Volvo S60 Inscription (2016 year). Manual

03 Instruments and controls

Option/accessory, for more information, see Introduction.

Front interior lighting

The lighting in the front part of the passenger

compartment is controlled with the buttons in

the ceiling console.

G021149

Light switches, front roof lighting

Drivers side front reading light, on/off

Passenger's side front reading light,

on/off
Overhead courtesy lighting.

Switch (3) has three positions for all passen-

ger compartment lighting:

•

Off: right side depressed, automatic light-

ing off.

•

Neutral position: automatic lighting is

on.

•

On – left side depressed, passenger

compartment lighting on.

Overhead courtesy lighting

The passenger compartment lighting is

switched on and off automatically when but-

ton (3) is in the neutral position.
The lighting comes on and remains on for

30 seconds if:

•

the vehicle is unlocked from the outside

with the key or remote control

•

the engine is switched off and the ignition

is in mode 0.

The lighting switches off when:

•

the engine is started

•

the vehicle is locked from the outside.

The lighting comes on and remains on for two

minutes if one of the doors is open.
The passenger compartment lighting can be

switched on and off manually within

30 minutes after the vehicle has been

unlocked.
If the lighting is switched on manually and the

vehicle is locked, the courtesy lighting will

switch off automatically after one minute.

Courtesy lights/door step lighting*

The courtesy lights/door step lighting switch

on/off automatically when one of the front

doors is opened/closed.

Glove compartment lighting

The glove compartment lighting switches

on/off automatically when the lid is opened/

closed.

Related information

•

Rear interior lighting (p. 83)

03 Instruments and controls

Rear interior lighting

The lights are switched on or off by pressing

each respective button.

Related information

•

Front interior lighting (p. 82)

Home safe lighting

When you leave your vehicle at night, you can

make use of the home safe lighting function

to illuminate the area in front of the vehicle.

This function illuminates the headlights, park-

ing lights, lights in the door mirrors, license

plate lights, front ceiling lighting and footwell
lighting. These lights will remain on for 30

60 or 90 seconds. The time interval can be
set in MY CAR under

Settings

Car

settings

Light settings

Home safe

light duration

. See My Car – introduction

(p. 66) for a description of the menu system.
1. Remove the key from the ignition slot to

put the ignition in mode 0 (see Ignition

modes (p. 69) for information about the

ignition modes).

2. Pull the turn signal lever as far as possible

towards the steering wheel and release it.

3. Exit the vehicle and lock the doors.

Related information

•

Approach lighting (p. 83)

Approach lighting

Approach lighting activates the parking lights,

door mirror lights, license plate lighting, dome

lighting and door step lighting when you

approach the vehicle.

This function is activated by pressing the

approach light button on the remote key (see

the illustration in Remote key – functions

(p. 127)).
The time interval for this lighting can be set

by pressing MY CAR and going to

Car

settings

Light settings

Approach light

duration

. See My Car – introduction (p. 66)

for a description of the menu system.

Related information

•

Home safe lighting (p. 83)

Factory setting

03 Instruments and controls

Option/accessory, for more information, see Introduction.

Windshield wipers

Move the lever toward the steering wheel to

start the windshield and headlight washers.

After the lever is released the wipers make

several extra sweeps.

CAUTION

•

Use ample washer fluid when washing

the windshield. The windshield should

be thoroughly wet when the wipers are

in operation.

•

Before using the wipers, ice and snow

should be removed from the wind-

shield/rear window. Be sure the wiper

blades are not frozen in place.

Windshield wipers off

Move the lever to position 0 to

switch off the windshield wipers.

Single sweep

Move the lever upward from posi-

tion 0 to sweep the windshield one

stroke at a time for as long as the

lever is held up.

Intermittent wiping

With the lever in this position, you

can set the wiper interval by twisting

the thumb wheel upward to increase

wiper speed or downward to decrease the

speed.

Continuous wiping

The wipers operate at normal

speed.
The wipers operate at high speed.

Windshield wiper service position

The windshield wipers must be in the service

position before the wiper blades can be

cleaned or replaced. See Wiper blades –

service position (p. 293) for additional infor-

mation.

