DB2 Server for VSE & VM SQL Reference (Version 7 Release 5)

CONNECT (for VSE)

If a CONNECT TO server_name is processed first, the server name is placed in the

CURRENT SERVER register. Also, the SQLERRMC field in the SQLCA is set with

eight blanks and the server_name separated by X'FF'. However, a CONNECT

authorization_name IDENTIFIED BY password must be processed to complete the

connection and establish the user identification before any other SQL statements

are processed.

If the TO clause is not specified, the application is connected to the default

application server. The server_name must be one that exists in the DBNAME

directory. If it is a remote server, it must be identitified as using TCP/IP

communication. Otherwise, an SQL error will be returned to the batch application.

TCP/IP does not perform any security checking during a physical connect. The

Batch application requester will use the DRDA security handshaking flows during

the logical connect to perform user ID and password verification. The physical

TCP/IP connection will be deallocated and reallocated whenever the application

switches to a different user ID or server name (using the CONNECT statement),

and DRDA security handshaking flows will be used again during the logical

connect. Either of these switches will not require the application to issue a

COMMIT RELEASE or ROLLBACK RELEASE. The Batch Resource Adapter will

retain and use the current user ID, password, and server name (unless different

ones are specified with a new CONNECT statement) after the new TCP/IP

physical connection is established. If a COMMIT RELEASE or ROLLBACK

RELEASE was issued prior to a CONNECT statement, then all user ID, password

and server name information is lost and must be supplied with the next

CONNECT.

If a Logical Unit of Work is ended by a COMMIT, and a CONNECT TO server_name is

the next SQL statement processed, a new connection is made to the application

server specified, with the user ID and password being the same as in the previous

connection.

If a Logical Unit of Work is ended with a COMMIT RELEASE, the next SQL statement

must be either:

v CONNECT userid IDENTIFIED BY pw or

v CONNECT userid IDENTIFIED BY pw TO server_name

to re-establish the proper user ID.

Summary of Variations of the CONNECT Statement

The various clauses may be specified in the following combinations:

1. CONNECT

This returns information about the currently connected authorization ID and

application server.

2. CONNECT authorization_name IDENTIFIED BY password

This switches to a new authorization ID on the currently established

application server.

3. CONNECT TO server_name

This switches the currently established authorization ID to a new application

server.

4. CONNECT authorization_name IDENTIFIED BY password TO server_name

This switches to both a new authorization ID and application server.

194

SQL Reference

CONNECT (for VSE)

Connection States

An application process is in one of three states at any time:

v Connectable and connected

v Unconnectable and connected

v Connectable and unconnected.

The connectable and connected state: An application process is connected to an

application server and CONNECT statements can be processed. The process enters

this state when it completes a rollback or successful commit from the

unconnectable and connected state, or a CONNECT statement is successfully

processed from the connectable and unconnected state.

The unconnectable and connected state: An application process is connected to

an application server, but a CONNECT statement cannot be successfully processed

to change application servers or to change authorization IDs. The process enters

this state from the connectable and connected state when it processes any SQL

statement other than CONNECT, COMMIT or ROLLBACK.

The connectable and unconnected state: An application process is not connected

to an application server. The only SQL statement that can be processed is

CONNECT. The process is initially in this state or enters this state when an SQL

statement is unsuccessful because of a failure that causes a rollback operation at

the application server and the loss of the connection. The process can also enter

this state if it successfully completes a commit or rollback with the release option

from the unconnectable and connected state or it processes a CONNECT statement

unsuccessfully.

The following diagram shows the state transitions:

CONNECT withsystemfailure

Connectable

and

Successful CONNECT

Unconnected

Connected

ROLLBACKor

SQLother than

CONNECT,COMMIT,

successful

COMMITwith

or ROLLBACK

Systemfailure

RELEASE

withrollback

anddeallocate

Unconnectable

and

Connected

ROLLBACKor

successful COMMIT

Figure 8. VSE Connection State Transitions

Chapter 6. Statements

195

CONNECT (for VSE)

Additional Rules

It is not an error to process consecutive CONNECT statements because CONNECT

itself does not remove the application process from the connectable state. It is an

error to process any SQL statement other than CONNECT, COMMIT, or

ROLLBACK, and then process CONNECT with any options. To avoid the error,

process a commit or rollback operation before processing the CONNECT.

Notes

If a program is connectable and connected, a CONNECT TO server_name results in the

old connection being disconnected before the new connection is attempted. If the

new connection fails, the program’s state is connectable and unconnected.

A CONNECT to the same application server without changing the authorization

ID is treated as a no-operation; the connection is not disconnected and

reconnected.

Examples

Example 1

In a PL/I program, connect to the application server TOROLAB3.

EXEC SQL CONNECT TO TOROLAB3;

Example 2

In a PL/I program, switch to a different application server called TOROLAB4.

Assume your user ID on TOROLAB4 is different than the one you are currently

using.

EXEC SQL BEGIN DECLARE SECTION;

DCL USERID

CHAR(8);

DCL PASWRD

CHAR(8);

EXEC SQL END DECLARE SECTION;

EXEC SQL CONNECT :USERID IDENTIFIED BY :PASWRD

TO TOROLAB4;

Example 3

In a PL/I program, connect to an application server whose name is stored in the

host variable APP_SERVER (varchar(18)).

EXEC SQL CONNECT TO :APP_SERVER;

Resolving Remote Server Name to Target Database

CICS Applications: If the CICS/VSE transaction issues an SQL CONNECT

statement with the ″TO server name″ clause, the server name is established

explicitly for the transaction and the Online Resource Adapter uses the DBNAME

Directory to resolve the server name to the target database.

If the CICS/VSE transaction did not issue an SQL CONNECT statement with

the“TO server name” clause, the Online Resource Adapter attempts to connect to

the default application server, as defined in the DBNAME Directory.

If the target database is a Remote server and the communications protocol to be

used is SNA, the application requester issues a GDS ALLOCATE command to

acquire a session for the remote system where the server runs. The SYSID used in

this ALLOCATE command is the SYSID value from the DBNAME Directory entry

(and the SYSID must match a CEDA DEF CONNECTION definition). Then the

196

SQL Reference

CONNECT (for VSE)

application requester issues a GDS CONNECT PROCESS command to initiate an

APPC basic conversation with the Remote server. The PROCNAME used by this

CONNECT PROCESS command is the REMTPN value from the DBNAME

Directory entry.

If the target database is a Remote server and the communications protocol to be

used is TCP/IP, the application requester issues a CONNECT to the TCP/IP

listener port number that is specified by the TCPPORT value from the DBNAME

Directory entry. The target database is identified by the IPADDR or TCPHOST

values from the DBNAME Directory entry.

If the target database is a Local or Host VM (guest sharing) server, normal

communications occurs using XPCC.

The default application server is determined when the CIRB transaction is invoked

and can be changed subsequently by a CIRC transaction. For more information on

establishing a default application server, see DB2 Server for VSE & VM Database

Administration.

Batch Applications: Batch applications access the Remote server in the same way

as CICS Transactions, but SNA communications protocol is not supported, only

TCP/IP. In addition, the Batch application must issue an SQL CONNECT

statement as the first SQL statement because an implicit connect is not allowed for

Batch applications.

Communications Protocols for Remote Server Access: The communications

method used to access a Remote server by CICS applications is specified by the

Communications Protocol setting in the SQLGLOB file, which can be either SNA or

TCP/IP. The remote server to be accessed must be connected by the desired

protocol. The default protocol in the SQLGLOB Default User entry is SNA, but this

can be changed. The protocol option can be specified for each user ID in the

SQLGLOB file. For more information about the SQLGLOB file, see DB2 Server for

VSE & VM Database Administration.

The communications method used to access a remote server by Batch applications

can only be TCP/IP; SNA is not supported for Batch applications.

If a server is identified in the DBNAME Directory as a Remote server, it must

contain information that identifies which communications protocols can be used to

access the Remote server. Either SNA or TCP/IP information (or both) can be

specified in the DBNAME Directory. For more information about the DBNAME

Directory, see DB2 Server for VSE & VM Database Administration.

Chapter 6. Statements

197

CREATE INDEX

The CREATE INDEX statement creates an index on a table.

Invocation

This statement can be embedded in an application program or issued interactively.

It is an executable statement that can be dynamically prepared.

Authorization

The privileges held by the authorization ID of the statement must include at least

one of the following:

v Ownership of the table

v The INDEX privilege for the table

v DBA authority.

If the index name includes a qualifier that is not the same as the authorization ID

of the statement, the privileges held by the authorization ID of the statement must

include DBA authority.

Syntax

►► CREATE

INDEX index_name

►◄

UNIQUE

ASC

▼

►► ON table_name

(

column_name

)

►◄

DESC

PCTFREE = 10

►►

►◄

PCTFREE = integer

Description

UNIQUE

Prevents the table from containing two or more rows with the same value of

the index key. The constraint is enforced when rows of the table are updated

or new rows are inserted.

The constraint is also checked during the execution of the CREATE INDEX

statement. If the table already contains rows with duplicate key values, the

index is not created.

When UNIQUE is used, null values are treated as any other values. For

example, if the key is a single column that can contain null values, that column

can contain no more than one null value. Unique indexes will not allow values

which differ only by the number of trailing blanks.

INDEX index_name

Provides a name for the index. The name, including the implicit or explicit

qualifier, must not identify an index that already exists at the application

server.

198

SQL Reference

CREATE INDEX

If the index name is qualified, the qualifier is the owner of the index.

Otherwise, the authorization ID of the statement is the owner of the index. The

owner has the privilege of dropping the index.

ON table_name

Identifies the table on which you want the index to be created. The table_name

must be the name of a base table (not a view) that exists at the application

server. The indicated table may be empty.

(column_name,...)

Identifies a column that is to be part of the index key.

Each column_name must be an unqualified name that identifies a column of the

table. Up to 16 unique columns may be specified. Indexes cannot be created for

views or for columns containing long strings.

ASC

Puts the index entries in ascending order by the column. This is the

default.

DESC

Puts the index entries in descending order by the column.

PCTFREE

Controls the amount of free space reserved in an index for later insertions and

updates. PCTFREE defines the percentage (integer) of the total space of the

index that is to be reserved for this purpose. PCTFREE may range from 0 to

99, but for practical purposes should not exceed 50. Increasing PCTFREE

causes the index to take more space in the database, but reduces the time

required to insert or update rows in the indexed table. If you do not include a

PCTFREE clause on the CREATE INDEX statement, the database manager sets

PCTFREE to 10.

Notes

If the named table already contains data, CREATE INDEX creates the index entries

for it. If the table does not yet contain data, CREATE INDEX creates a description

of the index; the index entries are created when data is inserted into the table.

The sum of the length attributes of the indexed columns, plus approximately 25%

of the length attributes of any indexed columns of varying-length character type,

must not exceed 255 bytes. If you are creating the index after data has been loaded

into the table, a sort is invoked during the preprocessing of the CREATE INDEX

command. If duplicate keys are allowed in the index, then the sort will require 4

bytes to be added to the encoded key. These four bytes are part of the 255 total

bytes.

At preprocessing time, the database manager optimizer chooses which index, if

any, is to be used in processing a given query or data manipulation statement. The

index provides a fast means to access the table directly by the indexed columns.

However, there is a slight increase in the time required to update the indexed

columns because the database manager must also update the index. It is good

practice to create indexes before preprocessing programs that might take advantage

of them. When you create a new index, existing packages are not marked incorrect

because they can still use their original access path. However, an existing program

may run more efficiently by taking advantage of the new index. If this is the case,

you should preprocess the program again. A new package is then created for the

program, possibly using the new index.

Chapter 6. Statements

199

CREATE INDEX

An index is maintained by the database manager until it is explicitly dropped

using a DROP INDEX statement, or until its table or dbspace is dropped.

Recovery of a CREATE INDEX statement could result in the index being marked

as invalid. The database manager will end if an attempt is made to mark an index

as not valid if the system limit of not valid indexes has been reached. The database

manager will not allow a CREATE INDEX statement to proceed if the number of

currently not valid indexes plus the number of potentially not valid indexes

(currently executing CREATE INDEX statements plus DBSU REORGANIZE INDEX

commands) has reached the limit.

If doing many updates to an indexed column or inserting many rows into an

indexed table (as the Database Services utility does), it is often best to drop the

index before doing the updates and then re-create it after the updates are complete.

Because the index is not being updated while the table is being updated, this can

be a significant performance improvement.

For information on how to calculate the length of an encoded key refer to the DB2

Server for VSE & VM Database Administration manual.

Examples

Example 1

Create an index named UNIQUE_NAM on the PROJECT table. The purpose of the

index is to ensure that there are not two entries in the table with the same value

for project name (PROJNAME). The index entries are to be in ascending order.

CREATE UNIQUE INDEX UNIQUE_NAM

ON PROJECT(PROJNAME)

See example 4 in ALTER TABLE for an alternate method of ensuring unique

project names.

Example 2: Create an index named JOB_BY_DEPT on the EMPLOYEE table.

Arrange the index entries in ascending order by job title (JOB) within each

department (WORKDEPT). Leave 33 percent of the space in the index free for later

insertions.

CREATE INDEX JOB_BY_DEPT

ON EMPLOYEE (WORKDEPT, JOB)

PCTFREE = 33

200

SQL Reference

CREATE PACKAGE

The CREATE PACKAGE statement creates a package.

Invocation

This statement can only be embedded in an application program written in

Assembler or REXX.

Authorization

None required. However, a DBA authority is required to create a package that is to

be owned by someone else.

Syntax

(1)

►►

CREATE PACKAGE

package_spec

►◄

(2)

▼

USING OPTIONs

option

host_variable

Notes:

PROGRAM is equivalent to PACKAGE, and is provided for compatibility with some

older versions of the SQL/DS product.

An option may be specified only once.

Description

package_spec

Provides a name for the package.

If the package_spec is identical to the name of an existing package and the

REPLACE option is specified, the existing package is implicitly dropped and

replaced with a new package.

USING OPTIONs option

USING OPTIONs host_variable

The options are as follows:

CCSIDSbcs (integer)

This option specifies the default CCSID to be used if a character column of

subtype SBCS is defined by a CREATE or ALTER TABLE statement in this

package without an explicit CCSID being specified for the column. If this

option is not specified, the target application server will use its system

default.

This option can only be used when connected to a DB2 Server for VM or

DB2 Server for VSE application server.

CCSIDMixed (integer)

This option specifies the default CCSID to be used if a character column of

subtype mixed is defined by a CREATE or ALTER TABLE statement in this

package without an explicit CCSID being specified for the column. If this

option is not specified, the target application server will use its system

default.

Chapter 6. Statements

201

CREATE PACKAGE

This option can only be used when connected to a DB2 Server for VM or

DB2 Server for VSE application server.

CCSIDGraphic (integer)

This option specifies the default CCSID to be used if a graphic column is

defined by a CREATE or ALTER TABLE statement in this package without

an explicit CCSID being specified for the column. If this option is not

specified, the target application server will use its system default.

This option can only be used when connected to a DB2 Server for VM or

DB2 Server for VSE application server.

CHARSUB Sbcs

CHARSUB Mixed

CHARSUB Bit

This option specifies the default character subtype to be used if a character

column is defined by a CREATE or ALTER TABLE statement in this

package without an explicit subtype or CCSID being specified. If this

option is not specified, the target application server will use its system

default.

This option can only be used when connected to a DB2 Server for VM or

DB2 Server for VSE application server.

DATE ISO

DATE USA

DATE EUR

DATE JIS

DATE LOCAL

This option specifies which output date format will be used by the SQL

statements. If the DATE option is not specified, the format specified at

installation time is used. If LOCAL is implicitly or explicitly specified, a

DATE installation exit must be installed.

If using DRDA protocol, ISO is the default format.

The DATE LOCAL option is not supported for non-modifiable packages

created by using extended dynamic statements with DRDA protocol. If

specified, an error will occur indicating an incorrect parameter.

EXPLAIN NO

EXPLAIN YES

This option, if set to YES, specifies whether explanatory information for all

explainable SQL statements in a package should be produced. NO is the

default.

ISOLation RR

ISOLation CS

ISOLation USER

ISOLation RS

ISOLation UR

This option specifies the isolation level for the package. The DB2 Server for

VSE & VM database manager supports RR, CS, UR, and USER. For a

description of isolation levels, see “Isolation Level” on page 20. For

information on USER, see the section on preprocessing and running a

program in the DB2 Server for VSE & VM Application Programming manual.

RR is the default.

202

SQL Reference

CREATE PACKAGE

In a VM environment, RS is not directly supported by the application

server. In a VSE environment, RS is not supported at all. In both VM and

VSE, isolation level RS is upgraded to level RR. (See the IBM SQL Reference

manual for details on RS.)

The ISOLATION USER option is not supported for non-modifiable

packages created by using extended dynamic statements with DRDA

protocol. If specified, USER will be overridden with CS.

KEEP

REVOKE

This option applies if the package has previously been created and the

owner of the package has granted the EXECUTE privilege on the resulting

package to other users.

KEEP causes these grants of the EXECUTE privilege to remain in effect

when the new package is created. KEEP is the default.

If the REVOKE option is specified, or if the owner of the package is not

entitled to grant all privileges embodied in the program, the preprocessor

revokes all existing grants of the EXECUTE privilege.

