If resistances and wires are OK:

z

Replace the respective knock sensor:

z

Knock Sensor (KS) 1 -G61-. See item 7 .

z

Knock Sensor (KS) 2 -G66-. See item 5 .

z

Erase DTC memory of Engine Control Module (ECM). See DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA .

z

Generate readiness code. See READINESS CODE, GENERATING .

Checking resistances and wires (Vehicles with engine code AVH, AZG, BDC)

z

Disconnect 2-pin connectors from knock sensors.

1. Knock Sensor (KS) 1 -G61-

2. Knock Sensor (KS) 2 -G66-

Fig. 16: Disconnecting 2-Pin Connectors From Knock Sensors (Engine Code AVH, AZG, BDC)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Measure resistance between terminals 1 + 2 at connectors to knock sensors. Specified value: INFINITY
ohm

NOTE:

Before disconnecting harness connectors, mark allocation to component.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle



Fig. 17: Measuring Resistance Between Knock Sensor Terminals 1 And 2 (Engine Code AVH,
AZG, BDC)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect test box to control module wiring harness. See TEST BOX FOR WIRING TEST,
CONNECTING .

z

Check wires between test box and 2-pin connector to Engine Control Module (ECM) for open circuit
according to wiring diagram. Wire resistance: max. 1.5 ohm

Fig. 18: Identifying Knock Sensor 2-Pin Harness Connector Terminals (Engine Code AVH, AZG,
BDC)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

KNOCK SENSOR WIRING TEST (ENGINE CODE AVH, AZG, BDC)

Component

Connector

Test box

Knock Sensor (KS) 1 -G61-

Terminal 1

Socket 106

Terminal 2

Socket 99

Knock Sensor (KS) 2 -G66-

Terminal 1

Socket 107



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle



z

Also check wires for short circuit to each other. Specified value: INFINITY ohm

If resistances and wires are OK:

z

Replace the respective knock sensor:

z

Knock Sensor (KS) 1 -G61-. See item 5 .

z

Knock Sensor (KS) 2 -G66-. See item 7 .

z

Erase DTC memory of Engine Control Module (ECM). See DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA .

z

Generate readiness code. See READINESS CODE, GENERATING .

Checking ignition coil (Vehicles with engine code AEG)

Recommended special tools and equipment

z

VAG1526 multimeter or VAG1715 multimeter

z

VAG1527 voltage test lamp

z

VAG1594 connector test kit

z

Wiring diagram

Test requirements

z

The respective fuses of Ignition Coil -N152- must be OK.

Fig. 19: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Terminal 2

Socket 99

NOTE:

Fuse holder is located behind access panel at far left end of dash.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle



z

Fuel Pump (FP) Relay -J17- must be OK, check:

z

Battery voltage must be at least 11.5 volts.

z

All electrical consumers such as, for example, lights and rear window defroster must be switched off.

z

Parking brake must be engaged or else daylight driving lights will be switched on.

z

For vehicles with automatic transmission, selector lever must be in position -P- or -N-.

z

If vehicle is equipped with an A/C system, it must be switched off.

z

Ground (GND) connections between engine and chassis must be OK.

z

Engine speed (RPM) sensor must be OK, checking. See CHECK ENGINE SPEED (RPM) SENSOR .

z

Camshaft Position (CMP) sensor must be OK, checking. See CHECK CAMSHAFT POSITION
(CMP) SENSOR .

z

Ignition switched off.

Test sequence

z

Disconnect 4-pin connector from Ignition Coil -N152- (arrow).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle
