DB2 Server for VSE & VM SQL Reference (Version 7 Release 5)

EXPLAIN

Table 11. Columns in PLAN_TABLE (continued)

Column Name

Data Type

Description

PKGOWNER

CHAR(8) NOT

This identifies the owner of the package in which this SQL

NULL

statement originated. This field is blank for explicit EXPLAIN

processing invoked by the EXPLAIN statement.

PLANNO

SMALLINT

A number identifying the current step of the plan. PLANNO

NOT NULL

indicates the order in which the database managerdoes the actions

of the plan for processing the query block. The PLAN_TABLE row

with PLANNO 1 indicates the first action, PLANNO 2 indicates the

second action, and so on. For each query block, each row entered

as the result of an execution of EXPLAIN PLAN has a different

PLANNO value.

METHOD

SMALLINT

METHOD is the action done at this step; it is either 0, 1, 2 or 3.

NOT NULL

Method is 0 only for the first table accessed (which has PLANNO

1). Because this is the first table, there is not yet a composite. Also,

because there is no composite, SORTCOMP (described below) is

blank for this row.

Methods 1 and 2 correspond to plan steps that are joins, and

identify the method by which the join is performed. Method 1 is

the nested loop join. That is, for each row of the composite, the

database managerfinds and joins matching rows of the new table.

Method 2 is the merge scan join. In a merge scan join, the database

managerscans the composite and the new table in order according

to the join column. It then joins rows with matching join columns.

This resembles processes used in merging files, except that one row

in the composite may match many rows of the new table, and

many rows in the composite may match one row of the new table.

Method 3 indicates that the database managermust perform

additional sorts at the end of processing the query block. The

following sorts are possible:

ORDER BY

GROUP BY

SELECT DISTINCT

UNION.

When METHOD is 3, CREATOR is all blanks, TNAME is the

empty string, TABNO is zero, and SORTNEW is N.

CREATOR

CHAR(8) NOT

Creator of the new table accessed in this plan step.

NULL

TNAME

VARCHAR(18)

Name of the new table accessed in the plan step.

NOT NULL

TABNO

SMALLINT

Because a table may be joined to itself, there may be several

NOT NULL

references to the same table in a query block. TABNO distinguishes

the different references. TABNO, CREATOR, and TNAME

correspond to the columns with the same names in

REFERENCE_TABLE. When there is no new table then these

columns have the values specified when METHOD is 3 (see above).

276

SQL Reference

EXPLAIN

Table 11. Columns in PLAN_TABLE (continued)

Column Name

Data Type

Description

ACCESSTYPE

CHAR(2) NOT

Indicates how the database manager will access the data. These are

NULL

the character values that can appear in ACCESSTYPE:

Accesses the new table by a fetch operation on a

fully-qualified unique index. This includes fetching the

first or last value of the index.

Accesses the new table using an index and specific key

values (identified in ACCESSCREATOR and

ACCESSNAME).

Accesses the new table using an index on the column in

an IN predicate with a list of literals.

W Accesses the new table using an index, but without

specific key values. This non-selective index scan locates

the rows in a table when it is more efficient to scan the

index than to scan all pages in the DBSPACE.

Accesses the new table by a scan of the DBSPACE in

which it resides.

Accesses the new table through the internal list. The

internal list is like a temporary table. It is created to

contain the result of a materialized view.

For any type of index access, ACCESSCREATOR and

ACCESSNAME identify the index. ACCESSTYPE is blank for the

top block of INSERT statements, as well as for UPDATE and

DELETE statements that use WHERE CURRENT OF CURSOR

clauses. ACCESSCREATOR is blanks and ACCESSNAME is the

null value in that case. (Access for INSERT’s is performed using

the first index created; UPDATE and DELETE statements using the

CURRENT OF CURSOR clause access using their cursors.)

MATCHCOLS

SMALLINT

For ACCESSTYPE ‘I1’, ‘I’, or ‘N’, the number of index keys that

NOT NULL

have key-matching predicates used in an index scan; otherwise, 0.

ACCESSCREATOR

CHAR(8) NOT

For ACCESSTYPE ‘I1’, ‘I’, ‘N’, or ‘W’, ACCESSCREATOR contains

NULL

the owner of the access path (index) that the database manageruses

to access the table. Otherwise, ACCESSCREATOR contains blanks.

ACCESSNAME

VARCHAR(18)

For ACCESSTYPE ‘I1’, ‘I’, ‘N’, or ‘W’, ACCESSNAME contains the

NOT NULL

name of the access path (index) that the database manageruses to

access the table. Otherwise, ACCESSNAME contains blanks.

INDEXONLY

CHAR(1) NOT

Indicates whether an index is sufficient to satisfy the request, and

NULL

to what degree.

All predicates may be applied to the index pages and all

data may be retrieved from the index pages.

W All sargable predicates may be applied to the index pages,

but data pages must be accessed to retrieve data satisfying

the predicates or residual predicates.

Data pages must be accessed to resolve predicates and

retrieve data. Note that, in a few circumstances, some

predicate filtering may still be achieved using an index.

Chapter 6. Statements

277

EXPLAIN

Table 11. Columns in PLAN_TABLE (continued)

Column Name

Data Type

Description

SORTNEW

CHAR(1) NOT

To access a table in a particular order, the database manager may

NULL

sort some fields of some rows of the new table (for example, for

merge scan joins). These are the character values that can appear in

SORTNEW:

If the database manager does not sort the new table.

If the database manager does sort, and removes

duplicates.

If the database manager sorts, and does not remove

duplicates.

SORTNEW is blank when no sort of the new table is possible, that

is, when METHOD is 3 and there is no new table.

SORTCOMP

CHAR(1) NOT

To access a composite in a particular order, the database manager

NULL

may sort some fields of some rows of the composite. These are the

character values that can appear in SORTCOMP:

If the database manager does not sort the composite.

If the database manager does sort, and removes

duplicates.

If the database manager does sort, and does not remove

duplicates.

SORTCOMP is blank when no sort of the composite is possible;

that is, when METHOD is 0 and there is no composite yet.

SORTN_UNIQ

CHAR(1) NOT

Whether a sort is performed on the new table to remove duplicate

NULL

rows. Y = Yes; N = No.

SORTN_JOIN

CHAR(1) NOT

Whether a sort is performed on the new table if METHOD is 2. Y =

NULL

Yes; N = No.

SORTN_ORDERBY

CHAR(1) NOT

Whether an ORDER BY clause results in a sort on the new table. Y

NULL

= Yes; N = No.

SORTN_GROUPBY

CHAR(1) NOT

Whether a GROUP BY clause results in a sort on the new table. Y =

NULL

Yes; N = No.

SORTC_UNIQ

CHAR(1) NOT

Whether a sort is performed on the composite table to remove

NULL

duplicate rows. Y = Yes; N = No.

SORTC_JOIN

CHAR(1) NOT

Whether a sort is performed on the composite table if METHOD is

NULL

2. Y = Yes; N = No.

SORTC_ORDERBY

CHAR(1) NOT

Whether an ORDER BY clause results in a sort on the composite

NULL

table. Y = Yes; N = No.

SORTC_GROUPBY

CHAR(1) NOT

Whether a GROUP BY clause results in a sort on the composite

NULL

table. Y = Yes; N = No.

TIMESTAMP

The time at which the EXPLAIN statement was processed.

NOT NULL

REMARKS

VARCHAR(254)

A field into which you can insert any character string of 254 or

NOT NULL

fewer characters.

Table 12. Columns in REFERENCE_TABLE

Column Name

Data Type

Description

QUERYNO

INTEGER

Query number. QUERYNO is intended for your use to distinguish among

queries. (See COST_TABLE for a description of QUERYNO.)

RINO

SMALLINT

RINO is intended to distinguish among queries and internally generated

NOT NULL

queries. (See COST_TABLE for a description of RINO.)

278

SQL Reference

EXPLAIN

Table 12. Columns in REFERENCE_TABLE (continued)

Column Name

Data Type

Description

QBLOCKNO

SMALLINT

Query block number, where 1 is the top level query block, that may have

NOT NULL

subqueries. Different query blocks receive different numbers.

PKGNAME

CHAR(8) NOT

This identifies the name of the package in which this SQL statement originated.

NULL

This field is blank for explicit EXPLAIN processing invoked by the EXPLAIN

statement.

PKGOWNER

CHAR(8) NOT

This identifies the owner of the package in which this SQL statement originated.

NULL

This field is blank for explicit EXPLAIN processing invoked by the EXPLAIN

statement.

REFTYPE

CHAR(6) NOT

An indication of the purpose of the current row in this table. Rows are inserted

NULL

for three reasons:

1. For each SQL statement, REFTYPE has a value indicating the type of

statement:

SELECT

A select statement

INSERT

An insert statement

UPDATE

An update statement

DELETE

A delete statement

SELUPD

A select statement with a ‘FOR UPDATE’ clause

DELCUR

A delete where current of cursor statement

UPDCUR

An update where current of cursor statement

2. For each table referenced, REFTYPE has the value ‘TABLE’.

3. For each column referenced, REFTYPE has the value ‘COLUMN’.

CREATOR

CHAR(8) NOT

Creator of a table referenced in the query block.

NULL

TNAME

VARCHAR(18)

Name of the table referenced in the query block.

NOT NULL

TABNO

SMALLINT

Because there may be several references to the same table in a query block

NOT NULL

(because a table may be joined to itself), TABNO differentiates among the

different references. TABNO may correspond to the order of tables in the FROM

clause of the query.

CNAME

VARCHAR(18)

Name of the column.

NOT NULL

COLNO

SMALLINT

Column number of a column in the table identified by CREATOR, TNAME, and

NOT NULL

TABNO. EXPLAIN REFERENCE causes at most one new row to be entered in

REFERENCE_TABLE for a particular column (COLNO) of a table (TABNO) in a

query block (QBLOCKNO).

Chapter 6. Statements

279

EXPLAIN

Table 12. Columns in REFERENCE_TABLE (continued)

Column Name

Data Type

Description

FILTER

FLOAT NOT

The filter factor associated with the query block’s most selective predicate on

NULL

this column.

The selectivity of a predicate is the fraction of the rows of the column’s table

that is estimated to satisfy the predicate. Not all columns referenced in a

statement have filter factors, however.

For each reference to a column, the EXPLAIN statement determines a filter

factor if the reference to the column meets these qualifications:

1. The column must be in a predicate that is connected by the AND logical

operator to the rest of the WHERE clause. If the predicate is not connected

by AND, it must have the only predicate in the WHERE clause.

2. The predicate in which the column appears must have the form “column op

expression.”

For each such column reference, the EXPLAIN statement determines a “filter

factor.” The smallest of these filter factors is returned in FILTER. This value is

between 0.0 and 1.0, and will be 1.0 if there are no predicates with filter factors

for the column. Filter factor may be used to estimate the cost of modifying rows

and indexes. Also, a small filter factor is one indicator that an index on the

column might be useful for processing the statement.

DBSSPRED

CHAR(1) NOT

Is there a sargable predicate (predicate applied at the first stage) associated with

NULL

this column?

There is a sargable predicate associated with this column. However, this

sargable predicate may not necessarily be the most selective one.

There may be no sargable predicate associated with this column.

For each reference to a column, the EXPLAIN statement determines sargability if

the reference to the column meets these qualifications:

1. The column must be in a predicate that is connected by the AND logical

operator to the rest of the WHERE clause. If the predicate is not connected

by AND, it must have the only predicate in the WHERE clause.

2. The predicate in which the column appears must have the form “column op

expression.”

For each such column reference, the EXPLAIN statement determines the

sargability of the predicate associated with the column. If a sargable predicate

exists, the value is set to ’Y’; otherwise, it is set to ’N’.

JOINPRED

CHAR(1) NOT

Is there a sargable equi-join predicate (using equal value in tables to join)

NULL

associated with this column? Y = Yes; N = No.

If yes, then DBSSPRED must be Y as well.

ORDERCOL

SMALLINT

If this column is referenced in an ORDER BY clause, give its relative position in

NOT NULL

the ORDER BY clause and sort direction. If the column is not referenced in the

ORDER BY clause, ORDERCOL is zero. Sort direction is indicated by a positive

number for ascending order and a negative number for descending order.

GROUPCOL

SMALLINT

If this column is referenced in a GROUP BY clause, give its relative position in

NOT NULL

the GROUP BY clause. If the column is not referenced in the GROUP BY clause,

GROUPCOL is zero.

UPDATECOL

CHAR(1) NOT

If this column is in the SET clause of an UPDATE statement, indicate how it is

NULL

updated.

Updated by a literal.

Updated by a column or expression.

blank Column is not referenced in the SET clause

280

SQL Reference

EXPLAIN

Table 12. Columns in REFERENCE_TABLE (continued)

Column Name

Data Type

Description

TIMESTAMP

The time at which the EXPLAIN statement was processed.

NOT NULL

Table 13. Columns in STRUCTURE_TABLE

Column Name

Data Type

Description

QUERYNO

INTEGER

Query number. QUERYNO is intended to

distinguish among queries. (See COST_TABLE for

a description of QUERYNO.)

RINO

SMALLINT NOT NULL

RINO is intended to distinguish among queries

and internally generated queries. (See

COST_TABLE for a description of RINO.)

QBLOCKNO

SMALLINT NOT NULL

Query block number, where 1 is the top level

query block that may have subqueries. Different

query blocks will receive different numbers.

PKGNAME

CHAR(8) NOT NULL

This identifies the name of the package in which

this SQL statement originated. This field is blank

for explicit EXPLAIN processing invoked by the

EXPLAIN statement.

PKGOWNER

CHAR(8) NOT NULL

This identifies the owner of the package in which

this SQL statement originated. This field is blank

for explicit EXPLAIN processing invoked by the

EXPLAIN statement.

ROWCOUNT

INTEGER NOT NULL

Estimated number of rows returned for the query

or subquery corresponding to this query block. For

queries, this is the estimated size of the response.

For update and delete statements, this is the

estimated number of affected rows. ROWCOUNT

can be used in estimating update costs. For insert

statements, the ROWCOUNT for the top level

query block (QBLOCKNO 1) is always 0, but the

ROWCOUNT’s for other query blocks, if any, are

normal estimates. ROWCOUNT is also 0 for

UPDATE and DELETE statements that use

WHERE CURRENT OF CURSOR clauses.

TIMES

FLOAT NOT NULL

Estimated number of times that “dependent”

query blocks of this block will be processed for

each execution of this query block. This field is no

longer in use, but is retained to provide for

compatibility with older versions of the SQL/DS

product.

PARENT

SMALLINT NOT NULL

The query block for which this block is performed.

This may be the query block in whose WHERE

clause the current query block appears. However,

some query blocks can be processed earlier, at the

opening of a “parent” query block, because there

are no correlations to intermediate query blocks

tables. In this case, PARENT identifies that

ancestor, rather than the parent given by the

statement’s structure.

Chapter 6. Statements

281

EXPLAIN

Table 13. Columns in STRUCTURE_TABLE (continued)

Column Name

Data Type

Description

ATOPEN

CHAR (1) NOT NULL

These are the characters that can appear in

ATOPEN:

If the query is done once at each open

(new invocation) of the PARENT.

If the number of times that the current

query block is invoked (per invocation of

its parent) equals the TIMES field value of

the parent.

TIMESTAMP

TIMESTAMP NOT NULL

The time at which the EXPLAIN statement was

processed.

Examples

Place information about a SELECT statement that selects all the rows from the

EMP_ACT table into your tables named REFERENCES_TABLE and COST_TABLE.

Tag the entries that contain this information with the reference number 1500.

EXPLAIN REFERENCE, COST

SET QUERYNO = 1500

FOR SELECT * FROM EMP_ACT

282

SQL Reference

FETCH

The FETCH statement positions a cursor on the next row of its result table and

assigns the values of that row to host variables, host structures, or both.

Invocation

This statement can only be embedded in an application program. It is an

executable statement that cannot be dynamically prepared.

Authorization

See “DECLARE CURSOR” on page 235 for an explanation of the authorization

required to use a cursor.

Syntax

►► FETCH cursor_name

INTO

host_variable_list

►◄

USING DESCRIPTOR descriptor_name

Description

cursor_name

Identifies the select cursor to be used in the fetch operation. The cursor_name

must identify a declared cursor as explained in “DECLARE CURSOR” on page

235. When the FETCH statement is processed, the cursor must be in the open

state.

If the cursor is currently positioned on or after the last row of the result table:

v SQLCODE is set to +100, and SQLSTATE is set to '02000'.

v The cursor is positioned after the last row.

v Host variables and host structure subfields are not assigned values.

If the cursor is currently positioned before a row, the cursor is positioned on

that row, and the values of that row are assigned to host variables and host

structure subfields as specified by INTO or USING.

If the cursor is currently positioned on a row other than the last row, after

execution of the FETCH statement the cursor is positioned on the next row.

Values of that row are assigned to host variables and host structure subfields

as specified by INTO or USING.

INTO

Introduces a list of host variables, host structures, or both.

host_variable_list

Identifies one or more host variables, host structures, or both, that must be

declared in the program in accordance with the rules for declaring host

variables and host structures.

The first value in the result row is assigned to the first host variable or host

structure subfield in the list, the second value to the second variable or

subfield, and so on.

