Fig. 145: Identifying Filter Bracket Assembly Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Oil pan, removing and installing

Special tools and equipment

z

3185 Extension socket wrench

Fig. 146: Identifying 3185 Extension Socket Wrench
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

3249 Socket



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 147: Identifying 3249 Socket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VAG 1331 Torque wrench (5 to 50 N.m)

z

Silicone sealant D 176 404 A2

z

Hand drill with plastic brush

z

Protective glasses

z

Flat scraper

Removing

z

Removing center and right insulation tray:

See PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING .

z

Drain engine oil.

z

Detach turbocharger oil return pipe from oil pan.

z

Loosen oil pan bolts using extension socket wrench 3185. Unscrew with socket 3249.

z

Remove oil pan; it may be necessary to release oil pan by tapping lightly with a rubber head hammer.

z

Remove sealant residue on cylinder block with a flat scraper.

z

Remove sealant residue on oil pan with a rotating brush, e.g. a hand drill with a plastic brush (wear
protective glasses).

NOTE:

Observe disposal regulations!



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



Fig. 148: Removing Sealant Residue On Oil Pan With Rotating Brush
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Clean sealing surface; it must be free of oil and grease.

Installing

z

Cut off tube nozzle at forward marking (nozzle approx. 3 mm diameter).

Fig. 149: Cutting Off Tube Nozzle At Forward Marking
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Apply silicone sealing compound, as shown, to clean oil pan sealing surface.

Sealing compound bead must be:

z

2-3 mm thick

z

and run on inside of bolt holes -arrows-

NOTE:

z

Note the use by date of the sealant.

z

Oil pan must be installed within 5 minutes of applying silicone sealing
compound.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.8 L 4-Cyl. (APH, AWV, AWP)



z

Apply silicone sealing bead as shown to clean sealing surface of oil pan (illustration shows position of
sealant bead on cylinder block).

Fig. 150: Applying Silicone Sealing Bead To Clean Sealing Surface Of Oil Pan
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install oil pan immediately and tighten bolts as follows:

1. Tighten all bolts oil pan/cylinder block very lightly and diagonally.

2. Lightly tighten three bolts oil pan/transmission.

3. Lightly tighten all bolts oil pan/cylinder block diagonally.

4. Tighten three bolts oil pan/transmission to 45 N.m.

5. Tighten all bolts oil pan/cylinder block diagonally to 15 N.m.

6. Tighten oil pan/oil return pipe to 10 N.m.

The rest of the assembly is basically a reverse of the disassembly sequence.

Oil pressure and oil pressure switch, checking

Special tools and equipment

NOTE:

The sealing compound bead must not be thicker, otherwise excess sealing
compound will enter the oil pan and may block the oil suction pipe
strainer.

NOTE:

z

When installing the oil pan on an engine which is out of vehicle,
ensure that the oil pan is flush with cylinder block on flywheel end.

z

The sealant must be allowed to dry for approx. 30 minutes after
installing the oil pan before the engine can be filled with engine oil.
