 (illus)
safety fan
missions menu, 18-2
channel A, 15-24 (illus)
adding new, 17-21 (illus)
(illus)
check fire, 15-41 (illus)
fan screen, 15-40 (illus)
message, send status,
current, 15-34 (illus),
fan segment screen, 17-21
18-25 (illus)
15-35 (illus)
(illus)
meteorological
data, 15-16 (illus)
current, 17-20 (illus)
final protective fire, 16-34
safety T, C-6 (illus)
edit station, 17-19 (illus)
(illus), 16-35 (illus)
save
new, 17-18 (illus)
geographic reference,
data screen, 16-15 (illus)
mission
15-17 (illus)
registration screen, 16-20
data, 18-3 (illus), 18-4
known point, 15-38 (illus),
(illus)
(illus), 18-24 (illus)
16-23 (illus)
initialization, 18-40
latitude/longitude alternate
scale, vernier, 11-2 (illus)
(illus), 18-50 (illus),
methods, 15-22 (illus)
screens, lightweight handheld
18-70 (illus)
login, 15-12 (illus)
mortar ballistic
message, 18-29 (illus)
manual
computer
polar, 18-13 (illus)
adjust fire, 16-18 (illus)
ammunition, 17-15 (illus),
quickfire, 18-15 (illus)
call for fire, 16-16
17-16 (illus)
status, 18-27 (illus)
(illus)
expended, 18-11 (illus)
new call for fire, 18-23
end of mission, 16-19
communications
(illus)
(illus)
parameters, 17-24 (illus)
password, 17-9 (illus)
message, 16-12 (illus),
direct lay mission, 18-16
polar mission, 18-13
16-30 (illus), 16-43
(illus)
(illus), 18-14 (illus)
(illus)
Edit Commo Address,
quick fire mission, 18-15
meteorological, current,
17-27 (illus)
(illus)
15-35 (illus)
edit lines, 17-19 (illus)
rounds complete, 18-31
military grid reference
end of mission, 18-10
(illus)
system alternate
(illus)
methods, 15-21 (illus)
17 July 2008
FM 3-22.91
Index-7
Index
mission
search and traverse
situations, example test,
data, 16-2 (illus), 16-6
end of mission and
Mortar Ballistic Computer
(illus), 16-13 (illus),
ammunition expended
(MBC), E-5
16-25 (illus)
screens, 18-83 (illus)
smoke
status, 16-29 (illus),
final adjustment, 18-80
card
16-42 (illus), 16-39
(illus)
example with solution,
(illus)
fire for effect solution,
18-67 (illus)
mounting azimuth and
18-81 (illus)
screen, 18-66 (illus)
references, 15-23 (illus)
first adjustment, 18-79
chart
(illus)
81-mm M819 red
initial solution, 18-79
new
phosphorus, 9-16
(illus)
call for fire, 16-5 (illus),
(illus)
16-24 (illus), 16-33
120-mm M929 white
(illus)
mission
phosphorus, 9-15
meteorological data,
data screen, 18-75 (illus)
(illus)
15-34 (illus)
initialization screen,
immediate, 18-70 (illus),
18-74 (illus)
18-71 (illus)
operation screen, 18-76
plain text message read,
Solution/Gun Orders screen,
(illus), 18-77 (illus)
15-42 (illus)
18-25 (illus)
plot, 16-9 (illus), 16-38
fields, 18-5 (illus)
(illus)
round and hand wheel fire
solution screens, 16-7 (illus),
polar, alternate methods,
data screen, 18-82 (illus)
16-10 (illus), 16-26 (illus),
15-21 (illus)
second solution, 18-80
16-28 (illus), 16-37 (illus),
position, 15-18 (illus)
(illus)
16-41 (illus)
registration, 16-21 (illus)
safety
special missions, 18-33
sheaf, 18-75 through 18-77
data, 16-8 (illus), 16-27
coordinated illumination,
(illus)
(illus), 16-36 (illus)
18-46
types and methods, 18-78
fans, 15-40 (illus)
final protective fires, 18-49
(illus)
save
illumination, 18-39
data, 16-15 (illus)
search mission, 13-11 (illus)
registration, 18-34
registration, 16-20
search and traverse, 18-74
searching fire, 8-20, 13-8
(illus)
smoke, 18-61
send, 15-43 (illus)
sectors, large, 4-37
spotting, determination of,
solution, 16-7 (illus),
sheaf(ves), 8-12
9-7 (illus), 14-20 (illus)
16-10 (illus), 16-26
adjustment, 9-1, 14-1,
(illus), 16-28 (illus),
subscriber fields, 4-16 (illus)
14-21
16-37 (illus)
out of, 14-4 (illus)
Subsequent Adjust screen,
solution end of mission,
record, computer, 4-3
16-40 (illus), 18-9
16-41 (illus)
types, 4-1, 4-2 (illus)
(illus)
subsequent adjust, 16-40
fields, 18-10 (illus)
(illus)
shift
targets(s), 15-37 (illus),
from a known point, 12-
subsequent command fields,
16-22 (illus)
23,
4-8 (illus)
unit, 15-27 (illus)
18-12
subtense bar, D-5 (illus)
configuration, 15-15
mission, 8-5
(illus)
superimposition of referred
shift mission screen, 18-12
list, 15-14 (illus)
deflection scale, 12-3
(illus)
universal transverse
(illus)
mercator, 15-20 (illus)
Index-8
FM 3-22.91
17 July 2008
Index
support
screen, 15-37 (illus), 16-22
U
digital device, 10-1
(illus), 18-6 (illus),
unit
18-21 (illus), 18-27
suppression, immediate,
configuration screen,
(illus)
18-72 (illus), 18-73 (illus)
15-15 (illus)
adjustments, 18-29
corrections, 2-6
surface danger zones, C-1
(illus), 18-30 (illus)
list screen, 15-14 (illus),
box fields and purposes,
survey control, 2-23
17-12 (illus), 17-13
18-23 (illus)
(illus)
switch(es)
buttons, 18-7 (illus)
screen, 15-27 (illus)
action, 6-5 (illus)
transfer of, 12-18
status fire, 15-30 (illus)
display, 6-10 (illus)
typical, 2-27
selection of, 2-26
grid mission, 8-1
technical firing control, 1-7,
initialization, 6-2 (illus)
universal transverse
8-11, 8-12 (illus)
Mortar Ballistic Computer,
mercator,
7-1
temperature, propellant, 4-35
15-20 (illus)
output, 6-9 (illus)
(illus)
V
panel, Mortar Ballistic
terminology, 2-14
Computer, 7-1 (illus)
vehicle motion sensor, 15-8
polar mission, 8-8
three distant points, D-1
(illus)
shift mission, 8-5
(illus)
vernier scale, 11-2 (illus)
systems, fire control, 1-2
tracing paper, positioning, of
vertical interval, 2-2
D-3 (illus)
T
and crest clearances, C-3
training
(illus)
tabs and screens, 16-3 (illus)
evaluation of, A-1
correction factors, 14-17
target(s), 2-15 (illus), 2-22
trajectory, 2-4, 2-5 (illus)
VMF R5, 15-34 (illus)
and known points, 18-21
and methods of attack,
transfer limits
W
2-28 (illus), 2-29 (illus)
multiple, 14-6 (illus)
warning order, 5-1
considerations, 2-16
registration point, 14-5
data updates, 4-47 (illus)
(illus)
weapon data fields, 4-10
description, 5-3
(illus), 4-16 (illus)
transmit switch entries, 9-21
direction to, 2-1 (illus)
(illus)
wind components, 4-33
identification fields, 4-11
(illus)
(illus)
traverse leg 1, D-6 (illus)
location, 5-2
window fields and purposes,
traversing fire, 8-13, 13-1
18-26 (illus)
17 July 2008
FM 3-22.91
Index-9















Content      ..     13      14      15
