Volkswagen New Beetle. Manual - part 570





Fig. 25: Opening Hand Hold Downward
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove trim from left and right-hand A-pillars.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle



See A-PILLAR UPPER TRIM, REMOVING AND INSTALLING

z

Carefully unhook molded headliner at front of roof cut-out -arrows- and pull downward until screws for
sliding/tilting sunroof can be accessed.

Fig. 26: Removing Molded Headliner From Front Of Roof Cut-Out
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unclip and disconnect connection.

z

Remove screws/bolts -arrows- and pull out drive for sliding/tilting sunroof.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle



Fig. 27: Removing Sliding/Tilting Sunroof Drive Screws/Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

The bolts/screws for the drive are micro-encapsulated and must always be replaced (3.5 N.m).

DRIVE FOR SLIDING/TILTING SUNROOF ("0" POSITION), ADJUSTING

There may be a requirement to adjust the "0" position if drive was removed when not in "0" position or
sliding/tilting sunroof was closed using emergency key.

Drive removed but still connected electrically.

z

Select "tilt sunroof" (raise) with pre-selection control rotary switch.

z

Select "close sunroof" with pre-selection control rotary switch.

z

Select "open sunroof" with pre-selection control rotary switch.

z

Select "close sunroof" with pre-selection control rotary switch.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle



z

Install drive in this position ("0" position) with sliding/tilting sunroof closed.

REMOVING PRE-SELECTION CONTROL FOR SLIDING/TILTING SUNROOF

z

Unclip trim -1- in direction of -arrow- and remove.

Fig. 28: Removing Trim Clip
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove screws -1- and carefully release frame locking lugs -arrows- of the automatic pre selector.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle
