ignition must be in at least mode I (p. 69). The

Tunnel console – 12-volt sockets

The electrical sockets can be used for 12-volt

accessories such as cell phone chargers and

coolers. For the socket to supply current, the

sockets are located between the cup holders

in the tunnel console and on the rear side of

the tunnel console (p. 119) for rear seat pas-

sengers.

The maximum current consumption is 10A

(120W) if only one of the 12-volt sockets in

the passenger compartment is in use. If both

the front and rear sockets are used at the

same time, the maximum current consump-

tion per socket is 7.5A (90W).
The auxiliary sockets can also be used to

power a cigarette lighter. Accessory cigarette

lighters and ashtrays can be purchased from

your Volvo retailer.

WARNING

Always keep the sockets covered when

not in use.

Related information

•

manually with the key blade, see Locking/

05 Loading and storage

120

Glove compartment

The glove compartment provides a lockable

storage compartment for small items.

The owner's manual and maps can be kept

here. There are also holders for pens and fuel

cards. The glove compartment can be locked

unlocking – glove compartment (p. 136).

Related information

•

Vanity mirror

The vanity mirrors are located on the upper

side of the sun visors.

The light comes on automatically when the

cover is lifted.

Related information

•

Bulbs – vanity mirror lighting (p. 293)

•

Loading – general

The load carrying capacity of your vehicle is

determined by factors such as the number of

passengers, the amount of cargo, the weight

of any accessories that may be installed, etc.

To increase loading space, the rear seat

backrests can be folded down, see Rear

seats – folding backrest (p. 74).

•

Unstable loads can be secured to the

load anchoring eyelets with straps or web

lashings to help keep them from shifting.

•

Stop the engine and apply the parking

brake when loading or unloading long

objects. The gear selector can be

knocked out of position by long loads,

which could set the vehicle in motion.

Related information

•

Load anchoring eyelets (p. 121)

•

Loading – roof load carriers (p. 121)

05 Loading and storage

121

Loading – roof load carriers

Using load carriers
Load carriers are available as Volvo accesso-

ries. Observe the following points when in

use:

•

To avoid damaging your vehicle and to

achieve maximum safety when driving,

we recommend using the load carriers

that Volvo has developed especially for

your vehicle.

•

Volvo-approved removable roof racks are

designed to carry the maximum allowable

roof load for this vehicle: 220 lbs (100 kg).

For non-Volvo roof racks, check the man-

ufacturer's weight limits for the rack.

•

Never exceed the rack manufacturer's

weigh limits and never exceed the maxi-

mum rated roof load of 220 lbs (100 kg).

•

Avoid single-point loads. Distribute loads

evenly.

•

Place heavier cargo at the bottom of the

load.

•

Secure the cargo correctly with appropri-

ate tie-down equipment.

•

Check periodically that the load carriers

and load are properly secured.

•

Remember that the vehicle's center of

gravity and handling change when you

carry a load on the roof.

•

The vehicle's wind resistance and fuel

consumption will increase with the size of

the load.

•

Drive smoothly. Avoid rapid starts, fast

cornering and hard braking.

Related information

•

Loading – general (p. 120)

•

Load anchoring eyelets (p. 121)

Load anchoring eyelets

WARNING

The two upper hooks shown in the illustra-

tion are for holding grocery bags only.

They are not intended for anchoring heavy

objects.

WARNING

•

Cover sharp edges on long loads to

help prevent injury to occupants.

Secure the load to help prevent shift-

ing during sudden stops.

•

Always secure large and heavy objects

with a seat belt or cargo retaining

straps.

•

Always secure the load to help prevent

it from moving in the event of sudden

stops.

•

Switch off the engine, apply the park-

ing brake and put the gear selector in

P when loading and unloading the

vehicle.

Related information

•

Loading – general (p. 120)

05 Loading and storage

122

Grocery bag holder

The grocery bag holder holds shopping bags

in place.

The grocery bag holder holds shopping bags

in place.
1.
2. Secure the shopping bags with the strap.

Related information

•

Loading – general (p. 120)

06 Locks and alarm

124

Remote key and key blade

WARNING

Never leave the remote key in the ignition

slot if children are to remain in the vehicle.

For more information on the various ignition

modes, see Ignition modes (p. 69).

Related information

•

•

Remote key – range (p. 128)

•

Remote key – loss

If either of the remote keys (p. 124) is lost, the

other should be taken with the vehicle to a

Volvo retailer. As an anti-theft measure, the

code of the lost remote key must be erased

from the system.

