Fig. 122: Loosening Rocker Shaft Exterior Bolts And Interior Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove rocker shafts.

z

Remove tandem pump. See TANDEM PUMP, REMOVING AND INSTALLING .

z

First remove bearing caps 5, 1 and 3. Loosen bearing caps 2 and 4 alternately and diagonally.

Fig. 123: Removing Camshaft Bearing Caps
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove camshaft.

Installing

NOTE:

z

Make sure that the camshaft bearing shells are not interchanged.

z

Mark the allocation of the camshaft bearing shells on the back with a
waterproof felt-tipped pen.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



z

Oil contact surfaces of bearing shells.

z

Install bearing shell 2 and 4 and tighten new bolts alternately and diagonally to:

8 N.m plus an additional 1/4 turn (90°).

z

Install bearing caps 5, 1 and 3 and also tighten new screws to:

8 N.m plus an additional 1/4 turn (90°).

NOTE:

z

When installing the camshaft No. 1 cylinder cam lobes must point upward.

Fig. 124: Identifying No. 1 Cylinder Cam Lobes
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Do not interchange used bearing shells (observe marking).

z

Observe correct seat of the bearing shell tabs in the bearing caps and the
cylinder head when installing the camshaft.

z

Before installing the bearing caps observe that the washers for the
cylinder head bolts are installed in the cylinder head.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 125: Identifying Camshaft Bearing Caps
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install camshaft seal. See OIL SEAL, REMOVING AND INSTALLING .

z

Install rocker shaft and tighten interior new securing bolts -2- first and then exterior bolts -1- using
alternate and diagonal sequence evenly.

Tightening torque: 20 N.m plus an additional 1/4 turn (90°)

NOTE:

z

Seal bearing caps 1 and 5 contact surfaces with AMV 174 004 01. See
SPECIAL TOOLS AND EQUIPMENT . See Fig. 110 .

z

Bearing cap 5 -1- must fit flush with outer edge of the cylinder head -2-
(arrows), otherwise this may lead to tandem pump leakage.

Fig. 126: Bearing Cap 5 Must Fit Flush With Outer Edge Of The Cylinder
Head
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 127: Tightening Rocker Shaft Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install hub onto camshaft.

z

Using counterhold T10051 tighten camshaft pulley securing bolt -1- to hub.

Tightening torque: 100 N.m

Fig. 128: Tightening Camshaft Pulley Securing Bolt
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install camshaft gear on hub.

NOTE:

The tooth segment (arrow) of the camshaft gear must point upward.