USING DESCRIPTOR descriptor_name

Identifies an output SQLDA that must contain a valid description of zero or

more host variables.

Chapter 6. Statements

283

FETCH

Before the FETCH statement is processed, the user must set some fields in the

SQLDA as described in the “Description” section of “EXECUTE” on page 264

and Table 20 on page 360.

The data type of a variable must be compatible with its corresponding value. If the

value is numeric, the variable must have the capacity to represent the whole part

of the value. For a datetime value, the variable must be a character string variable

of a minimum length as defined in “String Representations of Datetime Values” on

page 49. If the value is null, an indicator variable must be specified.

Each value with a corresponding variable is assigned to the variable in accordance

with the assignment rules described in Chapter 3. If the number of variables is less

than the number of values in the row, the SQLWARN3 field of the SQLCA is set to

'W'. If an assignment error occurs, the value is not assigned to the variable, and no

more values are assigned to variables. Any values that have already been assigned

to variables remain assigned.

Error Conditions

See the DB2 Server for VSE & VM Application Programming manual for a description

of the possible errors when FETCH is processed.

Notes

Cursor Positioning

An open cursor has three possible positions:

v Before a row

v On a row

v After the last row.

If a cursor is on a row, that row is called the current row of the cursor. A cursor

referenced in an UPDATE or DELETE statement must be positioned on a row. A

cursor can only be on a row as a result of a FETCH statement.

It is possible for an error to occur that makes the state of the cursor unpredictable.

Examples

There are two tables, FORUM and ARCHIVE, each with the following columns:

Name:

FORUM

RECEIVED

SOURCE

TOPIC

ENTRY_TEXT

Type:

char(8)

timestamp

char(8)

char(64)

varchar(4000)

not null

Desc:

Forum name

Date and

Userid of

Topic within

The text

time entry

person

the forum

appended in

received

appending

this entry

entry

The FORUM table contains a number of named forums. Each forum contains one

or more topics and each topic contains one or more entries. When a topic is no

longer current its entries are either deleted or moved to the ARCHIVE table.

The following PL/I program performs maintenance on the forum table. A user can

invoke the program with one of three commands. Each command is accompanied

by a string of text that can be found within the TOPIC column of the entries for a

given topic (this need not be the entire TOPIC value). The three commands are:

284

SQL Reference

FETCH

(changes the contents of the TOPIC value for all that topic’s entries)

(moves all entries for that topic to the ARCHIVE table)

(deletes all entries for that topic without archiving them).

CLEANUP: PROC OPTIONS(MAIN);

DCL NOT_END BIT(1);

DCL ACTION

BINARY FIXED(15);

/* 1=chg-topic

2=archive

3=delete */

EXEC SQL BEGIN DECLARE SECTION;

DCL SRCH_FORUM CHAR(8);

DCL SRCH_TOPIC CHAR(66) VARYING;

DCL NEW_TOPIC

CHAR(64) VARYING;

DCL FORUM

CHAR(8);

DCL

1 ENTRY,

5 TSTMP

CHAR(26),

5 PERSON

CHAR(8),

5 TOPIC

CHAR(64) VARYING;

DCL TXT

CHAR(4000) VARYING;

EXEC SQL END DECLARE SECTION;

EXEC SQL INCLUDE SQLCA;

EXEC SQL WHENEVER NOT FOUND CONTINUE;

EXEC SQL WHENEVER SQLWARNING CONTINUE;

EXEC SQL WHENEVER SQLERROR GOTO ERRCHK;

EXEC SQL CONNECT TO TOROLAB3;

GET LIST (ACTION, SRCH_FORUM, SRCH_TOPIC, NEW_TOPIC);

SRCH_TOPIC = ’%’ || SRCH_TOPIC || ’%’;

EXEC SQL DECLARE CUR CURSOR FOR

SELECT * FROM FORUM

WHERE FORUM = :SRCH_FORUM AND TOPIC LIKE :SRCH_TOPIC

FOR UPDATE OF TOPIC;

EXEC SQL OPEN CUR;

EXEC SQL FETCH CUR INTO :FORUM, :ENTRY, :TXT;

IF SQLSTATE = ’02000’

THEN DO;

DISPLAY (’No notes found for requested forum and topic’);

GO TO FINISHED;

END;

NOT_END = ’1’B;

DO WHILE (NOT_END);

EXEC SQL FETCH CUR INTO :FORUM, :ENTRY, :TXT;

IF SQLSTATE = ’02000’ THEN

NOT_END = ’0’B;

ELSE DO;

SELECT;

WHEN (ACTION = 1)

/* change topic value */

EXEC SQL UPDATE FORUM

SET TOPIC = :NEW_TOPIC

WHERE CURRENT OF CUR;

WHEN (ACTION = 2)

/* archive entry to another table

DO;

EXEC SQL INSERT INTO ARCHIVE

VALUES (:FORUM, :TSTMP, :PERSON, :TOPIC, :TXT);

EXEC SQL DELETE FROM FORUM WHERE CURRENT OF CUR;

END;

WHEN (ACTION = 3)

/* delete topic */

EXEC SQL DELETE FROM FORUM WHERE CURRENT OF CUR;

END; /* select */

END;

/* else do */

END;

/* do while */

FINISHED:

EXEC SQL CLOSE CUR;

EXEC SQL COMMIT WORK;

RETURN;

ERRCHK:

DISPLAY (’Unexpected Error -changes will be backed out’);

Chapter 6. Statements

285

Extended FETCH

The Extended FETCH statement positions a cursor on the next row of its result

table and assigns the values of that row to host variables. The cursor must have

been opened using the Extended OPEN statement.

Invocation

This statement can only be embedded in an application program written in

Assembler or REXX.

Authorization

The authorization ID of the statement must have one of the following:

v ownership of the package

v DBA authority

v EXECUTE privilege on the package.

Syntax

►► FETCH cursor_variable USING DESCRIPTOR descriptor_name

►◄

Description

cursor_variable

Identifies the cursor that is to be used. The cursor must have been defined by a

preceding Extended DECLARE CURSOR statement in the same logical unit of

work.

USING DESCRIPTOR descriptor_name

Identifies an output SQLDA that must contain a valid description of host

variables.

Before the Extended FETCH statement is processed, the user must set some

fields in the SQLDA as described in the “Description” section of “EXECUTE”

on page 264 and Table 20 on page 360.

The indicated cursor must be declared and opened.

Notes

In most respects, the Extended FETCH statement is identical to the FETCH

statement (see “FETCH” on page 283). However, in the Extended FETCH

statement, the cursor_name is a host variable, thereby making it possible for a user

to provide the cursor name when the program is run and to FETCH in a logical

unit of work or program other than the one in which the statement was prepared.

Extended DECLARE CURSOR, OPEN, and FETCH must occur in the same logical

unit of work.

Examples

FETCH :CURSOR1 USING DESCRIPTOR MYSQLDA

Chapter 6. Statements

287

GRANT

GRANT (Package Privileges)

This form of the GRANT statement grants the privilege to process statements in a

package.

Invocation

This statement can be embedded in an application program or issued interactively.

It is an executable statement that can be dynamically prepared.

Authorization

To process this statement, the privileges held by the authorization ID of the

statement must include the EXECUTE privilege on the package and GRANT

authority on that privilege. Someone with DBA authority may grant the EXECUTE

privilege on a package owned by another user.

Syntax

(1)

▼

►►

GRANT EXECUTE ON

package_name

authorization_name

►

PUBLIC

►

►◄

WITH GRANT OPTION

Notes:

RUN can be specified as a synonym for EXECUTE to support applications developed

for previous releases of SQL/DS.

Description

EXECUTE ON package_name

Identifies the package upon which the EXECUTE privilege is being granted.

The package_name must identify a package that exists at the application server.

Specifies to whom the privileges are granted.

authorization_name,...

Lists one or more authorization IDs. You cannot use the ID of the GRANT

statement itself; you cannot grant privileges to yourself.

PUBLIC

Grants the EXECUTE privilege on the package to all users.

WITH GRANT OPTION

Allows the named authorization_names to grant the EXECUTE privilege on the

package to other users.

If WITH GRANT OPTION is omitted, the named authorization_names cannot

grant the EXECUTE privilege to others unless they have received that

authority from some other source.

288

SQL Reference

GRANT

The GRANT authority cannot be passed to PUBLIC. If you use PUBLIC and

WITH GRANT OPTION together, the statement is processed; but a warning is

given and the EXECUTE privilege is granted to PUBLIC without GRANT

authority.

Notes

Only the authorization ID that preprocesses a package (or an authorization ID with

DBA authority) can drop that package from the database. A 'drop' privilege cannot

be granted to another authorization ID.

Examples

Example 1

Grant the ability to process the TIMESHEET package (which is used by the

TIMESHEET program) to everyone.

GRANT EXECUTE ON TIMESHEET TO PUBLIC

Example 2

Grant the ability to process the TABB package (which is used by the TABB

program) to KING, BROWN, and BLACK. Allow them to grant this privilege to

others.

GRANT EXECUTE ON TABB

TO KING, BROWN, BLACK

WITH GRANT OPTION

Chapter 6. Statements

289

GRANT

GRANT (System Authorities)

This form of the GRANT statement changes passwords and authorities.

Invocation

This statement can be embedded in an application program or issued interactively.

It is an executable statement that can be dynamically prepared.

Authorization

DBA authority is needed to grant authorities and to change others’ passwords.

DBA authority is not needed for someone to change their own password if they

have been granted connect authority explicitly by a DBA. (A user able to access the

database only because connect authority has been granted to ALLUSERS cannot

use this command to change their own password.)

Syntax

►► GRANT

CONNECT

AUTH

►◄

DBA

RESOURCE

▼

CONNECT TO

authorization_name

(1)

ALLUSERS

SCHEDULE TO subsystemid IDENTIFIED

password

AUTH:

▼

authorization_name

ID:

▼

IDENTIFIED BY

password

Notes:

ALLUSERS can only be specified once and is not applicable to a VSE application

server.

Description

CONNECT

Grants CONNECT authority to the specified authorization_names. A user can

use this parameter with the IDENTIFIED BY clause to change his or her own

password.

DBA

Grants DBA authority to the specified authorization_names. This also means that

the specified authorization_names will be automatically granted CONNECT and

RESOURCE authority. Someone with DBA authority

has all privileges on all

290

SQL Reference

GRANT

objects in the database, including the authority to drop any object. However, a

DBA may not grant any privileges on an object the DBA does not own unless

the owner has given the DBA that right. A DBA also cannot revoke any

privilege on an object unless the DBA granted that privilege in the first place.

For a complete description of DBA authority, see the DB2 Server for VSE & VM

Database Administration manual.

RESOURCE

Grants RESOURCE authority to the specified user(s). This also means that the

specified user(s) will be automatically granted CONNECT authority. Someone

with RESOURCE authority has the ability to create tables in public dbspaces.

Introduces a list of one or more authorization_names

authorization_name

An authorization id.

ALLUSERS

Specifies that the CONNECT authority is granted implicitly to every

system-defined user. Granting CONNECT to ALLUSERS is a special case

that establishes implicit connect capability for all users in the system when

operating under the DB2 Server for VM environment.

VSE Users

ALLUSERS is not a valid option since implicit CONNECT authority

is not applicable to VSE application servers.

IDENTIFIED BY password...

Adds or changes the password for each authorization_name specified. If you

specify IDENTIFIED BY, you must include a password for every

authorization_name specified. The password specifies the new or changed

password for each of the specified authorization_names. Passwords are limited

to eight characters. The passwords and authorization_names must correspond as

shown in example 2 below. If the password is the same as the one that

currently exists for the authorization_name, or if no passwords are specified, the

change has no real effect.

SCHEDULE

Grants the authority to connect users without specifying a password. Used

with the VSE Guest Sharing facility. For more information, see the DB2 Server

for VM System Administration or the DB2 Server for VSE System Administration

manual.

TO subsystemid

The subsystem ID of the CICS subsystem running under the VSE guest.

IDENTIFIED BY password

The new or changed password by which the subsystem will identify itself.

Examples

Example 1

Grant DBA authority to THOMPSON and THORN.

GRANT DBA TO THOMPSON, THORN

Chapter 6. Statements

291

GRANT

GRANT (Table Privileges)

This form of the GRANT statement grants privileges on table and views.

Invocation

This statement can be embedded in an application program or issued interactively.

It is an executable statement that can be dynamically prepared.

Authorization

The privileges held by the authorization ID of the statement must include the

privilege being granted and GRANT authority on that privilege. Someone with

DBA authority may grant table privileges on a table or view owned by another

user.

Syntax

►► GRANT

ALL

►

PRIVILEGES

(1)

▼

ALTER

DELETE

(1)

INDEX

INSERT

(1)

REFERENCES

SELECT

UPDATE

▼

(

column_name

)

▼

►

table_name

authorization_name

►◄

view_name

PUBLIC

WITH GRANT OPTION

Notes:

The ALTER, INDEX and REFERENCES options do not apply to views.

Description

ALL or ALL PRIVILEGES

Grants table privileges on the table or view identified in the ON clause. The

privileges granted are those possessed by the authorization ID of the GRANT

statement. ALL PRIVILEGES is the default.

ALTER

Grants the privilege to use the ALTER TABLE statement. This privilege cannot

be granted on a view.

DELETE

Grants the privilege to use the DELETE statement.

Chapter 6. Statements

293

GRANT

INDEX

Grants the privilege to use the CREATE INDEX statement. This privilege

cannot be granted on a view.

INSERT

Grants the privilege to use the INSERT statement.

REFERENCES

Grants the privilege to create, drop, activate, or deactivate a referential

constraint in which the table is the parent table. This privilege does not apply

to views.

This privilege is required to reference the parent table when a referential

constraint is defined or added by the CREATE TABLE or ALTER TABLE

statement respectively.

This privilege is also required on the parent table when the user wants to use

the ALTER TABLE statement to drop, activate, or deactivate a foreign key on a

dependent table that references the parent table.

SELECT

Grants the privilege to use the SELECT statement or the CREATE VIEW

statement.

UPDATE

Allows the grantee(s) to update the table or view.

(column_name,...)

Restricts the update privilege to the columns listed. If a list of column

names is not specified or if UPDATE is granted using the specification of

ALL PRIVILEGES, the grantee(s) may update all updateable columns of

the table, even those created later by the ALTER TABLE statement.

ON table_name or view_name

Identifies the table or view upon which you are granting the privileges. The

table_name or view_name must identify a table or view that exists at the

application server.

Indicates to whom the privileges are granted.

authorization_name,...

Lists one or more authorization IDs. The ID of the GRANT statement itself

cannot be used. (Privileges cannot be granted to oneself.)

PUBLIC

Grants the privileges to all users.

WITH GRANT OPTION

Allows the named authorization_names to grant the privileges to other

authorization_names. If you omit WITH GRANT OPTION, the named

authorization_names cannot grant the privileges to others unless they have that

authority from some other source.

You cannot pass the GRANT authority to PUBLIC. If you use PUBLIC and

WITH GRANT OPTION together, the statement is processed; but a warning is

given and the privileges are granted to PUBLIC without GRANT authority.

294

SQL Reference

GRANT

Examples

Example 1

Given that you have DBA authority, and that you have all grant authorities on the

table WESTERN_COURSES (owned by KATHLEEN), grant all privileges on the

table to PUBLIC.

GRANT ALL ON KATHLEEN.WESTERN_COURSES

TO PUBLIC

Example 2

Grant the appropriate privileges on your CALENDAR table so that ROANNA and

EMMA can read it and insert new entries into it, but do not allow them to change

or remove any entries. Do not allow ROANNA or EMMA to grant those privileges

to others.

GRANT SELECT, INSERT ON CALENDAR

TO ROANNA, EMMA

Example 3

Grant the UPDATE privilege on the RATING and CRITIQUE columns from the

public table TORONTO_RESTAURANT (owned by ONTARIO) to MARGARET

and COMPDEPT. Allow them to grant those privileges to others.

GRANT UPDATE (RATING, CRITIQUE) ON ONTARIO.TORONTO_RESTAURANT

TO MARGARET, COMPDEPT

WITH GRANT OPTION

Chapter 6. Statements

295

INCLUDE

The INCLUDE statement inserts declarations, statements, or both, into a source

program.

Invocation

This statement can only be embedded in an application program. It is not an

executable statement. It is not supported in REXX.

Authorization

None required.

Syntax

►► INCLUDE

SQLCA

►◄

SQLDA

text_file_name

Description

SQLCA

Indicates the description of an SQL communication area (SQLCA) is to be

included. INCLUDE SQLCA must not be specified more than once in the same

program. INCLUDE SQLCA must not be specified if the program includes a

stand-alone SQLCODE (see “SQL Return Codes” on page 142). For a

description of the SQLCA, see “SQL Communication Area (SQLCA)” on page

353.

SQLDA

Indicates the description of an SQL descriptor area (SQLDA) is to be included.

SQLDA should not be specified in a COBOL, or Fortran program, as it will be

interpreted as a text_file_name. For a description of the SQLDA, see “SQL

Descriptor Area (SQLDA)” on page 359.

text_file_name

Identifies an external source file to be used as input when your program is

precompiled.

The statements contained in the external source specified by text_file_name may

be host language statements or SQL statements (except for another INCLUDE

statement). INCLUDE text_file_name statements may not be nested, but the

external source may contain INCLUDE SQLDA or INCLUDE SQLCA

statements. The INCLUDE text_file_name may appear in an SQL DECLARE

section or the entire SQL DECLARE section(s) may be placed within an

external source file.

Notes

The INCLUDE statement may be used to obtain secondary input from a CMS file

in VM or a source member in VSE. If a source program input to a preprocessor

uses the INCLUDE facility, any files to be used as secondary input must be

accessed by the user. The INCLUDE statement causes input to be read from the

specified file name until the end of the file, at which time the SYSIN input in VM

or the SYSIPT input in VSE resumes.

296

SQL Reference

INCLUDE

In VM

The file to be included must have one of the following file types:

Language

File Type

Assembler

ASMCOPY

CCOPY

COBOL

COBCOPY

Fortran

FORTCOPY

PL/I

PLICOPY

In VSE

The source member must be cataloged as one of the following source types:

Language

Source Type

Assembler

COBOL

Fortran

PL/I

For COBOL programs, INCLUDE SQLCA must not be specified in other than the

Working Storage Section.

See the DB2 Server for VSE & VM Application Programming manual for more

information on using external source files.

Examples

Include an SQL Communications Area into a PL/I program.

EXEC SQL INCLUDE SQLCA;

Chapter 6. Statements

297

INSERT

The INSERT statement inserts rows into a table or view. Inserting a row into a

view also inserts the row into the table on which the view is based.

There are two forms of this statement:

v The INSERT using VALUES form inserts a single row into the table or view using

the values provided or referenced.

v The INSERT by subselect form inserts one or more rows into the table or view

using values from other tables or views.

Invocation

This statement can be embedded in an application program or issued interactively.

It is an executable statement that can be dynamically prepared.

Authorization

The privileges held by the authorization ID of the statement must include at least

one of the following:

v Ownership of the table

v The INSERT privilege for the table or view

v DBA authority.

The INSERT privilege on a view is only inherent in DBA authority. Ownership of a

view does not necessarily include the INSERT privilege on the view because the

privilege may not have been granted when the view was created, or it may have

been granted, but subsequently revoked.

If a subselect is specified, the privileges held by the authorization ID of the

statement must also include at least one of the following:

v Ownership of the tables or views identified in the subselect

v The SELECT privilege on every table or view identified in the subselect

v DBA authority.

Syntax

►►

INSERT INTO

table_name

►

view_name

▼

(

column_name

)

►

VALUES

(

▼

constant

)

►◄

host_variable_list

NULL

special_register

subselect

WITH

Description

INTO table_name

298

SQL Reference

INSERT

INTO view_name

Identifies the object of the insert operation. The name must identify a table or

view that exists at the application server, but it must not identify a catalog

table, a view of a catalog table, or a read-only view (see “Read-only views” on

page 233). However, someone with DBA authority may insert rows into a few

of the catalog tables. See “Updateable Columns” on page 371.

A value cannot be inserted into a view column that is derived from:

v A constant, expression, or scalar function

v The same base table column as some other column of the view.

If the object of the insert operation is a view with such columns, a list of

column names must be specified, and the list must not identify these columns.

(column_name,...)

Specifies the columns for which insert values are provided. Each name must be

an unqualified name that identifies a column of the table or view. The same

column must not be identified more than once. A view column that cannot

accept insert values must not be identified.

Omission of the column list is an implicit specification of a list in which every

column of the table or view is identified in left-to-right order. This list is

established when the statement is prepared and therefore does not include

columns that were added to a table after the statement was prepared.

SQL statements can be implicitly or explicitly rebound (prepared again). The

effect of a rebind on INSERT statements that do not include a column list is to

re-establish the list. Therefore, the number of columns into which data will be

inserted may change.

VALUES

Introduces one row of values to be inserted. The values of the row are the

values of the constants, host variables, host structure subfields, and keywords

specified in the clause.

Each host variable and host structure named must be described in the program

in accordance with the rules for declaring host variables and host structures.

The number of values in the VALUES clause must equal the number of names

in the column list. The first value is inserted in the first column in the list, the

second value in the second column, and so on.

For an explanation of constant and host-variable-list, see Chapter 3. For a

description of special-register, see “Special Registers” on page 62. NULL

specifies the null value. A constant or special register cannot be used to specify

the insert value for a long string column.

subselect

Inserts the rows of the result table of a subselect. There may be one, more than

one, or none. If there are none, SQLCODE is set to +100 and SQLSTATE is set

to '02000'.

(For an explanation of subselect, see Chapter 5, “Queries,” on page 121.)

The base object of the INSERT, and the base object of the subselect, or any

subquery of the subselect, must not be the same table.

The number of columns in the result table must equal the number of names in

the column list. The value of the first column of the result is inserted in the

first column in the list, the second value in the second column, and so on.

Chapter 6. Statements

299

INSERT

A non-null value cannot be inserted into a long string column using a

subselect.

WITH Specifies the isolation level at which the subselect is executed.

Repeatable read

Cursor stability

The default isolation level of the statement is the isolation level of the package.

INSERT Rules

Insert values must satisfy the following rules. If they do not, or if any other errors

occur during the execution of the INSERT statement, no rows are inserted.

Default values: The value inserted in any column that is not in the column list is

null. Columns that do not allow null values must be included in the column list.

Similarly, if you insert into a view, the null value is inserted into any column of

the base table that is not included in the view. Hence, all columns of the base

table that are not in the view must allow null values.

Assignment: Insert values are assigned to columns in accordance with the

assignment rules described in Chapter 3.

Validity: If the table named, or the base table of the view named, has one or

more unique indexes, each row inserted into the table must conform to the

constraints imposed by those indexes.

If you name a view whose definition includes WITH CHECK OPTION, each

row inserted into the view must conform to the definition of the view. If the

view you name is dependent on other views whose definitions include WITH

CHECK OPTION, the inserted rows must also conform to the definitions of

those views.

If you name a view whose definition does not include WITH CHECK OPTION,

rows can be inserted that do not conform to the definition of the view. Those

rows cannot appear in the view but are inserted into the base table of the view.

For an explanation of the rules governing these situations, see “CREATE VIEW”

on page 231.

Referential Integrity: For each constraint defined on the table, each non-null insert

value of each foreign key must be equal to a primary key value of the parent

table.

Length: If the insert value is a number, the column must be a numeric column

with the capacity to represent the integral part of the number. For INSERT using

VALUES, if the insert value is a string, the column must be a string column with

a length attribute at least as great as the length of the string. For INSERT by

subselect, the column may be a string column with a shorter length attribute, in

which case truncation will occur with no error. Note that character string values

may also be assigned to datetime columns as defined in “Datetime

Assignments” on page 57.

If you are inserting rows into a parent table that is part of a referential constraint,

the database manager implicitly checks that the primary key remains unique and

does not contain null values.

Notes

Rows are inserted in an order determined by the database manager; that is, no

facility is provided to specify the position in the table of a newly inserted row.

300

SQL Reference

INSERT

If an error occurs during the execution of an INSERT, you must inspect

SQLWARN6 to determine the extent of the error. The following are current settings

for SQLWARN6 when there is an error indication and the possible responses:

1. SQLWARN6 is set to 'S'. A severe error has occurred, leaving the system in an

unusable state.

v No further requests are possible. The application must end, or, in a DB2

Server for VSE & VM environment, may switch to another database.

2. SQLWARN6 is set to 'W'. An error occurred causing the LUW to be rolled back

automatically. The system is still in a usable state. The application can either:

v begin a new LUW and proceed or

v stop.

3. SQLWARN6 is blank. An error has occurred, but the LUW is still active. For

recoverable pools, any changes made by the request have been rolled back,

hence the failing request has not left any partial results in the database. For

information on nonrecoverable storage pools, see the DB2 Server for VM System

Administration or the DB2 Server for VSE System Administration manual. The

application can do one of the following:

v Continue forward processing of the LUW

v Commit the changes made before the failing request

v Roll back the LUW.

The order of rows being inserted is determined by the database manager; no

facility is provided to specify the position in the table of a newly inserted row. The

SQLERRD(3) portion of the SQLCA indicates the number of rows that were

inserted.

Unless appropriate locks already exist, one or more exclusive locks are acquired at

the execution of a successful INSERT statement. Until the locks are released, an

inserted row can only be accessed by the application process that performed the

insert. For further information about locking, see the description of the COMMIT,

ROLLBACK, LOCK TABLE, and LOCK DBSPACE statements.

Put blocking is available with the DRDA protocol if the application has been

preprocessed with the IBLOCK option. The database manager does not notify the

application program of an insert error until the INSERTs that fills a block is

processed. To determine when (or if) rows are actually inserted into the database,

your program should examine SQLERRD(3) in the SQLCA when doing INSERTs.

For example, assuming 10 data rows to be inserted fit into one block, and that the

data for the fourth insert is in error. The database manager tries to process the

block of ten inserts, but encounters the error in the fourth row. It stops processing

the block - that is, three rows are inserted successfully. SQLERRD(3) contains the

number of rows that were successfully inserted. In this case, it contains a value of

3. If all rows were inserted successfully, it would contain 10. The application

program can use SQLERRD(3) to determine where the error occurred.

Examples

Example 1

Insert a new department with the following specifications into the DEPARTMENT

table:

v Department number (DEPTNO) is ‘E31’

v Department name (DEPTNAME) is ‘ARCHITECTURE’

v Managed by (MGRNO) a person with number ‘00390’

v Reports to (ADMRDEPT) department ‘E01’.

Chapter 6. Statements

301

INSERT

INSERT INTO DEPARTMENT

VALUES (’E31’, ’ARCHITECTURE’, ’00390’, ’E01’)

Example 2

Insert a new department into the DEPARTMENT table as in example 1, but do not

assign a manager to the new department.

INSERT INTO DEPARTMENT (DEPTNO, DEPTNAME, ADMRDEPT)

VALUES (’E31’, ’ARCHITECTURE’, ’E01’)

Example 3

Create a temporary table MA_EMP_ACT with the same columns as the EMP_ACT

table. Load MA_EMP_ACT with the rows from the EMP_ACT table with a project

number (PROJNO) starting with the letters ‘MA’.

CREATE TABLE MA_EMP_ACT

(EMPNO

CHAR(6) NOT NULL,

PROJNO

CHAR(6) NOT NULL,

ACTNO

SMALLINT NOT NULL,

EMPTIME

DEC(5,2),

EMSTDATE

DATE,

EMENDATE

DATE )

INSERT INTO MA_EMP_ACT

SELECT * FROM EMP_ACT

WHERE SUBSTR(PROJNO, 1, 2) = ’MA’

Example 4

Use a PL/I program statement to add a skeleton project to the PROJECT table.

Obtain the project number (PROJNO), project name (PROJNAME), department

number (DEPTNO), and responsible employee (RESPEMP) from host variables and

a host structure. Use the current date as the project start date (PRSTDATE). Assign

a NULL value to the remaining columns in the table.

DCL 1 PROJECT,

5 PRJNO CHAR(5),

5 PRJNM CHAR(24) VARYING;

DCL 1 EMPLOYEE,

5 DPTNO CHAR(3),

5 REMP

CHAR(6),

5 LNAME

CHAR(25);

EXEC SQL INSERT INTO PROJECT

( PROJNO, PROJNAME, DEPTNO, RESPEMP, PRSTDATE)

VALUES (:PROJECT, :EMPLOYEE.DPTNO, :REMP, CURRENT DATE);

302

SQL Reference

LABEL ON

The LABEL ON statement adds or replaces labels in the catalog descriptions of

tables, views, or columns.

Invocation

This statement can be embedded in an application program or issued interactively.

It is an executable statement that can be dynamically prepared.

Authorization

The privileges held by the authorization ID of the statement must include at least

one of the following:

v Ownership of the table or view

v DBA authority.

Syntax

►► LABEL ON

options_a

IS string_constant

►◄

table_name

(

options_b

)

view_name

options_a

TABLE

table_name

view_name

COLUMN

table_name.column_name

view_name.column_name

options_b

▼

column_name IS string_constant

Description

TABLE

Indicates that the label is for a table or a view.

table_name

view_name

Identifies a table or view to which the label applies. The name must

identify a table or view at the application server.

The label is placed into the TLABEL column of the SYSTEM.SYSCATALOG

catalog table for the row that describes the table or view.

COLUMN

Indicates that the label is for a column.

table_name.column_name

view_name.column_name

Identifies the column, qualified by the name of the table or view in which it

appears. The column_name must identify a column of the specified table or

view that exists at the application server.

Chapter 6. Statements

303

LABEL ON

The label is placed in the CLABEL column of the SYSTEM.SYSCOLUMNS

catalog table, for the row that describes the column.

Multiple Labels:

To define a label for more than one column within the same table or view

within the same statement, the table or view name is followed by a list of one

or more column_name and string-constant pairs in parentheses.

The column_name must identify a column of the specified table or view that

exists at the application server.

IS Introduces the label you want to provide.

string_constant

Can be any SQL character string constant of up to 30 characters. The

constant may contain mixed double-byte and single-byte characters.

Notes

Unlike synonyms, labels cannot be used as identifiers. Instead, they can be used in

displays created by applications that process SQL statements dynamically.

A DESCRIBE statement specified with USING BOTH or USING LABELS can be

used to return column labels in an SQLDA. The program can then move the label

from the SQLNAME field of the SQLDA into a work area. A column is considered

to have no label if either its LABEL column in SYSTEM.SYSCOLUMNS is NULL,

or if it has a zero length value. If there is no column label when the program

issues a DESCRIBE, the SQLNAME field of the SQLDA is set to length 0, and the

field is cleared to 30 blanks. For this reason, the program should move the label

into a work area using the length returned in SQLDA only after it makes sure that

the length is not zero.

Examples

Example 1

Insert a label for the EMP_ACT table into the catalog.

LABEL ON TABLE EMP_ACT

IS ’EMPLOYEE ACTIVITY BY PROJECT’

Example 2

Insert a label for the EMP_VIEW1 view into the catalog.

LABEL ON TABLE EMP_VIEW1

IS ’EMPLOYEE WITHOUT SALARY’

Example 3

Insert a label for the EDLEVEL column of the EMPLOYEE table into the catalog.

LABEL ON COLUMN EMPLOYEE.EDLEVEL

IS ’HIGHEST GRADE LEVEL’

Example 4

Insert a label for two different columns of the EMPLOYEE table into the catalog.

LABEL ON EMPLOYEE

(WORKDEPT IS ’DEPTNO IN EMPLOYEE’,

EDLEVEL IS ’HIGHEST GRADE LEVEL ’)

304

SQL Reference

LOCK DBSPACE

The LOCK DBSPACE statement either prevents concurrent application processes

from changing a dbspace or prevents concurrent application processes from using

a dbspace.

Invocation

This statement can be embedded in an application program or issued interactively.

It is an executable statement that can be dynamically prepared.

Authorization

The privileges held by the authorization ID of the statement must include at least

one of the following:

v Ownership of the dbspace

v DBA authority.

Syntax

►► LOCK DBSPACE dbspace_name IN

MODE

►◄

EXCLUSIVE

Description

dbspace_name

Identifies the dbspace to be locked. The dbspace must exist at the application

server. You cannot lock any dbspace containing the database manager's system

catalog.

The LOCK statement can be used to lock both private and public dbspaces. If

the dbspace_name is unqualified, the database manager will first look for a

private dbspace and, if that does not exist, it will look for a public dbspace

with the same dbspace name.

IN SHARE MODE

Prevents concurrent application processes from executing any but read-only

operations on the dbspace.

IN EXCLUSIVE MODE

Prevents concurrent application processes from executing any operations on

the dbspace. This option requires a Z lock on the dbspace.

Locking prevents concurrent operations. A lock is not necessarily acquired during

the execution of LOCK DBSPACE if a suitable lock already exists. The lock that

prevents the concurrent operations is held until the termination of the unit of

work.

Examples

Obtain a lock on the dbspace named DSP3. Allow others to read from the DSP3

while it is locked.

LOCK DBSPACE DSP3 IN SHARE MODE

Chapter 6. Statements

305

LOCK TABLE

The LOCK TABLE statement either prevents concurrent application processes from

changing a table or prevents concurrent application processes from using a table.

Invocation

This statement can be embedded in an application program or issued interactively.

It is an executable statement that can be dynamically prepared.

Authorization

The privileges held by the authorization ID of the statement must include at least

one of the following:

v Ownership of the table

v The SELECT privilege for the table

v DBA authority.

Syntax

►► LOCK TABLE table_name IN

MODE

►◄

EXCLUSIVE

Description

table_name

Identifies the table. The table_name must identify a base table that exists at the

application server. If you lock a table in a private dbspace the entire dbspace is

locked because locking is always performed at the dbspace level for private

dbspaces.

IN SHARE MODE

Prevents concurrent application processes from executing any but read-only

operations on the table.

IN EXCLUSIVE MODE

Prevents concurrent application processes from executing any operations on

the table. This option requires an IX lock on the dbspace and a Z lock on the

table.

Locking prevents concurrent operations. A lock is not necessarily acquired during

the execution of LOCK TABLE if a suitable lock already exists. The lock that

prevents the concurrent operations is held until the termination of the unit of

work.

The lock is acquired when the LOCK TABLE statement is processed.

Examples

Obtain a lock on the DEPARTMENT table. Do not allow others to either update or

read from DEPARTMENT while it is locked.

LOCK TABLE DEPARTMENT IN EXCLUSIVE MODE

306

SQL Reference

OPEN

The OPEN statement opens a cursor.

Invocation

This statement can be embedded only in an application program. It is an

executable statement that cannot be dynamically prepared.

Authorization

See “DECLARE CURSOR” on page 235 for the authorization required to use a

cursor. The authorization for the OPEN statement is checked when the related

DECLARE CURSOR statement is prepared.

Syntax

►► OPEN cursor_name

►◄

USING

host_variable_list

USING DESCRIPTOR descriptor_name

Description

cursor_name

Identifies the cursor to be opened. The cursor_name must identify a declared

cursor as explained in the Notes for the DECLARE CURSOR statement. When

the OPEN statement is processed, the cursor must be in the closed state, and it

must have been successfully prepared or declared.

If using an insert-cursor and the program is blocking, this statement tells the

application server to prepare to block the rows to be inserted. If not blocking,

the application server prepares to insert a single row into the database. Rows

are not actually inserted into the database until one or more PUT statements

have been processed.

If opening a query-cursor, the result table of the cursor is derived by evaluating

that select-statement. The evaluation uses the current values of any special

registers specified in the select-statement and the current values of any host

variables or host structures specified in it or in the USING clause of the OPEN

statement. The rows of the result table may be derived during the execution of

the OPEN statement, and a temporary table created to hold them; or they may

be derived during the execution of subsequent FETCH statements. In either

case, the cursor is placed in the open state and positioned before the first row

of its result table. If the table is empty, the position of the cursor is effectively

“after the last row.”

USING

Introduces a list of host variables or host structures or both whose values are

substituted for the parameter markers (question marks) of a prepared

statement. (For an explanation of parameter markers, see “PREPARE” on page

313.) If the DECLARE CURSOR statement names a prepared statement that

includes parameter markers, you must use USING. If the prepared statement

does not include parameter markers, USING is ignored. USING must not be

used if the select-statement of the cursor is specified in the DECLARE

CURSOR statement.

A USING clause cannot appear in the OPEN statement for an insert-cursor.

Chapter 6. Statements

307

OPEN

host_variable_list

Identifies a list of host variables, host structures, or both, that must be

declared in the program in accordance with the rules for declaring host

variables and host structures.

The total number of host variables and host structure subfields must be the

same as the number of parameter markers in the prepared statement. The

nth variable or subfield corresponds to the nth parameter marker in the

prepared statement.

USING DESCRIPTOR descriptor_name

Identifies an input SQLDA that must contain a valid description of host

variables.

Before the OPEN statement is processed, the user must set some fields in the

SQLDA as described in the “Description” section of “EXECUTE” on page 264

and Table 20 on page 360.

If the select-statement of the cursor was prepared (rather than declared) and that

statement contains parameter markers, when that statement is evaluated each

parameter marker in the statement is effectively replaced by its corresponding host

variable. With the exception of the LIKE predicate, the replacement of a parameter

marker is an assignment operation in which the source is the value of the host

variable, and the target is a variable within the database manager. The attributes of

the target variable are determined as follows:

If the parameter marker was specified as the operand of a unary minus, the

target is double-precision floating-point.

If the parameter marker was specified as the operand of an arithmetic operator,

the data type, scale, and precision of the target are the same as the other

operand of that operator.

If the parameter marker was specified as a comparison operand, the attributes of

the target are the same as the other operand of the predicate. However, if the

data type of the other operand is DATE, TIME, or TIMESTAMP, the target is

effectively CHAR(254).

When the parameter marker is specified as a comparison operand in the

BETWEEN predicate,

- If there is an operand that is specified solely as a column name (or a column

function with the argument being a column with a field procedure defined on

it), then the attributes of the leftmost operand are used.

- Otherwise, the attributes of the leftmost operand that is not a parameter

marker are used.

When the parameter marker is specified as a comparison operand in the IN

predicate,

- The attributes of the leftmost operand that is not a parameter marker are

used.

If the parameter marker is the pattern in a LIKE predicate, then:

If the first operand in the predicate is a character string column, the target is

VARCHAR(n), where n is 10 more than the length attribute of the column with

this exception: if that length is greater than 246, then n is 256.

If the first operand in the predicate is a graphic string column, the target is

VARCHAR(n), where n is 5 more than the length attribute of the column with

this exception: if that length is greater than 123, then n is 128.

308

SQL Reference

OPEN

Let V denote a host variable that corresponds to parameter marker P. The value of

V is assigned to the target variable for P in accordance with the rules for assigning

a value to a column. Thus:

v V must be compatible with the target.

v If V is a string, its length must not be greater than the length attribute of the

target.

v If V is a number, the absolute value of its integer part must not be greater than

the maximum absolute value of the integer part of the target.

v If the attributes of V are not identical to the attributes of the target, the value is

converted to conform to the attributes of the target.

When the SELECT statement of the cursor is evaluated, the value used in place of

P is the value of the target variable for P. For example, if V is CHAR(6), and the

target is CHAR(8), the value used in place of P is the value of V padded with two

blanks.

The USING clause is intended for a prepared SELECT statement that contains

parameter markers. However, it can also be used when the SELECT statement of

the cursor is part of the DECLARE CURSOR statement. In this case the OPEN

statement is processed as if each host variable in the SELECT statement were a

parameter marker, except that the attributes of the target variables are the same as

the attributes of the host variables in the SELECT statement. The effect is to

override the values of the host variables in the SELECT statement of the cursor

with the values of the host variables specified in the USING clause.

Notes

Closed state of cursors

All cursors in a program are in the closed state when:

v The program is initiated

v A program initiates a new unit of work by executing a COMMIT or ROLLBACK

statement.

A cursor can also be in the closed state because:

v A CLOSE statement was processed

v An error was detected that made the position of the cursor unpredictable.

To retrieve rows from the active set of a query-cursor, a FETCH statement must be

processed while the cursor is open. To insert rows into the active set of an

insert-cursor, a PUT statement must be processed while the cursor is open. The only

way to change the state of a cursor from closed state to open is to process an

OPEN statement.

Effect of temporary tables: If the result table of a query cursor is not read-only,

its rows are derived during the execution of subsequent FETCH statements. The

same method may be used for a read-only result table. However, if a result table is

read-only, the database manager may choose to use the temporary table method

instead. With this method the entire result table is inserted into a temporary table

during the execution of the OPEN statement. When a temporary table is used, the

results of a program can differ in these two ways:

v An error can occur during OPEN that would otherwise not occur until some

later FETCH statement.

v An INSERT, UPDATE, and DELETE statement processed while the cursor is

open cannot affect the result table.

Chapter 6. Statements

309

OPEN

Conversely, if a temporary table is not used, INSERT, UPDATE, and DELETE

statements processed while the cursor is open can affect the result table if issued

from the same application process. The effect of such operations is not always

predictable. For example, if cursor C is positioned on a row of its result table

defined as SELECT * FROM T, and you insert a row into T, the effect of that insert

on the result table is not predictable because its rows are not ordered. A

subsequent FETCH C might or might not retrieve the new row of T.

Examples

Example 1

Write the embedded statements in a COBOL program that will:

1. Define a cursor C1 that is to be used to retrieve all rows from the

DEPARTMENT table for departments that are administered by (ADMRDEPT)

department ‘A00’

2. Place the cursor C1 before the first row to be fetched.

EXEC SQL DECLARE C1 CURSOR FOR

SELECT DEPTNO, DEPTNAME, MGRNO FROM DEPARTMENT

WHERE ADMRDEPT = ’A00’ END-EXEC.

EXEC SQL OPEN C1

END-EXEC.

Example 2

Code an OPEN statement to associate a cursor DYN_CURSOR with a dynamically

defined select-statement in a PL/I program. Assume each prepared

select-statement always has two parameter markers in its WHERE clause with the

first having a data type of integer and the second having a data type of

varchar(64). (The related host variable definitions, PREPARE statement and

DECLARE CURSOR statement are also shown in the example below.)

EXEC SQL BEGIN DECLARE SECTION;

DCL HV_INT

BINARY

FIXED(31);

DCL HV_VCHAR64

CHAR(64)

VARYING;

DCL STMT1_STR

CHAR(200) VARYING;

EXEC SQL END DECLARE SECTION;

EXEC SQL PREPARE STMT1_NAME FROM :STMT1_STR;

EXEC SQL DECLARE DYN_CURSOR CURSOR FOR STMT1_NAME;

EXEC SQL OPEN DYN_CURSOR USING :HV_INT, :HV_VCHAR64;

Example 3

Code an OPEN statement as in example 2, but in this case the number and data

types of the parameter markers in the WHERE clause are not known.

EXEC SQL BEGIN DECLARE SECTION;

DCL STMT1_STR CHAR(200) VARYING;

EXEC SQL END DECLARE SECTION;

EXEC SQL INCLUDE SQLDA;

EXEC SQL PREPARE STMT1_NAME FROM :STMT1_STR;

EXEC SQL DECLARE DYN_CURSOR CURSOR FOR STMT1_NAME;

EXEC SQL OPEN DYN_CURSOR USING DESCRIPTOR :SQLDA;

Example 4

This example shows the SQL statements used with a cursor CURSOR3 in a PL/I

program. In this program, CURSOR3 inserts a row into the MA_ACT view (and

therefore into the EMP_ACT table, which is the base table for the view) based on

310

SQL Reference

Extended OPEN

The Extended OPEN statement opens a cursor declared using an Extended

DECLARE CURSOR statement for a previously prepared statement. The open

cursor retrieves the results of a query, or inserts values into the database.

Invocation

This statement can only be embedded in an application program written in

Assembler or REXX.

Authorization

The authorization ID of the statement must have one of the following:

v ownership of the package

v DBA authority

v EXECUTE privilege on the package.

Syntax

►► OPEN cursor_variable

►◄

USING DESCRIPTOR descriptor_name

Description

cursor_variable

Identifies the cursor that is to be opened. The cursor must have been defined

by a preceding Extended DECLARE CURSOR statement in the same logical

unit of work.

USING DESCRIPTOR descriptor_name

Identifies an input SQLDA structure that provides information concerning

input variables that were specified as parameter markers (?) when the

statement was prepared.

Before the Extended OPEN statement is processed, the user must set the fields

in the SQLDA described in the “Description” section of “EXECUTE” on page

264 and Table 20 on page 360.

When the cursor is to be used for inserting data into a table, the USING

DESCRIPTOR clause should not be included because the clause must be in the

PUT statement.

Notes

In most respects, the Extended OPEN statement is similar to the OPEN statement

(see “OPEN” on page 307). However, in the Extended OPEN statement, the

cursor_name is a host variable, thereby making it possible for a user to provide the

cursor name when the program is run and to open the cursor in a logical unit of

work or program other than the one in which the statement was prepared.

Extended DECLARE CURSOR and Extended OPEN must occur in the same logical

unit of work.

Examples

OPEN :CURSOR1 USING DESCRIPTOR MYSQLDA

312

SQL Reference

PREPARE

The PREPARE statement is used by application programs to dynamically prepare

an SQL statement for execution. The PREPARE statement creates an executable

SQL statement, called a prepared statement, from a character string form of the

statement, called a statement string. The prepared statement is a named object that

can be referred to only within the logical unit of work in which it is created.

Invocation

This statement can only be embedded in an application program. It is an

executable statement that cannot be dynamically prepared.

Authorization

The authorization rules are those defined for the SQL statement specified by the

PREPARE statement. For example, see Chapter 5, “Queries,” on page 121 for the

authorization rules that apply when a select-statement is prepared. The

authorization ID is the run-time authorization ID.

Syntax

►► PREPARE statement_name FROM

string_constant

►◄

host_variable

Description

statement_name

Provides a name for the prepared statement. No two prepared statements in a

single source program may use the same statement name. In REXX, the

statement_name must not be the same as the cursor_name declared in the

program.

FROM

Introduces the statement string. The statement string is the value of the

specified string_constant or the identified host_variable.

string_constant

String constants are supported in all languages except Assembler and C.

You should avoid using either delimited identifiers or DBCS strings in

statements specified in string constants because results are unpredictable.

When the string_constant form of the PREPARE statement is used in

Fortran programs:

v If the statement_name is referenced in a DECLARE CURSOR statement,

the PREPARE statement must come first.

v Any unqualified objects are qualified with the authorization ID of the

person preparing the program.

host_variable

Identifies a host variable that is described in the program in accordance

with the rules for declaring character string variables. An indicator variable

must not be specified.

In Assembler, C, COBOL, and REXX, the host variable must be a

varying-length string variable. In C, it cannot be a NUL-terminated string.

In Fortran, the host variable must be a fixed-length string variable. In PL/I,

Chapter 6. Statements

313

PREPARE

the host variable can either be a fixed-length or varying-length string

variable. The host variable must have a maximum length of 8192.

In a PL/I Version 2 program, a prepared statement containing DBCS

characters must be coded as a mixed string using the new PL/I Mixed

format.

For example:

DYNSTR = ’SELECT COL1 FROM TABLE WHERE COL2 = G’<

>’M;

EXEC SQL PREPARE STMT1 FROM :DYNSTR;

Rules for statement strings

The string_constant or host_variable must contain one of the following SQL

statements:

ACQUIRE DBSPACE

GRANT Package Privileges

ALLOCATE CURSOR

GRANT System Authorities

ALTER DBSPACE

GRANT Table Privileges

ALTER TABLE

INSERT

ASSOCIATE LOCATORS

LABEL ON

COMMENT ON

LOCK DBSPACE

CREATE INDEX

LOCK TABLE

CREATE SYNONYM

REVOKE Package Privileges

CREATE TABLE

REVOKE System Authorities

CREATE VIEW

REVOKE Table Privileges

DELETE

select-statement

DROP

UPDATE

EXPLAIN

UPDATE STATISTICS

Furthermore, the statement string must not:

v Begin with EXEC SQL and end with a statement terminator

v Include references to host variables

v Include comments.

Parameter markers: Although a statement string cannot include references to host

variables, it may include parameter markers; those can be replaced by the values of

host variables when the prepared statement is processed. A parameter marker is a

question mark (?) that is used where a host variable could be used if the statement

string were a static SQL statement. For an explanation of how parameter markers

are replaced by values, see “OPEN” on page 307 and “EXECUTE” on page 264.

Rules for parameter markers:

v Parameter markers must not be used:

- In a select list (SELECT ? is incorrect)

- As an operand of the concatenation operator

- As both operands of a single arithmetic or comparison operator (WHERE ? =

? is incorrect)

- As an operand in a datetime arithmetic expression

v At least one of the operands of the BETWEEN or IN predicates must not be a

parameter marker.

v An argument of a scalar function cannot be specified solely as a parameter

marker. For example, VALUE(COL1, COL2, ?) is not valid.

v If a scalar function is used in other than a SELECT list, and it has an argument

that can be specified as an arithmetic expression, a parameter marker can be

included in that expression, provided that it is the operand of an arithmetic

operator and that the other operand is a number.

314

SQL Reference

PREPARE

Notes

When a PREPARE statement is processed, the statement string is parsed and

checked for errors. If the statement string is incorrect, a prepared statement is not

created and the error condition that prevents its creation is reported in the SQLCA.

Prepared statements can be referred to in the following kinds of statements, with

the following restrictions shown:

In ...

The prepared statement ...

DESCRIBE

has no restrictions

DECLARE CURSOR

must be a select-statement or an insert-statement

EXECUTE

must not be a select-statement

A prepared statement can be processed many times. Indeed, if a prepared

statement is not processed more than once and does not contain parameter

markers, it is more efficient to use the EXECUTE IMMEDIATE statement rather

than the PREPARE and EXECUTE statements.

All prepared statements created in a logical unit of work are destroyed when the

logical unit of work is terminated.

Examples

Example 1

Prepare and process a non-select-statement in a COBOL program. Assume the

statement is contained in a host variable HOLDER and that the program will place

a statement string into the host variable based on some instructions from the user.

The statement to be prepared does not have any parameter markers.

EXEC SQL PREPARE STMT_NAME FROM :HOLDER END-EXEC.

EXEC SQL EXECUTE STMT_NAME END-EXEC.

Example 2

Prepare and process a non-select-statement as in example 1, except code it for a

PL/I program. Also assume the statement to be prepared can contain any number

of parameter markers.

EXEC SQL PREPARE STMT_NAME FROM :HOLDER;

EXEC SQL EXECUTE STMT_NAME USING DESCRIPTOR :INSERT_DA;

Assume that the following statement is to be prepared:

INSERT INTO DEPARTMENT VALUES(?, ?, ?, ?)

To insert department number G01 named COMPLAINTS, which has no manager

and reports to department A00, the structure INSERT_DA should have the

following values before running the EXECUTE statement.

Chapter 6. Statements

315

DB2 Server for VSE & VM SQL Reference (Version 7 Release 5) - page 8
