Volkswagen New Beetle. Manual - part 2452

3. Ball sleeve

z

Removing. See Removing ball sleeve from selector mechanism cover

z

Pressing in. See Driving ball sleeve into selector mechanism cover

4. Oil seal

z

Pry out with screwdriver

z

Installing. See Installing oil seal onto stop

5. Selector mechanism cover

6. Sleeve

z

The lug points to reverse light switch

z

Lightly coat lug with MoS

2

 grease

7. Hex nut, 25 N.m

z

Self-locking

z

Always replace

8. Housing

z

For back-up light switch

9. Bolt

10. Cap

z

For transmission breather

11. Sleeve

z

Drive in onto stop if present as an individual part

12. Gear selector lever

z

Install so that master spline aligns with selector shaft

z

Can be replaced with selector mechanism installed

z

Installation position. See GEAR LEVER

13. Relay lever

z

Installation position. See GEAR LEVER

14. Nut, 15 N.m

15. Actuating arm

z

With axis pin for mounting relay lever

z

Installation position. See SELECTOR MECHANISM

16. Bolt

z

Press into actuating arm

17. O-ring

z

Pull onto actuating arm axis pin

18. Spacer

z

Press into relay lever

19. Locking bolt, 40 N.m



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



20. End cover

Fig. 62: Exploded View Of Selector Shaft Assembly (Up To 05.99)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing ball sleeve from selector mechanism cover



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 63: Removing Ball Sleeve From Selector Mechanism Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Before pulling out ball sleeve, destroy plastic cage and remove balls.

A. Internal extractor, e.g. Kukko 21/3, 18.5... 23.5 mm

Driving ball sleeve into selector mechanism cover



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 64: Driving Ball Sleeve Into Selector Mechanism Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing oil seal onto stop
