A14 FRONT SUSPENSION 800 XC SP S01NP8BS and 800 XC SP S01NP8BSA and 800 XC SP S01NP8BSB Part numbers may have changed since this microfiche was issued. To ensure that correct parts are received, refer to the Electronic Catalog, which is updated monthly. Ref. Part No. Qty. Description Ref. Part No. Qty. Description 1 7512597 2 Bolt 2 5434036 8 Bushing, Radius Rod, Pivot, Outer 3 5132779 2 Bushing, Shoulder 4 7547066 4 Nut, Nylok 5 1820679-067 1820679-246 2 2 Rod, Radius, Upper, Black Rod, Radius, Upper, Blue (B) 6 7542520 2 Nut, Jam 7 7542439 12 Nut, Nylok 8 7515433 4 Screw 9 5630580 2 Retainer, Spring, Slotted 10 7041950-067 2 Spring, Compression 11 7041926 2 Shock, Gas, IFP 12 7517583 6 Screw 13 7555832 4 Washer 14 5132728 2 Arm, Steering 15 7555797 4 Washer, Flat 16 1820962-293 1820963-293 1820962-067 1820963-067 1820962-246 1820963-246 1 1 1 1 1 1 Asm., Trailing Arm, Red, LH Asm., Trailing Arm, Red, RH Asm., Trailing Arm, Black, LH (A) Asm., Trailing Arm, Black, RH (A) Asm., Trailing Arm, Blue, LH (B) Asm., Trailing Arm, Blue, RH (B) NOTE: Assemblies include 19 and 20 17 7555820 2 Washer, Flat 18 5132364 2 Cup, Mount, Trailing Arm 19 7061042 2 Bearing, Spherical 20 7710437 2 Ring, Retaining 21 7512099 2 Screw 22 7061057 2 Rod End, RH 23 3573909 2 Bushing 24 7080433 2 Fitting, Lubrication 25 5433234 2 Bushing, Torsion Bar 26 7621477 6 Rivet 27 5244415-067 1 Bar, Torsion 28 5433329 2 Slide, Torsion Bar 29 7556509 2 Bushing 30 3574208 2 Bushing, Flanged 31 6230160-067 2 Shaft, Spindle 32 7080306 2 Fitting, Lubrication 33 5010158 2 Bushing 34 7061060 2 Rod End 35 7542711 2 Nut, Jam 36 1820677-067 1820677-246 2 2 Rod, Radius, Lower, Black Rod, Radius, Lower, Blue (B) 37 7542703 2 Nut, FLEXLOC 38 7061061 2 Rod End 39 5132780 2 Bushing, Shoulder 40 7512684 2 Bolt 7/00 |