Related information

•

Engine compartment – washer fluid

(p. 295)

Rain sensor*

The rain sensor automatically regulates wiper

speed according to the amount of water on

the windshield.

The sensitivity of the rain sensor can be

adjusted moving the thumb wheel up (the

wipers will sweep the windshield more fre-

quently) or down (the wipers will sweep the

windshield less frequently).

NOTE

The wipers will make an extra sweep each

time the thumb wheel is adjusted upward.

When the rain sensor is activated, the symbol

will illuminate in the instrument panel.

Activating and setting the sensitivity

When activating the rain sensor, the vehicle

must be running or in ignition mode II and the

windshield wiper lever must be in position 0

or in the single sweep position.
Activate the rain sensor by pressing the but-
ton

. The windshield wipers will make

one sweep.
Press the lever up for the wipers to make an

extra sweep. The rain sensor returns to active

mode when the stalk is released back to

position 0.

03 Instruments and controls

Option/accessory, for more information, see Introduction.

Deactivating

Deactivate the rain sensor by pressing the
button

or press the lever down to

another wiper position.
The rain sensor is automatically deactivated

when the key is removed from the ignition

slot or five minutes after the ignition has been

switched off.

CAUTION

The rain sensor should be deactivated

when washing the car in an automatic car

wash, etc. If the rain sensor function is left

on, the wipers will start inadvertently in the

car wash and could be damaged.

Windshield washer

Move the lever toward the steering wheel to

start the windshield and headlight washers.

After the lever is released the wipers make

several extra sweeps.

Heated washer nozzles*
The washer nozzles are heated automatically

in cold weather to help prevent the washer

fluid from freezing.

High-pressure headlight washing*
High-pressure headlight washing consumes a

large quantity of washer fluid. To save fluid,

the headlights are washed using two alterna-

tives:

•

Low/high beam headlights on. The

headlights will be washed the first time

the windshield is washed. Thereafter, the

headlights will only be washed once for

every five times the windshield is washed

within a 10-minute period.

•

Parking lights on. Optional Active Bend-

ing Lights will be washed once for every

five times the windshield is washed. Nor-

mal halogen headlights will not be

washed.

CAUTION

•

Use ample washer fluid when washing

the windshield. The windshield should

be thoroughly wet when the wipers are

in operation.

•

When approx. 1 US quart (1 liter) of

washer fluid remains in the reservoir,

the headlights will no longer be

washed. A text message will also be

displayed to remind the driver to fill the

washer fluid reservoir.

Related information

•

Engine compartment – washer fluid

(p. 295)

03 Instruments and controls

Tailgate wiper/washer

The tailgate wiper operates at two speeds:

intermittent and continuous.

NOTE

The rear wiper is equipped with a cut-off

function, which means that it will not oper-

ate if its electric motor overheats. The

wiper will function again after a cool-down

period (30 seconds or longer, depending

on the heat of the motor and ambient tem-

perature conditions).

Tailgate wiper and reverse gear
If the windshield wipers are on and the trans-

mission is put into reverse gear, the tailgate

wiper will go into intermittent wiping func-
tion

. This function is deactivated when a dif-

ferent gear is selected.

NOTE

On vehicles with the optional rain sensor,

the tailgate wiper will be activated when

reverse is selected, if the rain sensor is

activated and it is raining.

If the tailgate wiper is in the normal (continu-

ous) wiping mode, selecting different gears

will not affect its function.

Related information

•

Engine compartment – washer fluid

(p. 295)

Power windows

All power windows can be operated using the

control panel in the driver's door. The control

panels in the other doors only operate the

window in the respective doors.

WARNING

•

Always remove the ignition key when

the vehicle is unattended to put the

ignition in mode 0 (see Ignition modes

(p. 69) for information about the igni-

tion modes).

•

Never leave children unattended in the

vehicle.

•

Make sure that the windows are com-

pletely unobstructed before they are

operated.

Operating
For the power windows to function, the igni-

tion must be in at least mode I. When the

vehicle has been running, the power windows

can be operated for several minutes after the

remote key has been removed from the igni-

tion slot, or until a door has been opened.

Consult your Volvo retailer if you would like to have this function deactivated.

