Hyundai i30 (2018 year). Manual - part 33

i

Information

If the vehicle is operated in extremely

dusty or sandy areas, replace the element

more often than the usual recommended

intervals (refer to “Maintenance Under

Severe Usage Conditions” in this chap-

ter).

NOTICE

• Do not drive with the air cleaner

OPDE076021

OPD076022

filter removed. This will result in

1. Loosen the air cleaner cover

2. Wipe the inside of the air cleaner.

excessive engine wear.

attaching clips and open the cover.

3. Replace the air cleaner filter.

• When removing the air cleaner

4. Lock the cover with the cover

filter, be careful that dust or dirt

attaching clips.

does not enter the air intake, or

damage may result.

5. Check if the cover is firmly installed.

• Use HYUNDAI genuine parts,

use of non-genuine parts could

damage the air flow sensor.

7

7-43

Maintenance

CLIMATE CONTROL AIR FILTER

Filter inspection

Filter replacement

If the vehicle is operated in the

severely air-polluted cities or on

dusty rough roads for a long period,

it should be inspected more fre-

quently and replaced earlier. When

you, the owner, replace the climate

control air filter, replace it performing

the following procedure, and be care-

ful to avoid damaging other compo-

OPD076025

nents.

3. Press and hold the lock (1) on both

Replace the filter according to the

OPD076024

sides of the cover.

Maintenance Schedule.

1. With the glove box open, remove

4. Pull out the cover (2).

the stoppers on both sides.

OPD076026

OPD076023

5. Replace the climate control air filter.

2. Remove the support strap (1).

6. Reassemble in the reverse order

of disassembly.

7-44

WIPER BLADES

NOTICE

Blade inspection

NOTICE

Contamination of either the wind-

Install a new climate control air filter

To prevent damage to the wiper

shield or the wiper blades with for-

in the correct direction with the

blades, arms or other compo-

eign matter can reduce the effective-

arrow symbol() facing downwards.

nents, do not:

ness of the windshield wipers.

Otherwise, the climate control effects

• Use gasoline, kerosene, paint

Common sources of contamination

may decrease, possibly with a noise.

thinner, or other solvents on or

are insects, tree sap, and hot wax

near them.

treatments used by some commer-

• Attempt to move the wipers

cial car washes. If the blades are not

manually.

wiping properly, clean both the win-

dow and the blades with a good

• Use non-specified wiper blades.

cleaner or mild detergent, and rinse

thoroughly with clean water.

i

Information

Commercial hot waxes applied by

automatic car washes have been

known to make the windshield diffi-

cult to clean.

i

Information

7

Wiper blades are consumable item and

normal wear of the wipers may not be

covered by your vehicle warranty.

7-45

Maintenance

Blade replacement

Front windshield wiper blade

When the wipers no longer clean

adequately, the blades may be worn

or cracked, and require replacement.

NOTICE

To prevent damage to the wiper arms

or other components, do not attempt

to move the wipers manually.

OAD075074L

NOTICE

1. Lift up the wiper blade clip

(1).

OPDE076027

The use of a non-specified wiper

Then lift up the wiper blade (2).

blade could result in wiper mal-

To replace a wiper blade, follow the

function and failure.

procedure mentioned to raise the

wiper arm.

NOTICE

Turn off the engine, move the wiper

switch to the single wiping (V) posi-

• In order to prevent damage to

tion within 20 seconds and hold the

the hood and the wiper arms, the

switch for more than 2 seconds until

wiper arms should only be lifted

the wiper arm is in the fully up posi-

when in the fully up position.

tion.

• Always return the wiper arms to

the windshield before starting

your journey

7-46

Rear window wiper blade

OAD075075L

OAD075076L

2. While pushing the lock

(3), pull

3. Remove the wiper blade from the

OTL075050

down the wiper blade (4).

wiper arm (5).

1. Raise the wiper arm and pull out

4. Install a new wiper blade assem-

the wiper blade assembly.

bly in the reverse order of removal.

5. Return the wiper arm on the wind-

shield.

7

7-47

Maintenance

BATTERY

(Continued)

WARNING

Batteries contain sulfu-

To prevent SERIOUS INJURY or

ric acid which is highly

DEATH to you or bystanders,

corrosive. Do not allow

always follow these precautions

acid to contact your

when working near or handling

eyes, skin or clothing.

the battery:

If acid gets into your eyes, flush

Always read and follow

your eyes with clean water for at

instructions carefully

least 15 minutes and get imme-

when handling a battery.

diate medical attention. If acid

OTL075051

Wear eye protection

gets on your skin, thoroughly

designed to protect the

wash the area. If you feel pain or

2. Install the new blade assembly by

eyes from acid splashes.

a burning sensation, get med-

inserting the center part into the

ical attention immediately.

slot in the wiper arm until it clicks

Keep all flames, sparks,

into place.

or smoking materials

• When lifting a plastic-cased

away from the battery.

battery, excessive pressure

3. Make sure the blade assembly is

on the case may cause battery

installed firmly by trying to pull it

Hydrogen is always

acid to leak. Lift with a battery

slightly.

present in battery cells,

carrier or with your hands on

is highly combustible,

To prevent damage to the wiper arms

opposite corners.

and may explode if ignit-

or other components, we recommend

ed.

