Volkswagen New Beetle. Manual - part 1006

4. Banjo bolt, 25 N.m

5. Clamp

6. 10 N.m

7. Bracket

8. 25 N.m

z

Always replace

9. 10 N.m

10. 10 N.m

Fig. 136: Turbocharger Oil Lines
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Work sequence

Removing

z

Remove sound insulation.

z

Position drip tray V.A.G 1306 underneath.

z

Remove air filter housing.

z

Unscrew union nut -2- or banjo bolt -4- at oil filter bracket.

z

Remove bolt -6-.

z

Unfasten union nut -2- at turbocharger.

z

Remove bolt -9- from bracket -7-.

z

Remove nut -8- and remove bracket -7-.

NOTE:

The following list refers to items in Fig. 137 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



z

Remove oil return line -1-.

Fig. 137: Turbocharger Oil Lines
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Installation is performed in reverse sequence of removal. In the process, note the following:

z

Install bracket -7- with nut -8- loosely to exhaust manifold.

z

Install union nut -2- or banjo bolt -4- at oil filter bracket hand-tight.

z

Install union nut -2- hand-tight at turbocharger.

z

Install union nut -2- or banjo bolt -4- at oil filter bracket with correct tightening torque.

z

Install union nut -2- to turbocharger with correct tightening torque.

z

Position clamps -5- on oil return line.

z

Install bolts -6- and -9- with correct tightening torque.

z

Tighten nut -8- with correct tightening torque.

CAUTION: Adhere strictly to the installation procedure for the oil return line.

NOTE:

The following list refers to items in Fig. 138 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 138: Turbocharger Oil Lines
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Oil pan, removing and installing

Special tools and equipment

z

3185 Jointed wrench

z

T10058 Socket insert

z

V.A.G1331 Torque wrench (5 to 50 N.m)

z

Hand drill with plastic brush attachment

z

Silicone sealing compound D 176 404 A2

Fig. 139: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove center and right side sound insulation:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



See NOISE INSULATION, ASSEMBLY OVERVIEW .

z

Drain engine oil.

z

Unbolt oil pan.

z

Remove oil pan. Loosen oil pan with light blows from a rubber-headed hammer, if necessary.

z

Use a flat scraper to remove sealant residue on cylinder block.

z

Remove sealant residue from oil pan with a rotating brush, e.g. a hand drill with a plastic brush
attachment (wear protective goggles).

Fig. 140: Removing Sealant Residue From Oil Pan With Rotating Brush
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Clean sealing surfaces. They must be free of oil and grease.

Installing

z

Cut off tube nozzle at front marking (nozzle approx. 3 mm diameter).

z

Apply silicone sealing compound, as shown, to clean oil pan sealing surface. Sealant bead must be:

NOTE:

Observe disposal regulations!

NOTE:

Loosen bolts on flywheel end of oil pan with jointed wrench 3185 and
remove with socket T10058.

NOTE:

z

Observe the use-by date of the sealing compound.

z

The oil pan must be installed within 5 minutes of applying silicone sealing
compound.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)