03 Instruments and controls

}}

Option/accessory, for more information, see Introduction.

NOTE

•

Movement of the windows will stop if

they are obstructed in any way.

•

To reduce buffeting wind noise if the

rear windows are opened, also open

the front windows slightly.

Manual up/down

–

Move one of the controls up/down

slightly.
> The power windows move up/down as

long as the control is held in position.

Auto up/down

–

Move one of the controls up/down as far

as possible and release it.
> The window will open or close com-

pletely.

Resetting
If the battery has been disconnected, the

auto open function must be reset so that it

will work properly.
1. Gently raise the front section of the but-

ton to close the window and hold it for

one second.

2. Release the button briefly.
3. Raise the front section of the button again

for one second.

Power door mirrors

The control on the driver's door is used to

adjust the position of the door mirrors.

Adjusting
1. Press the L button for the left door mirror

or the R button for the right door mirror.

The light in the button comes on.

2. Adjust the position with the joystick in the

center.

3. Press the L or R button again. The light

should no longer be on.

WARNING

Objects seen in the mirrors may appear

further away than they actually are.

Retractable power door mirrors*
The mirrors can be retracted for parking/driv-

ing in narrow spaces:
1. Press down the L and R buttons at the

same time.

2. Release them after approximately one

second. The mirrors automatically stop in

the fully retracted position.

Fold out the mirrors by pressing down the L

and R buttons at the same time. The mirrors

automatically stop in the fully extended posi-

tion.

Storing the position*
The mirror positions are stored in the key

memory when the vehicle has been locked

with the remote key. When the vehicle is

unlocked with the same remote control the

mirrors and the driver's seat adopt the stored

positions when the driver's door is opened.
The function can be activated/deactivated in
MY CAR under

Settings

Car settings

Car key memory

Personal settings in

key memory

. See My Car – introduction

(p. 66) for a description of the menu system.

03 Instruments and controls

Option/accessory, for more information, see Introduction.

Tilting the door mirrors when parking*

The door mirrors can be tilted down to help

give the driver a better view along the sides of

the vehicle, for example when parallel park-

ing.
To activate this function, select reverse gear

and press the L or R mirror control button to

tilt the mirror down.
The function can be activated/deactivated in
MY CAR under

Settings

Car settings

Side mirror settings

Tilt left mirror

Tilt

right mirror

. See My Car – introduction

(p. 66) for a description of the menu system.
The door mirror will reset to its normal posi-

tion:

•

after 10 seconds when reverse is disen-

gaged and the car remains stopped.

•

immediately when reverse is disengaged

and the vehicle's forward speed exceeds

approximately 6 mph (10 km/h).

•

immediately if you press the correspond-

ing L or R button again.

•

when the engine is turned off.

•

when the side mirrors are folded in.

NOTE

Only one mirror can be tilted down at a

time.

Home safe and approach lighting
The light on the door mirrors comes on when

approach lighting or home safe lighting is

selected, see Approach lighting (p. 83) and

Home safe lighting (p. 83).

Related information

•

Interior rearview mirror (p. 90)

•

Heated windshield*, rear window and

door mirror defrosters (p. 89)

•

Power door mirrors – automatic tilting/

retraction (p. 88)

Power door mirrors – automatic

tilting/retraction

The control on the driver's door is used to

adjust the position of the door mirrors.

Automatically tilting the door mirrors
when parking
The door mirrors can tilt down automatically

to help give the driver a better view along the

sides of the vehicle, for example when paral-

lel parking. When the transmission is no

longer in reverse, the mirrors will automati-

cally return to their original position.
This function can be activated/deactivated in
MY CAR under

Settings

Car settings

Side mirror settings

In reverse gear tilt

left mirror

In reverse gear tilt right

mirror

. See My Car – introduction (p. 66) for

information about the MY CAR menu system.

Automatic retraction when locking
When the vehicle is locked/unlocked with the

remote key the door mirrors are automatically

retracted/extended.
The function can be activated/deactivated in
MY CAR under

Settings

Car settings

Side mirror settings

Retract side mirrors

when locking

. See My Car – introduction

(p. 66) for a description of the menu system.

03 Instruments and controls

Option/accessory, for more information, see Introduction.

Resetting to neutral
Mirrors that have been moved out of position

by an external force must be electrically reset

to the neutral position for electric retracting/

extending to work.

•

Retract the mirrors with the L and R but-

tons.

•

Fold them out again with the L and R but-

tons.

The mirrors are now reset in neutral position.

Related information

•

Interior rearview mirror (p. 90)

•

Heated windshield*, rear window and

door mirror defrosters (p. 89)

Heated windshield*, rear window and

door mirror defrosters

The heating function is used to defrost/de-ice

the windshield and/or the rear window and

door mirrors.

Max. defroster/heated windshield (1), rear win-

dow and door mirror defroster (2)

Press button (1) to defrost/de-ice the wind-

shield and/or button (2) to defrost the rear

window and door mirrors. The indicator lights

in the respective buttons indicate that the

function is active. Switch the function off

when then windshield/rear window/mirrors

have cleared to help avoid battery drain. The

heating function will also switch off automati-

cally after a certain amount of time.
Auto-defrosting for the rear window and door

mirrors (if the vehicle is started when the

ambient temperature is below 45 °F (7 °C)

can be selected in MY CAR under

Settings

Climate settings

Automatic rear

defroster

. See My Car – introduction (p. 66)

for a description of the menu system.

03 Instruments and controls

Option/accessory, for more information, see Introduction.

Interior rearview mirror

The interior rearview mirror has an auto-dim

function that helps reduce glare from follow-

ing vehicle's headlights.

Auto-dim function
The interior rearview mirror’s auto-dim func-

tion is controlled by two sensors: one point-

ing forward (located on the forward-facing

side of the mirror, which monitors the amount

of ambient light) and one pointing rearward

(located on the side of the mirror facing the

driver at the upper edge, which senses the

strength of following vehicles' headlights),

and work together to help eliminate glare.

NOTE

Related information

•

Power door mirrors (p. 87)

Digital compass*

The rear-view mirror has an integrated display

that shows the compass direction in which

the vehicle is traveling.

Operation
Eight different directions are shown with the

abbreviations:

(north),

(north east),

(east),

(southeast),

(south),

(south-

west),

(west) and

(northwest).

Calibration
North America is divided into 15 magnetic

zones and the compass will need to be cali-

brated if the vehicle is driven into a new one

(see the magnetic zones on the map in the

following section "Selecting a magnetic

zone"). To do so:
1. Stop the vehicle in a large open area,

safely out of traffic and away from steel

structures and high-tension electrical

wires.

2. Start the vehicle.

NOTE

•

For best calibration results, switch off

all electrical equipment in the vehicle

(climate system, windshield wipers,

audio system, etc.) and make sure that

all doors are closed.

•

Calibration may not succeed or be

incorrect if the vehicle's electrical

equipment is not switched off.

3.
4. Press and hold the button for 3 seconds

until the number of the current magnetic

zone is displayed.

5. Press the button repeatedly until the

number of the desired magnetic zone

(

1-15

) is displayed. See the magnetic

zones on the map in the following section

"Selecting a magnetic zone").

6. Wait until

is again displayed in the mir-

ror.

7. Drive slowly in a circle at a speed of no

more than 6 mph (10 km/h) until a direc-

tion is displayed. This indicates that cali-

bration is complete.

8. Drive around in a circle an additional two

times to fine-tune the calibration.

03 Instruments and controls

}}

Option/accessory, for more information, see Introduction.

9. Vehicles with an electrically heated

windshield:* if

is displayed when the

heating function is activated, perform

step 7 with the heating function on. See

also Max. defroster and electrically

heated windshield* (p. 112) for additional

information about the heated windshield.

Repeat the calibration procedure if neces-

sary.

Selecting a magnetic zone

G018632

Magnetic zones.

The earth is divided into 15 magnetic zones.

The correct zone must be selected for the

compass to work correctly.
1. Put the ignition in mode II.
2. Using a pen or similar object, press and

hold the button on the rear side of mirror

for at least 3 seconds. The number for the

current area will be shown.

3. Press the button repeatedly until the

number for the required geographic area

(1 – 15) is shown.

4. The display will revert to showing the

compass direction after several seconds.

HomeLink

Wireless Control System*

– introduction

HomeLink

can be used to open garage

doors, gates, etc.

WARNING

•

If you use HomeLink

to open a

garage door or gate, be sure no one is

near the gate or door while it is in

motion.

•

When programming a garage door

opener, it is advised to park outside of

the garage.

•

Do not use HomeLink

with any

garage door opener that lacks safety

stop and reverse features as required

by U.S. federal safety standards (this

includes any garage door opener

model manufactured before April 1,

1982). A garage door that cannot

detect an object - signaling the door to

stop and reverse - does not meet cur-

rent U.S. federal safety standards. For

more information, contact HomeLink

at: www.homelink.com.

03 Instruments and controls

Option/accessory, for more information, see Introduction.

The HomeLink

®19

Wireless Control System

provides a convenient way to replace up to

three hand-held radio-frequency (RF) trans-

mitters used to activate devices such as gate

operators, garage door openers, entry door

locks, security systems, even home lighting.

Additional information can be found on the

Internet at, www.homelink.com/

www.youtube.com/HomeLinkGentex or by

phoning the hotline at 1–800–355–3515.
Retain the original transmitter of the RF

device you are programming for use in other

vehicles as well as for future HomeLink pro-

gramming. It is also suggested that upon the

sale of the vehicle, the programmed Home-

Link buttons be erased for security purposes.

Refer to “Resetting HomeLink Buttons” in
HomeLink

Wireless Control System* – pro-

gramming (p. 92).

Using HomeLink
To operate, simply press and hold the pro-

grammed HomeLink button until the trained

device begins to operate (this may take sev-

eral seconds). Activation will now occur for

the trained device (i.e., garage door opener,

gate operator, security system, entry door

lock, home/office lighting, etc.). For conven-

ience, the hand-held transmitter of the device

may also be used at any time. In the event

that there are still programming difficulties or

questions, contact HomeLink at:

www.homelink.com/www.youtube.com/

HomeLinkGentex or by phoning the hotline at

1–800–355–3515.

NOTE

If the ignition is switched off, HomeLink

will function for 30 minutes after the driv-

er's door has been opened.

HomeLink

Wireless Control System*

– programming

The HomeLink Wireless Control System pro-

vides a convenient way to replace up to three

hand-held radio-frequency (RF) transmitters

used to activate devices such as gate opera-

tors, garage door openers, entry door locks,

security systems, even home lighting. Addi-

tional information can be found on the Inter-

net atwww.homelink.com/www.youtube.com/

HomeLinkGentex or by phoning the hotline at

1–800–355–3515.

NOTE

Some vehicles may require the ignition to

be switched on or be in the “accessories”

position for programming and/or operation

of HomeLink. It is also recommended that

a new battery be placed in the hand-held

transmitter of the device being pro-

grammed to HomeLink for quicker training

and accurate transmission of the radio-fre-

quency signal. The HomeLink buttons

must be reset first. When this has been

completed, Homelink is in learning mode

so that you can perform programming.

1. Position the end of your hand-held trans-

mitter 1–3 inches (5–14 cm) away from

the HomeLink button you wish to pro-

gram while keeping the indicator light in

view.

HomeLink and the HomeLink house are registered trademarks of Gentex Corporation.

03 Instruments and controls

}}

2. Simultaneously press and hold both the

chosen HomeLink and hand-held trans-

mitter buttons until the HomeLink indica-

tor light changes from a slow to a rapidly

blinking light. Now you may release both

the HomeLink and hand-held transmitter

buttons.

NOTE

Some devices may require you to replace

this Programming Step 2 with procedures

noted in the “Gate Operator / Canadian

Programming” section. If the HomeLink

indicator light does not change to a rapidly

blinking light after performing these steps,

contact HomeLink at www.homelink.com/

www.youtube.com/HomeLinkGentex or by

phoning the hotline at 1–800–355–3515.

3. Firmly press, hold for five seconds and

release the programmed HomeLink but-

ton up to two separate times to activate

the door. If the door does not activate,

press and hold the just-trained HomeLink

button and observe the indicator light.

