Volkswagen New Beetle. Manual - part 1527

Fig. 10: Disconnecting 3-Pin Connector From Camshaft Position Sensor (Engine Code AVH, AZG,
BDC)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect multimeter to terminal 1 (B+) and 3 (Ground -GND-) of connector for Camshaft Position (CMP)
sensor for voltage measurement.

Fig. 11: Connecting Multimeter To Camshaft Position Sensor Harness Connector Terminal 1 And
3 (Engine Code AVH, AZG, BDC)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Switch ignition on. Specified value: 4.0 to 6.0 V

z

Switch ignition off.

If there is no voltage:

z

Connect test box to control module wiring harness. See TEST BOX FOR WIRING TEST,
CONNECTING .

z

Check for open circuits in wires between test box and connector according to wiring diagram.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle



Terminal 1 + socket 98

Terminal 2 + socket 86

Terminal 3 + socket 108

Wire resistance: max. 1.5 ohm

Fig. 12: Identifying Camshaft Position Sensor Harness Connector Terminals (Engine Code AVH,
AZG, BDC)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Also check wires for short circuit to each other. Specified value: INFINITY ohm

If no malfunctions are found in the wires and there was voltage between terminals 1 + 3:

z

Replace Camshaft Position (CMP) Sensor -G40-. See item 15 .

z

Erase DTC memory of Engine Control Module (ECM). See DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA .

z

Generate readiness code. See READINESS CODE, GENERATING .

If no malfunctions are found in wires and there was no voltage between terminals 1 + 3:

z

Replace Motronic Engine Control Module (ECM) -J220-. See REPLACING ENGINE CONTROL
MODULE (ECM) .

Check knock sensors

NOTE:

z

Contact surfaces between knock sensor and cylinder block must be free
of corrosion, dirt and grease.

z

For the Knock Sensors to function properly, it is important for tightening
torque to be exactly 20 Nm.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle



Recommended special tools and equipment

z

VAG1526 multimeter or VAG1715 multimeter

z

VAG1594 connector test kit

z

Wiring diagram

Test requirements

z

Securing bolt for knock sensors tightened to 20 Nm.

z

Ignition switched off.

Checking resistances and wires (Vehicles with engine code AEG)

z

Checking resistances and wires (Vehicles with engine code AVH, AZG, BDC). See CHECKING
RESISTANCES AND WIRES (VEHICLES WITH ENGINE CODE AVH, AZG, BDC) .

z

Disconnect 2-pin connectors from knock sensors.

1. Knock Sensor (KS) 1 -G61-

2. Knock Sensor (KS) 2 -G66-

Fig. 13: Disconnecting 2-Pin Connectors From Knock Sensors (Engine Code AEG)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Measure resistance between terminals 1 + 2 at connectors to knock sensors. Specified value: INFINITY
ohm

z

Use only gold-plated terminals when servicing terminals in harness
connector of knock sensors.

NOTE:

Before disconnecting harness connectors, mark allocation to component.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle



Fig. 14: Measuring Resistance Between Knock Sensor Terminals 1 And 2 (Engine Code AEG)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect test box to control module wiring harness. See TEST BOX FOR WIRING TEST,
CONNECTING .

z

Check wires between test box and 2-pin connector to Engine Control Module (ECM) for open circuit
according to wiring diagram. Wire resistance: max. 1.5ohm

Fig. 15: Identifying Knock Sensor 2-Pin Harness Connector Terminals (Engine Code AEG)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

KNOCK SENSOR WIRING TEST (ENGINE CODE AEG)

z

Also check wires for short circuit to each other. Specified value: INFINITY ohm

Component

Connector

Test box

Knock Sensor (KS) 1 -G61-

Terminal 1

Socket 68

Terminal 2

Socket 67

Knock Sensor (KS) 2 -G66-

Terminal 1

Socket 60

Terminal 2

Socket 67
