10.12

Battery and Electrical Systems

9923311 - 2010-2012 PRO-RIDE RUSH/Switchback/RMK Service Manual

3. Hold the brake lever. Press and hold the MODE and

SEL buttons for 3 seconds, then release. SECURE
OFF should be displayed. If not, repeat this step.

4. Wait until ENTER CODE displays, and then press and

release MODE button 3 consecutive times to enter
and accept the 000 base code.

NOTE: If the ENTER CODE screen exits due to
inactivity, repeat step 3.

NOTE: Security is now LOCKED.

5. SECURE ON will be displayed. The display will

alternate between SECURE ON and ENTER CODE.

6. Wait until ENTER CODE displays, then press and

release MODE button 3 consecutive times to enter
and accept the 000 digit base code.

PRESS MODE

ENTER AND EXIT

PRESS MODE

ENTER AND EXIT

10.13

Battery and Electrical Systems

9923311 - 2010-2012 PRO-RIDE RUSH/Switchback/RMK Service Manual

7. SECURE OFF displays if the system unlocks.

8. Immediately after locking and unlocking the security

system, and while SECURE OFF is displayed, press
and hold the MODE button to bring up the enter code
screen.

9. When ENTER CODE displays, use the MODE and

SEL buttons to select and accept each digit of a new
personal security code.

• SEL = Advances up 1 digit (0 to 9 to 0)

• MODE = Enter and move 1 digit to right

10. After pressing MODE to accept the last digit, view the

display screen. The new code and CODE SET will
display if the system accepted the new code. If
successful, you will not see this screen again.

NOTE: If steps 9-11 are not completed immediately
after performing the initialization procedure, the
security code will be 000. See Changing Security Code
to enter a new passcode.

11. Record the new security code in a safe place (Owner’s

Manual or Customer RO) for future reference.

Security System: Locking

1. Start the engine in a well ventilated area.

2. Hold the brake lever. Press and hold the MODE and

SEL buttons for 3 seconds, then release. SECURE
OFF should be displayed. If not, repeat this step.

• SEL = Advances up 1 digit (0 to 9 to 0)

• MODE = Enter and move 1 digit to right

3. When ENTER CODE displays, press and release SEL

to advance the digit. When the first digit of your
security code is displayed, press and release the
MODE button to accept the digit and move to the next
digit.

NOTE: If the ENTER CODE screen exits due to
inactivity, repeat the locking procedure.

4. Continue to use MODE and SEL to select and accept

the remaining two digits of the security code.

5. After pressing MODE to accept the last digit, view the

display screen. SECURE ON displays if the system
locks. Engine RPM speed is now limited and the
snowmobile cannot be driven.

10.14

Battery and Electrical Systems

9923311 - 2010-2012 PRO-RIDE RUSH/Switchback/RMK Service Manual

NOTE: When the engine is running and security is
locked, the display will alternate between SECURE ON
and ENTER CODE.

6. If an incorrect code is entered, BAD CODE will be

displayed. Wait until the display returns to the ENTER
CODE screen and then re-enter the correct passcode.

Security System: Unlocking

1. When the engine is running and security is locked, the

display will alternate between SECURE ON and
ENTER CODE.

NOTE: When the system is locked and the engine
temperature is above 120°F (49°C), the correct pass
code must be entered within 60 seconds or the engine
will shut down.

• SEL = Advances up 1 digit (0 to 9 to 0)

• MODE = Enter and move 1 digit to right

2. When ENTER CODE displays, press and release

SEL to advance the digit. When the first digit of your
security code is displayed, press and release MODE
to accept the digit and move to the next digit.

3. Continue to use MODE and SEL to select and accept

the remaining two digits of the code.

4. After pressing MODE to accept the last digit, view the

display screen. SECURE OFF displays if the system
unlocks.

5. If an incorrect code is entered, BAD CODE will be

displayed. Wait until the display returns to the ENTER
CODE screen and then re-enter the correct passcode.

10.15

Battery and Electrical Systems

9923311 - 2010-2012 PRO-RIDE RUSH/Switchback/RMK Service Manual

Security System: Changing Passcode

To change the current security code to a new code,
perform these steps:

NOTE: The instrument cluster illustrations on the
following pages reference the 000 default security
code. Use the owner’s current security code.

1. Start the engine and lock the parking brake.

2. Lock and then unlock the security function on the

instrument cluster using the existing passcode.

3. Immediately after unlocking security, press and hold

the MODE button to display the ENTER CODE
screen.

• SEL = Advances up 1 digit (0 to 9 to 0)

• MODE = Enter and move 1 digit to right

4. When ENTER CODE displays, use the MODE and

SEL buttons to select and accept each digit of the new
security code.

5. After pressing MODE to accept the third digit, the new

code and CODE SET will display if the system
accepted the new code. If successful, this screen will
not be displayed again.

6. Record the new security code in a safe place (Owner’s

Manual or Customer RO) for future reference.

Security System: User Notes

• Security system activation requires an authorized

Polaris dealer using Digital Wrench™ to turn on
the function in the ECU.

• First time use requires an initialization procedure

to turn on the security function in the instrument
cluster.

• Holding the brake lever closed and pressing the

MODE and SEL buttons for 3 seconds will bring up
the security display on the instrument cluster.

• If the brake lever is not held while pressing the

MODE and SEL buttons for 3 seconds, the
instrument cluster will start the record/playback
data logging function.

• Pressing the MODE button will accept the selected

digit and move to the next digit. After entering the
third digit, pressing MODE a fourth time will enter
the code.

• Pressing the SEL button advances each digit up

from 0 to 9 then back to 0.

• If the engine is running and security is locked, the

ECU will shut the engine off when the engine
temperature is above 120°F (49°C) for 60
seconds.

• The instrument cluster retains the last

programmed security passcode. Disabling and
enabling the security function in the ECU does not
change the code in the insturment cluster. If the
passcode is unkown or BAD CODE is displayed
perform the Reset Passcode Procedure to reset
the code back to 000.

• Reflashing the ECU using the Engine Controller

Reprogramming function disables the security
function. Perform the Security Enable procedure
after reflashing the ECU.
