Airspeed Factors
Nomenclature
Paragraph
Max Weight
Evaluated
Number
(Pounds)
Air Speed
(Knots)
Two Empty Sixcon Storage Modules, Fuel/Water,
TAMCN B2085/B2086 and One Full Sixcon
9-3
15,600
120
Storage Module, Side by Side
Two Full Sixcon, Storage Modules, Fuel/Water, TAMCN
B2085/B2086 and One Sixcon Pump Module,
9-3
22,500
120
Fuel/Water, TAMCN B1580/B1581, Side by Side
Two Empty Sixcon, Storage Modules, Fuel/Water,
TAMCN B2085/B2086 and One Sixcon Pump
9-3
7,900
120
Module, Fuel/Water, TAMCN B1580/B1581, Side
by Side
One Full Sixcon, Storage Modules, Fuel/Water,
TAMCN B2085/B2086 and Two Sixcon Pump
9-3
14,800
120
Modules, Fuel/Water, TAMCN B1580/B1581, Side
by Side
One Empty Sixcon, Storage Modules, Fuel/Water,
TAMCN B2085/B2086 and Two Sixcon Pump
9-3
7,500
120
Modules, Fuel/Water, TAMCN B1580/B1581, Side
by Side
Three Sixcon Pump Modules, Fuel/Water, TAMCN
9-3
7,100
120
B1580/B1581, Side by Side
One Full and One Empty Sixcon, Storage Modules,
Fuel/Water, TAMCN B2085/B2086 and One Sixcon
9-3
15,200
120
Pump Module, Fuel/Water, TAMCN B1580/B1581,
Side by Side
Five 500-Gallon Fuel Drums
9-4
18,825
100
Load Handling System-Compatible Water Tank
9-5
9,200
135
Rack System
Satellite Communications Shelter, AN/TSC-93B (V)
10-2
3,250
100
1 or (V) 2
Operations Control Group, AN/TPQ-36 Firefinder,
10-2
2,200
90
Block II
Operations Central Shelter, Firefinder, AN/TPQ-36
10-3
2,869
80
(V) 8, S-788
Biological Agent, Automatic, Integrated Detection
10-3
3,300
100
System, s-788
Downsized Direct Support Section, Standard
10-3
2,400
70
Integrated Command Post Systems, S-787/S-788
Multiplexer Terminal Set, AN/TSQ-146(V)
10-4
6,190
120
Battery Servicing Shelter, AN/TSM-133
10-4
5,420
130
Repeater Set, Radio, AN/TRC-138A
10-4
4,720
80
Radio Terminal Set, AN/TRC-173
10-4
3,790
80
Repeater Set, Radio, AN/TRC-174
10-4
4,100
80
Radio Terminal Set, AN/TRC-175
10-4
4,690
80
Regency Net Force Terminal, AN/TRC-179(V)1
10-4
8,200
110
Meteorological Data System (MDS)
10-4
4,750
130
FM 4-20.199/MCRP 4-11.3E, VOL III/NTTP 3-04.13/
20 February 2009
AFMAN 11-223 (I), VOL III/COMDINST M13482.4B
C-17
Appendix C
Nomenclature
Paragraph
Max Weight
Evaluated
Number
(Pounds)
Air Speed
(Knots)
Position Location Reporting System Master Station,
10-4
6,050
100
AN/TSQ-129
Enhanced Position Location Reporting System,
10-4
6,289
100
Net Control Station, AN/TSQ-158
Tactical Satellite Communications Terminal,
10-4
6,200
100
AN/TSC-85B
IFTE Base Shop Test Facility, (BSTF), Basic, S-
10-4
7,806
120
280C/G, AN/TSM-191(V)3
IFTE Base Shop Test Facility, (BSTF), HAWK, S-
10-4
7,748
120
280C/G, AN/TSM-191(V)2
IFTE 60 Hz Storage Shelter,
10-4
6,365
110
S-280C/G, S-744/TSM-191V
IFTE 400 Hz Storage Shelter,
10-4
5,119
110
S-280C/G, S-175/TSM-191V
Communications Nodal Control Element (CNCE),
10-4
10,000
120
AN/TSQ-111
Airborne Reconnaissance Low-Imagery (ARL-I),
10-4
8,500
80
and Airborne Reconnaissance Low-Comint (ARL-
C), Fly Away Kits, Types A1/B1/C1
Joint Stars MGSM LRIP Shelter System, OA-
10-4
8,700
100
9408/TSQ-168(V)1
E0145 Bottle Cleaning and Charging Station
10-4
6,400
70
E1022 Maintenance Facility Night Sight
10-4
6,400
70
Central Office, Telephone, Automatic, AN/TTC-
10-4
5,700
60
42(V)
Airborne Mobile Direct Air Support Central (DASC),
10-4
5,600
60
AN/UYQ-3A
AN/TYA-16B
10-4
3,325
60
EMI, TAMCN C6110
10-5
7,700
50
Electronic EMI HSOP Shelter
10-5
4,140
50
Air Radar Shelter, AN/TPS-73
10-5
14,500
50
Air Radar Shelter, AN/TPS-63B
10-5
7,360
70
Rigid EMD Communications Shelter
10-5
7,000
50
Communications Central, ANTGC37
10-6
16,733
80
Rigid Shelter, General Purpose, TAMCN C6122
10-6
15,000
75
Electromechanical Induction (EMI)
10-6
15,000
70
Tactical Air Operations Module (TAOM), AN/TYQ-
10-6
16,175
100
23
Tactical Air Operations Module (TAOM), AN/TYQ-
10-6
15,187
100
23, Up Graded
Maintenance Repair Group Shelter, AN/TSM-170
10-6
10,900
90
Radar Surveillance Center, AN/TSQ-107
10-6
9,950
70
Control and Communications Shelter, AN/TSQ-131
10-6
14,050
80
FM 4-20.199/MCRP 4-11.3E, VOL III/NTTP 3-04.13/
C-18
AFMAN 11-223 (I), VOL III/COMDINST M13482.4B
20 February 2009
Airspeed Factors
Nomenclature
Paragraph
Max Weight
Evaluated
Number
(Pounds)
Air Speed
(Knots)
Non-Divisional AVIM Shop, Machine/ Welding Shop
10-6
Min-11,000
120
Max-13,200
Non-Divisional AVIM Shop, Pneudraulics Shop
10-6
Min-11,000
120
Max-13,200
Non-Divisional AVIM Shop, Power Train Shop
10-6
Min-11,000
120
Max-13,200
Non-Divisional AVIM Shop, Engine Shop
10-6
Min11,000
120
Max13,200
Non-Divisional AVIM Shop, Sheet Metal/Paint Shop
10-6
Min11,000
120
Max13,200
Non-Divisional AVIM Shop, Tool Crib Shop
10-6
Min11,000
120
Max13,200
Non-Divisional AVIM Shop, Propeller/Rotor Shop
10-6
Min11,000
120
Max13,200
Non-Divisional AVIM Shop, Electrical/Instrument
10-6
Min11,000
120
Shop
Max13,200
Non-Divisional AVIM Shop, Production/Quality
10-6
Min11,000
120
Control Shop
Max13,200
AN/TSQ-108A(V)2
10-6
13,050
80
Improved Direct Air Support Center
10-6
10,000
70
Shop Set, Maintenance Facility Night Sight, E1713
10-6
8,400
80
Shop Set, Maintenance Artillery, E1712
10-6
8,400
80
Shop Set, Maintenance Small Arms, E1714
10-6
8,400
Trojan Transportable Mini-Switch (TTMS) ISO
10-6
14,700
80
Shelter
EMI, EMC, S717T, Communications, TAMCN A2336
10-6
6,400
75
Non-Expandable Communications, TAMCN A2337
10-6
10,000
80
Tactical Reconnaissance Processing Evaluation
10-6
13,200
80
System (TERPES)
Trojan Air Transportable Electronic
Reconnaissance System (TATERS), SCINS
10-6
13,320
110
Communications Subsystem Shelter
Trojan Air Transportable Electronic
Reconnaissance System (TATERS), TOTS
10-6
10,720
60
Nonexpandable Shelter
Trojan Air Transportable Electronic
Reconnaissance System (TATERS), CHIPS
10-6
14,220
90
Receiver Group Shelter
Trojan Air Transportable Electronic
Reconnaissance System (TATERS), PEELS
10-6
15,100
80
Electric Power Plant Shelter
Containerized Shower (CS)
10-6
10,070
60
Standard Automotive Tools Set (SATS) with Core
10-6
10,760
110
Tool Set
FM 4-20.199/MCRP 4-11.3E, VOL III/NTTP 3-04.13/
20 February 2009
AFMAN 11-223 (I), VOL III/COMDINST M13482.4B
C-19
Appendix C
Nomenclature
Paragraph
Max Weight
Evaluated
Number
(Pounds)
Air Speed
(Knots)
Standard Automotive Tools Set with Core and Mod
10-6
12,660
110
1 Tool Set
Standard Automotive Tools Set with Core and Mod
10-6
13,420
110
1 and Mod 2 Tool Sets
AN/TYC-5A Data Communications Terminal
10-7
7,451
50
Shelter, Knockdown, 8- x 8- x 20-Foot
10-8
3,800
110
Jam-Resistant Secure Communications Satellite
10-9
20,730
60
Communications Terminal with Mobilizer
AN/TRC-173A
10-10
3,500
100
AN/TRC-174A
10-10
3,425
100
AN/TRC-175A
10-10
3,350
100
AN/TRC-138B
10-10
3,525
100
AN/TRC-138C
10-10
3,430
100
NATO Airbase Satcom Shelter Pallet, AN/TSC-93B
10-11
5,751
130
(V) 2
Trojan Air Transportable Electronic Reconnaissance
10-12
12,750
60
System High Gain Antenna Group Shelter
Digital Tech Controller Housed in a Modified
10-13
9,100
90
Gitchner Shelter
Full-Up Power Pack (FUPP) Container, M1A1,
11-2
13,620
120
Metal or Fiberglass
Two (2) ISU-90 Shipping/Storage Containers,
11-3
7,500-Each
90
Tandem
15,000-Total
Authorized Stockage List Mobility System FPU-12
11-4
20,000
110
(12-Foot Section Only)
Authorized Stockage List Mobility System FPU-8/12
11-5
25,000
130
(8- & 12-Foot Sections Connected)
26,000
Three Quadcons (3), Empty
11-6
5,292
100
Three Quadcons (3), Loaded
11-6
16,000
110
Four Quadcons (4), Empty
11-6
7,056
130
Four Quadcons (4), Loaded
11-6
16,000
130
Multiple Launch Rocket System with Two Rocket
11-7
10,010
110
Pods/Containers, (with Six Rockets)
Two Enclosure Assembly Launch Pods, Guided
11-7
10,222
110
Missile Launch Assembly
Multiple Launch Rocket System with Four
11-8
20,020
120
Enclosure Assembly Launch Pods
Guided Missile Launch Assembly with Four
11-8
20,444
120
Enclosure Assembly Launch Pods
Antenna, Satellite, Quick Reaction, (QRSA), OE-
12-2
4,830
110
361/G
NATO Air Base SATCOM Power Pallet, AN/TSC-
12-3
8,630
120
85B (V)2
FM 4-20.199/MCRP 4-11.3E, VOL III/NTTP 3-04.13/
C-20
AFMAN 11-223 (I), VOL III/COMDINST M13482.4B
20 February 2009
Airspeed Factors
Nomenclature
Paragraph
Max Weight
Evaluated
Number
(Pounds)
Air Speed
(Knots)
AN/TSC-93B Satellite Communications Terminal
12-4
3,644
120
without ALTA
AN/TSC-93B Satellite Communications Terminal
12-4
3,957
120
with ALTA
Palletized Loading System, M1077 Flatrack,
13-2
Min-6,500
120
Loaded
Max-20,000
Two M1077 Flatracks, Empty, Stacked
13-3
6,500
120
Three M1077 Flatracks, Empty, Stacked
13-3
9,750
120
Enhanced Palletized Loading System, Flatrack,
13-4
Min-10,500
80
Loaded
Max-22,000
One Enhanced, Flatrack, Empty
13-5
7,400
80
Two Enhanced, Flatracks, Empty, Stacked
13-5
14,800
80
Container Roll-In/Out Platform, Loaded
13-6
Min-6,500
120
Max-20,000
Two Through Five Container Roll-In/Out Platform,
13-7
Min-7,300
130
Empty, Stacked
Max-20,000
Naval Special Warfare Rigid Inflatable Boat without
13-8
15,070-
70
Trailer
18,230
Naval Special Warfare Rigid Inflatable Boat with
13-8
19,240-
70
Trailer
22,400
Naval Special Warfare Rigid Inflatable Boat Trailer
13-9
3,716
80
Special Operations Craft-Riverine Trailer
13-9
4,300
80
Special Operations Craft-Riverine
13-10
20,400
100
Special Operations Craft-Riverine with SOC-R
13-11
24,000
100
Trailer
35-Foot Riverine Assault Craft
13-12
13,800
70
35-Foot Riverine Assault Craft with Trailer
13-12
15,800
110
Small Unit Riverine Craft with Trailer
13-13
20,400
50
M35A1/A2 2 ½-Ton Cargo Truck
14-2
13,180
90
Water Trailer, M149/M149A1
14-3
Min-2,540
60
Max-6,060
Water Trailer, M149/M149A2
14-3
Min-2,800
60
Max-6,320
M114A1 155-mm Howitzer
14-4
12,660
90
One Conex Container
14-5
1,578
60
One MILVAN Container
14-6
4,710
60
FM 4-20.199/MCRP 4-11.3E, VOL III/NTTP 3-04.13/
20 February 2009
AFMAN 11-223 (I), VOL III/COMDINST M13482.4B
C-21
This page intentionally left blank.
Glossary
ACP
assault command post
AETC
auxiliary equipment transportation container
AFATADS
advanced field artillery tactical data systems
AL
Alabama
ARL-C
airborne reconnaissance low-comint
ARL-I
airborne reconnaissance low-imagery
ARTS
all-purpose remote transport system
ASLMS
autorized stockage list mobility system
AS
aviation section
ASK
acoustic suppression kit
ATG
antenna transceiver group
ATTN
attention
AVT
air vehicle transport
BCP
battery command post
bn
battalion
BSTF
base shop test facility
CAFSM
compressed air foam system, mobile
CBC
cargo bed cover
CGS
common ground station
CHIPS
command hardware intelligence processing subsystem
CLAWS
complementary low altitude weapons system
CMTH
contact maintenance truck, heavy
CNCE
communications nodal control element
CONEX
container express
COPS
crash-out-package system
CROP
container roll-in/out platform
CS
containerized shower
CWTRS
compatible water tank rack system
DA
Department of the Army
DASC
direct air support central
DAMP
digital antenna mast program
DC
District of Columbia
DPPC
deployable print production center
DTC
digital tech controller
DTSS-L
digital topographic support system-light
EAGS
expeditionary arresting gear system
EALP
enclosure assembly launch pods
EBFL
extendable boom forklift
FM 4-20.199/MCRP 4-11.3E, VOL III/NTTP 3-04.13/
20 February 2009
AFMAN 11-223 (I), VOL III/COMDINST M13482.4B
Glossary-1
Glossary
ECU
environmental control unit
ELAMS
expandable light airmobile shelter
EMI
electromechanical induction
EPLRS
enhanced position location reporting system
FAAR
forward area alerting radar
FL
Florida
FME
field maintenance equipment
FOPS
falling objects protection system
FUPP
full-up power pack
GCS
ground control station
GMLA
guided missile launch assembly
GPH
gallons per hour
GPM
gallons per minute
GVW
gross vehicle weight
HEMAT
heavy expanded mobility ammunition trailer
HGAG
high gain antenna group
H-HMMWV
heavy high-mobility multipurpose wheeled vehicle
HIPIR
high power illuminator radar
HMD
high mobility downsized
HMDA
high mobility digital group multiplexer assemblage
HMMH
high mobility materiel handler
HMMWV
high-mobility multipurpose wheeled vehicle
HMT
high mobility trailers
HQ
headquarters
HSTRU
hydraulic system test and repair unit
HZ
Hertz
IAS
intelligence analysis system
IEW
intelligence and electronic warfare
IFAV
interim fast attack vehicle
IMETS
integrated meteorological systems
ISO
International Organization of Standardization
IPDS
inland petroleum distribution system
ISYSCON
integrated system control
JRSC
jam-resistant secure communication
JSTAR
joint surveillance target attack radar
JTIDS
joint tactical information distribution system
KW
kilowatt(s)
LAV
light armored vehicle
lbs
pounds
LHS
load handling system
LIN
line number
FM 4-20.199/MCRP 4-11.3E, VOL III/NTTP 3-04.13/
Glossary-2
AFMAN 11-223 (I), VOL III/COMDINST M13482.4B
20 February 2009
Glossary
LMS
lightweight multipurpose shelter
LMTV
light medium tactical vehicle
LOSAT
line of sight anti-tank
LRTF
light rough terrain forklift
LTACFIRE
lightweight tactical fire control system
LVAD
low velocity airdrop
MAK
Marine armor kit
MANPADS
man portable air defense system
MASINT
measurements and signature intelligence
MDS
meteorological data system
MEWSS-PIP
mobile electronic warfare support system-product improvement program
MGB
medium girder bridge
MHG
meterological hydrogen generator
MICLIC
mine clearing line charge
MIL STD
military standard
MLRS
multiple launch rocket system
mm
millimeter
MPU
mobile power unit
MR
mobile radio
MRBS
mobile radio broadcasting subsystem
MSFDCS
multiservice flight data collection sheet
MSM
maintenance section multifunctional
MT
mobile television
MTBS
mobile television broadcasting subsystem
MTL
multi-terrain loader
MTV
medium tactical vehicle
MTVR
medium tactical vehicle replacement
NABS
NATO airbase satcom
NATO
North Atlantic Treaty Organization
NAVAIR
Naval Air Systems Command
NCS-E(D)
downsized net control system
NJ
New Jersey
NSC
Natick Soldier Center
NSN
national stock number
NSWRIB
naval special warfare rigid inflatable boat
OC
operations central
OCG
operational control group
PCP
platoon command post
PEELS
primary electrical equipment life support
PLS
palletized loading system
PN
part number
FM 4-20.199/MCRP 4-11.3E, VOL III/NTTP 3-04.13/
20 February 2009
AFMAN 11-223 (I), VOL III/COMDINST M13482.4B
Glossary-3
Glossary
POC
platoon operations center
PPU
primary power unit
PSV/MC
platoon support van/maintenance center
PQAS
petroleum quality analysis system
PTO
pioneer tool outfit
PTT
portable tower trailer
QM
quartermaster
QRSA
quick reaction satellite antenna
RAC
riverine assault craft
RI
Rhode Island
RIE
required individual equipment
RLST
remote landing site tower
ROPS
roll-over protection system
ROWPU
reverse osmosis water purification unit
RP/C
rocket pod/container
RT
rough terrain
SATS
standard automotive tool set
SCINS
satellite communications intesat nodal subsytem
SDDCTEA
Surface Deployment and Distribution Command Transportation Engineering
Agency
SE
shop equipment
SEE
small emplacement excavator
SHF
super high frequency
SICPS
standardized integrated command post systems
SIU
sensor interface unit
SIXCON
six-compartment container
SMART-T
secure mobile anti-jam tactical terminal
SMMS
sensor mobile monitoring system
SOC-R
special operation craft-riverine
SOMS
special operations media system
SSS
single shelter switch
STIK
soft top installation kit
SURC
small unit riverine craft
TAMCN
Table of Authorized Material Control Number
TAOM
tactical air operations module
TATERS
trojan air transportable electronics reconaissance system
TDN
tactical data network
TERPES
Tactical electronic reconaissance processing evaluation system
TM
technical manual
TMS
tactical messaging system
TOTS
temporary occupancy troop shelter
FM 4-20.199/MCRP 4-11.3E, VOL III/NTTP 3-04.13/
Glossary-4
AFMAN 11-223 (I), VOL III/COMDINST M13482.4B
20 February 2009
Glossary
TOW
tube launched, optically tracked, wire guided
TQG
tactical quiet generator
TRADOC
Training and Doctrine Command
TRSS
tactical remote sensor system
TSS
tracked suspension system
TTCS
tactical terminal control system
TTMS
trojan transportable miniswitch
TUAV
tactical unmanned vehicle
UMTE
unmanned threat emitter
US
United States
USA
United States Army
USMC
United States Marine Corps
VA
Virginia
W/WO
with/without
FM 4-20.199/MCRP 4-11.3E, VOL III/NTTP 3-04.13/
20 February 2009
AFMAN 11-223 (I), VOL III/COMDINST M13482.4B
Glossary-5
References
AF Form 847 Recommendation for Change of Publication.
AFMAN 24-204(I) /TM 38-250. Preparing Hazardous Materials for Military Air Shipments, 15 April
2007.
DA Form 2028 Recommended Change to Publications and Blank Forms.
DA Form 7382-R Sling Load Inspection Record.
FM 4-20.197/MCRP 4-11.3E, Vol I/NTTP 3-04.11/AFMAN 11-223(I), VOL I/COMDINST
M13482.2B. Multiservice Helicopter Sling Load: Basic Operations and Equipment, 20 July
2006.
FM 10-450-4/AFJMAN 11-223, VOL II; COMDTINST M13482.3A; MCRP 4-23E, VOL II; NWP
3-04.12. Multiservice Helicopter Sling Load: Single-Point Load Rigging Procedures, 30 May
1998.
MIL-STD-913A. Requirements for the Certification of Sling Loaded Military Equipment for External
Transportation by Department of Defense Helicopters, 3 February 1997.
TM 9-2320-285-24P. Unit, Direct Support, and General Support Maintenance Repair Parts and
Special Tools Lists, Truck Tractor, Yard-type: 43,500 GVW, DED, 4 x 2 Army Model
M878A1 (Ottawa Model 50) (NSN 2320-01-121-2102), 5 June 1992.
TM 9-1015-252-10. Operator's Manual for Howitzer, Light, Towed: 105-MM, M119A2 (NSN 1015-
01-482-4914) (EIC: 3WE) LIN: H57505, 15 August 2006.
TM 9-3990-206-14&P. Operator’s, Unit, Direct Support and General Support Maintenance Manual
(Including Repair Parts and Special Tools List) for Palletized Load System (PLS) Flatrack
Model M1077 /M1077A1 (NSN 3990-01-307-7676) ISO Compatible Palletized Flatrack M1
(IPF) (3990-01-406-1340), 2 June 2006.
FM 4-20.199/MCRP 4-11.3E, VOL III/NTTP 3-04.13/
20 February 2009
AFMAN 11-223 (I), VOL III/COMDINST M13482.4B
References-1
Index
1
C
130GS Grader, Sectionalized, 8-21
Certification of Equipment for Helicopter Sling Load, 1-
2
Certified Sling Loads, 1-1
3
Classification Definitions of Sling Load, 1-1
35-Foot Riverine Assault Craft (RAC) with or without
Communication or Electronic Systems Housed in
Trailer, 13-19
Lightweight Multipurpose Shelters (LMS), 10-3
Communication or Electronic Systems Housed in S-250
Shelters, 10-1
4
Communication or Electronic Systems Housed in S-280
420-D Backhoe Loader, 8-12
Shelters, 10-4
Container Roll-In/Out Platform (CROP), Empty,
Stacked, 13-10
6
Container Roll-In/Out Platform (CROP), Loaded, 13-8
Containerized Kitchen Mounted on the Containerized
613BS Scraper, Elevating, Sectionalized, 8-24
Kitchen Trailer, 3-34
613WDS Water Distributor, Sectionalized, 8-26
D
8
D5B Tractor Dozer, Sectionalized, 8-1
8- x 8- x 10-Foot Shelters, 10-7
Deployable Print Production Center (DPPC) on COPS
8- x 8- x 20-Foot Shelters, 10-9
Trailer, 3-25
Digital Group Multiplexer (DGM) Digital Antenna Mast
9
Program (DAMP) Pallet Trailer, 12-5
Digital Tech Controller (DTC) Housed in a Modified
950BS Scoop Loader, Sectionalized, 8-18
Gitchner Shelter, 10-23
Downsized Digital Group Multiplexer (DGM)
A
Assemblages, 10-18
Dry Support Bridge on M1077 Flatrack, 8-64
AN/MPQ-57 and AN/MPQ-61 High-Power Illuminator
Dual HMMWV, Side by Side (Shotgun Method), 2-38
Radar (HIPIR) Phase II and Phase III Mounted on the
Dual HMMWV, Side by Side (Shotgun Method), with
M390 (Modified) Trailer, 7-10
AMTECH Helmet Hardtop Basic, 2-46
AN/MRC-142B Radio Terminal Set with 30M Mast on
Dual M56 Smoke Generating Systems on M1113
M998 HMMWV, 2-68
HMMWV, Side by Side (Shotgun Method), 2-35
AN/TYC-5A Data Communications Terminal, 10-13
Applicability Paragraph, 1-3
Assault Command Post With High Mobility Wheel Set,
E
3-32
Enhanced Palletized Loading System, Flatrack, Empty,
Authorized Stockage List Mobility System (ASLMS),,
13-6
11-5, 11-7
Enhanced Palletized Loading System, Flatrack, Loaded,
Avenger, 7-1
13-5
Avenger on M1097/M1097A1/M1097A2 with ECU and
Equipment Rigging Procedures, 1-3
PPU with or without Bustle Box Stowed on Roof, 7-3
Extendable Boom Forklift (EBFL) (New Version)
Aviation Ground Power Unit, 4-8
(USMC), 8-52
Extendable Boom Forklift (USMC), 8-50
B
Boat, Bridge, Erection, 8-55
F
Field Maintenance Equipment Shop (FME), 7-14
Field Maintenance Equipment Shop 21, Unmanned
Shop, Electrical Equipment, 7-16
FM 4-20.199/MCRP 4-11.3E, VOL III/NTTP 3-04.13/
20 February 2009
AFMAN 11-223 (I), VOL III/COMDINST M13482.4B
Index-1
Index
Five 500-Gallon Fuel Drums, 9-7
Launch Rocket System (G-MLRS) Rockets / Guided
Front Power Unit, MK48, 2-110
Missile Launch Assembly (GMLA)Pods with Army
Full-Up Power Pack (FUPP) Container, M1A1, 11-1
Tactical Missile System (ATACMS) Missiles, Two
Containers, 11-11
Light Armored Vehicle (LAV) (USMC), 2-112
G
Light Medium Tactical Vehicles (LMTV)
General Rigging Instructions, 1-4
M1078/M1078A1/, 2-94, 2-96
Light Rough Terrain Forklift (LRTF) (USMC), 8-54
Lightweight Generator Frame Assembly (AN/TSC-93B
H
Reconfiguration), Satellite Communications
Terminal, 12-7
Helmet Hardtop (AMTECH) Cargo Bed Cover on
Load Description, 1-3
M1097A2 HMMWV, 2-50
Load Handling System-Compatible Water Tank Rack
High Mobility Materiel Handler (HMMH), 8-17
System (LHS-CWTRS), 9-9
High Mobility Trailer with AN/MJQ-35A Power Unit, 4-
LRT-110, 7 ½-Ton Crane, 8-38
6
LRT-110, 7 ½-Ton Crane Boom, 8-40
High Mobility Trailer-Light (HMT), M1101 with
LRT-110, 7 ½-Ton Crane Power Unit, 8-42
AN/TSQ-198, Tactical Terminal Control System
(TTCS), 3-21
High Mobility Trailers (HMT) with Generator for Joint
M
Surveillance Target Attack Radar (JSTAR) SystemS,
3-19
M101A1 Howitzer, 105-mm, with or without A-22
High Mobility Trailers (HMT), M1101/M1102, 3-17
Cargo Bags, 6-1
Hookup, 1-4
M101A2 3/4-Ton Trailer, 3-1
M102 Howitzer, 105-mm, 6-6
M1025A2 Truck, 1 1/4-Ton (HMMWV) with Line of
I
