12. O-ring

z

Always replace

13. Baffle plate

14. 15 N.m

15. 15 N.m

16. Oil pan

z

Clean sealing surface before installing

z

Insert with silicone sealant D 176 404 A2. See OIL PAN, REMOVING AND INSTALLING .

17. Seal

z

Always replace

18. Oil drain plug, 30 N.m

z

Replace plug with attached seal

19. 19-Oil pump

z

With pressure relief valve of 12 bar

z

Before installing, check that both dowel sleeves for centering oil pump/cylinder block are installed

z

Replace if contact surfaces and gears are scored

z

Removing and installing. See OIL PUMP, REMOVING AND INSTALLING

20. Chain gear for oil pump

21. 25 N.m

z

Use counter-bracket T10051 to loosen and tighten

22. Chain

z

Mark direction of rotation before removing

Fig. 133: Identifying Lubrication System Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Dipstick Marks



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



1. max. mark

2. min. mark

a. Area above hatched field up to max. mark: Do not top up with engine oil!

b. Oil level within hatched field: Engine oil level can be topped up.

c. Area from min. mark up to hatched field: Add a max. of 0.5 liter of engine oil!

Fig. 134: Identifying Dipstick Marks
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Part 2: Disassembling oil filter bracket

1. Oil pressure switch -F1-, 20 N.m

z

0.7 bar connector, brown

z

If sealing ring is leaking, cut open and replace

z

Checking. See OIL PRESSURE AND OIL PRESSURE SWITCH, CHECKING

2. Seal

z

Always replace

3. 15 N.m plus an additional 1/4 turn (90°)

z

Always replace

z

First install upper left and lower right bolt, then tighten four bolts diagonally

4. Oil filter bracket

5. Seal

NOTE:

The following lists refers to items in Fig. 134 .

NOTE:

The following list refers to items in Fig. 135 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



z

Always replace

6. Oil supply line

z

To exhaust turbocharger

z

Removing and installing. See PART 3: REMOVING AND INSTALLING OIL RETURN
LINE TO TURBOCHARGER

7. Banjo bolt, 20 N.m

z

Prescribed torque. See item 4 in PART 3: REMOVING AND INSTALLING OIL RETURN
LINE TO TURBOCHARGER .

8. Sealing cap, 25 N.m

z

Loosen and tighten with oil filter wrench 3417

9. O-ring

z

Always replace

10. Oil filter element

z

Note installed position: top

11. Sealing plug, 25 N.m

12. Seal

z

Always replace

13. Oil cooler

z

Make sure clearance to adjacent components.

z

See note. See LUBRICATION SYSTEM COMPONENTS, REMOVING AND INSTALLING

14. Seal

z

Always replace

z

Install into groove on oil cooler.

15. Sealing plug, 10 N.m

z

If sealing ring is leaking, cut open and replace

16. Sealing plug

z

For pressure relieve valve

z

Do not loosen



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 135: Disassembling Oil Filter Bracket Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Part 3: Removing and installing oil return line to turbocharger

Assembly overview

1. Oil supply line

z

To exhaust turbocharger

2. Union nut, 22 N.m

z

When tightening and loosening counterhold line union

3. Seal

z

Always replace

NOTE:

The following list refers to items in Fig. 136 .
