z

Coolant hose connection diagram, See COOLANT HOSE CONNECTION DIAGRAM

7. Retaining clip

z

Check if seated securely

8. 10 N.m

9. To bottom of expansion tank

z

Coolant hose connection diagram, See COOLANT HOSE CONNECTION DIAGRAM

10. To top of radiator

z

Coolant hose connection diagram, See COOLANT HOSE CONNECTION DIAGRAM

11. O-ring

z

Replace

12. Connecting unions

13. To bottom of radiator

z

Coolant hose connection diagram, See COOLANT HOSE CONNECTION DIAGRAM

14. Oil cooler

z

Removing and installing, See PART II (OIL FILTER HOUSING, DISASSEMBLING AND
ASSEMBLING)
 .

15. 15 N.m

16. Coolant thermostat

z

Checking: Heat up thermostat in water

z

Starts to open: approx. 86°C

z

Opening stroke: min. 7 mm

z

Removing and installing, See THERMOSTAT, REMOVING AND INSTALLING

17. Toothed belt

z

Mark direction of rotation before removing

z

Check for wear

z

Do not kink

z

Removing, installing and tensioning. See TOOTHED BELTS, REMOVING, INSTALLING
AND TENSIONING
 .

18. Coolant pump

z

Check for ease of movement

z

If damaged or leaking replace complete

z

Removing and installing, See COOLANT PUMP, REMOVING AND INSTALLING

19. Rear toothed belt guard

20. 20 N.m

21. Throttle valve control module

z

Heated by coolant

z

Coolant hose connection diagram, See COOLANT HOSE CONNECTION DIAGRAM

22. To top of expansion tank



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)



z

Coolant hose connection diagram, See COOLANT HOSE CONNECTION DIAGRAM

23. O-ring

z

Replace if damaged

Fig. 3: Exploded View Of Engine Side Cooling System Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

COOLANT HOSE CONNECTION DIAGRAM

Engine code AEG (up to Model Year 1998)

1. Radiator

2. Oil cooler

3. Coolant pump/coolant thermostat

4. Cylinder head/cylinder block

5. Expansion tank

6. Intake manifold

7. Throttle valve control module

8. Union

9. Heating system heat exchanger

10. Coolant pipe

11. ATF cooler

z

Only models with an automatic transmission

NOTE:

Engine codes AEG (from Model Year 1999), AVH, AZG, BDC, BEV, BGD, see
ENGINE CODES AEG (FROM MODEL YEAR 1999), AVH, AZG, BDC, BEV, BGD .

NOTE:

The following list refers to items in Fig. 4 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)



Fig. 4: Coolant Hose Connection Diagram (Engine Code AEG Up To Model Year 1998)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engine codes AEG (from Model Year 1999), AVH, AZG, BDC, BEV, BGD

1. Radiator

2. Oil cooler

3. Coolant pump/coolant thermostat

4. Cylinder head/cylinder block

5. Expansion tank

6. Intake manifold

7. Throttle valve control module

8. Connecting unions

9. Heating system heat exchanger

10. Quick-action coupling

11. Coolant pipe

12. ATF cooler

z

Only models with an automatic transmission

NOTE:

The following list refers to items in Fig. 5 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)



Fig. 5: Coolant Hose Connection Diagram (Engine Codes AEG From Model Year 1999, AVH, AZG,
BDC, BEV, BGD)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

COOLING SYSTEM, DRAINING AND FILLING

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

T10007 Refractometer

z

V.A.G 1306 Drip tray

z

Torque wrench VAG 1331

z

VAS 5024 Assembly tool for spring-type clamps

z

Adapter for expansion tank VAG 1274/8

z

VAS 6096 Coolant system charging unit

Fig. 6: Identifying Special Tools
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Draining



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 2.0L (AEG, AVH, AXG, BDC BEV & BGD)
