Volkswagen New Beetle. Manual - part 586





Fig. 42: Window Electric Motor Screws
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle



z

Take cable guide housing carefully off motor.

z

The tensioning roller for the cable must not come off the motor.

z

Remove motor.

Installing

Install in reverse order.



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle



1998-2004 ACCESSORIES & EQUIPMENT

Turn Signal And Emergency Flasher System Troubleshooting - New Beetle

CHECKING TURN SIGNAL AND EMERGENCY FLASHER SYSTEM

REQUIRED FOR TROUBLESHOOTING

z

Multimeter Fluke 83

z

Connector Test Kit VW 1594

z

Valid wiring diagram

Before starting troubleshooting, battery negative terminal must be securely tightened.

PREREQUISITE

z

S2 - Fuse 2 (10A) in fuse panel OK!

z

S239 - Fuse 39 (15A) in fuse panel OK!

z

All turn signal bulbs OK!

PREPARATION

z

Switch OFF ignition and all electrical consumers

z

Remove turn signal switch. See STEERING COLUMN SWITCHES .

z

Remove turn signal switch trim.

TROUBLESHOOTING

If malfunction has not been eliminated after all test steps, replace Emergency Flasher Switch (E3).

After repairing malfunction, please perform functional test of turn signal and emergency flasher system.

CAUTION: DO NOT damage, enlarge or bend connector terminals or cavities by

forcing probes into them when performing electrical checks. Always use
connector test kit VW 1594 to make the necessary electrical connections.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Turn Signal And Emergency Flasher System Troubleshooting - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Turn Signal And Emergency Flasher System Troubleshooting - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Turn Signal And Emergency Flasher System Troubleshooting - New Beetle