• Do not attempt to jump start

that the wiper blade be replaced by an

your vehicle if your battery is

authorized HYUNDAI dealer.

Keep batteries out of

frozen.

reach of children.

(Continued)

(Continued)

7-48

For best battery service

Battery capacity label

(Continued)

■ Example

• NEVER attempt to recharge

the battery when the vehicle’s

battery cables are connected

to the battery.

• The electrical ignition system

works with high voltage.

NEVER touch these compo-

nents with the engine running

or when the ignition switch is

in the ON position.

OPD076028

OLMB073072

NOTICE

The actual battery label in the vehicle

•

Keep the battery securely mounted.

• When you do not use the vehicle

may differ from the illustration.

•

Keep the battery top clean and dry.

for a long time in a low tempera-

1. CMF60L-BCI

: The HYUNDAI

ture area, disconnect the battery

•

Keep the terminals and connec-

model name of battery

and keep it indoors.

tions clean, tight, and coated with

petroleum jelly or terminal grease.

2.12V : The nominal voltage

• Always charge the battery fully

to prevent battery case damage

•

Rinse any spilled electrolyte from

3.60Ah(20HR) : The nominal capacity

7

in low temperature areas.

the battery immediately with a

(in Ampere hours)

solution of water and baking soda.

4.92RC : The nominal reserve capac-

NOTICE

•

If the vehicle is not going to be

ity (in min.)

used for an extended time, discon-

5.550CCA : The cold-test current in

If you connect unauthorized elec-

nect the battery cables.

amperes by SAE

tronic devices to the battery, the

battery may be discharged. Never

6.440A

: The cold-test current in

use unauthorized devices.

amperes by EN

7-49

By jump starting

Reset items

CAUTION

After a jump start from a good bat-

Items should be reset after the bat-

tery, drive the vehicle for 20-30 min-

tery has been discharged or the bat-

AGM battery (if equipped)

utes before it is shutoff. The vehicle

tery has been disconnected.

•

Absorbent Glass Matt (AGM)

may not restart if you shut it off

•

Auto up/down window

batteries are maintenance-

before the battery had a chance to

•

Sunroof

free and we recommend that

adequately recharge. See

“Jump

the AGM battery be serviced

Starting” in chapter 6 for more infor-

•

Trip computer

by an authorized HYUNDAI

mation on jump starting procedures.

•

Climate control system

dealer. For charging your

•

Driver position memory system

AGM battery, use only fully

i

Information

automatic battery chargers

•

Clock

that are specially developed

An inappropriately disposed

•

Audio system

for AGM batteries.

battery can be harmful to

the environment and human

•

When replacing the AGM bat-

health.

tery, we recommend that you

use parts for replacement

Dispose the battery according to your

from an authorized HYUNDAI

local law(s) or regulation.

dealer.

•

Do not open or remove the

cap on top of the battery. This

7

may cause leaks of internal

electrolyte that could result in

severe injury.

7-51

Maintenance

TIRES AND WHEELS

Tire care

(Continued)

WARNING

For proper maintenance, safety, and

•

Replace tires that are worn,

Tire failure may cause loss of

show uneven wear, or are dam-

maximum fuel economy, you must

always maintain recommended tire

vehicle control resulting in an

aged. Worn tires can cause

accident. To reduce risk of

loss of braking effectiveness,

inflation pressures and stay within the

load limits and weight distribution rec-

SERIOUS INJURY or DEATH,

steering) control, or traction.

take the following precautions:

ommended for your vehicle.

•

ALWAYS replace tires with the

•

Inspect your tires monthly for

same size as each tire that

proper inflation as well as

was originally supplied with

wear and damage.

this vehicle. Using tires and

•

The recommended cold tire

wheels other than the recom-

pressure for your vehicle can

mended sizes could cause

be found in this manual and on

unusual handling characteris-

the tire label located on the dri-

tics, poor vehicle control, or

ver’s side center pillar. Always

negatively affect your vehi-

use a tire pressure gauge to

cle’s Anti-Lock Brake System

measure tire pressure. Tires

(ABS) resulting in a serious

with too much or too little

accident.

pressure wear unevenly caus-

OPD086007

ing poor handling.

All specifications (sizes and pressures)

•

Check the pressure of the

can be found on a label attached to the

spare every time you check

driver’s side center pillar.

the pressure of the other tires

on your vehicle.

(Continued)

7-52

Recommended cold tire infla-

WARNING

CAUTION

tion pressures

All tire pressures

(including the

Recommended pressures must

•

Under-inflation results in

spare) should be checked when the

be maintained for the best ride,

excessive wear, poor handling

tires are cold. “Cold tires” means the

vehicle handling, and minimum

and reduced fuel economy.

vehicle has not been driven for at

tire wear.

Wheel deformation is also

least three hours or driven less than

Over-inflation or under-inflation

possible. Keep your tire pres-

1.6 km (one mile).

sures at the proper levels. If a

can reduce tire life, adversely

Warm tires normally exceed recom-

affect vehicle handling, and

tire frequently needs refilling,

mended cold tire pressures by 28 to

we recommend it be checked

lead to sudden tire failure that

41 kPa (4 to 6 psi). Do not release air

could result in loss of vehicle

by an authorized HYUNDAI

from warm tires to adjust the pres-

dealer.

control resulting in an accident.

sure or the tires will be under-inflat-

Severe under-inflation can lead

•

Over-inflation produces a

ed. For recommended inflation pres-

harsh ride, excessive wear at

to severe heat build-up, causing

sure, refer to “Tire and Wheels” in

blowouts, tread separation and

the center of the tire tread,

chapter 8.

and a greater possibility of

other tire failures that can result

in the loss of vehicle control

damage from road hazards.

resulting in an accident. This

risk is much higher on hot days

and when driving for long peri-

7

ods at high speeds.

7-53

■ With a full-size spare tire (if equipped)

Wheel alignment and tire bal-

i

Information

ance

The outside and inside of the unsym-

The wheels on your vehicle were

metrical tire is distinguishable. When

aligned and balanced carefully at the

installing an unsymmetrical tire, be

factory to give you the longest tire life

sure to install the side marked "out-

and best overall performance.

side" face the outside. If the side

marked "inside" is installed on the

In most cases, you will not need to

outside, it will have a bad effect on

have your wheels aligned again.

vehicle performance.

However, if you notice unusual tire

CBGQ0706

wear or your vehicle pulling one way

■ Without a spare tire

or the other, the alignment may need

WARNING

to be reset.

If you notice your vehicle vibrating

• Do not use the compact spare

when driving on a smooth road, your

tire for tire rotation.

wheels may need to be rebalanced.

• Do not mix bias ply and radial

ply tires under any circum-

NOTICE

stances. This may cause

unusual handling characteris-

Improper wheel weights can dam-

tics that may cause loss of

age your vehicle’s aluminum

ODH073802

vehicle control resulting in an

wheels. Use only approved wheel

7

accident.

weights.

Disc brake pads should be inspected

for wear whenever tires are rotated.

7-55

Maintenance

Tire replacement

(Continued)

WARNING

•

When replacing tires

(or

Tread wear indicator

To reduce the risk of DEATH or

wheels), it is recommended to

SERIOUS INJURY:

replace the two front or two

•

Replace tires that are worn,

rear tires (or wheels) as a pair.

show uneven wear, or are

Replacing just one tire can

damaged. Worn tires can

seriously affect your vehicle’s

cause loss of braking effec-

handling.

tiveness, steering control, and

•

Tires degrade over time, even

traction.

when they are not being used.

•

Always replace tires with the

Regardless of the remaining

same size as each tire that

tread, HYUNDAI recommends

OLMB073027

that tires be replaced after six

was originally supplied with

this vehicle. Using tires and

(6) years of normal service.

If the tire is worn evenly, a tread wear

indicator will appear as a solid band

wheels other than the recom-

•

Heat caused by hot climates or

mended sizes could cause

frequent high loading condi-

across the tread. This shows there is

less than 1.6 mm (1/16 in.) of tread

unusual handling characteris-

tions can accelerate the aging

tics, poor vehicle control, or

process. Failure to follow this

left on the tire. Replace the tire when

this happens.

negatively affect your vehi-

warning may cause sudden

cle’s Anti-Lock Brake System

tire failure, which could lead to

Do not wait for the band to appear

(ABS) resulting in a serious

a loss of vehicle control result-

across the entire tread before replac-

accident.

ing in an accident.

ing the tire.

