RADIATOR, REMOVING AND INSTALLING

Special tools and equipment

z

T10007 Refractometer

z

V.A.G 1306 Drip tray for VAG1202A

z

V.A.G 1331 Torque wrench (5 to 50 N.m)

z

VAS 5024 Assembly tool for spring-type clips

Fig. 10: Identifying Special Tools And Equipment (Radiator)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Drain coolant. See COOLANT, DRAINING AND FILLING .

z

Remove front end:

See FRONT END, ASSEMBLY OVERVIEW .

z

Remove coolant hoses from radiator.

z

Remove connectors from thermal switch and coolant fan.

z

Remove lock carrier:

See LOCK CARRIER, ASSEMBLY OVERVIEW

z

Remove radiator securing bolts and take out radiator.

NOTE:

Models with air conditioning system:

z

Observe additional information and removal work. See ADDITIONAL
INFORMATION AND ASSEMBLY WORK ON MODELS WITH AN A/C



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW



Installing

Installation is performed in reverse order. Note the following:

z

Fill with coolant. See COOLANT, DRAINING AND FILLING .

Additional information and assembly work on models with an A/C system

z

Release refrigerant lines/hoses from retainers/clamps if necessary.

z

Secure radiator to body before removing lock carrier.

z

To remove radiator, secure condenser to body.

COOLANT PUMP, REMOVING AND INSTALLING

Special tools and equipment

z

T10007 Refractometer

z

V.A.G 1306 Drip tray for VAG1202A

z

V.A.G 1331 Torque wrench (5 to 50 N.m)

z

VAS 5024 Assembly tool for spring-type clips

Fig. 11: Special Tools And Equipment (Coolant Pump)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

SYSTEM .

CAUTION: The air conditioning system refrigerant circuit must not be opened.

NOTE:

To prevent damage to the condenser as well as to the refrigerant lines, ensure
that lines and hoses are not stretched, kinked or bent.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW



Removing

z

Drain coolant. See COOLANT, DRAINING AND FILLING .

z

Remove toothed (timing) belt. See TOOTHED BELT, REMOVING AND INSTALLING .

z

Remove coolant pump securing bolts -1- and remove coolant pump -2- carefully.

Fig. 12: Removing Coolant Pump And Securing Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Installation is performed in reverse order. Note the following:

z

Clean or smooth sealing surface for O-ring.

z

Moisten new O-ring -3- with coolant.

z

Insert coolant pump -2- into cylinder block and tighten securing bolts -1-.

Tightening torque: 15 N.m

z

Install toothed (timing) belt. See TOOTHED BELT, REMOVING AND INSTALLING .

z

Fill with coolant. See COOLANT, DRAINING AND FILLING

NOTE:

Always replace seals and gaskets.

NOTE:

The coolant pump plug faces downward.
