DB2 Server for VSE & VM SQL Reference (Version 7 Release 5)

ALTER PROCEDURE

specified, the SERVER GROUP clause must have been provided on the

CREATE PROCEDURE statement, or it must be provided on the

ALTER PROCEDURE statement.

PARAMETER STYLE

Identifies the linkage convention used to pass parameters to the stored

procedure. All of the linkage conventions provide arguments to the stored

procedure containing the parameters specified on the SQL CALL statement. See

the DB2 Server for VSE & VM Database Administration manual for more

information. The following parameter styles options are valid for DB2 Server

for VSE & VM:

GENERAL

If the GENERAL linkage convention is used:

v the SQL CALL statement must provide a parameter for each

parameter expected by the stored procedure

v input parameters cannot be null

v nulls can be passed for output parameters only

v the stored procedure cannot return nulls for output parameters

GENERAL WITH NULLS

If the GENERAL WITH NULLS linkage convention is used:

v the SQL CALL statement must provide a parameter for each

parameter expected by the stored procedure. When the database

manager invokes the stored procedure, it sends it the parameters

specified on the SQL CALL statement, as well as an array of

indicator variables (with one indicator variable for each parameter).

The stored procedure must contain a declaration for this array.

v input parameters can be null. This is achieved through the use of

indicator variables, or by specifying the keyword null.

v the stored procedure can return nulls for output parameters, by

using indicator variables.

STAY RESIDENT

Specifies whether the stored procedure load module or phase remains loaded

in memory after the stored procedure ends. Possible values are:

NO The load module or phase is deleted from memory after the stored

procedure ends.

YES The load module or phase remains loaded in memory after the stored

procedure ends.

PROGRAM TYPE

Specifies whether the stored procedure runs as a MAIN routine or as a SUB

routine. Currently, DB2 Server for VSE & VM supports only stored procedures

written as MAIN routines. If PROGRAM TYPE SUB is specified, DB2 Server

for VSE & VM will override it with PROGRAM TYPE MAIN.

RUN OPTIONS

Specifies the Language Environment run-time options to be passed to the

stored procedure. The options must be specified as a character string up to 254

bytes enclosed in single quotation marks. If this option is not specified, or an

empty string is passed, then DB2 Server for VSE & VM passes no run-time

options to the Language Environment, and Language Environment uses its

installation defaults. Note that DB2 Server for VSE & VM does not do any

Chapter 6. Statements

153

ALTER PROCEDURE

checking of the options provided. For a complete description of Language

Environment run-time options, see Language Environment for MVS & VM

Programming Reference.

RESULT SETS or RESULT SET

Specifies the maximum number of query result sets that can be returned by

this stored procedure. The largest value that can be specified is 32767.

COMMIT ON RETURN

Indicates whether the unit of work should be committed immediately upon

return from the stored procedure.

NO The database manager should not issue COMMIT when the stored

procedure returns.

YES The database manager should issue COMMIT when the stored

procedure returns when the following statements are true:

v The SQLCODE returned by the CALL statement is not negative

v The stored procedure is not in a must abort state

The COMMIT operation includes the work performed by the calling

application as well as the stored procedure. Any cursors that are open

when the COMMIT occurs will be closed during COMMIT processing.

Examples

Example 1

ALTER PROCEDURE MYPROC STAY RESIDENT NO

154

SQL Reference

ALTER PSERVER

The ALTER PSERVER statement alters the definition of an existing stored

procedure server.

The STOP PSERVER command must be issued with the NOIMPLICIT option

before the ALTER PSERVER statement will be accepted.

Invocation

This statement can be issued from an application program or interactively. It is an

executable statement that can be dynamically prepared.

Authorization

The issuer of the ALTER PSERVER statement must have DBA authority.

Syntax

(1)

▼

►► ALTER PSERVER

procedure-server

GROUP

►◄

group-name

AUTOSTART NO

AUTOSTART YES

DESCRIPTION description

Notes:

One or more clauses may be specified, however each clause may be specified at most

once.

Description

procedure-server

The name of the stored procedure server. This must be an ordinary identifier of

8 characters or less.

GROUP

The name of the group that this stored procedure server will be in after the

ALTER PSERVER statement has been executed. If a group name is specified, it

must be an ordinary identifier of 1 to 18 characters. If the GROUP clause is

specified without group-name, the stored procedure server will be put in the

default group.

group-name

The name of the stored procedure group. It cannot be any of the following:

GROUP

IMPLICIT

NOIMPLICIT

NORMAL

QUICK

AUTOSTART

Determines whether the database manager will issue a START PSERVER

command for this stored procedure server when the database is started.

NO START PSERVER will not be issued when the database is started.

YES START PSERVER will be issued when the database is started.

Chapter 6. Statements

155

ALTER TABLE

The ALTER TABLE statement adds a single column to an existing table, and adds,

drops, activates, or deactivates primary and foreign keys.

Invocation

This statement can be embedded in an application program or issued interactively.

It is an executable statement that can be dynamically prepared.

Authorization

The privileges held by the authorization ID of the statement must include at least

one of the following:

v Ownership of the table

v The ALTER privilege for the table

v DBA authority.

To create, drop, activate, or deactivate a foreign key, the authorization ID of the

statement must also hold at least one of the following on the parent table:

v Ownership of the table

v The REFERENCES privilege for the table

v Administrative authority.

To drop, activate, or deactivate a primary key, the authorization ID of the

statement must also hold at least one of the following on each table that has a

foreign key referencing the primary key that is being dropped.

v Ownership of the table

v The ALTER privilege for the table

v DBA authority.

Syntax

Chapter 6. Statements

157

ALTER TABLE

►► ALTER TABLE table_name

ADD

column-definition-block

►◄

ADD

primary-key-block

referential-constraint-block

unique-block

DROP

PRIMARY KEY

FOREIGN KEY constraint_name

UNIQUE constraint_name

ACTIVATE

ALL

PRIMARY KEY

FOREIGN KEY constraint_name

UNIQUE constraint_name

DEACTIVATE

ALL

PRIMARY KEY

FOREIGN KEY constraint_name

UNIQUE constraint_name

DATA CAPTURE

NONE

CHANGES

column-definition-block:

column_name

data-type

(1)

fieldproc-block

data-type:

INTeger

SMALLINT

(53)

FLOAT

(integer)

REAL

DOUBLE PRECISION

(5,0)

DECimal

NUMERIC

( integer

)

,integer

(1)

CHARacter

(integer)

FOR SBCS DATA

VARCHAR

(integer)

FOR MIXED DATA

LONG VARCHAR

FOR BIT DATA

CCSID integer

(1)

GRAPHIC

(integer)

(1)

VARGRAPHIC

(integer)

CCSID integer

LONG VARGRAPHIC

DATE

TIME

TIMESTAMP

Notes:

These clauses may be specified in any order.

158

SQL Reference

ALTER TABLE

fieldproc-block:

FIELDPROC program_name

(

▼

constant

)

primary-key-block:

(1)

ASC

PCTFREE = 10

▼

PRIMARY KEY

(

column_name

)

DESC

PCTFREE = integer

Notes:

There can be up to 16 columns in a primary key.

referential-constraint-block:

FOREIGN KEY

(

▼

column_name

) REFERENCES table_name

►

constraint_name

►

RESTRICT

ON DELETE

CASCADE

SET NULL

unique-block:

(1)

ASC

PCTFREE = 10

UNIQUE

(

▼

column_name

)

constraint_name

DESC

PCTFREE = integer

Notes:

There can be up to 16 columns on a unique constraint.

Description

table_name

Identifies the table to be changed. It must be a table that exists at the

application server and must not be a view or a catalog table. If the table_name

is qualified, the qualifier is the owner of the table. Otherwise, the authorization

ID of the statement is the owner of the table.

