Volkswagen New Beetle. Manual - part 905





Fig. 16: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

Vehicles with air conditioner: Observe additional information and removal instructions. See ADDITIONAL
INFORMATION AND REMOVAL INSTRUCTIONS FOR VEHICLES WITH AIR CONDITIONER
 .

z

Pull coolant hose off connecting flange -3-.

z

Unbolt securing bolts -4- of connecting flange -3- and remove connecting flange -3- with thermostat -1-.

Fig. 17: Unbolting Securing Bolts Of Connecting Flange And Removing Connecting Flange With
Thermostat

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

NOTE:

z

Always replace seals and gaskets.

z

Drain coolant. See DRAINING .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.8L (APH, AWV & AWP)



Installation is carried out in the reverse order, when doing this note the following:

z

Moisten new O-ring -2- with coolant.

z

Insert thermostat -1- into connecting flange -3- and turn 1/4 turn (90°) to right.

z

Install connecting flange -3- with thermostat -1- into engine block.

z

Tighten securing bolts -4-.

Tightening torque: 15 N.m

Fig. 18: Tightening Securing Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Fill with coolant. See FILLING .

AFTER-RUN COOLANT PUMP -V51-, CHECKING

Special tools and equipment

z

VAG 1527 B LED test light

NOTE:

The brace on the thermostat must be almost vertical.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 19: Identifying VAG 1527 B LED Test Light
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VAG 1594 A Auxiliary test set

z

Wiring diagram

Fig. 20: Identifying VAG 1594 A Auxiliary Test Set
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking conditions

z

Fuse No. 16 OK.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 21: Identifying Fuse No. 16
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test sequence

z

Pull 2 pin connector off After-run coolant pump -V51 -.

z

Connect contacts of After-run coolant pump -V51- to battery using auxiliary cables from VAG 1594.

After-run coolant pump must run.

Fig. 22: Connecting Contacts Of After-Run Coolant Pump To Battery
Courtesy of VOLKSWAGEN OF AMERICA, INC.

If the after-run coolant pump does not run:

z

Replace after-run coolant pump -V51-.

NOTE:

Fuse box is located behind access panel at far left end of dash.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.8L (APH, AWV & AWP)
