2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 71: Installing Selector Mechanism Cover And Selector Shaft Changed
Courtesy of VOLKSWAGEN OF AMERICA, INC.

As of date of manufacture of September 4th 2000 the bolt -2- is installed into the selector mechanism cover -1-.

Tightening torque

15 N.m

The selector shaft locating sleeve has been equipped with the segment -3-.

Function

When shifting down from the 5th to 4th gear the bolt -2- guides the selector shaft via the segment -3- into the
4th gear gap.

Selector mechanism cover and selector shaft changed



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 72: Changing Selector Mechanism Cover And Selector Shaft
Courtesy of VOLKSWAGEN OF AMERICA, INC.

As of date of manufacture of August 6th 2001 the selector shaft is manufactured with the recesses -A-.

The spring -B- is fitted in the selector mechanism cover.

Function

With one selected forward gear, the selector shaft is secured via one of the recesses -A- with the spring -B- in
the selector mechanism cover.

SELECTOR FORKS, DISASSEMBLING AND ASSEMBLING

Special tools and equipment

z

VW 402 Press plate

z

3290/1 Press piece from mounting device 3290

z

3301 Mounting device

z

VW 431 Press piece

z

VW 472/2 Spacer sleeve

z

10-206 Drift