ADD

Adds a column to the table. All column values are NULL and the column is

the last table column on the rightmost side. That is, if initially there are n

columns, the added column is column n+1. The value of n cannot be greater

than 254.

Chapter 6. Statements

159

ALTER TABLE

Adding the new column must not make the total byte count of all columns

exceed the maximum record size of approximately 4072 bytes. For more

information, see “Notes” on page 228.

column_definition_block

column_name

Names the column to be added to the table. The name cannot already be

used by an existing column of the table.

data_type

Is one of the data types in the descriptions listed under “CREATE TABLE”

on page 219.

fieldproc_block

FIELDPROC program_name

Names a field procedure for the column. A field procedure may be

used only with a short string column. If FIELDPROC is omitted, the

column has no field procedure.

constant

Is a parameter passed to the field procedure when the ALTER TABLE

statement invokes it. A parameter list is optional. The number of

parameters and the data type of each are determined by the field

procedure. The maximum length of the parameter list is 254 bytes,

including commas, but excluding insignificant blanks and excluding

the delimiting parentheses after blank compression takes place.

primary_key_block

PRIMARY KEY

Is a set of column values in the table that enforces a unique constraint.

Only one primary key is allowed in a parent table. Primary key values

must be unique and must be defined as NOT NULL.

Defining a primary key on a table sets up the table to be referenced by

another table’s foreign key to establish a referential constraint.

column_name

Identifies the column or columns that comprise the primary keys. Each

column_name must be an unqualified name that identifies a column of the

table. No column in a primary key can contain a long string. The same

column cannot be specified more than once.

ASC

Creates the primary key such that the values from this column are

arranged in ascending order. This is the default.

DESC

Creates the primary key such that the values from this column are

arranged in descending order.

PCTFREE

Is the percentage of space in each index page reserved for later insertions

and updates of primary keys. The integer may range from 0 to 99, but for

practical purposes should not exceed 50. Increasing PCTFREE causes the

index to take up more space, but reduces the time required to insert or

update primary key rows of the indexed table.

160

SQL Reference

ALTER TABLE

referential_constraint_block

FOREIGN KEY

Defines a foreign key composed of the identified columns. Consists of one

or more columns in this dependent table that together must take on a

value that exists in the primary key of the referenced parent table. The

columns in the dependent table may contain nulls. If any of the columns

contain a null value, the foreign key is considered null.

constraint_name

Provides a name for the referential constraint. A constraint_name cannot be

used more than once in the same table. Although the database manager

generates a constraint_name if one is not specified, a constraint_name

should be explicitly chosen to make it easier for a user to drop, activate,

and deactivate the foreign key.

column_name

Identifies the column or columns that comprise the foreign key. Each

column_name must be an unqualified name that identifies a column of the

table. The data type and length of foreign key columns must match the

data type and length of the primary key columns. Only the null attribute

of a foreign key column may be different. The same column cannot be

specified more than once.

REFERENCES table_name

Specifies the name of the parent table involved in the referential constraint.

The table_name cannot identify the table that is being altered.

ON DELETE

Defines the delete rule to be followed when a row is deleted from the

parent table in a relationship.

RESTRICT

Prevents deletion of a parent row until all the dependent rows have

been deleted. This is the default.

CASCADE

Causes all dependent rows to be deleted also.

SET NULL

Sets to null all columns of the foreign key values in each dependent

row that can contain nulls. At least one column of the foreign key in

the dependent table must be able to contain nulls.

The following restrictions for ON DELETE are checked when a table is

altered.

v If a table has more than one referential constraint referencing the same

parent, all the delete rules on those constraints must be the same and

must not be SET NULL.

v If a table is delete-connected to the same parent through multiple paths,

all of the delete rules on the paths, except for the last one, must be

CASCADE. The last delete rule on all paths must be the same and must

not be SET NULL.

v A referential cycle involving two or more tables must not cause a table

to be delete-connected to itself.

For additional information and examples of application restrictions see

“Definition Restrictions” on page 16.

Chapter 6. Statements

161

ALTER TABLE

unique_block

UNIQUE

Adds a unique index automatically for the column or columns

specified. If there are duplicates in the values of the columns, then a

unique constraint is not added.

constraint_name

Provides a name for the unique constraint. A constraint_name cannot be

used more than once in the same table. Although the database

manager generates a constraint_name if one is not specified, a

constraint_name should be explicitly chosen to make it easier for a user

to drop, activate, and deactivate the unique constraint.

column_name

Identifies the column or columns that comprise the unique key. Each

column_name must be an unqualified name that identifies a column of

the table. No column in a unique constraint can be nullable. No

column in a unique constraint can contain a long string. The same

column cannot be specified more than once. These columns should not

be the same as that of a primary key in the same table.

ASC

Creates the unique key such that the values from this column are

arranged in ascending order. This is the default.

DESC

Creates the unique key such that the values from this column are

arranged in descending order.

PCTFREE

Is the percentage of space in each index page reserved for later

insertions and updates of unique keys. The integer may range from 0

to 99, but for practical purposes should not exceed 50. Increasing

PCTFREE causes the index to take up more space, but reduces the time

required to insert or update unique keys.

DROP PRIMARY KEY

Drops the definition of the primary key, thereby removing all referential

constraints in which the table is a parent. Dropping a primary key causes

the foreign keys that reference the parent table to be dropped.

DROP FOREIGN KEY constraint_name

Drops the definition of the foreign key, thereby removing the named

referential constraint.

DROP UNIQUE constraint_name

Drops the unique index associated with the constraint and the information

in the system catalog tables.

ACTIVATE ALL

Causes all the referential constraints defined for a primary key to be

enforced automatically. ACTIVATE ALL is equivalent to activating the

primary key, then activating all the explicitly inactive foreign keys and

unique constraints.

ACTIVATE PRIMARY KEY

Causes the primary key to be enforced automatically. If the primary key is

already active, this clause drops and re-creates the primary key index. If

the primary key is inactive, then the primary key index is re-created first.

If any dependent foreign keys are deactivated implicitly when the primary

162

SQL Reference

ALTER TABLE

key is made inactive, those foreign keys are verified against the primary

key. If the primary key index is created successfully and the dependent

foreign key values are found in the primary key of the object table, then

the primary key and the dependent foreign keys are activated. None of the

keys are activated if an error occurs.

ACTIVATE FOREIGN KEY constraint_name

Causes the referential constraint defined by the named foreign key to be

enforced automatically. If the primary key of the parent table referenced by

this foreign key is inactive, the foreign key is not activated. If the

associated primary key is active, the foreign key values are verified against

the values in the primary key. If all values are found in the parent primary

key, the dependent foreign key is activated.

ACTIVATE UNIQUE constraint_name

Activates a unique key on an existing table.

DEACTIVATE ALL

Suspends the restrictions imposed by the referential constraints and makes

the parent and dependent tables involved in a referential constraint

unavailable to users other than the DBA and the owner of the table. All

primary and foreign keys become inactive. DEACTIVATE ALL is

equivalent to deactivating the primary key, all active foreign keys in the

table, and all unique constraints.

DEACTIVATE PRIMARY KEY

Suspends the restrictions imposed by the referential constraints and makes

the parent and dependent tables involved in a referential constraint

unavailable to users other than the DBA and the owner of the table.

Deactivating a primary key drops the primary key index from the object

table and implicitly deactivates all active dependent foreign keys.

DEACTIVATE FOREIGN KEY constraint_name

Suspends the restrictions imposed by the referential constraints and makes

the parent and dependent tables involved in a referential constraint

unavailable to users other than the DBA and the owner of the table.

DEACTIVATE UNIQUE constraint_name

Deactivates a unique key on an existing table.

DATA CAPTURE

Specifies if log records for this table should contain the full before image

(DATA CAPTURE CHANGES) or the partial before image (DATA CAPTURE

NONE) for UPDATE operations. If this option is not specified, it defaults to

DATA CAPTURE NONE. If DataPropagator Capture is being used to capture

changes to this table, DATA CAPTURE CHANGES must be specified. If

DataPropagator Capture is not being used to capture updates to this table,

DATA CAPTURE NONE should be specified to reduce the amount of data

logged for updates to this table.

NONE

Include the partial before image in log records for UPDATE operations. If

DataPropagator Capture is not being used to capture updates to this table,

DATA CAPTURE NONE should be specified to reduce the amount of data

logged for updates to this table.

CHANGES

Include the full before image in log records for UPDATE operations. If

DataPropagator Capture is being used to capture changes to this table,

DATA CAPTURE CHANGES must be specified.

Chapter 6. Statements

163

ALTER TABLE

Notes

It is not possible to:

v Use NOT NULL. All values in a new column are NULL when created.

v See an added column in any existing view of the table.

v Change the name of a column unless the table is dropped and recreated with the

new column name.

v Add a PRIMARY KEY, FOREIGN KEY, or UNIQUE constraint on any catalog

table.

It is not a good practice to:

v Duplicate a referential constraint in the same table (that is, to have two foreign

keys with the same column list referencing the same table).

v Duplicate a unique constraint in the same table (that is, to have two unique

constraints with the same column list in the same table).

v Have a unique constraint with the same columns as the primary key of the same

table.

In these cases, a warning is issued but the duplicate specification is accepted.

Adding, dropping, activating, or deactivating keys invalidates the packages that

access tables affected by these changes in the keys. When an SQL statement

attempts to invoke an incorrect package, the database manager tries to dynamically

rebind the package.

The characteristics of a primary key or foreign key cannot be directly altered. All

specifications of the key must first be dropped and then respecified.

Examples

Example 1

Add a new column named RATING, which is one character long, to the

DEPARTMENT table.

ALTER TABLE DEPARTMENT

ADD RATING CHAR

Example 2

Add a new column named SITE_NOTES to the PROJECT table. Create

SITE_NOTES as a varying-length column with a maximum length of 1000

characters. The values of the column do not have an associated character set and

therefore should not be translated.

ALTER TABLE PROJECT

ADD SITE_NOTES VARCHAR(1000) FOR BIT DATA

Example 3

Assume a new table EQUIPMENT has been created with the following columns:

Column Name

Data Type

EQUIP_NO

INT

EQUIP_DESC

VARCHAR(50)

LOCATION

VARCHAR(50)

EQUIP_OWNER

CHAR(3)

Add a referential constraint to the EQUIPMENT table so that the owner

(EQUIP_OWNER) must be a department number (DEPTNO) that is present in the

DEPARTMENT table. If a department is removed from the DEPARTMENT table,

164

SQL Reference

ALTER TABLE

the owner (EQUIP_OWNER) values for all equipment owned by that department

should become unassigned (or set to null). Give the constraint the name

DEPT_EQUIP.

ALTER TABLE EQUIPMENT

ADD FOREIGN KEY DEPT_EQUIP (EQUIP_OWNER)

REFERENCES DEPARTMENT

ON DELETE SET NULL

Example 4

Add a constraint to the PROJECT table to ensure that there are not two entries in

the table with the same value for project name (PROJNAME).

ALTER TABLE PROJECT

ADD UNIQUE (PROJNAME)

See example 1 in “CREATE INDEX” on page 198 for an alternate method of

ensuring unique project names.

Example 5

Alter a table to create log records with the partial before image for UPDATE

operations where DataPropagator Capture is not capturing updates for the table:

ALTER TABLE SALARY1

DATA CAPTURE NONE

Example 6

Alter a table to create log records with the full before image for UPDATE

operations because DataPropagator Capture requires this information for update

log records:

ALTER TABLE SALARY2

DATA CAPTURE CHANGES

Chapter 6. Statements

165

ASSOCIATE LOCATORS

The ASSOCIATE LOCATORS statement obtains the RESULT SET LOCATOR value

for each result set data type returned by a stored procedure.

Invocation

This statement can be embedded in an application program. It is an executable

statement that can be dynamically prepared. It cannot by issued interactively.

Authorization

None required.

Syntax

►► ASSOCIATE

LOCATOR

►

RESULT SET

(1)

LOCATORS

▼

►

(

rs-locator-variable

) WITH PROCEDURE

host-variable

►◄

procedure-name

Notes:

RESULT SET LOCATOR variables are only supported in client applications written in

Assembler, C, COBOL, and PL/I.

Description

rs-locator-variable

Identifies a result set locator variable that has been declared according to the

rules for declaring result set locator variables. One result set locator variable is

required for each result set that is returned by a stored procedure. If a stored

procedure returns fewer result sets than the number of result set locator

variables specified, then the extra variables are assigned a value of zero.

WITH PROCEDURE host-variable or procedure-name

Identifies the stored procedure that returns result set locators. The procedure

name may be specified either directly or within a host variable.

If a host-variable is specified, it must be a character-string variable and it must

not include an indicator variable. Note that the value is not converted to

uppercase.

If procedure-name is specified, it must be an ordinary identifier, which implies

that it cannot contain blanks or special characters, and the value is converted

to uppercase. Therefore, if it is necessary to use a lowercase name that contains

blanks or special characters, then the name must be specified in a

host-variable. The procedure name must be left-justified. The form in which a

procedure name exists varies according to the server where the procedure is

stored.

DB2 Server for VSE & VM:

The name of the procedure to execute. The name can be up to 18

166

SQL Reference

ASSOCIATE LOCATORS

characters long and must match a value in the NAME column of the

SYSTEM.SYSROUTINES catalog table.

DB2

Common Server/DB2 Universal Database (except OS/390 and OS/400):

procedure-name

The name (with no extension) of the procedure to execute. This

is used both as the name of the stored procedure library and

the function name within that library.

procedure-library!function-name

The exclamation point character acts as a delimiter between the

library name and the function name of the stored procedure.

absolute-path!function-name

The absolute-path specifies the complete path to the stored

procedure library.

In all of these cases the total length of the procedure name including

its implicit or explicit full path must not be longer than 254 bytes.

DB2

Universal Database Server for OS/390:

An implicit or explicit three-part name. The parts are as follows:

high order

The location name of the server where the procedure is stored.

middle

SYSPROC

low order

Some value in the PROCEDURE column of the

SYSIBM.SYSPROCEDURES catalog table.

DB2

Universal Database Server for OS/400:

The external program name is assumed to be the same as the

procedure name.

For portability, the procedure name should be specified as a single token no

larger than eight bytes.

The ASSOCIATE LOCATORS statement can only be executed against a stored

procedure that has already been invoked by the program using the SQL CALL

statement.

Notes

More than one locator can be assigned to a result set. The same ASSOCIATE

LOCATORS statement can be issued more than once with different result set

locator variables.

If the number of result set locator variables listed in the ASSOCIATE

LOCATORS statement is less than the number of result sets returned by the

stored procedure, all variables in the statement are assigned a value, and a

warning is issued.

If the number of result set locator variables listed in the ASSOCIATE

LOCATORS statement is more than the number of locators returned by the

stored procedure, then the extra variables are assigned a value of zero.

The ASSOCIATE LOCATORS statement assigns result set locator values to

result set locator variables from the SQLVAR sections of the SQLDA. The first

SQLDATA field is assigned to the first locator variable, the second SQLDATA

field to the second locator variable, and so on.

Chapter 6. Statements

167

ASSOCIATE LOCATORS

4. For the ASSOCIATE LOCATORS statement to be successful, the application

must be connected to the site at which the stored procedure was executed.

Examples

The statements in the following examples are assumed to be in PL/I programs.

