If the after-run coolant pump -V51- runs:

z

Switch ignition off and on again.

z

Connect LED test light VAG 1527 B to disconnected connector for After-run coolant pump -V51- with
auxiliary cable from VAG 1594 A

LED must light up.

LED does not light up:

z

Locate and repair open circuit using wiring diagram:

See appropriate WIRING DIAGRAM article.

NOTE:

This check must be performed within 10 minutes of switching ignition off.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.8L (APH, AWV & AWP)



1998-2004 ENGINE

Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW

COOLING SYSTEM COMPONENTS, REMOVING AND INSTALLING

Perform cooling system leakage test with cooling system tester V.A.G 1274 and adapters V.A.G 1274/8 and
V.A.G 1274/9.

Cooling system components - body side. See COOLING SYSTEM COMPONENTS - BODY SIDE .

Cooling system components - engine side. See COOLING SYSTEM COMPONENTS - ENGINE SIDE .

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM

Draining and filling with coolant. See COOLANT, DRAINING AND FILLING .

Coolant mixing ratios. See COOLANT, DRAINING AND FILLING .

COOLING SYSTEM COMPONENTS - BODY SIDE

1. Radiator

z

Removing and installing. See RADIATOR, REMOVING AND INSTALLING

CAUTION: When performing repair work, especially due to the confined conditions in

the engine compartment, pay attention to the following:

z

Route all types of hoses/lines (e.g. for fuel, hydraulics, EVAP system,
coolant, refrigerant, brake fluid and vacuum) as well as electrical
wiring so that the original positions are restored.

z

Ensure sufficient clearance to all moving or hot components.

NOTE:

z

When the engine is warm, the cooling system is under pressure. If
necessary, release the pressure before beginning repair work.

z

Hoses are secured with spring-type clips. In case of repair, only use
spring-type clips.

z

Assembly tool VAS 5024 or hose clip pliers V.A.G 1921 are recommended
for installing spring-type clips.

z

When installing coolant hoses, route stress-free so that they do not come
into contact with other components (observe markings on coolant
connection and hose).

NOTE:

The following list refers to items in Fig. 1 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW



z

After replacing, replace entire quantity of coolant

2. O-ring

z

Always replace

3. Upper coolant hose

z

Secured to radiator with retaining clip

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM

4. Connector

5. Cap

z

Check with coolant system tester V.A.G1274 and adapter V.A.G 1274/9

z

Pressure relief valve must open at a pressure of 1.4 to 1.6 bar

6. 2.5 N.m

7. Expansion tank

z

Perform leak test on coolant system with coolant system tester V.A.G 1274 and adapter V.A.G
1274/8

z

Test pressure: 1.4 to 1.6 bar

z

Observe markings. See COOLANT, DRAINING AND FILLING .

8. To coolant pipe

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM

9. Air ducting

10. 5 N.m

11. Supplementary fan

z

Only models with optional equipment

12. Fan ring

z

For additional fan

13. Fan ring

14. Coolant fan

15. Bracket

z

For coolant fan connector.

16. Lower coolant hose

z

Secured to radiator with retaining clip

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM .

17. O-ring

z

Always replace

18. Coolant Fan Control (FC) Thermal Switch -F18-, 35 N.m

z

For electric fan

z

Switching temperatures:

1. Speed



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW



on: 92...97 °C

off: 84...91 °C

2. Speed

on: 99...105 °C

off: 91...98 °C

19. Bracket

z

For bottom of radiator

z

Note installed position

20. Bracket

z

For top of radiator

z

Note installed position

Fig. 1: Identifying Cooling System Components - Body Side
Courtesy of VOLKSWAGEN OF AMERICA, INC.

COOLING SYSTEM COMPONENTS - ENGINE SIDE

1. 15 N.m

2. Coolant pump

z

Check for ease of movement

z

Note installed position

z

Removing and installing. See COOLANT PUMP, REMOVING AND INSTALLING

3. O-ring

NOTE:

The following list refers to items in Fig. 2 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW
