Fig. 67: Exploded View Of Selector Shaft Assembly (As Of 06.99)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing ball sleeve from selector mechanism cover



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 68: Removing Ball Sleeve From Selector Mechanism Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Before pulling out ball sleeve, destroy plastic cage and remove balls.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



A. Internal extractor, e.g. Kukko 21/3, 18.5... 23.5 mm

Pressing ball sleeve into selector mechanism cover

Fig. 69: Pressing Ball Sleeve Into Selector Mechanism Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing oil seal onto stop



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 70: Installing Oil Seal Onto Stop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Selector mechanism cover and selector shaft changed



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
