You can also adjust the clock by touching the clock
displayed on the upper right corner of the display or
the Clock icon on the home screen.
1. Touch the clock on the display.

The clock screen of the select face-type appears.

2. Select Settings.
3. Select Day & Time.
4. Select Set Date & Time.
5. Select Automatic Date & Time, then select OFF.
6. Select Set Date or Set Time.
7. Adjusting the dates, hours and minutes by

selecting /

8. Select Save to set the time.

You can customize the clock display to show the 12
hour clock or 24 hour clock.

2 Customized Features P. 381

You can customize the date display to MM/DD/YYYY,
DD/MM/YYYY or YYYY/MM/DD.

2 Customized Features P. 381

Models with Display Audio

3 4

Models with Display Audio

3 4

166

Co
ntrols

Locking and Unlocking the Doors

Key Types and Functions

This vehicle comes with the following keys:

Use the key to start and stop the engine, and to lock and unlock all the doors, fuel
fill door and to open the trunk.
You can also use the remote transmitter or smart entry system

to lock and unlock

all the doors, fuel fill door and to open the trunk.

Key Types and Functions

All the keys have an immobilizer system. The
immobilizer system helps to protect against vehicle
theft.

2 Immobilizer System P. 183

Follow the advice below to prevent damage to the
keys:

•

Do not leave the keys in direct sunlight, or in
locations with high temperature or high humidity.

•

Do not drop the keys or set heavy objects on them.

•

Keep the keys away from liquids, dust and sand.

•

Do not take the keys apart except for replacing the
battery.

If the circuits in the keys are damaged, the engine
may not start, and the remote transmitter may not
work.
If the keys do not work properly, have them
inspected by a dealer.

You can remotely start the engine using the remote.

2 Remote Engine Start with Vehicle

Feedback

P. 469

Models with remote engine starter

Models without smart entry system

Models with smart entry system

Models with smart entry system and
remote engine starter

* Not available on all models

167

Locking and Unlocking the Doors

Key Types and Functions

Co
ntrols

The built-in key can be used to lock/unlock the
doors or open the trunk when the remote
battery becomes weak and the power door
lock/unlock operation is disabled.

To remove the built-in key, slide the release
knob and then pull out the key. To reinstall
the built-in key, push the built-in key into the
remote until it clicks.

Contains a number that you will need if you
purchase a replacement key.

■

Built-in Key

Built-in Key

Release Knob

■

Key Number Tag

Key Number Tag

Keep the key number tag separate from the key in a
safe place outside of your vehicle.
If you wish to purchase an additional key, contact a
dealer.

If you lose your key and you cannot start the engine,
contact a dealer.

168

Locking and Unlocking the Doors

Low Remote Signal Strength

Co
ntrols

Low Remote Signal Strength

The vehicle transmits radio waves to locate the remote when locking/unlocking the
doors

, and fuel fill door

, opening the trunk

, or to start the engine.

In the following cases, locking/unlocking the doors

, and fuel fill door

, opening the

trunk

, or to start the engine may be inhibited or operation may be unstable:

• Strong radio waves are being transmitted by nearby equipment.
• You are carrying the remote together with telecommunications equipment,

laptop computers, cell phones, or wireless devices.

• A metallic object is touching or covering the remote.

Low Remote Signal Strength

Communication between the remote and the vehicle
consumes the remote’s battery.
Battery life is about two years, but this varies
depending on regularity of use.
The battery is consumed whenever the remote is
receiving strong radio waves. Avoid placing it near
electrical appliances such as televisions and personal
computers.

* Not available on all models

169

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Continued

Co
ntrols

Locking/Unlocking the Doors from the Outside

When you carry the remote, you can lock/
unlock the doors, fuel fill door, and open the
trunk.
You can lock/unlock the doors, fuel fill door
within a radius of about 32 inches (80 cm) of
the outside door handle. You can open the
trunk within about 32 inches (80 cm) radius
from the trunk release button.

■

Locking the doors

Touch the door lock sensor on the front door.

Some exterior lights flash; the beeper
sounds; all the doors and fuel fill door
lock; and the security system sets.

■

Using the Smart Entry with Push Button Start System

Locking/Unlocking the Doors from the Outside

If the interior light switch is in the door activated
position, the interior light comes on when you unlock
the doors.
No doors opened: The light fades out after 30
seconds.
Doors relocked: The light goes off immediately.

2 Interior Lights P. 221

Door Lock Sensor

Using the Smart Entry with Push Button Start System

If you do not open a door within 30 seconds of
unlocking the vehicle with the smart entry system,
the doors and trunk will automatically relock.

You can lock or unlock doors using the smart entry
system only when the power mode is in VEHICLE OFF.

•

Do not leave the remote in the vehicle when you
get out. Carry it with you.

•

Even if you are not carrying the remote, you can
lock/unlock the doors while someone else with the
remote is within range.

•

The door may be unlocked if the door handle is
covered with water in heavy rain or in a car wash if
the remote is within range.

•

If you grip a front door handle wearing gloves, the
door sensor may be slow to respond or may not
respond by unlocking the doors.

•

After locking the door, you have up to 2 seconds
during which you can pull the door handle to
confirm whether the door is locked.

* Not available on all models

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

170

Co
ntrols

■

Unlocking the doors and trunk

Grab the driver’s door handle:

The driver’s door and fuel fill door
unlocks.

Some exterior lights flash twice and the
beeper sounds twice.

Grab the front passenger’s door handle:

All the doors and fuel fill door unlock.

Some exterior lights flash twice and the
beeper sounds twice.

Press the trunk release button:

The trunk unlocks and opens.

A beeper will sound.

2 Using the Trunk Release Button

P. 181

Trunk Release Button

Using the Smart Entry with Push Button Start System

•

If you need to unlock the door immediately after
locking it, wait at least 2 seconds before gripping
the handle, otherwise the door will not unlock.

•

The door might not open if you pull it immediately
after gripping the door handle. Grip the handle
again and confirm that the door is unlocked before
pulling the handle.

•

Even within the 32 inches (80 cm) radius, you may
not be able to lock/unlock the doors with the
remote if it is above or below the outside handle.

•

The remote may not operate if it is too close to the
door and door glass.

The light flash, beep and door unlock mode settings
can be customized using the audio/information
screen.

2 Customized Features P. 381

* Not available on all models

Continued

171

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

■

Locking the vehicle (Walk away auto
lock®)

When you walk away from the vehicle while
carrying the remote, the doors will
automatically lock.
The auto lock function activates when all
doors are closed, and the remote is within
about 5 feet (1.5 m) radius of the outside door
handle.
Exit vehicle while carrying remote and close
door(s).
1. While within about 5 feet (1.5 m) radius of

the vehicle.

The beeper sounds; the auto lock
function will be activated.

2. Carry the remote beyond about 5 feet

(1.5 m) from the vehicle and remain outside
this range for 2 or more seconds.

Some exterior lights flash; the beeper
sounds; all doors will then lock.

Locking the vehicle (Walk away auto lock®)

The auto lock function is set to OFF as the factory
default setting. The auto lock function can be set to
ON using the audio/information screen.
If you set the auto lock function to ON using the
audio/information screen, only the remote that was
used to unlock the driver’s door prior to the setting
change can activate auto lock.

2 Customized Features P. 381

After the auto lock function has been activated,
when you stay within the locking/unlocking
operation range, the indicator on the remote will
continue to flash until the doors are locked.

When you stay beside the vehicle within the
operation range, the doors will automatically lock
approximately 30 seconds after the auto lock
function activating beeper sounds.

When you open a door after the auto lock function
activating beeper sounds, the auto lock function will
be delayed until all doors are closed.

When all doors have been closed and the remote is
inside the vehicle, or if the remote is not detected
within about 5 feet (1.5 m) of the vehicle, auto lock
function will not be activated.

If you press the unlock button on the remote within
the operation range soon after the auto lock function
activating beeper sounds, the auto lock function will
be canceled.