(Continued)

7-56

Compact spare tire replacement

Wheel replacement

Tire maintenance

(if equipped)

When replacing the metal wheels for

In addition to proper inflation, correct

A compact spare tire has a shorter

any reason, make sure the new

wheel alignment helps to decrease

tread life than a regular size tire.

wheels are equivalent to the original

tire wear. If you find a tire is worn

Replace it when you can see the

factory units in diameter, rim width

unevenly, have your dealer check the

tread wear indicator bars on the tire.

and offset.

wheel alignment.

The replacement compact spare tire

When you have new tires installed,

should be the same size and design

make sure they are balanced. This

Tire traction

tire as the one provided with your

will increase vehicle ride comfort and

new vehicle and should be mounted

Tire traction can be reduced if you

tire life. Additionally, a tire should

on the same compact spare tire

drive on worn tires, tires that are

always be rebalanced if it is removed

wheel. The compact spare tire is not

improperly inflated or on slippery

from the wheel.

designed to be mounted on a regular

road surfaces. Tires should be

size wheel, and the compact spare

replaced when tread wear indicators

Tire sidewall labeling

tire wheel is not designed for mount-

appear. To reduce the possibility of

ing a regular size tire.

losing control, slow down whenever

This information identifies and

there is rain, snow or ice on the road.

describes the fundamental charac-

WARNING

teristics of the tire and also provides

the tire identification number

(TIN)

The original tire should be

for safety standard certification. The

TIN can be used to identify the tire in

7

repaired or replaced as soon as

possible to avoid failure of the

case of a recall.

spare and loss of vehicle control

resulting in an accident.The com-

pact spare tire is for emergency

use only. Do not operate your

vehicle over 80 km/h (50 mph)

when using the compact spare

tire.

7-57

Maintenance

1

Example tire size designation:

Wheel size designation

(These numbers are provided as an

Wheels are also marked with impor-

5,6

example only; your tire size designa-

tant information that you need if you

7

tor could vary depending on your

ever have to replace one. The follow-

vehicle.)

ing explains what the letters and

4

numbers in the wheel size designa-

205/55R16 91H

tion mean.

Example wheel size designation:

2

205 - Tire width in millimeters.

3

6.5JX16

55 - Aspect ratio. The tire’s section

6.5 - Rim width in inches.

height as a percentage of its

1

OLMB073028

width.

J - Rim contour designation.

1. Manufacturer or brand name

R - Tire construction code (Radial).

16 - Rim diameter in inches.

Manufacturer or brand name is

16 - Rim diameter in inches.

shown.

91 - Load Index, a numerical code

associated with the maximum

load the tire can carry.

2. Tire size designation

H - Speed Rating Symbol. See the

A tire’s sidewall is marked with a tire

speed rating chart in this section

size designation. You will need this

for additional information.

information when selecting replace-

ment tires for your car. The following

explains what the letters and num-

bers in the tire size designation

mean.

7-58

Tire speed ratings

3. Checking tire life (TIN : Tire

4. Tire ply composition and

The chart below lists many of the dif-

Identification Number)

material

ferent speed ratings currently being

Any tires that are over six years old,

The number of layers or plies of rub-

used for passenger car tires. The

based on the manufacturing date,

ber-coated fabric in the tire. Tire

speed rating is part of the tire size

(including the spare tire) should be

manufacturers also must indicate the

designation on the sidewall of the

replaced by new ones. You can find

materials in the tire, which include

tire. This symbol corresponds to that

the manufacturing date on the tire

steel, nylon, polyester, and others.

tire’s designed maximum safe oper-

sidewall (possibly on the inside of the

The letter "R" means radial ply con-

ating speed.

wheel), displaying the DOT Code.

struction; the letter "D“ means diago-

The DOT Code is a series of num-

nal or bias ply construction; and the

Speed

bers on a tire consisting of numbers

letter "B" means belted-bias ply con-

Rating

Maximum Speed

and English letters. The manufactur-

struction.

Symbol

ing date is designated by the last four

S

180 km/h (112 mph)

digits (characters) of the DOT code.

5. Maximum permissible infla-

T

190 km/h (118 mph)

tion pressure

DOT : XXXX XXXX OOOO

H

210 km/h (130 mph)

This number is the greatest amount

of air pressure that should be put in

V

240 km/h (149 mph)

The front part of the DOT means a

the tire. Do not exceed the maximum

W

270km/h (168mph)

plant code number, tire size and

permissible inflation pressure. Refer

tread pattern and the last four num-

Y

300km/h (186mph)

to the Tire and Loading Information

bers indicate week and year manu-

7

label for recommended inflation

factured.

pressure.

For example:

DOT XXXX XXXX 1516 represents

that the tire was produced in the 15th

week of 2016.

7-59

Content   ..  31  32  33  34   ..
