Fig. 20: Disconnecting 4-Pin Connector From Ignition Coil -N152- (Engine Code AEG)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking voltage supply

z

Connect multimeter to terminals 2 + 4 of the disconnected connector for voltage measurement.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle



Fig. 21: Connecting Multimeter To Igntion Coil Harness Connector Terminals 2 And 4 (Engine
Code AEG)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Switch on ignition. Specified value: at least 11.5 V

z

Switch ignition off.

If there is no voltage:

z

Check wire between 4-pin connector terminal 2 and relay carrier for open circuits according to wiring
diagram. Wire resistance: max. 1.5 ohm

Fig. 22: Identifying Igntion Coil Harness Connector Terminals (Engine Code AEG)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check for open circuit in wire between 4-pin connector terminal 4 and Ground (GND) according to
wiring diagram. Wire resistance: max. 1.5 ohm

If there is no malfunction in voltage supply:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle



z

Check activation. See CHECKING ACTIVATION .

Checking activation

z

Remove fuse 32 from fuse holder. Fuse holder is located behind access panel at far left end of dash.

Fig. 23: Locating Fuse 32
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Using adapter cables, connect voltage tester (VAG1527) to terminals 1 + 4 (ignition output 1), terminals
3 + 4 (ignition output 2), of disconnected connector.

Fig. 24: Identifying Ignition Coil Harness Connector Terminals (Engine Code AEG)

WARNING:

Do not touch ignition coil connecting parts or adapter cables during the
following test.

NOTE:

By removing fuse 32, voltage supply to the fuel injectors is interrupted.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle



Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Operate starter and test ignition signal from Engine Control Module (ECM). LED should flicker.

z

Switch ignition off.

If LED flickers and voltage supply is OK:

z

Replace Ignition Coil -N152-. See item 12 .

z

Erase DTC memory of Engine Control Module (ECM). See DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA .

z

Generate readiness code. See READINESS CODE, GENERATING .

If LED does not flicker:

z

Check wires. See CHECKING WIRING .

Checking wiring

z

Connect test box to control module wiring harness. See TEST BOX FOR WIRING TEST,
CONNECTING .

z

Check wires between test box and 4-pin connector for open circuit according to wiring diagram.

Terminal 1 + socket 71

Terminal 3 + socket 78

Wire resistance: max. 1.5 ohm

Fig. 25: Identifying Ignition Coil Harness Connector Terminals (Engine Code AEG)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Also check wires for short circuit to each other. Specified value: INFINITY ohm