The activation range of
the auto lock function is
about 5 feet (1.5 m)

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

172

Co
ntrols

To temporarily deactivate the function:
1. Set the power mode to OFF.
2. Open the driver’s door.
3. Using the master door lock switch, operate

the lock as follows:
Lock

Unlock

Lock

Unlock.

The beeper sounds and the function is
deactivated.

To restore the function:
• Set the power mode to ON.
• Lock the vehicle without using the auto lock

function.

• Walk away at least more than about 5 feet

(1.5 m) away from the vehicle while
carrying the remote.

• Open any door.

Locking the vehicle (Walk away auto lock®)

The auto lock function does not operate when any of
the following conditions are met.

•

The remote is inside the vehicle.

•

A door or the hood is not closed.

•

The power mode is set to any mode other than
OFF.

•

The remote is not located within a radius of about
5 feet (1.5 m) from the vehicle when you get out of
the vehicle and close the doors.

Auto lock function operation stop beeper
After the auto lock function has been activated, the
auto lock operation stop beeper sounds for
approximately two seconds in the following cases.

•

The remote is put inside the vehicle through a
window.

•

You are located too close to the vehicle.

•

The remote is put inside the trunk.

If the warning beeper sounds, check that you are
carrying the remote. Then, open/close a door and
confirm the auto lock activation beeper sounds once.

In the case that the remote is out of operating range
when you close a door or the trunk, a beeper will
sound to indicate that the auto lock function has
been canceled.

Continued

173

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

■

Locking the doors

Press the lock button.
Once:

Some exterior lights flash, all the doors
and fuel fill door lock, and the security
system sets.

Twice (within five seconds after the first
push):

Some exterior lights flash, the beeper
sounds and verifies the security system is
set.

■

Unlocking the doors

Press the unlock button.
Once:

Some exterior lights flash twice, and the
driver’s door, fuel fill door unlocks.

Twice:

Some exterior lights flash twice, and the
remaining doors unlock.

■

Using the Remote Transmitter

Using the Remote Transmitter

If you do not open a door within 30 seconds of
unlocking the vehicle with the remote transmitter,
the doors will automatically relock.
You can change the relock timer setting.

2 Customized Features P. 370, 381

You can lock or unlock doors using the remote
transmitter only when the power mode in VEHICLE
OFF.

The remote transmitter uses low-power signals, so
the operating range may vary depending on the
surroundings.

The remote will not lock the vehicle when a door is
open.

If the distance at which the remote transmitter works
varies, the battery is probably low.
If the LED does not come on when you press a
button, the battery is dead.

2 Replacing the Button Battery P. 653

You can customize the door unlock mode setting.

2 Customized Features P. 370, 381

LED

Unlock Button

Lock Button

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

174

Co
ntrols

If the lock or unlock button of the remote does not work, use the key instead.

Fully insert the key and turn it.

■

Locking/Unlocking the Doors Using a Key

Locking/Unlocking the Doors Using a Key

When you lock the driver’s door with a key, all the
other doors and the fuel fill door lock at the same
time. When unlocking, the driver’s door unlocks first.
Turn the key a second time within a few seconds to
unlock the remaining doors.

You can customize the door unlock mode setting.

2 Customized Features P. 370, 381

Lock

Unlock

175

Locking and Unlocking the Doors

Locking/Unlocking the Doors from the Outside

Co
ntrols

If you do not have the key on you, or if for some reason you cannot lock a door using
the key, you can lock the door without it.

■

Locking the front doors

Push the lock tab forward

or push the

master door lock switch in the lock direction

, and close the door.

■

Locking the rear doors

Push the lock tab forward and close the door.

■

Lockout prevention system

The doors cannot be locked when the remote is inside the vehicle.

■

Locking a Door Without Using a Key

Locking a Door Without Using a Key

When you lock the driver’s door or lock the
passenger’s door using the master door lock switch,
all the other doors and the fuel fill door lock at the
same time.

Before locking a door, make sure that the key is not
inside the vehicle.

Content .. 9 10 11 12 ..