•

If the indicator light stays on con-

stantly, programming is complete

and your device should activate when

the HomeLink button is pressed and

released.

•

If the indicator light blinks rapidly for

two seconds and then turns to a

constant light continue with “Pro-

gramming” steps 4-6 to complete the

programming of a rolling code equip-

ped device (most commonly a garage

door opener).

4. At the garage door opener receiver

(motor-head unit) in the garage, locate

the “learn” or “smart” button. This can

usually be found where the hanging

antenna wire is attached to the motor-

head unit.

5. Firmly press and release the “learn” or

“smart” button. (The name and color of

the button may vary by manufacturer.)

There are 30 seconds to initiate step 6.

6. Return to the vehicle and firmly press,

hold for two seconds and release the pro-

grammed HomeLink button. Repeat the

“press/hold/release” sequence a second

time, and, depending on the brand of the

garage door opener (or other rolling code

equipped device), repeat this sequence a

third time to complete the programming

process.

HomeLink should now activate your rolling

code equipped device.

03 Instruments and controls

Gate Operator/Canadian Programming

Canadian radio-frequency laws require trans-

mitter signals to “time-out” (or quit) after sev-

eral seconds of transmission – which may not

be long enough for HomeLink to pick up the

signal during programming. Similar to this

Canadian law, some U.S. gate operators are

designed to “time-out” in the same manner.
If you live in Canada or you are having diffi-

culties programming a gate operator or

garage door opener by using the “Program-

ming” procedures, replace “Programming

HomeLink” step 2 with the following:

•

Continue to press and hold the HomeLink

button while you press and release -

every two seconds (“cycle”) your hand-

held transmitter until the HomeLink indi-

cator light changes from a slow to a rap-

idly blinking light. Now you may release

both the HomeLink and hand-held trans-

mitter buttons.

Proceed with “Programming” step 3 to com-

plete.

Resetting HomeLink Buttons
Use the following procedure to reset (erase

programming) from the three HomeLink but-

tons (individual buttons cannot be reset but

can be “reprogrammed” as outlined in the fol-

lowing section):

1. Press and hold the two outer HomeLink

buttons until the indicator light begins to

flash.

2. Release both buttons.

> HomeLink is now in the training (or

learning) mode and can be pro-

grammed at any time beginning with

“Programming” - step 1.

Reprogramming a Single HomeLink
Button
To program a device to HomeLink using a

HomeLink button previously trained, follow

these steps:
1. Press and hold the desired HomeLink

button. DO NOT release the button.

2. The indicator light will begin to flash after

20 seconds. Without releasing the Home-

Link button, proceed with “Programming”

- step 1.

For questions or comments, contact Home-

Link at: www.homelink.com/

www.youtube.com/HomeLinkGentex or by

phoning the hotline at 1–800–355–3515.
This device complies with FCC rules part 15

and Industry Canada (IC) RSS-210. Operation

is subject to the following two conditions: (1)

This device may not cause harmful interfer-

ence, and (2) This device must accept any

interference that may be received including

interference that may cause undesired opera-

tion.

NOTE

The transmitter has been tested and com-

plies with FCC and IC rules. Changes or

modifications not expressly approved by

the party responsible for compliance could

void the user’s authority to operate the

device.

The term “IC:” before the certification/registration number only signifies that Industry Canada technical specifications were met.

03 Instruments and controls

Option/accessory, for more information, see Introduction.

Volvo Sensus

Volvo Sensus is the core of the contact inter-

face with your vehicle. Sensus provides infor-

mation, entertainment and offers access to

functions that make owning and operating a

Volvo easier.

Volvo Sensus is the operating system in your

vehicle and it enables you to interact intui-

tively with the vehicle’s various features and

functions, including accessing the Internet,

when it suits you.
Volvo Sensus uses the center console screen

to display information and menus, and to

offer a user interface that enables you to

make personalized settings for e.g., vehicle,

infotainment and climate system functions.
The buttons on the center console or the

steering wheel keypad are used to activate/

deactivate functions and change numerous

settings.
Pressing the MY CAR button on the center

console displays all of the settings related to

driving and operating the vehicle, such as

City Safety, lock and alarm functions, auto-

matic blower speed, setting the clock, etc.
Pressing the source buttons on the center
console (RADIO, MEDIA, TEL,

, NAV* and

CAM*, etc.) make it possible to select e.g.,

AM or FM radio, play a CD or DVD, use the
Bluetooth

hands-free feature, the navigation

system* or the park assist camera*.
See your on-board owner’s manual or the

separate printed supplements for detailed

information about the functionality offered by

Volvo Sensus.

Center console control panel

Volvo Navigation System (VNS)* – NAV:

see the separate VNS manual for operat-

ing instructions.
Infotainment (RADIO, MEDIA, TEL)

Vehicle-related settings - MY CAR.

Internet connected vehicle.

Climate system.

Park assist camera - CAM*.

Related information

•

My Car – introduction (p. 66)

•

Climate – general information (p. 107)

•

Rear Park Assist Camera (PAC) – intro-

duction (p. 201)

03 Instruments and controls

Option/accessory, for more information, see Introduction.

Information display – menu controls

The controls on the left steering wheel lever

are used to access the menus (p. 96) that

are displayed in the instrument panel (p. 58).

The menus displayed depend on the current

ignition mode (p. 69).

Analog Instrument panel and menu controls

Digital Instrument panel* and menu controls

OK: access to the list of mes-

sages (p. 97) and message confirma-

tion.
Thumb wheel: browse among menus and

options in the list of functions.
RESET: reset the active function. Used in

certain cases to select/activate a func-

tion, see the explanation under each

respective function.

The menus shown on the information displays

in the instrument panel are controlled with the

left lever. The menus displayed depend on

ignition mode. Press OK to erase a message

and return to the menus.

Information display – menu overview

The menus displayed depend on the current

ignition mode (p. 69).

The following menu alternatives may vary,

depending on the equipment installed in the

vehicle.

Analog instrument panel
Digital speed
Trip comp. opt.
Service status
Messages (##)

Digital instrument panel*
Settings
Themes
Contrast mode/Color mode
Service status
Messages
Trip computer reset

Related information

•

Information displays – introduction (p. 58)

•

Information display – menu controls

(p. 96)

•

Information display – messages (p. 97)

Number of messages in parentheses

03 Instruments and controls

}}

Information display – messages

The controls on the left steering wheel lever

are used to scroll among messages displayed

in the instrument panel and to confirm selec-

tions.
When information, indicator or warning sym-

bols illuminate, an explanatory message will

be displayed in the instrument panel.

When a warning (p. 64), information (p. 62) or

indicator symbol (p. 62) comes on, a corres-

ponding message appears in the information

panel. An error message is stored in a mem-

ory list until the fault is rectified.
Press OK to acknowledge and scroll among

the messages.

NOTE

If a warning message appears while you

are using the trip computer, the message

must be read and confirmed by pressing

OK before the previous activity can be

resumed.

Message

Description

Stop
engine

Stop and switch off the

engine as soon as possi-

ble. Serious risk of dam-

age. Contact an author-

ized Volvo workshop.

Stop safely

Stop and switch off the

engine. Serious risk of

damage. Contact an

authorized Volvo work-

shop.

Service
urgent

Have the vehicle checked

by an authorized Volvo

workshop immediately.

Service
required

Have the vehicle checked

by an authorized Volvo

workshop as soon as pos-

sible.

See man-
ual

Read the owner's manual.

Book time

for mainte-

nance

Time to book service at an

authorized Volvo retailer.

Message

Description

Time for

regular

mainte-

nance

Time for regular service at

an authorized Volvo work-

shop. The timing is deter-

mined by the number of

miles driven, number of

months since the last

service, engine running

time.

Mainte-

nance over-

due

If the service intervals are

not followed, the warranty

does not cover any dam-

aged parts. Contact an

authorized Volvo work-

shop for service.

Temporarily
OFF

A function has been tem-

porarily switched off and

is reset automatically while

driving or after starting

again.

Low battery

Power save

mode

The audio system is

switched off to save cur-

rent. Charge the battery.

There will also be a system-specific part of this message

Volvo S60 Inscription (2016 year). Manual - part 5
