Snowmobile Polaris 600 RMK F/O, 700 RMK F/O, 800 RMK F/O (2004 year). Instruction - part 15





E1

STARTING MOTOR (600)

600 RMK 144 F/O S04NK6ES and 600 RMK 144 STOCK A S04NK6ESA and 600 RMK 144 STOCK B S04NK6ESB and 600 RMK 144 STOCK C S04NK6ESC

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

14

17

18

19

20

E

2003 Polaris Sales Inc.

Ref. Part No.

Qty. Description

Ref. Part No.

Qty. Description

1 7542103

1 Nut, FLEXLOC

2 2200758

1 Kit, Asm., Commutator Cap (Incl. 3)

3 2200759

--------------

--------------

--------------

--------------

--------------

1

1

2

1

1

1

Kit, Brush & Spring

Asm., Brush & Screw

Asm., Brush

Bushing, Insulation

Washer, Insulation

Nut

4 7542153

2 Nut, Flanged, Nylok

5 7516823

3 Screw

6 5244250

1 Bracket, Starter, Rear

7 7555843

2 Washer, Flat

8 5245467

1 Bracket, Starter, Front

9 7552603

2 Washer, Spring Lock

10 7512492

2 Screw

11 7517322

2 Screw

12 4170006

1 Motor, Starter, Domestic

13 2200756

1 Kit, Asm., Armature

14 2200755

--------------

--------------

--------------

--------------

--------------

--------------

--------------

1

1

1

1

1

1

1

1

Kit, Drive Hardware

Washer, Curved Spring

Washer, Thrust

Spacer

Spring, Antidrift

Pinion, Stop

Ring, Lock

Cover, Dust

15 2200757

1 Kit, Asm., Drive Cap

16 2200754

--------------

--------------

1

1

1

Kit, Asm., Drive

Plate, Drive

Pinion

17 2200753

--------------

1

2

Kit, Screw

Bolt, Thru

18 3082939

4 Nut

19 3080077

4 Washer, Spring

20 3083211

1 Switch, Magnetic (Incl. 18,19)

3/03

E2

STARTING MOTOR (700)(800)

700 RMK 144 F/O S04NK7CS and 700 RMK 144 STOCK A S04NK7CSA and 700 RMK 144 STOCK B S04NK7CSB and 700 RMK 144 STOCK C S04NK7CSC and 700 RMK 151 F/O S04NL7CS and 700 RMK 151 STOCK A

S04NL7CSA and 700 RMK 151 STOCK B S04NL7CSB and 700 RMK 151 STOCK C S04NL7CSC and 800 RMK 144 F/O S04NK8CS and 800 RMK 144 STOCK A S04NK8CSA and 800 RMK 144 STOCK B S04NK8CSB and 800

RMK 144 STOCK C S04NK8CSC and 800 RMK 151 F/O S04NL8CS and 800 RMK 151 STOCK A S04NL8CSA and 800 RMK 151 STOCK B S04NL8CSB and 800 RMK 151 STOCK C S04NL8CSC and 800 RMK 159 F/O S08NM8CS

and 800 RMK 159 STOCK A S08NM8CSA and 800 RMK 159 STOCK B S08NM8CSB and 800 RMK 159 STOCK C S08NM8CSC

4

9

5

7

6

3

13

11

14

12

15

18

17

16

12

10

2

1

8

5

E

2003 Polaris Sales Inc.

Part numbers may have changed since this microfiche was issued. To ensure that correct parts are received, refer to PartSmart, which is updated monthly.

Ref. Part No.

Qty.

Description

Ref. Part No.

Qty.

Description

1 7542103

1 Nut, FLEXLOC

2 2200758

1 Kit, Asm., Commutator Cap (Incl. 3)

3 2200759

--------------

--------------

--------------

--------------

--------------

1

1

2

1

1

1

Kit, Brush & Spring

Asm., Brush & Screw

Asm., Brush

Bushing, Insulation

Washer, Insulation

Nut

4 7542153

2 Nut, Flanged, Nylok

5 7517957

4 Screw

6 5245780

1 Bracket, Starter, Rear

7 5245781

1 Bracket, Starter, Big Block

8 7552603

2 Washer, Spring Lock

9 7512492

2 Screw

10 4170006

1 Motor, Starter, Domestic

11 2200756

1 Kit, Asm., Armature

12 2200755

--------------

--------------

--------------

--------------

--------------

--------------

--------------

1

1

1

1

1

1

1

1

Kit, Drive Hardware

Washer, Curved Spring

Washer, Thrust

Spacer

Spring, Antidrift

Pinion, Stop

Ring, Lock

Cover, Dust

13 2200757

1 Kit, Asm., Drive Cap

14 2200754

--------------

--------------

1

1

1

Kit, Asm., Drive

Plate, Drive

Pinion

15 2200753

--------------

1

2

Kit, Screw

Bolt, Thru

16 3082939

2 Nut

17 3080077

2 Washer, Spring

18 3083211

1 Switch, Magnetic (Incl. 16,17)

5/01

E3

TOOL KIT

600 RMK 144 F/O S04NK6ES and 600 RMK 144 STOCK A S04NK6ESA and 600 RMK 144 STOCK B S04NK6ESB and 600 RMK 144 STOCK C S04NK6ESC and 700 RMK 144 F/O S04NK7CS and 700 RMK 144 STOCK A

S04NK7CSA and 700 RMK 144 STOCK B S04NK7CSB and 700 RMK 144 STOCK C S04NK7CSC and 700 RMK 151 F/O S04NL7CS and 700 RMK 151 STOCK A S04NL7CSA and 700 RMK 151 STOCK B S04NL7CSB and 700

RMK 151 STOCK C S04NL7CSC and 800 RMK 144 F/O S04NK8CS and 800 RMK 144 STOCK A S04NK8CSA and 800 RMK 144 STOCK B S04NK8CSB and 800 RMK 144 STOCK C S04NK8CSC and 800 RMK 151 F/O S04NL8CS

and 800 RMK 151 STOCK A S04NL8CSA and 800 RMK 151 STOCK B S04NL8CSB and 800 RMK 151 STOCK C S04NL8CSC and 800 RMK 159 F/O S08NM8CS and 800 RMK 159 STOCK A S08NM8CSA and 800 RMK 159

STOCK B S08NM8CSB and 800 RMK 159 STOCK C S08NM8CSC

2

3

4

8

6

7

5

1

E

2003 Polaris Sales Inc.

Part numbers may have changed since this microfiche was issued. To ensure that correct parts are received, refer to PartSmart, which is updated monthly.

Ref. Part No.

Qty.

Description

Ref. Part No.

Qty.

Description

1 2874017

1 Kit, Tool (Incl. 2-4)

2 --------------

1 Screwdriver, Phillips

3 --------------

1 Wrench, 9/16 x 1/2, Open End

4 --------------

1 Wrench, Spark Plug Combination

5 2871845

1 Screwdriver, Flat, Shielded

6 9918225

9918282

9918284

9918286

9918287

1

1

1

1

1

Manual, Owner’s, ’04 RMK/Switchback

Supplement, Owner’s Manual, ’04 600

RMK 144 Stock and F/O

Supplement, Owner’s Manual, ’04 700

RMK 144/151 Stock and F/O

Supplement, Owner’s Manual, ’04 800

RMK 144/151 Stock and F/O

Supplement, Owner’s Manual, ’04 800

RMK 159 Stock and F/O

7 9918079

1 Video--Suspension Setup

8 7080287

1 Strap, Emergency Starter

3/03
