Volkswagen New Beetle. Manual - part 924





z

Drain coolant. See COOLANT, DRAINING AND FILLING .

z

Remove coolant hose from pipe union.

z

Remove securing bolts -1- of pipe union -2- and remove pipe union -2- with thermostat -4-.

z

Turn thermostat -4- 1/4 turn (90°) to left and remove from pipe union -2-.

Fig. 15: Removing Pipe Union With Thermostat
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Installation is performed in reverse order. Note the following:

z

Coat new O-ring -3- with coolant and install to pipe union -2-.

z

Insert thermostat -4- into pipe union -2- and turn 1/4 (90°) to right.

NOTE:

The brace on the thermostat must be almost vertical.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 16: Installing Connecting Union With Thermostat
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Install connecting union -2- with thermostat -4- into engine block.

z

Tighten securing bolts -1-.

Tightening torque: 15 N.m

z

Fill with coolant. See COOLANT, DRAINING AND FILLING .
