5. Circlip

6. Turbocharger

z

Checking charge air pressure control. See CHARGE AIR PRESSURE SYSTEM, CHECKING

z

Charge air pressure control valve and charge air pressure control valve vacuum unit are
components of the turbocharger and cannot be replaced individually

z

Fill turbocharger with oil via connection before connecting oil supply pipe

z

After installing turbocharger run engine at idling speed for approx. 1 minute and do not rev up, to
ensure oil supply for turbocharger.

7. O-ring

z

Always replace

8. 10 N.m

9. Intake pipe

10. Gasket

z

Always replace

z

Note installation position

11. 20 N.m

12. Heat shield

13. 10 N.m

14. Banjo bolt, 30 N.m

15. Oil supply pipe

16. 30 N.m

z

Always replace

z

Coat threads and bolt head seating surface with G 052 112 A3

17. Exhaust manifold

18. Gasket

z

Always replace

z

Note installation position

19. 20 N.m

20. Banjo bolt, 30 N.m

21. 25 N.m

z

Always replace

z

Coat threads with G 052 112 A3

22. Banjo bolt, 35 N.m

23. Coolant return pipe

24. 25 N.m

25. Spacer sleeve

26. Banjo bolt, 35 N.m

27. 10 N.m



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



28. Coolant supply pipe

29. Banjo bolt, 35 N.m

30. 30 N.m

z

Only use genuine bolt from parts catalog

31. Support bracket

z

Between turbocharger and cylinder block

32. 25 N.m

33. Gasket

z

Always replace

34. Gasket

z

Always replace

35. 10 N.m

36. Oil return pipe

z

To oil pan

37. 10 N.m

38. 10 N.m

z

Do not alter setting

z

Must not be loosened



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 1: Removing And Installing Turbocharger With Attachments - Part I
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Turbocharger with attachments, removing and installing Part II

Only for engine code APH

Engine codes AWP, AWV. See ENGINE CODES AWP, AWV .

1. Charge pressure bypass valve

z

Checking charge air pressure regulation. See CHARGE AIR PRESSURE SYSTEM,
CHECKING

2. Connecting pipe/hose

z

Recirculating valve for turbocharger - N249-*/**. See 16

3. Pressure regulator valve

z

For crankcase ventilation

4. Connecting pipe/hose

z

From charge pressure bypass valve to upper air duct

5. To crankcase ventilation

6. From air filter

7. Upper air guiding duct

z

Vehicles with engine code APH, with screw clamp

8. Bracket

9. 25 N.m

10. 10 N.m

11. From exhaust turbocharger-exhaust connection

12. Connecting pipe/hose

NOTE:

z

Components marked with an * are checked by the On Board Diagnostic
(OBD).

See On Board Diagnostic (OBD) .

z

Components marked with ** are checked by the Output Diagnostic Test
Mode (DTM).

See Output Diagnostic Test Mode (DTM) .

z

Observe installed position of heat protection mats

NOTE:

The following list refers to items in Fig. 2 .