Example 1

Use :loc1 and :loc2 to obtain the result set locator values for the two result sets

returned by stored procedure P1:

EXEC SQL ASSOCIATE RESULT SET LOCATORS (:loc1, :loc2)

WITH PROCEDURE P1;

Example 2

Use :loc1 and :loc2 to obtain the result set locator values for the two result sets

returned by the stored procedure named by host variable :hv1:

EXEC SQL ASSOCIATE LOCATORS (:loc1, :loc2)

WITH PROCEDURE :hv1;

168

SQL Reference

BEGIN DECLARE SECTION

The BEGIN DECLARE SECTION statement marks the beginning of an SQL declare

section where host variables must be defined.

Invocation

This statement can only be embedded in an application program. It is not an

executable statement. It is not supported in REXX.

Authorization

None required.

Syntax

►► BEGIN DECLARE SECTION

►◄

Description

The BEGIN DECLARE SECTION statement can be coded in the application

program wherever variable declarations can appear in accordance with the rules of

the host language. An SQL declare section ends with an END DECLARE SECTION

statement, described on page “END DECLARE SECTION” on page 263.

The BEGIN DECLARE SECTION and the END DECLARE SECTION statements

must be paired and may not be nested.

SQL statements (other than the 'INCLUDE text-file-name' form of the INCLUDE

statement) cannot be specified within an SQL declare section.

In programs other than REXX, all variables referenced in SQL statements must be

declared in one or more SQL declare sections. With the exception of Assembler, the

SQL declare section must appear before the first reference to the variable. In REXX,

host variables are declared without the use of these statements; meaning they are

implicitly declared.

Variables declared outside an SQL declare section must not have the same name as

variables declared within an SQL declare section.

Examples

Example 1

In an Assembler program, define the host variables HVSMINT (smallint),

HVVCHR24 (varchar(24)), and HVDEC72 (dec(7,2)).

EXEC SQL BEGIN DECLARE SECTION

HVSMINT DS

HVVCHR24 DS

H,CL24

HVDEC72

PL4’12345.67’

EXEC SQL END DECLARE SECTION

Example 2

In a C program, define the host variables hv_smint (smallint), hv_vchar24

(varchar(24)), hv_double (float), and host structure name_structure (char(9),char(9)).

EXEC SQL BEGIN DECLARE SECTION;

static short

hv_smint;

static struct hv_char {

Chapter 6. Statements

169

BEGIN DECLARE SECTION

short hv_vchar24_len;

char hv_vchar24_value[24];

}

hv_vchar24;

static double

hv_double;

static struct name_struct {

char lname[9];

char fname[9];

}

name_structure;

EXEC SQL END DECLARE SECTION;

Example 3

In a COBOL program, define the host variables HV-SMINT (smallint),

HV-VCHAR24 (varchar(24)), HV-DEC72 (dec(7,2)), and host structure

NAME-STRUCTURE (char(9),char(9)).

WORKING-STORAGE SECTION.

EXEC SQL BEGIN DECLARE SECTION END-EXEC.

HV-SMINT

PIC S9(4)

COMP-4.

HV-VCHAR24.

49 HV-VCHAR24-LENGTH PIC S9(4)

COMP-4.

49 HV-VCHAR24-VALUE PIC X(24).

HV-DEC72

PIC S9(5)V9(2) COMP-3.

NAME-STRUCTURE.

05 FNAME

PIC X(9).

05 LNAME

PIC X(9).

EXEC SQL END DECLARE SECTION END-EXEC.

Example 4

In a Fortran program, define the host variables HVSMINT (smallint), HVCHAR24

(char(24)), and HVDOUBLE (float).

EXEC SQL BEGIN DECLARE SECTION

INTEGER*2

HVSMINT

CHARACTER*24

HVCHAR24

REAL*8

HVDOUBLE

EXEC SQL END DECLARE SECTION

Note: Because varying-length character strings are not supported in Fortran, a

character host variable large enough to use the largest expected value must be

used.

Example 5

In a PL/I program, define the host variables HV_SMINT (smallint), HV_VCHAR24

(varchar(24)), HV_DEC72 (dec(7,2)), and host structure NAME_STRUCTURE

(char(9),char(9)).

EXEC SQL BEGIN DECLARE SECTION;

DCL HV_SMINT

BINARY

FIXED(15);

DCL HV_VCHAR24

CHAR(24)

VARYING;

DCL HV_DEC72

FIXED

DECIMAL(7,2);

DCL

01 NAME_STRUCTURE,

05 FNAME

CHAR(9),

05 LNAME

CHAR(9);

EXEC SQL END DECLARE SECTION;

170

SQL Reference

CALL

The CALL statement invokes a stored procedure. The database manager uses the

cached information from SYSTEM.SYSROUTINES, SYSTEM.SYSPARMS, and

SYSTEM.SYSPSERVERS to process the statement.

Invocation

This statement must be embedded in an application program. It is an executable

statement that cannot be dynamically prepared. However, a host variable can be

specified for the procedure-name, enabling the procedure name to be resolved at

run time.

Authorization

The privileges required to execute the CALL statement are determined by the

application server and must be held by the owner of the package containing the

CALL statement. If the server is DB2 Server for VSE & VM, that authorization ID

must have at least one of the following for each of the packages associated with

the stored procedure:

v Run privilege on the package

v Ownership of the package

v DBA authority

Syntax

►► CALL

procedure-name

►◄

host-variable

(

)

▼

host-variable

constant

NULL

USING DESCRIPTOR descriptor-name

Description

procedure-name or host variable

Identifies the procedure to call. The procedure name may be specified either

directly or within a host variable.

If procedure-name is specified it must be an ordinary identifier, which implies

that it cannot contain blanks or special characters, and that the value is

converted to upper case. If it is necessary to use lower case names, blanks, or

special characters, the name must be specified in a host-variable.

If a host-variable is specified, it must be a character-string variable and it must

not include an indicator variable. Note that the value is not converted to upper

case. Procedure-name must be left-justified.

The procedure name can take one of several forms. The forms supported vary

according to the server at which the procedure is stored.

v DB2 Server for VSE & VM:

The name of the procedure to execute. The name can be up to 18 characters

long, and must match a value in the NAME column of the

SYSTEM.SYSROUTINES catalog table.

Chapter 6. Statements

171

CALL

DB2 common server / DB2 Universal Database (except OS/390 and

OS/400):

procedure-name

The name (with no extension) of the procedure to execute. This is

used both as the name of the stored procedure library and the

function name within that library.

procedure-library!function-name

The exclamation character (!) acts as a delimiter between the library

name and the function name of the stored procedure.

absolute-path!function-name

The absolute-path specifies the complete path to the stored

procedure library.

In all these cases, the total length of the procedure name including its

implicit or explicit full path must not be longer than 254 bytes.

DB2 Universal Database Server for OS/390:

An implicit or explicit three part name. The parts are as follows:

high order

The location name of the server where the procedure is stored.

middle

SYSPROC

low order

Some value in the PROCEDURE column of the

SYSIBM.SYSPROCEDURES catalog table.

DB2 Universal Database Server for OS/400:

The external program name is assumed to be the same as the

procedure-name

For portability, procedure-name should be specified as a single token no larger

than 8 bytes. Note that when the SQL CALL statement is preprocessed, the

database manager does not check whether the procedure is defined, or

whether the caller is authorized to invoke it. This checking is done at run time

only.

Parameters (host variable, constant, or NULL)

Identifies a list of values to be passed as parameters to the procedure.

Each specification of a host-variable, constant, or NULL is a parameter of the

CALL. If USING DESCRIPTOR is specified, each host variable described by the

identified SQLDA is a parameter of the CALL. The nth parameter of the CALL

corresponds to the nth parameter of the stored procedure. When the CALL

statement is executed, the number of parameters of the CALL must be the

same as the number of parameters expected by the stored procedure, and each

pair of corresponding parameters must be consistent as explained below.

Each parameter of the stored procedure is defined at the server. In addition to

attributes such as data type and length, the description of each parameter

indicates how it is used by the stored procedure:

v IN means the parameter is used only as an input value

v OUT means the parameter is used only as an output value

v INOUT means the parameter is used as both an input and an output value

DB2 Server for VSE & VM gets the parameter descriptions from the cached

information from the new catalog table SYSTEM.SYSPARMS.

172

SQL Reference

CALL

Other servers might acquire parameter descriptions from other sources such as

the SQL DECLARE PROCEDURE statement.

When the CALL statement is executed, the value of each parameter of the

CALL defined as IN or INOUT is assigned to the corresponding parameter of

the stored procedure in accordance with the DB2 Server for VSE & VM rules

for assigning values to host variables. Control is then passed to the stored

procedure in accordance with the calling conventions of the host language.

When execution of the stored procedure is complete, the value of each

parameter defined as OUT or INOUT is assigned to the corresponding

parameter of the CALL in accordance with the DB2 Server for VSE & VM rules

for assigning values to host variables.

Note: DB2 Server for VSE & VM does not support the use of structures or

arrays for stored procedure parameters.

host-variable

The parameter of the CALL is the identified host variable. Host-variable must

identify a host variable (not a structure) described in the program according to

the rules for declaring host variables and the data type of the variable must be

compatible with the data type of the corresponding parameter of the stored

procedure. If an indicator variable is specified, its value must not be negative

unless

v the parameter style for the stored procedure (as defined in

SYSTEM.SYSROUTINES) is GENERAL WITH NULLS

v the parameter style for the stored procedure (as defined in

SYSTEM.SYSROUTINES) is GENERAL and the corresponding parameter of

the stored procedure is defined as OUT.

constant

The parameter of the CALL is the specified value. The data type of the

constant must be compatible with the datatype of the corresponding parameter

of the stored procedure and that parameter must be defined as IN.

NULL

The parameter of the CALL is the null value. The corresponding parameter of

the stored procedure must be defined as IN and the description of the stored

procedure must allow for null parameters.

USING DESCRIPTOR descriptor-name

Identifies an SQLDA that must contain a valid description of host variables

(unless the stored procedure has no parameters in which case the SQLDA is

not used). In C, the descriptor-name can be a pointer to an SQLDA.

Before the CALL statement is processed, the user must set the following fields

in the SQLDA:

v SQLN to indicate the number of SQLVAR occurrences provided in the

SQLDA (this number must not be less than SQLD)

v SQLDABC to indicate the number of bytes of storage allocated for the

SQLDA (this number must be not less than SQLN*44+16)

v SQLD to indicate the number of variables used in the SQLDA when

processing the statement (this number must be the same as the number of

parameters defined for the stored procedure).

v SQLVAR occurrences to indicate the attributes of the variables

Chapter 6. Statements

173

CALL

Notes

1. The capability of calling stored procedures is provided to improve the

performance of distributed operations, but the capability is not limited to

distributed operations. Thus, the application server can be the local DB2 Server

for VSE & VM.

2. The values of all parameters are passed from the application requester to the

application server. To improve the performance of this operation, host variables

that correspond to OUT parameters and have lengths of more than a few bytes

should be set to null before the CALL statement is issued.

3. If accounting is active, the activity done and resources used by the database

manager on behalf of the stored procedure will be included in the accounting

records of the userid that issued the SQL CALL.

Examples

Example 1

A package for a PL/I application exists on DB_A. A package for the stored

procedure REPORT1 exists on DB_B. The SYSTEM.SYSROUTINES table on DB_B

describes the procedure REPORT1 which allows nulls and has two parameters. The

first parameter is defined as IN and the second as OUT. Here are some of the

statements in the PL/I application that runs at DB_A:

EXEC SQL CONNECT TO DB_B;

VAR1

= 920176;

IVAR2 = -1;

EXEC SQL

CALL REPORT1(:VAR1, :VAR2 INDICATOR :IVAR2);

174

SQL Reference

The CLOSE statement closes a cursor. In doing so, it stops the usage of the group

of rows pointed to by the named cursor. Closing the cursor permits the database

manager to release the resources associated with maintaining an open cursor.

Invocation

This statement can only be embedded in an application program. It is an

executable statement that cannot be dynamically prepared.

Authorization

None required. See “DECLARE CURSOR” on page 235 for the authorization

required to use a cursor.

Syntax

►► CLOSE cursor_name

►◄

Description

cursor_name

Is an ordinary identifier that identifies the cursor to be closed. The cursor_name

must identify a cursor defined in a DECLARE statement of your program.

When the CLOSE statement is processed, the cursor must be in the open state.

When the CLOSE statement is processed, the indicated cursor leaves the open

state, and its active set becomes undefined. No FETCH or PUT statement can be

processed on the cursor, and no DELETE or UPDATE statement can refer to its

current position, until the cursor is reopened by an OPEN statement.

Notes

Explicitly closing cursors as soon as possible can improve performance.

When a CLOSE statement is processed in a program that is blocking PUTS, the

remaining rows in an incomplete block are inserted. SQLERRD(3) contains the

number of rows that were successfully inserted.

Note that both the COMMIT and ROLLBACK statements automatically close all

cursors (except when blocking an insert cursor - a COMMIT or ROLLBACK

statement issued when there is an OPEN with a blocked insert cursor results in an

error). CLOSE, however, does not cause a commit or rollback operation; these

operations must be coded separately.

Examples

In a COBOL program, use the cursor C1 to fetch the values from the first four

columns of the EMP_ACT table a row at a time and put them in the following host

variables:

v EMP (char(6))

v PRJ (char(6))

v ACT (smallint)

v TIM (dec(5,2)).

Finally, close the cursor.

Chapter 6. Statements

175

Extended CLOSE

The Extended CLOSE statement “closes” the cursor_name which was opened by an

Extended OPEN statement.

Invocation

This statement can only be embedded in an application program written in

Assembler or REXX.

Authorization

The authorization ID of the statement must have one of the following:

v ownership of the package

v DBA authority

v EXECUTE privilege on the package.

Syntax

►► CLOSE cursor_variable

►◄

Description

cursor_variable

Identifies the cursor that is to be closed. The cursor must have been defined by

a preceding Extended DECLARE CURSOR statement in the same logical unit

of work.

When the cursor is closed, its active set becomes undefined. No FETCH or PUT

statement can be processed on the cursor, and no DELETE or UPDATE statement

can refer to its current position, until the cursor is reopened by an Extended OPEN

statement.

Notes

CLOSE permits the database manager to release the resources associated with

maintaining an open cursor.

In most respects, the Extended CLOSE statement is identical to the CLOSE

statement (“CLOSE” on page 175). However, in the Extended CLOSE statement,

the cursor_variable is a host variable, thereby making it possible for a user to

provide the cursor_variable when the program is run and to CLOSE the cursor in a

logical unit of work or program other than the one in which the statement was

prepared.

Examples

CLOSE :CURSOR1

Chapter 6. Statements

177

COMMENT ON

The COMMENT ON statement adds or replaces comments (also called remarks) in

the catalog descriptions of tables, views, or columns.

Invocation

This statement can be embedded in an application program or issued interactively.

It is an executable statement that can be dynamically prepared.

Authorization

The privileges held by the authorization ID of the statement must include one of

the following:

v Ownership of the table or view

v DBA authority.

Syntax

►► COMMENT ON

options_a

IS str_constant

►◄

table_name

(

options_b

)

view_name

options_a

TABLE

table_name

view_name

COLUMN

table_name.column_name

view_name.column_name

options_b

▼

column_name IS str_constant

Description

TABLE

Indicates that the comment applies to a table or view.

table_name or view_name

Identifies a table or view to which the comment applies. The name must

identify a table or view that exists at the application server.

The comment is placed in the REMARKS column of the

SYSTEM.SYSCATALOG catalog table for the row that describes the table or

view.