LABEL (label_text)

This option specifies a label for the package. Label_text can be, at most, 30

characters in length. If specified, label_text is stored in column PLABEL in

the SYSTEM.SYSACCESS catalog table; the default is 30 spaces.

NOBLocK

BLocK

SBLocK

This option specifies if rows should be inserted and retrieved in groups.

If the BLocK option is specified, all eligible query cursors return results in

groups of rows. All eligible insert cursors process inserts in groups of rows.

If NOBLocK is specified, rows are not grouped.

SBLocK is primarily for use with application servers that support the FOR

FETCH ONLY clause on the DECLARE CURSOR statement. When SBLock

is specified, all eligible cursors return results in group of rows. This is the

default.

NOCHECK

CHECK

ERROR

This option specifies what action to take when an SQL statement is

prepared into the package and checked for validity. For all options, if a

statement fails its validity check, an appropriate SQLCODE and SQLSTATE

is returned in the SQLCA.

v If NOCHECK is specified and any SQL statement fails its validity check,

the package will not be created. This is the default.

v If CHECK is specified, the package is not created, even if all SQL

statements pass their validity check.

v If ERROR is specified, the package is created even if any SQL statement

fails its validity check. The subsequent execution of a not valid statement

results in a -525 SQLCODE, SQLSTATE 51015. Note that for a modifiable

package, ERROR and EXIST may not be specified together.

NODESCRIBE

Chapter 6. Statements

203

CREATE PACKAGE

DESCRIBE

This option allows the use of the Extended DESCRIBE for statements

added to the created package.

If DESCRIBE is specified, Extended DESCRIBE statements can be

processed.

If NODESCRIBE is specified, these Extended DESCRIBE statements cannot

be processed. This is the default. NODESCRIBE is not supported with

DRDA protocol and will be changed to DESCRIBE.

NOEXIST

EXIST

This option specifies the action to be taken when objects referenced in a

program are checked for existence and their access authorizations are

checked.

If NOEXIST is specified, a warning is returned to the program if object and

authorization existence is not found. This will not affect the creation of the

package (for instance, if NOCHECK is in effect and everything else is

valid, then the package will be created). NOEXIST is the default.

If EXIST is specified, an error is returned to the program if an object does

not exist or if the authorization ID of an Extended PREPARE statement

does not have the appropriate privileges on an object. In such a case, the

package is not created, even if ERROR is specified. For modifiable

packages, ERROR and EXIST may not be specified together.

NOMODIFY

MODIFY

This option specifies whether the created package can be modified after it

is stored through a COMMIT. Sections are added to the package by using

the Extended PREPARE and deleted by using the DROP STATEMENT

function.

Sections in packages created with the MODIFY option can also be

processed or dropped before committing the logical unit of work in which

they were prepared.

The MODIFY option should not be used if the entire package will be

replaced using the REPLACE option. Once a package has been created

with the MODIFY option specified, it can be changed but not replaced by

subsequent CREATE PACKAGE statements. To replace a package created

with the MODIFY option, it is necessary to enter a DROP PACKAGE

statement and then enter a CREATE PACKAGE.

NOMODIFY is supported with DRDA protocol; however, there are some

restrictions (see Appendix G, “DRDA Considerations,” on page 425).

MODIFY is not supported with DRDA protocol and will be changed to

NOMODIFY. NOMODIFY is the default.

OWner (authorization_name)

This option specifies the owner of the package being created. If this option

is not specified, the binder’s authorization ID at the application server is

used.

For DB2 Server for VSE & VM application servers, the authorization_name

must be the same as the binder’s authorization ID at the application server.

QUALifier (collection_id)

This option specifies the default collection_id to be used within the package

204

SQL Reference

CREATE PACKAGE

to resolve unqualified object names. If this option is not specified, the

binder’s authorization ID at the application server is used.

For DB2 Server for VSE & VM application servers, the collection-id must be

the same as the binder’s authorization ID at the application server.

RELease COMMIT

RELease DEALLOCATE

This option specifies when the application server should release the

package execution resources and any associated locks.

If COMMIT is specified, the resources are released when a logical unit of

work (LUW) is committed or rolled back. This is the default.

If DEALLOCATE is specified, the resources are released when the

application process terminates.

For DB2 Server for VSE & VM application servers, the only acceptable

option is RELEASE(COMMIT).

REPLACE

NEW

This option specifies whether the package being created is new or whether

it will replace an existing package that has the same name. REPLACE is

the default.

If NEW is specified, an error results if a package already exists with the

same name.

If REPLACE is specified and no previous package exists with the same

name, no error or warning is given. If NEW is specified along with KEEP

or REVOKE, an error results.

Chapter 6. Statements

205

CREATE PACKAGE

TIME ISO

TIME USA

TIME EUR

TIME JIS

TIME LOCAL

This option specifies which output time format will be used by the SQL

statements. If the TIME option is not specified, the format specified at

installation time is used. If LOCAL is implicitly or explicitly specified, a

TIME installation exit must be installed.

If using DRDA protocol, ISO is the default format.

The TIME LOCAL option is not supported for non-modifiable packages

created by using extended dynamic statements with DRDA protocol. If

specified, an error will occur indicating an incorrect parameter.

host_variable

Contains a list of options, delimited by a comma or blank. This host variable

must be declared as VARCHAR and has a maximum length of 8192.

Notes

The package is stored in the database when a COMMIT is issued.

When the logical unit of work, in which the CREATE PACKAGE statement is

entered, is committed (using COMMIT), a new package is created. ROLLBACK

prevents the storage of the new package. A package created with the MODIFY

option can be committed even if it contains no statements. Only one package may

be created or modified within a logical unit of work.

Before SQL/DS Version 3 Release 1, the values for the ISOLATION, DATE, and

TIME bind options were derived from the corresponding options with which the

application was preprocessed. With SQL/DS Version 3 Release 1, these options

became pure bind options, meaning that their values are to be based only on their

specification in the CREATE PACKAGE statement. This change will only take

effect after the application issuing the CREATE PACKAGE statement has been

repreprocessed, reassembled, and relinked.

Note: For DB2 Server for VSE, if a combination of the NOBIND, BIND, or the

PACKAGE, NOPACKAGE or the CHECK, NOCHECK and ERROR was

specified, the preprocessor will generate an error message. For example, if

PACKAGE, NOPACKAGE, NOBIND, BIND were all specified, the

preprocessor will display the following error messages:

ARI0583E - Keywords PACKAGE and NOPACKAGE were both found.

- Specify only one.

ARI0583E - Keywords NOBIND and BIND were both found.

- Specify only one.

ARI0586I - Preprocessing ended with 2 errors and

- 0 warnings.

For DB2 Server for VSE, if NOBIND, NOCHECK and NOPACKAGE are all

specified, no action would be taken for this preprocessing. This is

considered an error and the following error messages will be displayed:

ARI5411E - Keywords NOBIND, NOCHECK and NOPACKAGE are

- specified. No preprocess will be done for this

- operation.

ARI0586I - Preprocessing ended with 1 errors and

- 0 warnings.

206

SQL Reference

CREATE PACKAGE

The restriction for non-modifiable packages created by using extended dynamic

statements with DRDA protocol are as follows:

v Only one CREATE PACKAGE statement is permitted in a logical unit of work.

v After a CREATE PACKAGE with the NOMODIFY option has been issued, only

Extended PREPARE SQL statements can follow in the same logical unit of work.

The following statements are the only ones valid in a package created using

CREATE PACKAGE:

- Extended DECLARE CURSOR

- Extended DROP STATEMENT

- Extended OPEN, FETCH, PUT, and CLOSE

- Extended EXECUTE

- Extended DESCRIBE

v After the unit of work containing the CREATE PACKAGE has completed, an

Extended PREPARE or DROP STATEMENT cannot be used to change the

package that was created with the CREATE PACKAGE statement.

Examples

CREATE PACKAGE JERRY.MUSICIANS USING OPTIONS DESCRIBE NEW BLOCK

Chapter 6. Statements

207

CREATE PROCEDURE

The CREATE PROCEDURE statement inserts the definition of a stored procedure

and the parameters it requires into SYSTEM.SYSROUTINES and

SYSTEM.SYSPARMS, and into the cache.

Invocation

This statement can be issued from an application program or interactively. It is an

executable statement that can be dynamically prepared. The PSERVER GROUP in

which the procedure will run must exist (there must be at least one PSERVER

defined in that group), before the procedure can be defined.

Authorization

The issuer of the CREATE PROCEDURE must have DBA authority.

Syntax

►► CREATE PROCEDURE procedure-name

(

)

►

AUTHID authid

parameters

208

SQL Reference

CREATE PROCEDURE

(1)

FENCED

(8)

▼

►

►◄

LANGUAGE ASSEMBLE

COBOL

PLI

EXTERNAL

NAME external-program-name

SERVER GROUP

server-group-name

DEFAULT SERVER GROUP YES

DEFAULT SERVER GROUP NO

PARAMETER STYLE

(3)

GENERAL WITH NULLS

(2)

GENERAL

STAY RESIDENT NO

STAY RESIDENT YES

PROGRAM TYPE MAIN

(4)

PROGRAM TYPE SUB

RUN OPTIONS run-time-options

RESULT SET 0

RESULT SET

integer

SETS

COMMIT ON RETURN NO

COMMIT ON RETURN YES

(5)

NOT DETERMINISTIC

(6)

DETERMINISTIC

(7)

CONTAINS SQL

(7)

NO SQL

(7)

READS SQL DATA

(7)

MODIFIES SQL DATA

(7)

NO COLLID

(7)

COLLID collection-id

(7)

WLM ENVIRONMENT

name

(name,*)

(7)

NO WLM ENVIRONMENT

(7)

ASUTIME NO LIMIT

(7)

ASUTIME LIMIT integer

(7)

EXTERNAL SECURITY DB2

(7)

EXTERNAL SECURITY

USER

DEFINER

(7)

NO DBINFO

(7)

DBINFO

Chapter 6. Statements

209

CREATE PROCEDURE

Notes:

This parameter is included for compatibility with the DB2 family. If specified,

it is ignored.

As an alternative to GENERAL, SIMPLE CALL may be used. This is for

compatibility within the DB2 family.

As an alternative to GENERAL WITH NULLS, SIMPLE CALL WITH NULLS

may be used. This is for compatibility within the DB2 family.

Currently, DB2 Server for VSE & VM supports stored procedures written as

main programs only.

VARIANT may be specified as an alternative to NOT DETERMINISTIC. This

is for compatibility within the DB2 family.

NOT VARIANT may be specified as an alternative to DETERMINISTIC. This

is for compatibility within the DB2 family.

This parameter is included for compatibility with the DB2 family. If specified,

it is ignored.

One or more clauses may be specified, however each clause may be specified

at most once.

Description

Only the parameters that are meaningful to DB2 Server for VSE & VM are

described.

procedure-name

Names the stored procedure. For DB2 Server for VSE & VM, the name must be

an ordinary identifier of 18 characters or less. The name must not identify a

stored procedure that already exists on the server. In addition, the name cannot

be ’AUTHID’ or ’ACTION’.

authid

The authorization ID for the stored procedure. authid must be an ordinary

identifier of 8 characters or less. If specified, then the stored procedure being

defined will be accessible only by authid. Note that authid cannot be ’AUTHID’

or ’ACTION’.

LANGUAGE

Specifies the programming language used to create the stored procedure. All

stored procedure programs must be designed to run in the IBM Language

Environment.

ASSEMBLE

Specifies that the stored procedure is written in Assembler.

Specifies that the stored procedure is written in C.

COBOL

Specifies that the stored procedure is written in COBOL.

PLI

Specifies that the stored procedure is written in PLI.

Note that the LANGUAGE clause must be specified on the CREATE

PROCEDURE statement.

EXTERNAL NAME external-program-name

Identifies the load module or phase associated with the stored procedure. The

load module or phase does not need to exist when the CREATE PROCEDURE

210

SQL Reference

CREATE PROCEDURE

statement is issued. However, when a CALL for the stored procedure is issued,

the load module must exist and be accessible to the stored procedure server.

If external-program-name is not specified, the name of the load module or phase

is assumed to be the same as the name of the stored procedure. In this case,

the name of the stored procedure must be 8 characters or less. Note that the

EXTERNAL clause must be specified on the CREATE PROCEDURE statement.

SERVER GROUP server-group-name

Identifies the name of the group of servers to be used to run this stored

procedure. Server-group-name must be an ordinary identifier of 18 characters

or less, and must be defined in SYSTEM.SYSPSERVERS.

If SERVER GROUP is specified without server-group-name, the stored procedure

must be able to run in the default server group. At least one server must exist

in the specified group. Note that the SERVER GROUP clause must be specified

on the CREATE PROCEDURE statement.

DEFAULT SERVER GROUP

Specifies whether the stored procedure can run in the default server group.

YES The stored procedure can run in the default server group. This is the

default.

NO The stored procedure cannot run in the default server group. If NO is

specified, a server-group-name must be provided on the SERVER

GROUP clause.

PARAMETER STYLE

Identifies the linkage convention used to pass parameters to the stored

procedure. All of the linkage conventions provide arguments to the stored

procedure containing the parameters specified on the SQL CALL statement. See

the DB2 Server for VSE & VM Database Administration manual for more

information. The following parameter styles options are valid for DB2 Server

for VSE & VM:

GENERAL

If the GENERAL linkage convention is used:

v the SQL CALL statement must provide a parameter for each

parameter expected by the stored procedure

v input parameters cannot be null

v nulls can be passed for output parameters only

v the stored procedure cannot return nulls for output parameters

Note that DB2 Server for VSE & VM does not support the parameter

style DB2SQL.

GENERAL WITH NULLS

If the GENERAL WITH NULLS linkage convention is used:

v the SQL CALL statement must provide a parameter for each

parameter expected by the stored procedure. When the database

manager invokes the stored procedure, it sends it the parameters

specified on the SQL CALL statement, as well as an array of

indicator variables (with one indicator variable for each parameter).

The stored procedure must contain a declaration for this array.

v input parameters can be null. This is achieved through the use of

indicator variables, or by specifying the keyword null.

v the stored procedure can return nulls for output parameters, by

using indicator variables.

Chapter 6. Statements

211

CREATE PROCEDURE

STAY RESIDENT

Specifies whether the stored procedure load module or phase remains loaded

in memory after the stored procedure ends. Possible values are:

NO The load module or phase is deleted from memory after the stored

procedure ends. This is the default.

YES The load module or phase remains loaded in memory after the stored

procedure ends.

PROGRAM TYPE

Specifies whether the stored procedure runs as a MAIN routine or as a SUB

routine. Currently, DB2 Server for VSE & VM supports stored procedures

written as MAIN routines only.

RUN OPTIONS

Specifies the Language Environment run-time options to be passed to the

stored procedure. The options must be specified as a character string up to 254

bytes and must be enclosed in single quotation marks. If this option is not

specified, or an empty string is passed, then DB2 Server for VSE & VM passes

no run-time options to the Language Environment, and Language Environment

uses its installation defaults. Note that DB2 Server for VSE & VM does not do

any checking of the options provided. For a complete description of Language

Environment run-time options, see Language Environment for MVS & VM

Programming Reference.

RESULT SETS or RESULT SET

Specifies the maximum number of query result sets that can be returned by

this stored procedure. The default is RESULT SETS 0, indicating that there are

no result sets. The largest value that can be specified is 32767.

COMMIT ON RETURN

Indicates whether the transaction should be committed immediately upon

return from the stored procedure.

NO The database manager should not issue COMMIT when the stored

procedure returns. This is the default.

YES The database manager should issue COMMIT when the stored

procedure returns when the following statements are true:

v The SQLCODE returned by the CALL statement is not negative

v The stored procedure is not in a must abort state

The COMMIT operation includes the work performed by the calling

application as well as the stored procedure. Any cursors that are open

when the COMMIT occurs will be closed during COMMIT processing.

212

SQL Reference

CREATE PROCEDURE

Parameters

parameters:

▼

data-type

OUT

parameter-name

(1)

INOUT

AS LOCATOR

data-type:

INT

INTEGER

SMALLINT

REAL

FLOAT

DOUBLE

DOUBLE PRECISION

DECIMAL

DEC

( integer

)

,integer

CHARACTER

CHAR

(integer)

FOR

SBCS

DATA

MIXED

BIT

VARCHAR(integer)

FOR

SBCS

DATA

MIXED

BIT

GRAPHIC(integer)

VARGRAPHIC(integer)

Notes:

This parameter is included for compatibility with the DB2

family. If specified, it is

ignored.

The fields of the parameters syntax diagram are:

The parameter is an input-only parameter to the stored procedure.

OUT The parameter is an output-only parameter to the stored procedure.

INOUT

The parameter is both an input and output parameter to the stored

procedure.

parameter-name

a one- to eight-character ordinary identifier defining the name of the

parameter for use in messages. If you do not specify a name, the

position of the parameter in the parameter list is used in the DB2

Server for VSE & VM messages.

INTEGER or INT

Large integer parameter

SMALLINT

Small integer parameter

REAL Single precision floating point

Chapter 6. Statements

213

CREATE PROCEDURE

FLOAT, DOUBLE, or DOUBLE PRECISION

Double precision floating point

DECIMAL or DEC

Decimal parameter. The (integer,integer) optional arguments are the

precision and scale respectively. The precision is the total number of

digits from 1 to 31. The scale is the number of digits to the right of the

decimal point, from 0 to the precision.

CHARACTER or CHAR

Fixed length character string parameter. The (integer) optional

argument specifies the length of the string, from 1 to 254. If you do not

specify (integer), the length is set to 1.

VARCHAR

Varying length character string parameter. The maximum length is

specified by the argument (integer) and varies from 1 to 32767. If the

length is greater than 254 then it is a long string column.

GRAPHIC

Fixed-length graphic string parameter. The (integer) optional argument

specifies the length of the string, from 1 to 127. If you do not specify

the (integer) argument, the length is set to 1.

VARGRAPHIC

Varying-length graphic character string parameter. The maximum

length is specified by the argument (integer) and varies from 1 to 16383

characters.

FOR subtype DATA

Specifies a subtype for a character string parameter. The subtype can

be one of the following:

SBCS Specifies that the parameter is a single-byte character string.

MIXED

Specifies that the parameter holds mixed single-byte and

double-byte data. This option is valid only when the DBCS

value is set to YES.

BIT Specifies that the parameter holds bit data. Character

conversion does not occur for data that is defined FOR BIT

DATA

As an example, in the following parameters string:

PARM1 CHAR(10) IN, PARM2 INTEGER INOUT, PARM3 INT OUT

PARM1, PARM2, and PARM3 are identifiers for error messages. You can

specify any name you want. The stored procedure associated with the

PARMLIST string would expect three parameters:

v An input character parameter of length 10

v An integer parameter for both input and output

v An integer parameter for output only

Notes

If a parameter represents a DB2 Server for VSE & VM DATE, TIME, or

TIMESTAMP value, it must be defined as CHARACTER or VARCHAR in the

PARMLIST.

214

SQL Reference

CREATE PSERVER

The CREATE PSERVER statement inserts the definition of a stored procedure

server into SYSTEM.SYSPSERVERS and puts the new definition into the cache.

Invocation

This statement can be issued from an application program or interactively. It is an

executable statement that can be dynamically prepared.

Authorization

The issuer of the CREATE PSERVER statement must have DBA authority.

Syntax

(1)

►►

CREATE PSERVER procedure-server

▼

►◄

GROUP group-name

AUTOSTART NO

AUTOSTART YES

DESCRIPTION description

Notes:

One or more clauses may be specified, however each clause may be specified at most

once.

Description

procedure-server

The name of the stored procedure server. The name must be an ordinary

identifier of 8 characters or less. The name must not identify a stored

procedure server that already exists on the server. In addition, the name cannot

be one of the following:

GROUP

IMPLICIT

NOIMPLICIT

NORMAL

QUICK

GROUP

The name of the group that this stored procedure server is in. Using stored

procedure groups gives the database administrator more flexibility in defining

the system. The use of stored procedure groups is optional; if the GROUP

clause is not specified, the stored procedure server becomes part of the default

group. If the GROUP clause is specified, the group-name must be an ordinary

identifier of 1 to 18 characters.

AUTOSTART

Determines whether the database manager will issue a START PSERVER

command for this stored procedure server when the database is started.

NO The stored procedure server will not be started when the database is

initialized. This is the default.

YES The stored procedure server will be started when the database is

initialized.

216

SQL Reference

CREATE SYNONYM

The CREATE SYNONYM statement defines an alternative name for a table or

view. This lets you refer to a table or view owned by another user without having

to enter the qualified name. You may also define a synonym for a table or view

that you own.

Invocation

This statement can be embedded in an application program or issued interactively.

It is an executable statement that can be dynamically prepared.

Authorization

None required.

Syntax

►► CREATE SYNONYM synonym FOR

qualified_table_name

►◄

qualified_view_name

Description

synonym

Provides an alternative name to use when referring to the table or view. The

synonym must be an SQL identifier that is not identical to one of your

synonyms or the unqualified name of a table or view that you own.

FOR

Identifies the qualified name of the table or view for which the synonym is to

be created. The qualifier is required, even when you are creating a synonym

for one of your own tables or views. You can create a synonym for a table or

view that does not as yet exist in the system catalog.

The synonym is defined only for your authorization ID, that is, the

authorization ID of the statement. If many users want to have the same

synonym, each user must enter a CREATE SYNONYM statement.

qualified_table_name

qualified_view_name

Identifies the object to which the synonym will apply. The name consists of

two parts and denotes a table or view already described or which will be

described in the catalog.

Notes

A synonym cannot be used with the table or view it represents in the same

statement.

Examples

Define an alternative name, PARTS, for TRUDEAU.INVENTORY.

CREATE SYNONYM PARTS

FOR TRUDEAU.INVENTORY

218

SQL Reference

CREATE TABLE

The CREATE TABLE statement defines a table. You provide the name of the table

and the names and attributes of its columns. Moreover, you may specify the

dbspace where the table is to be created.

Invocation

This statement can be embedded in an application program or issued interactively.

It is an executable statement that can be dynamically prepared.

Authorization

The privileges held by the authorization ID of the statement must include at least

one of the following:

v DBA authority

v RESOURCE authority

v A private dbspace that was acquired for you.

If the table name is qualified by an identifier other than your authorization ID, you

must have DBA authority.

See the description of the IN clause for further information on authorization.

Chapter 6. Statements

219

CREATE TABLE

Syntax

(1)

►► CREATE TABLE table_name

(

▼

column_definition_block

)

▼

►◄

(1)

IN dbspace_name

primary_key_block

(2)

referential_constraint_block

DATA CAPTURE

NONE

unique_block

CHANGES

Notes:

There can be up to 255 columns in a table.

The same clause must not be specified more than once.

column_definition_block:

column_name

data_type

(1)

fieldproc_block

Notes:

These clauses may be specified in any order.

data_type:

INTeger

SMALLINT

NOT NULL

(53)

UNIQUE

FLOAT

PRIMARY KEY

(integer)

REAL

DOUBLE PRECISION

(5,0)

DECimal

NUMERIC

( integer

)

,integer

(1)

CHARacter

(integer)

FOR SBCS DATA

VARCHAR

(integer

FOR MIXED DATA

LONG VARCHAR

FOR BIT DATA

CCSID integer

(1)

GRAPHIC

(integer)

CCSID integer

VARGRAPHIC

(integer)

LONG VARGRAPHIC

DATE

TIME

TIMESTAMP

220

SQL Reference

CREATE TABLE

fieldproc_block:

FIELDPROC program_name

(

▼

constant

)

primary-key-block:

(1)

ASC

PCTFREE = 10

PRIMARY KEY

(

▼

column_name

)

DESC

PCTFREE = integer

Notes:

A PRIMARY KEY can have up to 16

columns.

referential-constraint-block:

▼

FOREIGN KEY

(

column_name

)

REFERENCES

table_name

►

constraint_name

►

RESTRICT

ON DELETE

CASCADE

SET NULL

unique-block:

(1)

ASC

PCTFREE = 10

UNIQUE

(

▼

column_name

)

constraint_name

DESC

PCTFREE = integer

Notes:

There can be up to 16 columns on a unique constraint.

Description

table_name

Provides a name for the table. The name, including the implicit or explicit

qualifier, must not identify a table, view, or synonym that already exists at the

application server.

If the table name is qualified, the qualifier is the owner of the table. Otherwise,

the authorization ID of the statement is the owner of the table. The owner has

all privileges on the table. The privileges can be granted by the owner and

cannot be revoked from the owner.

If user SCOTT preprocesses a program that creates a table named SUMMARY,

and user JONES runs the program, the owner of the SUMMARY table is

Chapter 6. Statements

221

CREATE TABLE

SCOTT. Note that JONES must be a DBA to run the program. Any program

preprocessed by SCOTT can refer to the SUMMARY table simply by the name

SUMMARY. When another authorization ID preprocesses a program that refers

to the SUMMARY table, the program must use SCOTT as a prefix to the

table_name, SCOTT.SUMMARY.

(column_name,...)

Names a column of the table. Do not qualify column_name and do not use the

same name for more than one column of the table.

data_type

Specifies one of the types in the following list.

INTeger

For a large integer. The value may range from -2147483648 to 2147483647.

SMALLINT

For a small integer. The value may range from -32 768 to 32 767.

FLOAT(integer)

FLOAT

For a floating-point number. If the integer is between 1 and 21 inclusive,

the format is that of single precision floating-point. If the integer is

between 22 and 53 inclusive, the format is that of double precision

floating-point. If the integer is omitted from the specification, double

precision floating-point is assumed.

In place of FLOAT(integer) you may specify either:

REAL

For single precision floating-point

DOUBLE PRECISION

For double precision floating-point

DECIMAL(precision-integer,scale-integer)

For a packed decimal number. The first integer is the precision of the

number; that is, the total number of digits; it can range from 1 to 31. The

second integer is the scale of the number; that is, the number of digits to

the right of the decimal point; the scale of the number can range from 0 to

the precision of the number.

DECIMAL(p) can be used for DECIMAL(p,0), and DECIMAL can be used

for DECIMAL(5,0).

NUMERIC

NUMERIC is a synonym for DECIMAL.

CHARacter(integer)

CHARacter

For a fixed-length character string of length integer, which can range from 1

to 254 bytes. If the length specification is omitted, a length of 1 character is

assumed.

VARCHAR(integer)

For a varying-length character string of maximum length integer, which can

range from 1 to 32 767 bytes. An integer greater than 254 defines a long

string column.

LONG VARCHAR

For a varying-length character string with a maximum length of 32 767

bytes.

A LONG VARCHAR column is always a long string column (even if its

actual length is 254 or less).

222

SQL Reference

CREATE TABLE

GRAPHIC(integer)

For a fixed-length graphic string of length integer, which can range from 1

to 127 double-byte characters. If the length specification is omitted, a

length of 1 character is assumed.

VARGRAPHIC(integer)

For a varying-length graphic string of maximum length integer, which must

range from 1 to 16 383 double-byte characters. An integer greater than 127

double-byte characters defines a long string column.

LONG VARGRAPHIC

For a varying-length string of double-byte characters, of maximum length

16 383 bytes. A LONG VARGRAPHIC column is always a long string

column (even if its actual length is 127 double-byte characters or less).

DATE

For a date.

TIME

For a time.

TIMESTAMP

For a timestamp.

column clauses (can be specified in any order)

NOT NULL

Prevents the column from containing null values.

NOT NULL PRIMARY KEY

Establishes a primary key column. (See “PRIMARY KEY” in the

primary-key-block section for a definition of a primary key.)

NOT NULL UNIQUE

Establishes a unique index on the column. (See “UNIQUE” in the

“unique-block” section for a definition of a unique index.)

FOR SBCS DATA

Indicates the column will contain single-byte characters.

FOR MIXED DATA

Indicates the column might contain values that have a mixture of

single-byte or double-byte characters.

FOR BIT DATA

Indicates that the values of a character column are not associated with a

coded character set and therefore are never converted. For example, the bit

pattern of the data should not be modified when moving table data

between ASCII and EBCDIC environments. The database manager sets the

SUBTYPE column in the SYSCOLUMNS catalog table to 'B' when this

option is specified.

CCSID integer

Uniquely identifies an encoding scheme and one or more pairs of character

sets and code pages, for either character or graphic data.

Depending on the specification of subtypes and CCSIDs, the database

manager assigns different values:

v If either SBCS or mixed data is specified, then the database default

CCSID for the subtype is assigned.

v If a CCSID is specified, then the subtype that matches the CCSID is

assigned.

Chapter 6. Statements

223

CREATE TABLE

v If neither SBCS nor mixed data is specified and a CCSID is also not

specified, then first the default subtype is assigned; then the database

default CCSID for that subtype is assigned.

v If graphic data is specified without a CCSID, then the database default

CCSID for graphic data is assigned.

The choice of CCSID, including allowing it to default, may significantly

affect performance. For performance implications related to CCSID, consult

the DB2 Server for VSE & VM Performance Tuning Handbook manual.

fieldproc-block

FIELDPROC program_name

Names a field procedure for the column. Use a field procedure only

with a short string column. The column has no field procedure if you

omit FIELDPROC.

constant

Is a parameter of the field procedure. A parameter list is optional. The

number of parameters and the data type of each are determined by the

field procedure. The maximum length of the parameter list is 254

bytes, including commas, but excluding insignificant blanks and the

delimiting parentheses after blank compression occurs.

primary-key-block

PRIMARY KEY

Is a set of column values in the table that enforces a unique constraint.

Only one primary key is allowed in a parent table. Primary key values

must be unique and must be defined as NOT NULL.

Defining a primary key on a table sets up the table to be referenced by

another table’s foreign key to establish a referential constraint.

column_name

Identifies the column or columns that comprise the primary key. Each

column_name must be an unqualified name that identifies a column of

the table, and that column must be defined as NOT NULL. No column

in a primary key can contain a long string. The same column cannot be

specified more than once.

ASC

Creates the primary key such that the values from this column are

arranged in ascending order. This is the default.

DESC

Creates the primary key such that the values from this column are

arranged in descending order.

PCTFREE

Is the percentage of space in each index page reserved for later

insertions and updates of the primary key. The integer can range from

0 to 99, but for practical purposes should not exceed 50. Increasing

PCTFREE causes the index to take up more space, but reduces the time

required to insert or update primary key rows of the indexed table.

referential-constraint-block

FOREIGN KEY

Defines a foreign key which consists of one or more columns in a

dependent table that together must take on a value that exists in the

224

SQL Reference

CREATE TABLE

primary key of the related parent table. The columns in the dependent

table may contain nulls. If any of the columns contain a null value, the

foreign key is considered null.

constraint_name

Provides a name for the referential constraint. You cannot use a

constraint_name more than once in the same table. Although the

database manager generates a constraint_name if you do not specify

one, you should specify your own constraint_name to make it easier for

you to drop, activate, and deactivate the foreign key.

column_name

Identifies the column or columns that comprise the foreign key. Each

column_name must be an unqualified name that identifies a column of

the table. The data type and length of foreign key columns must match

the data type and length of the primary key columns. Only the null

attribute of a foreign key column may be different. The same column

cannot be specified more than once.

REFERENCES table_name

Specifies the name of the parent table involved in the referential

constraint. The table_name cannot identify the table that is being

created. The identified table must already exist and cannot be the

system catalog table.

ON DELETE

Defines the delete rule to be followed when a row is deleted from the

parent table in a relationship.

RESTRICT

Prevents deletion of a parent row until all the dependent rows

have been deleted. RESTRICT is the default value.

CASCADE

Causes all dependent rows to be deleted also.

SET NULL

Sets to null all columns of the foreign keys in each dependent row

that can contain nulls. At least one column of the foreign key in

the dependent table must be able to contain nulls.

The following restriction for ON DELETE is checked when a table is

created.

v If a table has more than one referential constraint referencing the

same parent, all the delete rules on those constraints must be the

same and must not be SET NULL.

v If a table is delete-connected to the same parent through multiple

paths, all of the delete rules on a path, except for the last one, must

be CASCADE. The last constraint on all paths must be the same, and

must not be SET NULL.

unique-block

UNIQUE

Adds a unique index for the column or columns specified. If there are

duplicates in the values of the columns, then a unique constraint is not

added.

constraint_name

Provides a name for the unique constraint. You cannot use the same

Chapter 6. Statements

225

CREATE TABLE

constraint_name more than once in the same table. Although the

database manager generates a constraint_name if you do not specify

one, you should specify your own constraint_name to make it easier

for you to drop, activate, and deactivate the unique constraint.

column_name

Identifies the column or columns that comprise the unique key. Each

column_name must be an unqualified name that identifies a column of

the table, and that column must be defined as NOT NULL. No column

in a unique constraint can be nullable. You cannot specify the same

column more than once. These columns should not be the same as that

of a primary key in the same table.

ASC

Creates the unique key such that the values from this column are

arranged in ascending order. This is the default.

DESC

Creates the unique key such that the values from this column are

arranged in descending order.

PCTFREE

Is the percentage of space in each index page reserved for later

insertions and updates of unique keys. The integer may range from 0

to 99, but for practical purposes should not exceed 50. Increasing

PCTFREE causes the index to take up more space, but reduces the time

required to insert or update unique keys.

IN dbspace_name

The name of the dbspace into which the table is to be placed. The dbspace

must exist at the application server. The default qualifier portion of

dbspace_name is the authorization ID of the statement. If dbspace_name is

omitted, the table will be created in one of the owner’s private dbspaces (if

the owner does not have any private dbspace, an error condition will

result).

A newly created table is placed in one of the existing dbspaces of the

database according to the following rules:

1. Specifying a dbspace_name in the CREATE TABLE statement puts the

table into the named dbspace. The owner of the dbspace must be either

the user who preprocessed the current program, or PUBLIC. If you

have DBA authority, you can create a table in a private dbspace of any

user by qualifying the dbspace_name with its owner’s user ID, as

follows:

CREATE TABLE ... IN SCOTT.DSP3

2. Not specifying a dbspace_name in the CREATE TABLE statement puts

the table into any private dbspace owned by the authorization ID who

preprocessed the program. Consider the following case:

a. The person who preprocessed the program has DBA authority.

b. No dbspace is specified.

c. The table name is qualified with an authorization_name.

The database manager places the table into any private dbspace owned

by the specified authorization ID. If there is no such dbspace, an error

condition results.

3. If the dbspace_name is not qualified, the database manager will not place

the table into a nonrecoverable dbspace by default. Specify the

dbspace_name to create a table in a nonrecoverable dbspace.

226

SQL Reference

CREATE TABLE

4. If both the table_name and the dbspace_name are qualified, but are not

qualified with the same authorization_name, and the authorization ID

who preprocessed the program has DBA authority, the database

manager uses both qualifiers. That is, if JIM has DBA authority, he may

create table KELLI.SUPPLIERS in JOE.SPACE1.

Table 9 summarizes where a table is placed depending on what is

specified. X represents the user ID of the person who preprocessed the

program. X is denoted as optional below because if no user ID is

specified, the creator always defaults to the user ID of the person who

preprocessed the program (X). Y represents some other user ID.

Table 9. Default table placement when user X preprocesses the program.

DBA Authority

DBSPACE

Database

Needed?

Table Creator

Table Name

Owner

DBSPACE Name

Manager Action

User X creates

X.A in a private

dbspace owned

by X.

Yes

User X creates

Y.A in any private

dbspace owned

by Y.

User X creates

X.A in X.B¹

Yes

User X creates

X.A in Y.B

Yes

User X creates

Y.A in Y.B¹

Yes

User X creates

Y.A in Z.B

If there is no PRIVATE DBSPACE B, but there is PUBLIC DBSPACE B, the PUBLIC DBSPACE will be used.

Concatenate the desired authorization_names to both the table_name and

the dbspace_name to avoid confusion. This concatenation always

identifies both the owner of the table and where the table will be

placed.

DATA CAPTURE

Specifies if log records for this table should contain the full before image

(DATA CAPTURE CHANGES) or the partial before image (DATA

CAPTURE NONE) for UPDATE operations. If this option is not specified,

it defaults to DATA CAPTURE NONE. If DataPropagator Capture is being

used to capture changes to this table, DATA CAPTURE CHANGES must

be specified. If DataPropagator Capture is not being used to capture

updates to this table, DATA CAPTURE NONE should be specified to

reduce the amount of data logged for updates to this table.

NONE

Include the partial before image in the log records for UPDATE operations.

If DataPropagator Capture is not being used to capture updates to this

table, DATA CAPTURE NONE should be specified to reduce the amount

of data logged for updates to this table.

CHANGES

Include the full before image in the log records for UPDATE operations. If

Chapter 6. Statements

227

CREATE TABLE

DataPropagator Capture is being used to capture changes to this table,

DATA CAPTURE CHANGES must be specified.

Notes

Once a table has been created, the data types of its columns may not be changed,

and columns may not be deleted from a table. However, new columns may be

added to the table (with the ALTER TABLE statement).

Byte counts

The sum of the byte counts of the columns must not be greater than 4077. The list

that follows gives the byte counts of columns by data type for columns that do not

allow null values. For a column that allows null values the byte count is one more

than shown in the list.

Data Type

Byte Count

INTEGER

SMALLINT

FLOAT( n)

If n is from 1 to 21, the byte count is 4. If n is from

22 to 53, the byte count is 8.

DECIMAL( p, s)

(p/2 + 1), rounded down to an integer.

CHAR( n)

VARCHAR( n)

n+2, or 6 if n>254

LONG VARCHAR

DATE

TIME

TIMESTAMP

GRAPHIC( n)

VARGRAPHIC( n)

2n+2, or 6 if n>127

LONG VARGRAPHIC

Dbspace use for long string columns: Actual data for a long string column is

stored in its own internal table in the dbspace. Thus, each table that contains long

string columns uses one of the available 255 tables in the dbspace.

Tables as part of a referential structure: Tables that are part of a referential

structure must be defined in DBSPACEs that are in the same type of storage pool.

That is, both parent and dependent tables in the same referential structure must be

in DBSPACEs that are in either a recoverable storage pool or a nonrecoverable

storage pool. If the tables are not in the same type of storage pool, any attempt to

define or change a referential constraint will produce an error.

Examples

Example 1

Given that you have DBA authority, create a table named ‘ROSSITER.INVENTORY’

with the following columns:

part number

integer between 1 and 9,999, must be present

description

character of length 1 to 24

quantity on hand

integer between 0 and 100,000

228

SQL Reference

CREATE TABLE

CREATE TABLE ROSSITER.INVENTORY

(PARTNO

SMALLINT

NOT NULL,

DESCRIPTION

VARCHAR(24),

QONHAND

INT)

Example 2

Given that you have DBA authority, create the SITE1_SUPPLIERS table in the

PUBLIC dbspace SPACE3 with the following columns and make KRISTEL the

owner of the table:

supplier number

integer between 1 and 99, must be present

name

character of length 15

address

character of length 1 to 35

CREATE TABLE KRISTEL.SITE1_SUPPLIERS

(SUPPNO

SMALLINT

NOT NULL,

NAME

CHAR(15),

ADDRESS

VARCHAR(15) )

IN "PUBLIC".SPACE3

Example 3

Create the EQUIPMENT table in one of your private dbspaces with the following

columns:

equipment number

integer between 0100000 and 8999999

equipment description

varying length string of up to 50 characters

location

varying length string of up to 50 characters

equipment owner

the number of the department that owns this

equipment, null if not owned by any department

Ensure there is a unique entry in the table for each piece of equipment and order

the entries in ascending order by equipment number (EQUIP_NO).

Also define a referential constraint with the table so that the equipment owner

(EQUIP_OWNER) must be a department (DEPTNO) that is present in the

DEPARTMENT table. If a department is removed from the DEPARTMENT table,

the equipment owner values for all equipment owned by that department should

become unassigned (that is, set to null). Give the constraint a name of

DEPT_EQUIP.

CREATE TABLE EQUIPMENT

(EQUIP_NO INT

NOT NULL,

EQUIP_DESC

VARCHAR(50),

LOCATION

VARCHAR(50),

EQUIP_OWNER

CHAR(3),

PRIMARY KEY(EQUIP_NO),

FOREIGN KEY DEPT_EQUIP (EQUIP_OWNER)

REFERENCES DEPARTMENT

ON DELETE SET NULL )

Example 4

On a DB2 Server for VM or DB2 Server for VSE application server with mixed data

supported and with a default character subtype (that is, CHARSUB) of mixed,

create a table named ‘MAPS’ in one of your private dbspaces. This table is

designed to be maintained from a DB2 for OS/2 application requester. The table is

to have the following columns (all values must be present):

Column

Description

Data Stored

MAP_NUMBER

map number

7 SBCS characters (to be

converted to EBCDIC)

LAST_UPD

last update

date

Chapter 6. Statements

229

CREATE TABLE

Column

Description

Data Stored

DESC

description

up to 40 ASCII mixed (to be

converted to EBCDIC)

MAP

the map

up to 4000 bytes (not to be

converted to EBCDIC)

CREATE TABLE MAPS

(MAP_NUMBER CHAR(7) FOR SBCS DATA NOT NULL,

LAST_UPD

DATE NOT NULL,

DESC

VARCHAR(40) NOT NULL,

MAP

VARCHAR(4000) FOR BIT DATA NOT NULL)

Example 5

Similar to example 4, except that the default character subtype in the system is

SBCS.

CREATE TABLE MAPS

(MAP_NUMBER CHAR(7) NOT NULL,

LAST_UPD

DATE

NOT NULL,

DESC

VARCHAR(40) FOR MIXED DATA NOT NULL,

MAP

VARCHAR(4000)

FOR BIT DATA NOT NULL)

Example 6

Similar to example 5, except that not only is the default character subtype SBCS

but the default CCSIDs for both SBCS and mixed are not those required in the

table (the table requires an SBCS CCSID of 290 and a mixed CCSID of 5026).

CREATE TABLE MAPS

(MAP_NUMBER

CHAR(7) CCSID 290

NOT NULL,

LAST_UPD

DATE NOT NULL,

DESC

VARCHAR(40) CCSID 5026

NOT NULL,

MAP

VARCHAR(4000)

FOR BIT DATA NOT NULL)

Example 7

Create a table and include the partial before image on UPDATE log records

because DataPropagator Capture is not capturing updates for this table:

CREATE TABLE SALARY1

DATA CAPTURE NONE

Example 8

Create a table and include the full before image on UPDATE log records because

DataPropagator Capture requires this information for update log records:

CREATE TABLE SALARY2

DATA CAPTURE CHANGES

230

SQL Reference

CREATE VIEW

The CREATE VIEW statement creates a view on one or more tables or views.

Invocation

This statement can be embedded in an application program or issued interactively.

It is an executable statement that can be dynamically prepared.

Authorization

The privileges held by the authorization ID of the statement must include at least

one of the following:

v DBA authority, or

v For each table or view identified in the subselect:

- The SELECT privilege on the view, or

- Ownership of the table or view.

If the specified view name includes a qualifier that is not the same as the

authorization ID of the statement, the privileges held by the authorization ID of

the statement must include DBA authority. If the view name is qualified by an

identifier that is not your authorization ID, you must have DBA authority.

Syntax

►► CREATE VIEW view_name

►

▼

(

column_name

)

► AS subselect

►◄

WITH CHECK OPTION

Description

view_name

Provides a name for the view. The name, including the implicit or explicit

qualifier, must not identify a table, view, or synonym that already exists at the

application server.

The implicit or explicit qualifier of the view_name is the owner of the view.

The owner always acquires the SELECT privilege on the view, and the

authority to drop the view. The SELECT may be granted to others only if the

owner has the authority to grant the SELECT privilege on every table or view

identified in the first FROM clause of the subselect.

If the owner has the INSERT, UPDATE, or DELETE privileges on the table or

view identified in the first FROM clause of subselect, then the owner also

acquires these privileges on the view being created. Only the owner of the

table or view identified in the first FROM clause of the subselect can grant the

privilege.

(column_name,...)

Names the columns in the view. If you specify a list of column names, it must

consist of as many names as there are columns in the result table of the

subselect. Each column_name must be unique and unqualified. If you do not

specify a list of column names, the columns of the view inherit the names of

the columns of the result table of the subselect.

Chapter 6. Statements

231

CREATE VIEW

You must specify a list of column names if the result table of the subselect has

duplicate column names or an unnamed column (a column derived from a

constant, function, or expression).

AS subselect

Defines the view. At any time, the view consists of the rows that would result

if the subselect were processed. Note that the subselect is not processed when

the view is created, which means that semantic errors (for example, specifying

"WHERE COL = '10'" when COL is a decimal column) are not detected until

the view is used. To determine whether a statement contains semantic errors,

you can enter a 'SELECT *' against the view after creating it.

subselect must not reference host variables. For an explanation of subselect, see

Chapter 5, “Queries,” on page 121.

WITH CHECK OPTION

Specifies the constraint that every row of the view must conform to the search

condition of the view. The constraint is enforced by the database manager

whenever rows of the view are inserted or updated. If the search condition is

not true for any inserted or updated row, an error is returned, and no rows are

inserted or updated.

The search condition of a view is the search condition specified in the first

WHERE clause of the subselect used to define the view.

WITH CHECK OPTION must not be specified if the view is read-only or if its

search condition includes a subquery. WITH CHECK OPTION is ignored if the

view is updateable but does not have a search condition. If WITH CHECK

OPTION is specified for an updateable view that does not allow inserts, the

constraint only applies to updates.

If WITH CHECK OPTION is omitted, the search condition of the view is not

used in the checking of any insert or update operations. The view can then be

used to insert a row that does not conform to the search condition of the view

and to update a row so that it no longer conforms to the search condition of

the view. A row that does not conform to the search condition of a view cannot

be retrieved using that view. It is also possible for this situation to exist when

WITH CHECK OPTION is specified; this can happen when the view is directly

or indirectly dependent on a view that was defined without the constraint.

The WITH CHECK OPTION constraint on view V is inherited by any

updateable view that is directly or indirectly dependent on V. Thus, if an

updateable view is defined on V, the constraint on V also applies to that view,

regardless of whether WITH CHECK OPTION is specified in the definition of

that view.

Consider the following updateable views:

v V1 defined on T0

v V2 defined on V1 WITH CHECK OPTION

v V3 defined on V2

v V4 defined on V3 WITH CHECK OPTION

v V5 defined on V4

When a row of V5 or V4 is inserted or updated, it is checked against the

conjunction of the search conditions of V4 and V2. When a row of V3 or V2 is

inserted or updated, it is checked against the search condition of V2. When a

row of V1 is inserted or updated, it is not checked against any search

condition.

232

SQL Reference

CREATE VIEW

FOR UPDATE OF, ORDER BY, and UNION cannot be used in the definition of a

view.

Notes

Read-only views

A view is read-only if its definition involves any of the following:

v The first FROM clause identifies more than one table or view

v The first FROM clause identifies a read-only view

v The first SELECT clause specifies the keyword DISTINCT

v The outer subselect contains a GROUP BY clause

v The outer subselect contains a HAVING clause

v The first SELECT clause contains a column function

v It contains a subquery such that the base object of the outer subselect, and of the

subquery, is the same table

v The first FROM clause identifies a catalog table with no updatable columns.

A read-only view cannot be the object of an INSERT, UPDATE, or DELETE

statement. Note that the fact that a table contains expressions does not make it a

read only view. As long as the expressions reference a single base table, such a view

can be used to delete rows from the base table or to update columns that are

defined without expressions. Rows can also be inserted into such views if the

columns defined as expressions are nullable.

If you use a 'SELECT *' clause in the view definition and then you add a column

to an underlying table (with the ALTER TABLE statement), the new column will

not appear in the view.

There is no specific number for the limit on the number of columns in a view,

because it depends on many factors which affect this limit. A view of up to 140

columns should work in most situations.

Examples

Example 1

Create a view named MA_PROJ upon the PROJECT table that contains only those

rows with a project number (PROJNO) starting with the letters ‘MA’.

CREATE VIEW MA_PROJ

AS SELECT * FROM PROJECT

WHERE SUBSTR(PROJNO, 1, 2) = ’MA’

Example 2

Create a view as in example 1, but select only the columns for project number

(PROJNO), project name (PROJNAME) and employee in charge of the project

(RESPEMP).

CREATE VIEW MA_PROJ

AS SELECT PROJNO, PROJNAME, RESPEMP

FROM PROJECT

WHERE PROJNO LIKE ’MA____’

Example 3

Create a view as in example 2, but, in the view, call the column for the employee

in charge of the project IN_CHARGE.

Chapter 6. Statements

233

CREATE VIEW

CREATE VIEW MA_PROJ

(PROJNO, PROJNAME, IN_CHARGE)

AS SELECT PROJNO, PROJNAME, RESPEMP FROM PROJECT

WHERE SUBSTR(PROJNO, 1, 2) = ’MA’

Note: Even though you are changing only one of the column names, the names of

all three columns in the view must be listed in the parentheses that follow

MA_PROJ.

Example 4

Create a view named PRJ_LEADER that contains the first four columns (PROJNO,

PROJNAME, DEPTNO, RESPEMP) from the PROJECT table together with the last

name (LASTNAME) of the person who is responsible for the project (RESPEMP).

Obtain the name from the EMPLOYEE table by matching EMPNO in EMPLOYEE

to RESEMP in PROJECT.

CREATE VIEW PRJ_LEADER

AS SELECT PROJNO, PROJNAME, DEPTNO, RESPEMP, LASTNAME

FROM PROJECT, EMPLOYEE

WHERE RESPEMP = EMPNO

Example 5

Create a view as in example 4, but in addition to the columns PROJNO,

PROJNAME, DEPTNO, RESEMP and LASTNAME, show the total pay (SALARY +

BONUS +COMM) of the employee who is responsible. Also select only those

projects with mean staffing (PRSTAFF) greater than one.

CREATE VIEW PRJ_LEADER (PROJNO, PROJNAME, DEPTNO, RESPEMP, LASTNAME, TOTAL_PAY )

AS SELECT PROJNO, PROJNAME, DEPTNO, RESPEMP, LASTNAME, SALARY+BONUS+COMM

FROM PROJECT, EMPLOYEE

WHERE RESPEMP = EMPNO AND PRSTAFF > 1

Example 6

This example shows something that can happen when a view defined WITH

CHECK OPTION depends on a view defined without this option. In this case, a

view named VV depends on a view named WW, and WW depends on the

EMPLOYEE sample table. The view definitions are as follows:

CREATE VIEW WW

AS SELECT * FROM EMPLOYEE

WHERE SALARY < 35000.00

CREATE VIEW VV

AS SELECT * FROM WW

WHERE SALARY > 30000.00

WITH CHECK OPTION

Assume both views have a single owner, who uses VV in the following UPDATE

statement:

UPDATE VV SET SALARY = SALARY + 5000.00

The update applies to every row in which SALARY is greater than 30000 but less

than 35000. After the update, all rows that were visible to WW have salaries

greater than 35000. Such salaries conform to the search condition of VV but not to

that of WW. Even so, because WW is not defined WITH CHECK OPTION, all

these rows are updated. As a result, any row in EMPLOYEE that was visible to VV

is now invisible to WW and is therefore also invisible to VV.

234

SQL Reference

DB2 Server for VSE & VM SQL Reference (Version 7 Release 5) - page 6