Additional or duplicate remote control keys

can be obtained from any authorized Volvo

retailer.
You can also obtain additional or duplicate

remote control keys from certain inde-

pendent repair facilities and locksmiths

that are qualified to make remote control

keys. Each key must be programmed to

work with your vehicle.
California Only:
A list of independent repair facilities and/or

locksmiths known to Volvo that can cut

and code replacement keys can be found:

•

on the Volvo website at

http://www.volvocars.com/us/keys

•

by calling Volvo Customer Care at

1-800-458-1552

The number of registered keys for the vehicle

can be found by pressing MY CAR and going
into

Settings

Information

Number of

keys

. For a description of the menu system,

see My Car – introduction (p. 66).
USA-5WK49264

FCC ID:KR55WK49264 + Siemens VDO

5WK49236
FCC ID:KR55WK49236, 5WK49266
FCC ID:KR55WK49266 + Siemens VDO

5WK49233
FCC ID:KR55WK49233
This device complies with part 15 of the FCC

rules and RSS-210. Operation is subject to

the following conditions: (1) This device may

not cause harmful interference, and (2) this

device must accept any interference

received, including interference that may

cause undesired operation.
Canada-5WK49264
IC:267T-5WK49264 + Siemens VDO

5WK49236
IC:267T-5WK49236, 5WK49266
IC:267T-5WK49266 + Siemens VDO

5WK49233
IC:267T-5WK49233
Operation is subject to the following condi-

tions: (1) this device may not cause interfer-

ence, and (2) this device must accept any

interference, including interference that may

cause undesired operation of the device.

Related information

•

more information on this feature, see Front

06 Locks and alarm

}}

Option/accessory, for more information, see Introduction.

125

Key memory

The memory in the remote key makes it possi-

ble to store certain personal settings.

The position of the side door mirrors, power

driver's seat* and the selected instrument
panel theme

are stored in the remote keys

when the vehicle is locked. The next time the

driver's door is unlocked with the same

remote key and the door is opened within

2 minutes, the power driver's seat and side

door mirrors will automatically move to the

position that they were in when the doors

were most recently locked with the same

remote key. If the seat/mirrors have not been

readjusted since the vehicle was locked, they

will already be in the position stored in that

particular remote key and will not move. For

seats – power seat (p. 71).
This feature can be activated or deactivated

in the vehicle's menu by pressing MY CAR
and going into

Settings

Car settings

Car key memory

. For a description of the

menu system, see My Car – introduction

(p. 66).

optional keyless drive, see Keyless drive*–

If the vehicle is locked with the remote key

or is left unlocked for more than 30

minutes, the key memory function will be

deactivated.
To reactivate the key's memory:

•

Press the unlock button on the remote

key.

For information regarding vehicles with the

locking/unlocking (p. 131).

Related information

•

Locking/unlocking confirmation (p. 125)

Locking/unlocking confirmation

Settings can be made in the menu system for

audible and visual confirmation when the

vehicle has been locked or unlocked. With

these functions activated, the following will

occur when the vehicle is locked/unlocked:

Locking confirmation

•

The turn signals flash once, an audible

signal sounds and the door mirrors will

fold* in.

Unlocking confirmation

•

The turn signals will flash twice and the

door mirrors will fold* out.

Making a setting

Different alternatives for locking/unlocking

confirmation can be selected in the menus by

pressing MY CAR on the center console con-

trol panel.

•

To activate visual confirmation: go to

Settings

Car settings

Light

settings

and select

Door lock

confirmation light

and/or

Unlock

confirmation light

by pressing OK/

MENU.

•

To activate audible confirmation: go to

Settings

Car settings

Lock

settings

and select

Audible

confirmation

by pressing OK/MENU.

For a description of the menu system, see My

Car – introduction (p. 66).

Optional digital instrument panel only

06 Locks and alarm

126

Option/accessory, for more information, see Introduction.

Lock indicator

Lock/alarm indicator light

A flashing indicator light at the base of the

windshield verifies that the vehicle is locked.

Related information

•

Locking/unlocking – from the outside

(p. 134)

•

Locking/unlocking – from inside (p. 135)

Immobilizer (start inhibitor)

The immobilizer is a start inhibitor that helps

prevent unauthorized persons from starting

the engine.
Each of the keys supplied with your vehicle

contains a coded transponder. The code in

the key is transmitted to an antenna in the

ignition slot where it is compared to the code

stored in the start inhibitor module. The vehi-

cle will start only with a properly coded key. If

you misplace a key, take the other keys to a

trained and qualified Volvo service technician

for reprogramming as an anti-theft measure.

The following messages (which may appear in

the instrument panel display) are related to

the immobilizer:

Message

Meaning

Insert car

key

Remote key not recognized

during start. Try to start the

vehicle again.

Car key

not found

Vehicles with keyless drive*

only. Remote key not recog-

nized during start. Try to

start the vehicle again.
If the problem continues,

insert the remote key into the

ignition slot and try to start

the vehicle again.

Immobil-

izer Try

start

again

Remote key fault during

start. Contact an authorized

Volvo workshop.

CAUTION

Never use force when inserting the remote

key in the ignition slot. The vehicle cannot

be started if the transponder is damaged.

USA–FCC ID: LTQWFS 125VO
This device complies with part 15 of the FCC

rules. Operation is subject to the following

condition: (1) This device may not cause

harmful interference, and (2) this device must

accept any interference received, including

06 Locks and alarm

Option/accessory, for more information, see Introduction.

127

interference that may cause undesired opera-

tion.
Canada–IC: 3659A-WFS125VO
Operation is subject to the following condi-

tions: (1) this device may not cause interfer-

ence, and (2) this device must accept any

interference, including interference that may

cause undesired operation of the device.
For information on starting the vehicle, see

Starting the engine (p. 211).

Remote key – functions

The remote key is used e.g., to unlock the

doors and start the engine.

Buttons on the remote

Unlock – Press the Unlock button on the

remote once to unlock the driver's door.
This function can be changed so that all

doors unlock at the same time by pressing
My Car and going to

Settings

Car

settings

Lock settings

Change doors

unlock setting

. For a description of the menu

system, see My Car – introduction (p. 66).

Approach lighting – As you approach

the vehicle, press the button on the remote

key to light the interior lighting, parking lights,

license plate lighting and the lights in the door

mirrors*.
These lights will switch off automatically after

30, 60 or 90 seconds. For a description of the

menu system, see My Car – introduction

(p. 66).

Panic alarm – This button can be used

to attract attention during emergency situa-

tions.
To activate the panic alarm, press and hold

this button for at least 3 seconds or press it

twice within 3 seconds. The turn signals and

horn will be activated. The panic alarm will

stop automatically after 2 minutes and

45 seconds.
To deactivate, wait approximately 5 seconds

and press the button again.
The Panic alarm button will not unlock the

vehicle.

Related information

•

Locking/unlocking – from inside (p. 135)

•

Locking/unlocking – from the outside

(p. 134)

•

Locking/unlocking confirmation (p. 125)

06 Locks and alarm

128

Remote key – range

The remote key has a range of approximately

60 ft. (20 m) from the vehicle.

with the key blade, see Alarm-related func-

Buildings or other obstacles may interfere

with the function of the remote key. The

vehicle can also be locked or unlocked

tions (p. 138).

If the remote key is removed from the vehicle

while the engine is running or if the ignition is

in mode I or II and all of the doors are closed,

a message will appear in the instrument panel

display and there will be an audible signal.
When the remote key is returned to the vehi-

cle, the message will be erased and the audi-

ble signal will stop after one of the following

has been done:

•

The remote key is inserted in the ignition

slot

•

The vehicle's speed exceeds 20 mph

(30 km/h)

•

The OK button on the left steering wheel

lever is pressed

Related information

•

Detachable key blade – unlocking

Detachable key blade – general

information

The visible ends of these key blades are

unique to make it easier to identify "your"

remote key.

Related information

•

(p. 129)

•

Detachable key blade – detaching/rein-

serting (p. 128)

Detachable key blade – detaching/

reinserting

The detachable key blade (p. 128) can be

removed or reinserted in the remote key as

follows:

Removing the key blade

Slide the spring loaded catch to the side.

Pull the key blade straight out of the

remote key.

Reinserting the blade
1. Hold the remote key with the slot for the

key blade up.

2. Carefully slide the key blade into its

groove.

3. Gently press the key blade in the groove

until it clicks into place.

06 Locks and alarm

}}

129

Related information

•

Detachable key blade – unlocking

(p. 129)

•

Child safety locks (p. 56)

Detachable key blade – unlocking

Your vehicle's remote key (p. 124) contains a

metal, detachable key blade that can be used

to unlock the driver's door, lock the glove

compartment, etc.

If the remote key does not function normally

(weak battery, etc.), the vehicle can be

unlocked with the detachable key blade.
1. Remove the detachable key

blade (p. 128) from the remote key.

2. Press the key blade approx. 0.5 in. (1 cm)

straight up in the hole on the underside of

the keyhole cover.
> The cover will come off due to the

pressure exerted when the key blade is

pushed upward.

3. Insert the key blade as far as possible in

the driver's door lock. Turn the key blade

to unlock the driver's door. This will trig-

ger the alarm.

4. To turn off the alarm, insert the remote

key in the ignition slot. This also applies

to vehicles equipped with the optional

keyless drive.

5. Press the cover back into place after the

door has been unlocked.

Related information

•

Remote key and key blade (p. 124)

•

Remote key – replacing the battery

(p. 129)

Remote key – replacing the battery

The remote key can be opened if the battery

needs to be replaced.

The battery should be replaced if:

•

The information symbol illuminates and

Low battery in remote control. Please

change batteries.

is shown in the dis-

play and/or

•

if the locks do not react after several

attempts to unlock or lock the vehicle.

The remote key's range is normally

approximately 60 ft (20 m) from the vehi-

cle.

06 Locks and alarm

130

Opening the remote key

The remote key has one CR 2430, 3V battery

only

To open the remote key

Slide the spring loaded catch to the

side.

Pull the key blade straight out of the

remote key.

Insert a small screwdriver in the hole

behind the spring loaded catch and care-

fully pry up the cover. Turn the remote

key with the buttons upward so that the

battery does not fall out when the cover is

removed.

Inserting a new battery

CAUTION

When handling batteries, avoid touching

their contact surfaces as this could result

in poor battery function in the remote key.

Note the position of the battery's (+) or (–)

sides.
1. Use a screwdriver to pry out the old bat-

tery.

2. Insert a new one with the (+) side down-

ward.

Closing the remote key

1. Press the remote key's cover into place.
2. Hold the remote key with the slot for the

key blade up.

3. Carefully slide the key blade into its

groove.

4. Gently press the key blade in the groove

until it clicks into place.

Volvo recommends that the batteries used

in the remote control meet the UN Manual

of Test and Criteria, Part III, sub-section

38.3.
Batteries installed in the key from the fac-

tory and batteries exchanged by an

authorized Volvo workshop fulfill the above

criteria.
Old batteries should be disposed of prop-

erly at a recycling center or at your Volvo

retailer.

Related information

•

06 Locks and alarm

}}

Option/accessory, for more information, see Introduction.

131

Keyless drive*– locking/unlocking

This system makes it possible to unlock and

lock the vehicle without having to press any

buttons on the remote key. It is only neces-

sary to have a keyless drive remote key in

your possession to operate the central locking

system.

mation, see Remote key and key blade

•

The gear selector must in the P posi-

tion before the vehicle can be locked

and the alarm can be armed.

•

The buttons on the keyless drive

remote key can also be used to lock

and unlock the vehicle. For more infor-

(p. 124).

Both of the remote keys provided with the

vehicle have the keyless function, and addi-

tional ones can be ordered. The system can

accommodate up to six remote keys.
The red rings in the illustration indicate the

area around the vehicle that is within range of

the keyless drive antennas.

Locking the vehicle

For a description of the menu system, see My

Unlocking the vehicle
The number of doors that are unlocked at the

same time can be set in the vehicle's menu

system. Press MY CAR and go to

Car

settings

Lock settings

Keyless entry

Car – introduction (p. 66).

Related information

•

Alarm indicator (p. 137)

Keyless drive* – unlocking with key

blade

If the remote key does not function normally

(weak battery, etc.), the vehicle can be

unlocked with the detachable key blade.

Driver's door keyhole cover

1. Remove the key blade from the remote

key (see Detachable key blade – detach-

ing/reinserting (p. 128) for instructions).

2. Press the key blade approx. 0.5 in. (1 cm)

straight up in the hole on the underside of

the keyhole cover.
> The cover will come off due to the

pressure exerted when the key blade is

pushed upward.

3. Insert the key blade as far as possible in

the driver's door lock. Turn the key blade

to unlock the driver's door. This will trig-

ger the alarm.

06 Locks and alarm

132

Option/accessory, for more information, see Introduction.

4. To turn off the alarm, insert the remote

key in the ignition slot. This also applies

to vehicles equipped with the optional

keyless drive.

5. Press the cover back into place after the

door has been unlocked.

Related information

•

Keyless drive*– locking/unlocking (p. 131)

•

Alarm – general information (p. 136)

Keyless drive* – key memory

When you leave the vehicle with a remote key

in your possession and lock any door, the
position of the driver's seat

and door mirrors

will be stored in the remote key's memory.

The next time a door is opened by a person

with the same remote key in his/her posses-

sion, the driver's seat and door mirrors will

automatically move to the position that they

were in when the door was most recently

locked.

If several people carrying remote keys

approach the vehicle at the same time, the

driver's seat and door mirrors will assume

the positions they were in for the person

who opens the driver's door.

on adjusting and storing the seat's position in

the seat memory.

Keyless drive*– locking/unlocking (p. 131)

If the vehicle is locked by pressing the but-

ton on one of the door handles or by

pressing the lock button on the remote

key, or if it is left unlocked for more than

30 minutes, the key memory function will

be deactivated.
To reactivate the key's memory:

•

Unlock the vehicle by pulling a door

handle with the remote key in your

possession or by pressing the unlock

button on the remote key.

Related information

•

•