COLUMN

Indicates that the comment applies to a column.

table_name.column_name or view_name.column_name

Identifies the column, qualified by the name of the table or view in which

it appears. The column_name must identify a column of the specified table

or view that exists at the application server.

178

SQL Reference

COMMENT ON

The comment is placed into the REMARKS column of the

SYSTEM.SYSCOLUMNS catalog table, for the row that describes the

column.

Multiple comments

To comment on more than one column in the same table or view within the

same statement, follow the table or view name with a list of one or more

column names and string constant pairs in parentheses. The column_name must

identify a column of the specified table or view that exists at the application

server.

IS Introduces the comment that you want to make.

string_constant

Can be any SQL character string constant of up to 254 characters. The

constant may contain mixed double-byte and single-byte characters.

Examples

Example 1

Insert a comment for the EMPLOYEE table into the catalog.

COMMENT ON TABLE EMPLOYEE

IS ’Reflects first quarter 1981 reorganization’

Example 2

Insert a comment for the EMP_VIEW1 view into the catalog.

COMMENT ON TABLE EMP_VIEW1

IS ’View of the EMPLOYEE table without salary information’

Example 3

Insert a comment for the EDLEVEL column of the EMPLOYEE table into the

catalog.

COMMENT ON COLUMN EMPLOYEE.EDLEVEL

IS ’highest grade level passed in school’

Example 4

Insert two comments into the catalog for two different columns of the EMPLOYEE

table.

COMMENT ON EMPLOYEE

(WORKDEPT IS ’see DEPARTMENT table for names’,

EDLEVEL IS ’highest grade level passed in school ’)

Chapter 6. Statements

179

COMMENT ON PROCEDURE

The COMMENT ON PROCEDURE statement adds or replaces comments to the

REMARKS column of the SYSTEM.SYSROUTINES catalog table for the row that

describes the stored procedure identified.

Invocation

This statement can be embedded in an application program or issued interactively.

It is an executable statement that can be dynamically prepared.

Authorization

The issuer must have DBA authority.

Syntax

►► COMMENT ON PROCEDURE procedure_name

►

AUTHID authid

► IS string_constant

►◄

Description

PROCEDURE

Indicates that the comment applies to a stored procedure.

procedure_name

Identifies a stored procedure that has been defined (meaning, a CREATE

PROCEDURE has been processed successfully for it).

AUTHID

Indicates that authid is specified.

authid

Identifies the authorization ID for the stored procedure. If specified, the

comment will only be added or updated for the version of procedure_name

that is accessible only by authid.

IS Introduces the comment that you want to make.

string_constant

Can be any SQL character string constant of up to 254 characters. The

constant may contain mixed double-byte and single-byte characters. The

comment is placed into the REMARKS column of the

SYSTEM.SYSROUTINES catalog table, for the row that describes the stored

procedure.

Examples

Example 1

Insert a comment for the STORPRC1 stored procedure into the catalog.

COMMENT ON PROCEDURE STORPRC1

IS ’Calculates project cost for the current month in person-hours’

Example 2

Insert a comment for the STORPRC2 stored procedure with AUTHID USER1 into

the catalog.

180

SQL Reference

COMMIT

The COMMIT statement terminates the current logical unit of work and commits

the application server changes that were made by that logical unit of work.

Invocation

This statement can be embedded in an application program or issued interactively.

It is an executable statement that cannot be dynamically prepared.

Authorization

None required.

Syntax

WORK

►►

COMMIT

►◄

RELEASE

Description

RELEASE

Specifies that when the COMMIT process is complete, your connection to the

application server is severed.

For VM users, when the next SQL statement is entered, you are automatically

connected with your logon user ID to the default application server. This

eliminates the need to enter a CONNECT statement to return to the system

default user ID after being connected to an application server as another user

ID.

For VSE interactive users, when the next SQL statement is entered, you are

automatically connected to the CICS default user ID on the same application

server. For VSE interactive users connected to a remote DRDA application

server, when the next SQL statement is entered, you are automatically

connected with your CICS signon user ID to the same application server.

For VSE batch applications, an explicit CONNECT with a user ID and

password is necessary after a COMMIT RELEASE to establish an SQL user ID.

In any case, if you are connected to an application server with a user ID other

than the default user ID and you enter a COMMIT without specifying

RELEASE, you will remain connected to the application server under that user

ID.

The COMMIT statement terminates the logical unit of work in which it is

processed and initiates a new logical unit of work. All changes that were made by

any of the following statements during the logical unit of work are committed:

ACQUIRE DBSPACE

GRANT Package Privileges

ALTER DBSPACE

GRANT System Authorities

ALTER PROCEDURE

Alter a Stored Procedure

ALTER PSERVER

Alter a Stored Procedure Server

ALTER TABLE

GRANT Table Privileges

COMMENT ON

INSERT

CREATE INDEX

LABEL ON

CREATE PACKAGE

Extended PREPARE

CREATE PROCEDURE

Define a Stored Procedure

182

SQL Reference

COMMIT

CREATE PSERVER

Define a Stored Procedure Server

CREATE SYNONYM

PUT

CREATE TABLE

Extended PUT

CREATE VIEW

REVOKE Package Privileges

DELETE

REVOKE System Authorities

DROP

REVOKE Table Privileges

DROP PROCEDURE

Remove a Stored Procedure

DROP PSERVER

Remove a Stored Procedure Server

DROP STATEMENT

UPDATE

EXPLAIN

UPDATE STATISTICS

All locks acquired by the logical unit of work are released. All cursors that were

opened during the logical unit of work are closed. All statements that were

prepared during the logical unit of work using the non-extended form of the

PREPARE statement are destroyed. Any cursors associated with a prepared

statement that is destroyed cannot be opened until the statement is prepared again.

Notes

If a COMMIT or ROLLBACK does not immediately precede the termination of an

application process, the database manager attempts to commit the work. If there

are errors during the commit process, it may not be successful. It is strongly

recommended that each application process explicitly ends its logical unit of work before

terminating.

The logical unit of work must be completed by using the COMMIT or ROLLBACK

statements before the CONNECT statement can be used to switch to another user

ID or application server.

TCP/IP does not perform any security checking during a physical connect. The

Batch application requester will use the DRDA security handshaking flows during

the logical connect to perform user ID and password verification. The physical

TCP/IP connection will be deallocated and reallocated whenever the application

switches to a different user ID or server name (using the CONNECT statement),

and DRDA security handshaking flows will be used again during the logical

connect. Either of these switches will not require the application to issue a

COMMIT RELEASE or ROLLBACK RELEASE. The Batch Resource Adapter will

retain and use the current user ID, password, and server name (unless different

ones are specified with a new CONNECT statement) after the new TCP/IP

physical connection is established. If a COMMIT RELEASE or ROLLBACK

RELEASE was issued prior to a CONNECT statement, then all user ID, password

and server name information is lost and must be supplied with the next

CONNECT.

Examples

In a PL/I program, transfer a certain amount of commission (COMM) from one

employee (EMPNO) to another in the EMPLOYEE table. Subtract the amount from

one row and add it to the other. Use the COMMIT statement to ensure that no

permanent changes are made to the database until both operations are completed

successfully.

XFRCOMM: PROC OPTIONS(MAIN);

EXEC SQL BEGIN DECLARE SECTION;

DCL AMOUNT

FIXED DECIMAL(5,2);

DCL FROM_EMPNO

CHAR(6);

DCL TO_EMPNO

CHAR(6);

EXEC SQL END DECLARE SECTION;

EXEC SQL INCLUDE SQLCA;

Chapter 6. Statements

183

CONNECT (for VM)

Overall Notes

The CONNECT statement connects an application process or a user, or both, to an

application server.

Invocation

This statement can only be embedded within an application program. It is an

executable statement that cannot be dynamically prepared. It should be noted,

however, that interactive SQL facilities, such as ISQL, provide an interface that

gives the appearance of interactive execution.

Authorization

The privileges held by the authorization ID of the statement or, when specified, the

authorization_name in the statement must include authorization to connect to the

identified application server. If an authorization_name is specified in the statement,

the appropriate password must also be specified.

Syntax

►► CONNECT

►

authorization_name

IDENTIFIED BY

password

host_variable

►

►◄

TO server_name

host_variable

Description

An application process can only be connected to one application server at a time.

This is called the current server. A default application server is established when

the application requester is initialized. When an application process is started, it is

implicitly connected to the default application server. The application process can

explicitly connect to a different application server by issuing a CONNECT

statement with the TO clause. There is no default connection for CONNECT with

no options. A connection lasts until one of the following occurs:

v COMMIT RELEASE or ROLLBACK RELEASE is processed

v CONNECT ... TO ... successfully switches databases

v the application terminates

v a severe error causes the connection to be severed.

authorization_name/host_variable

Is the user ID trying to CONNECT to the application server. If used within an

interactive facility, it must be a valid ordinary identifier with a maximum

length of 8. If it is used in an application program, it must be a valid host

variable, specified without an indicator variable, declared as a fixed-length

8-character string, and initialized before the statement is processed. (For

programs written in C the host variable must be declared as a NUL-terminated

string with a length of 9.) The value can be less than 8 characters; unused

character positions in the host variable must be padded with blanks to the

right.

Chapter 6. Statements

185

CONNECT (for VM)

IDENTIFIED BY password/host_variable

Is the password of the authorization_name. If used within an interactive facility,

it must be a valid ordinary identifier with a maximum length of 8. If it is used

in an application program, it must be a valid host variable, specified without

an indicator variable, declared as a fixed-length 8-character string, and

initialized before the statement is processed. (For programs written in C, the

host variable must be declared as a NUL-terminated string with a length of 9.)

The value can be less than 8 characters; unused character positions in the host

variable must be padded with blanks to the right.

TO server_name/host_variable

Identifies the application server by the specified server_name or by a

host_variable which contains the server_name. The server_name must be a valid

ordinary identifier. Unlike authorization_name and password, if it is used in an

application, it may be specified either directly or within a host variable.

If a host_variable is specified, it must be a character string variable with a

length attribute that is not greater than 18, and an indicator variable may not

be specified. (For programs written in C, if the host variable is declared as a

NUL-terminated string, it must have a length attribute that is between 2 and

19.) The server_name that is contained within the host_variable must be

left-justified and must not be delimited by quotation marks; if a fixed-length, it

must be padded on the right with blanks if its length is less than that of the

host variable.

The default is the currently active application server. If no application server is

currently active, the default is the application server established by SQLINIT.

(See the DB2 Server for VSE & VM Database Administration for information on

SQLINIT.)

When the CONNECT statement is processed, the server_name must identify an

application server described in the local directory (see the DB2 Server for VM

System Administration manual) and the application process must be in the

connectable state. (See “Notes” on page 187 for information about connection

states.)

If the CONNECT statement is successful:

v The application process is disconnected from its previous application server, if

any, and connected to the identified application server

v The name of the application server is placed in the CURRENT SERVER special

v When using the DRDA protocol, information about the application server is

placed in the SQLERRP field of the SQLCA. If the application server is an IBM

product, the information has the form pppvvrrm, where:

- ppp identifies the product as follows:

DSN for DB2 for OS/390

ARI for DB2 Server for VSE & VM

QSQ for DB2 for OS/400

SQL for DB2 for OS/2 and DB2 for AIX.

- vv is a two-digit version identifier such as '02'

- rr is a two-digit release identifier such as '03'

- m is a one-digit modification level such as '0'.

For example, if the application server is Version 7 Release 5 of the DB2 Server

for VSE & VM, the value of SQLERRP is 'ARI06010'.

When using the SQLDS protocol, SQLERRP is set to 'ARI

186

SQL Reference

CONNECT (for VM)

For more information on the DRDA protocol and the SQLDS protocol, see

“Distributed Relational Database” on page 23.

v The authorization ID and the server_name of the connection are placed in the

SQLERRMC field of the SQLCA. The authorization ID precedes the server_name

and these are separated by X'FF'.

If the CONNECT statement is unsuccessful because the application process is not

in the connectable state or the server_name is not listed in the local directory, the

connection state of the application process is unchanged. If the CONNECT

statement is unsuccessful for any other reason, the application process remains in

the connectable state.

CONNECT with No Operand

This form of the CONNECT statement returns information about the current

authorization ID and application server. The information is returned in the

SQLERRP and SQLERRMC fields of the SQLCA as described above. This form of

CONNECT:

v Does not require the application process to be in the connectable state.

v If already connected, does not change the connection state. If unconnected,

causes a connection to the default application server.

Notes

It is a good practice for the first SQL statement processed by an application process

to be the CONNECT statement.

Summary of Variations of the CONNECT Statement

The various clauses may be specified in the following combinations:

1. CONNECT

This returns information about the currently connected authorization ID and

application server.

2. CONNECT authorization_name IDENTIFIED BY password

This switches to a new authorization ID on the currently established

application server.

3. CONNECT TO server_name

This switches the currently established authorization ID to a new application

server.

4. CONNECT authorization_name IDENTIFIED BY password TO server_name

This switches to both a new authorization ID and application server.

Only variations 1 and 2 are available in single user mode.

Table 8. CONNECT Variations Supported by Communication Protocols

Single User

Multiple User

Variation

SQLDS Protocol

DRDA Protocol

Mode

Variation 1

Yes

Variation 2

Yes

Variation 3

Yes

Variation 4

Yes

Connection States: An application process is in one of four states at any time:

v Connectable and connected

Chapter 6. Statements

187

CONNECT (for VM)

v Unconnectable and connected

v Connectable and unconnected

v Implicitly connectable.

An application process is initially in the implicitly connectable state.

The connectable and connected state: An application process is connected to an

application server and CONNECT statements can be processed. The process enters

this state when it completes a rollback or successful commit from the

unconnectable and connected state, or a CONNECT statement is successfully

processed from the connectable and unconnected state.

The unconnectable and connected state: An application process is connected to an

application server, but a CONNECT statement cannot be successfully processed to

change application servers or to change authorization IDs. The process enters this

state from the connectable and connected state when it processes any SQL

statement other than CONNECT, COMMIT or ROLLBACK.

The connectable and unconnected state: An application process is not connected to an

application server. The only SQL statement that can be processed is CONNECT.

The process enters this state when an SQL statement is unsuccessful because of a

failure that causes a rollback operation at the application server and the loss of the

connection. The process can also enter this state if it processes a CONNECT

statement unsuccessfully.

The implicitly connectable state: An application process is not connected to an

application server and CONNECT statements can be processed. The process enters

this state when it completes a rollback or successful commit with the release option

from the unconnectable and connected state.

The following diagram shows the state transitions:

188

SQL Reference

CONNECT (for VM)

Failure of implicit connect

Implicitly

Connectable

Begin process (first SQL statement)

CONNECT with system failure

Connectable

and

Successful CONNECT

Connected

Unconnected

SQL other than CONNECT,

COMMIT, or ROLLBACK

System failure

with rollback

Unconnectable

and deallocate

and

Connected

with

ROLLBACK or

RELEASE successful COMMIT

Figure 7. VM Connection State Transitions

Additional Rules: It is not an error to process consecutive CONNECT statements

because CONNECT itself does not remove the application process from the

connectable state. It is an error to process any SQL statement other than

CONNECT, COMMIT, or ROLLBACK, and then process CONNECT with any

options. To avoid the error, process a commit or rollback operation before

processing the CONNECT.

A CONNECT to the current application server is treated like any other CONNECT.

Such a CONNECT can cause the redundant deallocation and allocation of a

conversation.

Notes

A VM user ID may be transformed when using DRDA protocol. See the DB2 Server

for VM System Administration manual for more information on the CMS

communications directory which may cause this transformation.

The old connection will not be disconnected until the new connection is made

successfully. Two connections are therefore held

for a short interval. If there are

Chapter 6. Statements

189

CONNECT (for VM)

many applications running concurrently that switch application servers, this may

cause a wait for sessions. If experiencing delays, use COMMIT RELEASE which

will disconnect explicitly.

Examples

Example 1

In a PL/I program, connect to the application server TOROLAB3.

EXEC SQL CONNECT TO TOROLAB3;

Example 2

In a PL/I program, switch to a different application server called TOROLAB4.

Assume your user ID on TOROLAB4 is different than the one you are currently

using.

EXEC SQL BEGIN DECLARE SECTION;

DCL USERID

CHAR(8);

DCL PASWRD

CHAR(8);

EXEC SQL END DECLARE SECTION;

EXEC SQL CONNECT :USERID IDENTIFIED BY :PASWRD

TO TOROLAB4;

Example 3

In a PL/I program, connect to an application server whose name is stored in the

host variable APP_SERVER (varchar(18)). Following a successful connection, copy

the 3 character product identifier of the application server to the host variable

PRODUCT (char(3)).

EXEC SQL CONNECT TO :APP_SERVER;

IF SQLSTATE = ’00000’ THEN

PRODUCT = SUBSTR(SQLERRP,1,3);

190

SQL Reference

CONNECT (for VSE)

Overall Notes

The CONNECT statement connects an application process or a user, or both, to an

application server.

Invocation

This statement can only be embedded within an application program. It is an

executable statement that cannot be dynamically prepared. It should be noted,

however, that interactive SQL facilities, such as ISQL, provide an interface that

gives the appearance of interactive execution.

Authorization

The privileges held by the authorization ID of the statement or, when specified, the

authorization_name in the statement must include authorization to connect to the

identified application server. If an authorization_name is specified in the statement,

the appropriate password must also be specified.

Syntax

►► CONNECT

►

(1)

authorization_name

IDENTIFIED BY

password

host_variable

►

►◄

TO server_name

host_variable

Notes:

An implicit connect is not allowed by a Batch application requester. Therefore, the

user ID and password must be supplied on the CONNECT statement used for Batch

application requester processing.

Description

An application process can only be connected to one application server at a time.

This is called the current server. A default application server is established when

the application requester is initialized. When an application process is started and

a CONNECT statement is issued, the application is connected to the default

application server. The application process can explicitly connect to a different

application server by issuing a CONNECT statement with the TO clause. There is

no default connection for CONNECT with no options. A connection lasts until one

of the following occurs:

v COMMIT RELEASE or ROLLBACK RELEASE is processed

v CONNECT ... TO ... successfully switches databases

v the application terminates

v a severe error causes the connection to be severed.

authorization_name/host_variable

Is the user ID trying to CONNECT to the application server. If used within an

interactive facility, it must be a valid ordinary identifier with a maximum

length of 8. If it is used in an application program, it must be a valid host

Chapter 6. Statements

191

CONNECT (for VSE)

variable, specified without an indicator variable, declared as a fixed-length

8-character string, and initialized before the statement is processed. (For

programs written in C the host variable must be declared as a NUL-terminated

string with a length of 9.) The value can be less than 8 characters; unused

character positions in the host variable must be padded with blanks to the

right.

IDENTIFIED BY password/host_variable

Is the password of the authorization_name. If used within an interactive facility,

it must be a valid ordinary identifier with a maximum length of 8. If it is used

in an application program, it must be a valid host variable, specified without

an indicator variable, declared as a fixed-length 8-character string, and

initialized before the statement is processed. (For programs written in C, the

host variable must be declared as a NUL-terminated string with a length of 9.)

The value can be less than 8 characters; unused character positions in the host

variable must be padded with blanks to the right.

Note: An implicit connect is not allowed by a Batch application requester.

Therefore, the user ID and password must be supplied on the

CONNECT statement used for Batch application requester processing.

TO server_name/host_variable

Identifies the application server by the specified server_name or by a

host_variable which contains the server_name. The server_name must be a valid

ordinary identifier. This option may be used only in an application and, unlike

authorization_name and password, it may be specified either directly or within

a host variable.

If a host_variable is specified, it must be a character string variable with a

length attribute that is not greater than 18, and an indicator variable may not

be specified. (For programs written in C, if the host variable is declared as a

NUL-terminated string, it must have a length attribute that is between 2 and

19.) The server_name that is contained within the host_variable must be

left-justified and must not be delimited by quotation marks; if a fixed-length, it

must be padded on the right with blanks if its length is less than that of the

host variable.

The default is the application server as defined in the DBNAME directory. If a

batch application attempts the connect, then the server_name must be one that

exists in the DBNAME directory. If it is a remote server, it must be identified

as using TCP/IP communication. Otherwise, an SQL error will be returned to

the batch application. (See the DB2 Server for VSE System Administration manual

for information on the DBNAME directory.)

When the CONNECT statement is processed, the server_name must identify an

application server described in the DBNAME directory (see the DB2 Server for VSE

System Administration manual) and the application process must be in the

connectable state. (See “Notes” on page 193 for information about connection

states.)

If the CONNECT statement is successful:

v The application process is disconnected from its previous application server, if

any, and connected to the identified application server

v The name of the application server is placed in the CURRENT SERVER special

192

SQL Reference

CONNECT (for VSE)

If you are connected using SQLDS protocol, the SQLERRP field in the SQLCA is

set to 'ARI

'. If you are connected using DRDA protocol, the format of

SQLERRP will be pppvvrrm, where:

- ppp identifies the product as follows:

DSN for DB2 for OS/390

ARI for DB2 Server for VSE & VM

QSQ for DB2 for OS/400

SQL for DB2 for OS/2 and DB2 for AIX.

- vv is a two-digit version identifier such as '02'

- rr is a two-digit release identifier such as '03'

- m is a one-digit modification level such as '0'.

v The authorization ID and the server_name of the connection are placed in the

SQLERRMC field of the SQLCA. The authorization ID precedes the server_name

and these are separated by X'FF'.

If the CONNECT statement is unsuccessful because the application process is not

in the connectable state or the server_name is not listed in the DBNAME directory,

the connection state of the application process is unchanged. If the CONNECT

statement is unsuccessful for any other reason, the application process remains in

the connectable state.

CONNECT with No Operand

This form of the CONNECT statement returns information about the current

authorization ID and application server. The information is returned in the

SQLERRP and SQLERRMC fields of the SQLCA as described above. This form of

CONNECT:

v Does not require the application process to be in the connectable state.

v Does not change the connection state.

Notes

In a batch program, either

v CONNECT

v CONNECT userid IDENTIFIED BY pw

v CONNECT userid IDENTIFIED BY pw TO server_name

v CONNECT TO server_name

must be the first SQL statement processed by the program. If a CONNECT TO

server_name statement is processed first, it must be followed by one of the other

three CONNECT statements above.

If a CONNECT with no options is processed first, the SQLERRMT fields will be set

to a blank user ID and blank server name. In this case, there is no default

application server. If the new target server is remote, then a new DRDA connection

to that remote server will be allocated and DRDA security handshaking will be

performed. If the new target server is local, DRDA flows are not possible and an

XPCC connection will be used. A CONNECT statement with no parameters

specified returns current connection information in the SQLERRP field of SQLCA.

If a DRDA connection exists when a CONNECT with no options is specified, the

current connection information is returned in the SQLERRP field of the SQLCA.

One of the remaining forms from the list above is required to establish the proper

identification of the user on the application server.

Chapter 6. Statements

193

DB2 Server for VSE & VM SQL Reference (Version 7 Release 5) - page 5