Sight Anti-Tank (LOSAT) Reloader Crane and High
Mobility Resupply Trailer (HMT), 5-83
IC45 Crawler Carrier, 8-9
M1037 (H-HMMWV) with Compressed Air-Foam
Inland Petroleum Distribution System (IPDS), Mainline
System, Mobile (CAFSM), 2-81
Pump on 20-Foot Flatrack, 8-75
M1037 (HMMWV) with AN/TPQ-36 Firefinder
Interim Fast Attack Vehicle Truck (IFAV), Long Wheel
Generator Pallet, 2-76
Base, 2-87
M1037 Shelter Carrier (HMMWV) with M101A2
Interim Fast Attack Vehicle Truck (IFAV), Long Wheel
Trailer, Cargo, 5-4
Base, Side by Side (Shotgun), 2-88
M1037 Shelter Carrier (HMMWV) with S-250 or S-
Introduction, 1-1, 3-1, 4-1, 5-1, 6-1, 7-1, 8-1, 9-1, 10-1,
250E Shelter, 2-9
11-1, 12-1, 13-1, 14-1
M1037 Shelter Carrier (HMMWV) with S-250/S-250E
Shelter and M116A2 Trailer Mounted Generators,
J
PU-751/PU753/PU-620/M, 5-7
M1037 Shelter Carrier, 1-1/4 Ton (HMMWV) with
Jam-Resistant Secure Communications (JRSC) Satellite
AN/TPQ-36, (S-250 Shelter), Operations Control
Communications Terminal with Mobilizer, 10-16
Group and Radar Set Antenna Mounted on M103A1
Joint Surveillance Target Attack Radar (JSTAR) System,
Trailer, 5-22
with LMS Shelter and Mission Trailer, HMT with
M1037/M1042 Shelter Carrier (HMMWV) with
Generator, 5-33
Lightweight Multipurpose Shelter (LMS), 2-14
JSTAR Common Ground Station (CGS) Support
M1037/M1097 Shelter Carrier (HMMWV) with G15840
Vehicle, M1097 HMMWV and M1102 High Mobility
Smoke Generator Set, M157/M157A1E1, 2-30
Trailer, 5-49
M1037/M1097 Truck, Utility, 1 1/4-Ton (HMMWV)
and M119, 105-mm Howitzer, 5-80
L
M1048 Trailer with Tracked Suspension System (TSS),
3-3
Launch Pod Container (LPC) with Multiple Launch
M105A3 Trailer, 3-29
Rocket System (MLRS) Rockets or Guided Multiple
M1082 Light Medium Tactical Vehicle (LMTV) and
Launch Rocket System (G-MLRS) Rockets / Guided
M1095 Medium Tactical Vehicle (MTV) Trailers, 3-
Missile Launch Assembly (GMLA)Pods with Army
31
Tactical Missile System (ATACMS) Missiles, Four
M1097 (H-HMMWV) with AN/TPQ-42, Meteorological
Containers, 11-14
Hydrogen Generator (MHG), 2-79
Launch Pod Container (LPC) with Multiple Launch
Rocket System (MLRS) Rockets or Guided Multiple
FM 4-20.199/MCRP 4-11.3E, VOL III/NTTP 3-04.13/
Index-2
AFMAN 11-223 (I), VOL III/COMDINST M13482.4B
20 February 2009
Index
M1097 (HMMWV) and High Mobility Trailer (HMT),
Installation Kit (STIK) and PU-797 Generator Set on
5-41
M116A3 Trailer, 5-68
M1097 (HMMWV) with AN/TSQ-183, Counter Battery
M1097A2 Shelter Carrier (HMMWV) with LMS Shelter
Radar and M101A2 Trailer, 5-30
Using Shelter Lift Rings as Sling Guides and PU-798
M1097 (HMMWV) with Contact Maintenance Truck,
Generator on M116A3 Trailer, 5-60
Heavy (CMTH), 2-54
M1097A2 Shelter Carrier (HMMWV) with S-250
M1097 (HMMWV) with High Mobility Digital Group
Shelter and Trailer Generator Sets on M116A3
Multiplexer (DGM) Auxiliary Equipment
Trailer, 5-66
Transportation Container (AETC) in 2 and 3 Mast
M1097A2 Shelter Carrier (HMMWV) with Special
Configurations, 2-58
Operations Media System (SOMS-B) in S-788G
M1097 Shelter Carrier (HMMWV) with S-250 Shelter
Shelter (LMS), 2-26
and Trailer Generator Sets on M116A2 Trailer, 5-25
M1098 HMMWV with Remote Landing Site Tower
M1097 Shelter Carrier, 1-1/4 Ton (HMMWV) with
(RLST), 2-56
AN/TPQ-36 (V) 7, (S-250 Shelter), Operations
M1112 400 Gallon Water Trailer, 3-27
Control Group and Radar Set Antenna Mounted on
M1113 (HMMWV) with LMS Shelter and High
M116A2 Trailer, 5-16
Mobility Trailer (HMT), 5-43
M1097 Shelter Carrier, 1-1/4 Ton (HMMWV) with
M1113 (HMMWV) with LMS Shelter and Shadow
AN/TPQ-36(V)7, (S-250 Shelter), Operations Control
Tactical Unmanned Aerial Vehicle (TUAV) Launch
Group, OKG-398/TPW, and M116A2 Equipment
Recovery Trailer, 5-74
Trailer Group, 5-36
M1113 (HMMWV) with M56 Smoke Generating
M1097 Shelter Carrier, Heavy HMMWV, with S-250 or
System, 2-32
S-250E Shelter, 2-12
M1113 (HMWWV) with Petroleum Quality Analysis
M1097 Truck, Utility, 1 1/4-Ton (HMMWV) with
System (PQAS) Shelter, 2-83
AN/MPQ-64 Tactical Quiet Generator (TQG) and
M1113 Shelter Carrier (HMMWV) with LMS Shelter
High Mobility Trailer (HMT) with Sentinel Antenna
and PU-798 Generator on M116A3 Trailer, 5-57
Transceiver Group (ATG), 5-52
M1113 Shelter Carrier (HMMWV) with LMS Shelter
M1097 Truck, Utility, 1-1/4 Ton (HMMWV) with Pallet
Using Shelter Lift Rings as Sling Guides and PU-798
Group OA-9134/TSC, Antenna AS-3036/TSC and
Generator on M116A3 Trailer, 5-63
PU-753 Generator Set on M116A2 Trailer, 5-13
M1113 Truck, 1 1/4-Ton (HMMWV) Petroleum Quality
M1097, 1-1/4 Ton (HMMWV) with Generator Pallet
Analysis System (PQAS) Shelter and PQAS Trailer,
Group and PU 799 G-85/TPQ-36 Generator Group on
5-91
M116A3 Trailer, 5-55
M1113 Truck, 1 1/4-Ton (HMMWV) with Line of Sight
M1097, 1-1/4 Ton (HMMWV) with Generator Pallet
Anti-Tank (LOSAT) Fire Unit and High Mobility
Group, G-86-TPQ-36 (V)7, and Radar Set Antenna
Resupply Trailer (HMT), 5-86
Mounted on M116A2 Trailer, 5-19
M1113 Truck, 1 1/4-Ton (HMMWV) with Line of Sight
M1097/M1097A2 Shelter Carrier (HMMWV) with
Anti-Tank (LOSAT) Fire Unit with Reloader Crane
Lightweight Multipurpose Shelter (LMS) (USMC), 2-
and Four Missiles, 7-6
16
M1113 Truck, 1 1/4-Ton (HMMWV) with M56 Smoke
M1097/M1097A2 Shelter Carrier (HMMWV) with
Generator and M101A2 Trailer, 5-88
Lightweight Multipurpose Shelter (LMS) using
M1113 Truck, Utility, Expanded Capacity (HMMWV)
Shelter Lift Rings as Sling Guides, 2-18
with Lightweight Multipurpose Shelter (LMS) using
M1097/M1113 Shelter Carrier (HMMWV) with
Shelter Lift Rings as Sling Guides, 2-21
Gitchner Model 1497A Shelter, 2-23
M1123 Cargo/Troop Carrier (HMMWV) with Marine
M1097A1 (H-HMMWV) with Fiberglass Cargo Bed
Armor Kit, Fully Armored Troop Section (USMC), 2-
Cover (CBC), 2-42
85
M1097A1 (HMMWV) with Tactical Data Network
M114A1 155-mm Howitzer, 14-5
(TDN)- Gateway (USMC), 2-28
M116A2 Trailer-Mounted Power Units, Generators, and
M1097A2 (H-HMMWV) with the Secure Mobile Anti-
Power Plants, 4-1
Jam RELIABLE Tactical Terminal (SMART-T), 2-60
M149-Series Water Trailer, 14-3
M1097A2 (HMMWV) with Advanced Field Artillery
M198 Howitzer, 155-mm, Towed with External Airlift
Tactical Data System (AFATDS) Full Size or Partial
Travel Lock Assembly, 6-13
Soft Top Installation Kit (STIK), 2-74
M200A1 Trailer-Mounted Power Units, Generators, and
M1097A2 (HMMWV) with Advanced Field Artillery
Power Plants, 4-5
Tactical Data System (AFATDS) Full Size Soft Top
M31 Expeditionary Arresting Gear System (EAGS), 3-
Installation Kit (STIK) and M101A1 Trailer, 5-38
37
M1097A2 (HMMWV) with Advanced Field Artillery
M353 Trailer Chassis with Mounted Generators, 4-3
Tactical Data System (AFATDS) Soft Top
M35A1/A2 2 ½-Ton Cargo Truck, 14-1
FM 4-20.199/MCRP 4-11.3E, VOL III/NTTP 3-04.13/
20 February 2009
AFMAN 11-223 (I), VOL III/COMDINST M13482.4B
Index-3
Index
M35A3 2 1/2-Ton Cargo Truck, 2-106
NATO Airbase Satcom (NABS) Shelter Pallet, AN/TSC-
M4 Robotic Mine Flail, 8-68
93B (V) 2, 10-19
M777/M777A1/M777A2, 155-mm Lightweight
Naval Special Warfare Rigid Inflatable Boat (NSWRIB)
Howitzer, 6-15
with or without Trailer, 13-11
M817A3 Semi-Trailer, 3-44
M871A1 Semitrailer, 3-15
O
M966/M1036/M1045/M1045A2/M1046 TOW Missile
Carrier
OE-361/G Quick Reaction Satellite Antenna, 12-1
(HMMWV)M1025/M1025A2/M1026/M1043/M1043
One Conex Container, 14-6
A2/M1043A2 with Marine Armor Kit
One MILVAN Container, 14-8
(MAK)(USMC)/M1044/M1151 Armament Carrier
(HMMWV)/M1114 Up-Armored HMMWV, 2-3
P
M989 Heavy-Expanded Mobility Ammunition Trailer
(HEMAT), 3-5
Palletized Loading System (PLS), M1077 Flatrack,
M989A1 Heavy-Expanded Mobility Ammunition Trailer
Empty, 13-3
(HEMAT II), 3-6
Palletized Loading System (PLS), M1077 Flatrack,
M996/M997/M997A1/M997A2 Truck, Ambulance,
Loaded, 13-1
(HMMWV), 2-1
Platoon Command Post (PCP)/Battery Command Post
M998 (HMMWV) with Two MRC-127 Stacks, 2-70
(BCP), 7-17
M998 HMMWV with Man Portable Air Defense
Platoon Support Van/Maintenance Center (PSV/MC), 7-
Systems (MANPADS), 2-77
12
M998 Truck, Cargo, 1 1/4-Ton (HMMWV) with
Pneumatic Tool and Compressor Outfit/Hydraulic
AMTECH Helmet Hardtop, 2-45
Pioneer Tool Outfit (PTO) on M353 Trailer, 8-70
M998/M1038 (HMMWV) with Lightweight Tactical
Positioning and Attaching the Sling, 1-5
Fire Control Systems (LTACFIRE)/Tactical Terminal
Preparation, 1-4
Control Systems (TTCS), 2-72
Preparing the Equipment, 1-4
M998/M1038 1 1/4-Ton Cargo Truck (HMMWV) and
Preparing the Load, 1-4
M102, 105-mm Howitzer, 5-77
Prohibited Sling Loads, 1-2
M998/M1038 Truck, Utility, 1-1/4 Ton (HMMWV) and
Prophet AN/MLQ-40(V) on M1097 HMMWV, 2-51
G-85/TPQ-36 (V)7 Generator Group on M116A2
Modified Trailer, 5-10
M998/M1038 Truck, Utility, 1-1/4 Ton (HMMWV) with
Q
M101A1/A2 Trailer, Cargo, 5-1
Quadcons, 11-8
M998/M1123 with Marine Armor Kit (MAK)
(USMC)/M1037 Modified (GVW 9,400
lbs)/M1038/M1097/M1097A1/, 2-6
R
Medium Girder Bridge (MGB) (USMC), 8-63
Requests for Sling Load Certification, 1-2
Medium Tactical Vehicle Replacement (MTVR)
Ribbon Bridge Erection Boat, MK2, 8-57
(USMC), 2-108
Ribbon Bridge Interior Bay, 8-59
Medium Tactical Vehicle, Tractor, M1088/M1088A1, 2-
Ribbon Bridge Ramp Bay, 8-61
100
Rigging, 1-4
Medium Tactical Vehicles
Roller, Compactor, Vibrator, 8-33
M1083/M1083A1/M1084/M1085/, 2-91
Roller, Towed, Vibrating, 8-28
Mine Clearing Line Charge Mounted on M200A1
Rollers, Towed, 8-29
Trailer, 8-36
Mine Clearing Line Charge Mounted on M353 Trailer,
8-34
S
Mk14 Trailer, Container Hauler, 3-8
Shelter, Knockdown, 8- x 8- x 20-Foot, 10-14
Mk15 Trailer, Wrecker/Recovery, 3-10
Mk16 Trailer, Fifth-Wheel Adapter, 3-12
Small Emplacement Excavator (SEE), 8-14
Small Emplacement Excavator (SEE) Transporter, 3-40
Mk17 Trailer, Drop Side, Cargo, 3-13
Small Unit Riverine Craft (SURC) with Trailer, 13-20
SP-7 Wheel-Mounted Crane, 8-44
N
Special Operations Craft-Riverine (SOC-R), 13-15
Special Operations Craft-Riverine (SOC-R) and Naval
NATO Air Base SATCOM (NABS) Power Pallet,
Special Warfare Rigid Inflatable Boat (NSWRIB)
AN/TSC-85B (V)2, 12-3
Trailer, 13-13
FM 4-20.199/MCRP 4-11.3E, VOL III/NTTP 3-04.13/
Index-4
AFMAN 11-223 (I), VOL III/COMDINST M13482.4B
20 February 2009
Index
Special Operations Craft-Riverine (SOC-R) with SOC-R
Truck Forklift, MC-4000, 8-45
Trailer, 13-17
Truck Forklift, MC-6000, 8-49
Special Operations Media Systems (SOMS B) on
Truck Forklift, RT-4000, 8-47
Commander's Crash-Out-Package System (COPS)
Truck, Cargo, 2 1/2-Ton, M35A2 Modified, Part of an
Trailer, 3-23
AN/MPQ-49A Forward Area Alerting Radar (FAAR)
SRS-106 Integrated Tower Systems Portable Tower
System, 2-104
Trailer (PTT), 8-67
Two M101A1 Howitzers, 105-mm, Side by Side
Standard Automotive Tools Set (SATS) Mounted on
(USMC), 6-4
Sats Trailer, 3-42
Two M102 Howitzers, 105-mm, with or without One,
Standard Automotive Tools Set (SATS) Trailer, 3-39
Two, or Three A-22 Cargo Bags, 6-7
Suitable Sling Loads, 1-1
Two M119A2 Howitzers, 105-mm, Forward Firing
Position, Side by Side, 6-10
Two Storage Modules, Fuel/Water (Side by Side), 9-1
T
Tactical Super High Frequency (SHF) Satellite Terminal
U
(TSST) on M1113 HMMWV, 2-64
Tactical Super Satellite Terminal (TSST) Mobile Power
Unique Items of Equipment or Operational
Unit (MPU) on M1113 HMMWV, 2-66
Requirements, 1-3
Tandem Lift of Two ISU-90 Shipping/Storage
Unique Sling Loads, 1-1
Containers, 11-3
Three Storage Modules, Fuel/Water (Side by Side), 9-3
V
Tractor (Dozer), Full Tracked, Type III, JD 450G, 8-7
Tractor Full Tracked, Case Model 1150, 8-3
Vibrating Roller, Caterpillar, RO-33, 8-31
Tractor Full Tracked, Case Model 1150E, 8-5
Viewing the Load, 1-5
Tractor, Wheeled, Industrial, Case Model 580, 8-10
Trojan Air Transportable Electronic Reconnaissance
W
System (TATERS) High Gain Antenna Group
(HGAG) Shelter, 10-21
Water Purification Unit, Reverse Osmosis (ROWPU), 8-
Trojan Spirit Lite (V)2 Central Communications,
72
AN/TSQ-226 (V)2 on M1113 (HMMWV) and M1102
Water Purification Unit, Reverse Osmosis (ROWPU),
Cargo Trailer, 5-46
Trailer Mounted, 8-74
Trojan Spirit Lite (V)2 Central Communications,
AN/TSQ-226 (V)2 on M1113 HMMWV, 2-61
FM 4-20.199/MCRP 4-11.3E, VOL III/NTTP 3-04.13/
20 February 2009
AFMAN 11-223 (I), VOL III/COMDINST M13482.4B
Index-5
|
