Guide channel -2- must be located in guide rails (cannot be moved by hand).

z

Slide guide upper part -1- (from front to rear only) centrally between marks.

z

Install drive in this position ("0" position).

Then check "0" position.

CARRIER UNIT, REMOVING AND INSTALLING

Removing

z

Remove pre-selector control for sliding/tilting sunroof, see REMOVING PRE-SELECTION
CONTROL FOR SLIDING/TILTING SUNROOF
 .

z

Remove molded headliner.

See ROOF TRIM .

z

Pull water drain hoses -arrows- off carrier unit -1-

z

Remove bolts/screws -2- and -4- (with sleeves) and lift carrier unit out of vehicle with help of a second
technician.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle



Fig. 33: Removing Carrier Unit
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle



z

Insert carrier unit -1-, align with bolt/screw holes and insert bolts/screws -2- and -4- (with sleeves).

z

Check routing of wiring and connections for electrical devices on roof and reinstate if necessary.

z

Tighten carrier unit -1- starting at drive -3- for sliding/tilting sunroof on left and right-hand sides moving
rearward (8 N.m).

z

Install water drain hoses -arrows-.

z

Install connection for drive -3-.

Fig. 34: Installing Carrier Unit
Courtesy of VOLKSWAGEN OF AMERICA, INC.

GUIDE CHANNEL, REMOVING

z

Remove sliding/tilting sunroof glass panel, see SLIDING/TILTING SUNROOF GLASS PANEL,
REMOVING
 .

z

Remove carrier unit, see CARRIER UNIT, REMOVING AND INSTALLING .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle



z

Remove drive for sliding/tilting sunroof, see DRIVE FOR SLIDING/TILTING SUNROOF,
REMOVING
 .

z

Unclip end piece -1- -arrow- from guide rail -2- and then pull off.

Fig. 35: Removing End Piece Clip From Guide Rail
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Carefully unclip water channel -1- from mounting on guide locking lug guide -2- on both sides with a
screwdriver.

NOTE:

When installing end piece -1- guide rail seal with Butyl adhesive sealing
cord AKL 450 005 05.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle
